EtherFast®12-Port

Gigabit Ethernet Switch

he EtherFast®12-Port Gigabit Ethernet Switch takes your

network to a whole new level of productivity—and does it

using your existing architecture. There’s no need to aban-

don your present equipment or radically change your way of

doing things.This switch from Linksys allows you to do what you

already do—only faster!

Apply this switching power to your current Ethernet network,and

your data traffic efficiency will improve several times over.

Connect your Gigabit-equipped workstations to the Switch's

10/100/1000 ports for full-duplex, dedicated bandwidth of up to

1000Mbps!

With the EtherFast 12-Port Gigabit Ethernet Switch,you can con-

nect your existing 10/100 Ethernet network to your Gigabit net-

work backbone without any additional equipment. All ports are

auto-negotiating, and have auto MDI/MDI-X. Address learning

and aging is supported,as well as 802.3x flow control with head-

of-line blocking prevention to keep your high-speed clients from

bogging down in low-speed traffic.

TheEtherFast 12-PortGigabit Ethernet Switch fromLinksys isthe

all-in-one solution for your Gigabit and 10/100 networking needs.

• 12 10/100/1000Mbps auto MDI/MDI-X RJ-45 ports

• Full wire speed reception and transmission

• Integrated address look-up engine, support for up to 32K

MAC addresses

• Head of Line (HOL) blocking prevention

• All ports support Auto MDI/MDI-X

• Rack mounting hardware included for easily rack mounting

the switch

EtherFast®12-Port Gigabit Ethernet Switch

Model No.: EF3512

Wire-speed switching and Linksys reliability

in an 12-port Gigabit switch

Features

Benefits

• Twelve 10/100/1000Mbps, half/full duplex,

switched ports

• Forwards and filters packets at non-blocking,

full wire speed

• All ports have auto speed negotiation and

MDI/MDI-X

• Supports address learning and aging, 802.3x

flow control and head-of-line blocking preven-

tion

Instant Wireless®Series

Package ContentsSpecifications

Model Number EF3512

Standards IEEE 802.3, 802.3u, 802.3x, 802.3ab

Ports 12 10/100/1000Mbps RJ-45 ports

Cabling Type Category 5e Recommended

LEDs Power,Temp, Fan, 10, 100, 1000,ACT, FDX

Environmental

Dimensions 16.93" x 1.75" x 9.45"

(430 mm x 44.5 mm x 240 mm)

Unit Weight 7.94 lbs. (3.6 kg)

Power 100-240V AC, 50W

Certifications FCC Class A, CE

Operating Temp. 32ºF to 122ºF (0ºC to 50ºC)

Storage Temp. -40ºF to 158ºF (-40ºC to 70ºC)

Operating Humidity 20% to 95%, Non-Condensing

Storage Humidity 20% to 95%, Non-Condensing

Minimum Requirements

DS-ef3512-122402NC KL

Linksys

World Headquarters:

17401 Armstrong Ave.

Irvine, CA 92614 USA

E-mail: [email protected]

[email protected]

Web: http://www.linksys.com

Linksys products are available in more than 50

countries, supported by 12 Linksys Regional

Offices throughout the world. For a complete

list of local Linksys Sales and Technical

Support contacts,visit ourWorldwideWeb Site

www.linksys.com

• One EtherFast 12-Port Gigabit Ethernet Switch

• One set of mounting brackets and screws for

rack mounting

• One AC Power cord

• One Setup CD including User Guide in PDF for-

mat

• 200Mhz CPU or better

• 64MB RAM Recommended

• Available Ethernet or Gigabit Ethernet

adapter

• CD-ROM Drive
