Instant PowerLine™

EtherFast®10/100 Bridge

he Linksys Instant PowerLine™ EtherFast®10/100

Bridge offers a complete Internet connection solu-

tion for your home powerline network. The

PowerLine Bridge makes sharing your broadband access

easier than ever. Build a strong and simple-to-use home

network by taking advantage of the most pervasive home

networking medium—powerlines.

The PowerLine Bridge is ideal for users who already have a

router. It can be plugged into an Ethernet port on a router

to equip a network with powerline capabilities and take

advantage of the router’s features. The PowerLine Bridge

can also plug directly into a cable or DSL modem to allow

Internet access and data transfer rates up to 14Mbps over

home powerlines.

With the PowerLine Bridge, create a network in no time at

all to share an Internet connection (a router may be

required), files, and printers, or even play multi-user net-

work games at blazingly fast speeds. It’s easy, convenient,

and cost-effective.

• Connects 10/100 Ethernet Network to

Powerline Network for Seamless Integration

• Share Internet Access Across Your Entire

Home Powerline Network*

• Up to 14Mbps Data Transfer Over Powerlines

• Fully HomePlug 1.0 Compliant

• Easy-to-Read LED indicators

• Easy Installation

•Free Technical Support—24 Hours a Day,

7 Days a Week for North America Only

•1-Year Limited Warranty

* Router may be required

Fast and Easy Integration Between

Your Ethernet and Powerline Networks

Features

• Stand-Alone Unit Attaches Directly to

Broadband Device and Home Powerline

Network for Seamless Integration

• No New Wires™Approach

• Share Broadband Internet Connection Across

Powerline Network Using Broadband Router

• Up to 14Mbps Data Transmission Rate from

Powerline Network to 10/100 Ethernet Network

• Fully HomePlug 1.0 Compliant

• PowerPacket™ Technology Facilitates Efficient

Packet Transmission

• 56-bit Data Encryption to Ensure Data Security

and Reliability

Instant PowerLine™ EtherFast®10/100 Bridge

(PLEBR10)

Benefits

CCoonnnneeccttOOvveerr

PPoowweerrlliinneess

Package Contents

Instant PowerLine™

EtherFast®10/100 Bridge

• One EtherFast®10/100 Bridge

• One Power Cord

• User Guide and Registration Card

• Quick Installation

• One Setup CD-ROM

Linksys

17401 Armstrong Ave.

Irvine, CA 92614 USA

Sales Information (800) 546-5797

World Wide Web* http://www.linksys.com

China (10) 6432 1923

Japan (03) 5259-5139

Philippines (632) 638 5580

Singapore 552-8998

Thailand 717-0770

United Kingdom 01245 352403

*Visit our website for the most current contact information.

DS-PLEBR10-012802NC JL

• Existing Ethernet/Fast Ethernet Network or

an Existing Ethernet/Fast Ethernet Network

Adapter and Network Cable

• TCP/IP Protocol

• CD-ROM Drive

• Windows 98, 2000, ME, NT, or XP for Initial

Setup

System Requirements

Specifications

Model Number: PLEBR10

Standards: IEEE 802.3, IEEE 802.3U, HomePlug 1.0

Ports:

Powerline One Powerline Port

LAN One 10BaseT/100BaseTX RJ-45 Port

Cabling Type:

Powerline Power Cord

LAN UTP Category 5 or Better

Topology: Star (Ethernet), Bus (Powerline)

Speed:

Powerline Up to 14Mbps

LAN 10/100Mbps

Encryption: 56-bit Data Encryption with Key Management

LEDs: Power

Powerline Link,Activity, Collision

Ethernet Link, 100,Activity

Environmental

Dimensions: 6.5" x 3.82" x 1.24" (165mm x 97mm x 31.5 mm)

Unit Weight: 0.7 lbs. (0.32 kg)

Certifications: FCC Class B, UL Listed, HomePlug 1.0

Operating Temp.: 32ºF to 104ºF (0ºC to 40ºC)

Storage Temp.: -4ºF to 158ºF (-20ºC to 70ºC)

Operating Humidity: 10% to 85% Non-Condensing

Storage Humidity: 5% to 90% Non-Condensing
