EtherFast®4116 16-Port

10/100 Ethernet Switch

With its advanced switching technology, the

EtherFast®4116 16-Port 10/100 Ethernet Switch will

boostyournetworkperformance with muchmorethan

just full duplex data transfer and dedicated bandwidth. It fea-

turesnon-blocking,wire-speedswitchingthatforwardspackets

as fast as your network can deliver them. Also included are

Address Learning and Aging to prevent data transfer errors and

Data Flow Control to help prevent packet collisions.

The EtherFast 4116's compact size fits into any environment,

or install it using the included rack mount brackets.

No matter how intensive your network demands, the EtherFast

Compact 16-Port 10/100 Ethernet Switch's advanced chipset

supports your needs with an affordable and efficient network-

ing solution you can count on.

• 16-Port 10/100 Full Duplex,Autosensing Ports

• Run Blazing Speeds of up to 200Mbps at Full Duplex

• Perfect for Running 10BaseT,100BaseTX HardwareTogether

Seamlessly

• Data Flow Control Filters Out Faulty Data Packets

• Auto MDI/MDI-X

• Broadcast storm prevention

EtherFast®4116 16-Port 10/100 Ethernet Switch

Model No.: EF4116

High-speed 10/100 Switching

with Linksys reliability On Your Desktop

Features

Benefits

• 16 Autosensing 10/100 full duplex, auto

MDI/MDI-X ports

• Run blazing speeds up to 200Mbps

• Address Learning and Data Flow Control for

transmission reliability

• Compact size fits into any environment

Instant EtherFast®Series

Package ContentsSpecifications

Model Number EF4116

Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3x

Ports 16 10/100Auto-Negotiation RJ-45 Ports

Cabling Type UTP/STP Category 5 or Better

LEDs Power, Link/Activity (per port),

Full Duplex/Collision (per port)

Environmental

Dimensions 6.69" x 1.77" x 10.51"

(170 mm x 45 mm x 267 mm)

Unit Weight 2.65 lbs. (1.2 kg)

Power 100-240V AC, 50-60 Hz

Certifications FCC Class A, CE

Operating Temp. 32ºF to 122ºF (0ºC to 50ºC)

Storage Temp. -40ºF to 158ºF (-40ºC to 70ºC)

Operating Humidity 20% to 95%, Non-Condensing

Storage Humidity 20% to 95%, Non-Condensing

• EtherFast®16-Port Switch

• AC Power Cable

• User Guide and Registration Card

• Mounting kit containing:

Four rubber feet for mounting the switch on

a table

Two mounting brackets

Six screws for attaching the brackets to the

switch

DS-ef4116-122402NC KL

Linksys

World Headquarters:

17401 Armstrong Ave.

Irvine, CA 92614 USA

E-mail: [email protected]

[email protected]

Web: http://www.linksys.com

Linksys products are available in more than 50

countries, supported by 12 Linksys Regional

Offices throughout the world. For a complete

list of local Linksys Sales and Technical

Support contacts,visit ourWorldwideWeb Site

www.linksys.com
