Linksys RV016 Manuale operativo

Model No.

Product Data

WIRED

RV016

The heart of your connection-redundant

secure small office network

A high-reliability Internet

connection-sharing router

and 16-port switch for

small business

Advanced SPI fire-

wall protects your

PCs from most known

Internet attacks

Features up to 7

Internet ports for load

balancing and con-

nection redundancy

Securely connects up

to 50 remote office or

traveling users to your

office network via VPN

The Virtual Private Network (VPN) capability cre-

ates encrypted ""tunnels"" through the Internet,

allowing up to 50 remote office or traveling

users to securely connect into your office net-

work from off-site. Users connecting through a

VPN tunnel are attached to your company's

network -- with secure access to files, e-mail,

and your intranet -- just as if they were in the

building. You can also use the VPN capability

to allow users on your small office network to

securely connect out to a corporate network.

The 10/100 16-Port VPN Router can serve as a

DHCP Server, and has a powerful SPI firewall to

protect your PCs against intruders and most

known Internet attacks. It can be configured

to filter internal users' access to the Internet,

and has IP address filtering so you can specify

exactly who has access to your network. Con-

figuration is a snap with the web browser-

based configuration utility.

As the heart of your small office network, the

connection-redundant Linksys 10/100 16-Port

VPN Router gives you the connection reliability

your business needs.

10/100 16-Port VPN Router

The Linksys 10/100 16-Port VPN Router is an advanced Inter-

net-sharing network solution for your small business needs.

Like any router, it lets multiple computers in your office share

an Internet connection, but the 16 ports on this Router fea-

ture unprecedented versatility. Two are dedicated Internet

ports that let you connect a second Internet line as a

backup to ensure that you're never disconnected. Or, you

can use both Internet ports at the same time, and let the

router balance your office's requirements between them for

maximum bandwidth efficiency.

Not enough? Up to five of the thirteen full-duplex switched

10/100 Ethernet ports can be reconfigured as Internet ports,

for an up to seven-port failover or load balanced redun-

dancy! Finally, a dedicated DMZ port gives you a publicly

accessible channel so you can set up a web or FTP server,

unimpeded by the powerful security features of the Router.

Product Data

Model No.

Features

• Stateful Packet Inspection

Firewall for maximum security

• 7 WAN ports for load bal-

anced connectivity to the

Internet

• 13-Port 10/100 Switch sup-

ports Auto-MDI/MDIX and up

to 200Mbps of throughput per

port

• IP filtering allows for restricted

access to the Internet and

other network resources

• Full IPSec Virtual Private Net-

work (VPN) Capability using

DES and 3DES Encryption

Algorithms

• Support for MD5 and SHA

Authentications Algorithms

• Create up to 50 simultaneous

IPSec VPN Tunnels

• Management via Web, Telnet,

SNMP, and Setup Wizards

make setup easy for Adminis-

trators

Linksys

A Division of Cisco Systems, Inc.

18582 Teller Avenue

Irvine, CA 92612 USA

E-mail: [email protected]

[email protected]

Web: http://www.linksys.com

Linksys products are available in more than 50

countries, supported by 12 Linksys Regional Offices

throughout the world. For a complete list of local

Linksys Sales and Technical Support contacts, visit

our Worldwide Web Site at www.linksys.com.

RV016

10/100 16-Port VPN Router

Specifications

Model Number RV016

Standards IEEE 802.3, IEEE 802.3u

Ports 16 10/100 RJ-45 Ports,

2 10/100 RJ-45 Internet Port,

1 10/100 RJ-45 DMZ Port,

Up to 7 10/100 RJ-45 Internet Ports

Buttons Reset

Cabling Type Category 5 Ethernet

LEDs Diag,

System, Link/Act 1-13, Internet/Act 1-7, DMZ

UPnP able/cert Yes

Security Features SPI Firewall, DES and 3DES Encryption for IPSec

VPN Tunnel, MD5 and SHA Authentication, URL Filtering

Environmental

Dimensions 11" x 1.75" x 9.50"

(W x H x D) (279 mm x 44 mm x 241 mm)

Unit Weight 3.25 lbs. (1.5 kg)

Power 3.3V 5Amps

Certifications FCC Class B, CE Class B

Operating Temp. 32ºF to 104ºF (0ºC to 40ºC)

Storage Temp. 32ºF to 158ºF (-0ºC to 70ºC)

Operating Humidity 10% to 85%, Non-Condensing

Storage Humidity 5% to 90%, Non-Condensing

RV016-DS-40202NC-KL

Package Contents

• One RV016 10/100 16-Port VPN Router

• One AC Power Cable

• One Setup CD with User Guide in PDF format

• One Registration Card

• Rackmounting kit

Minimum Requirements

• Broadand Connection for Interent

Connection Sharing

• TCI/IP Protocol installed on each PC

Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2004
