Linksys E2000 Manuale utente

Revision 1.1 Page 1

®®

Linksys®E2000 Wireless-N Router

Configuration Guide

Revision 1.1

Maretron, LLP

9014 N. 23rd Ave #10

Phoenix, AZ 85021-7850

http://www.maretron.com

Maretron Manual Part #: M003009

Linksys® E2000 Wireless-N Router Configuration Guide

Page 2 Revision 1.1

Revision History

Rev. Description

1.0 Original document

1.1 Corrected typographical errors

Revision 1.1 Page 3

®®

Table of Contents

1Introduction ...........................................................................................................................4

2Configuring the WiFi/Router..................................................................................................6

2.1Connecting to the WiFi/Router ................................................................................. 6

2.2Adding an IPG100 to the Network............................................................................ 9

2.3Adding a PC based N2KServer®to the Network. ................................................... 12

2.4Adding a MBB100 N2KView Client to the Network................................................. 14

2.5Adding a DSM800 N2KView Client to the Network ................................................ 15

2.6Adding a Wired PC N2KView Client to the Network............................................... 15

2.7Adding a Wireless PC N2KView Client to the Network........................................... 16

2.8Adding a Mobile N2KView Client to the Network.................................................... 16

3Resetting the WiFi/Router to Maretron Configuration..........................................................17

3.1Physically Reset the WiFi/Router ........................................................................... 17

3.2Give your Wireless Network a name ...................................................................... 17

3.3Programming network security............................................................................... 18

Appendix A-Client/Server Architecture.............................................................................19

A.1Examples of NMEA 2000® Client/Server Architectures ......................................... 20

A.2TCP/IP Networks.................................................................................................... 21

A.3NAT (Network Address Translation)....................................................................... 22

A.4PAT (Port Address Translation).............................................................................. 22

A.5Static and Dynamic IP Addressing ......................................................................... 23

A.6Software Firewall Configuration.............................................................................. 23

A.7Data Security and Encryption................................................................................. 23

Table of Figures

Figure 1 - Typical WiFi/Router Connection................................................................................ 4

Figure 2 – LAN Client/Server Architecture Example with USB100.......................................... 20

Linksys® E2000 Wireless-N Router Configuration Guide

1 Introduction

Thank you for purchasing the Maretron preconfigured Linksys®E2000 Wireless-N Router (from

here on referred to as WiFi/Router). The WiFi/Router is used to interconnect one or more wired

or wireless devices running Maretron’s N2KView®vessel monitoring and control software with

a device running Maretron’s N2KServer® (i.e., N2KServer®runs on Maretron’s Internet

Protocol Gateway (IPG100) or a PC connected to an NMEA 2000®network via Maretron’s

USB gateway (USB100)). Figure 1 shows a typical configuration where multiple devices

running Maretron’s N2KView®software (e.g., laptop computer, desktop computer, smart

phone, tablet, Maretron DSM800 display, or Maretron MBB100 black box) are connected back

to an NMEA 2000®network through the WiFi/Router and the Maretron Internet Protocol

Gateway (IPG100).

Figure 1 - Typical WiFi/Router Connection

Page 4 Revision 1.1

Revision 1.1 Page 5

®®

Although the WiFi/Router is mostly pre-configured by Maretron, there are a few steps that must

be performed to establish the connection between Maretron’s N2KView®vessel monitoring

and control software (client) and Maretron’s N2KServer®(server). If you are installing a system

similar to Figure 1 where the N2KServer®is running on the IPG100, then you should read

paragraphs 2, 2.1 and 2.2 (skip paragraph 2.3). If you are installing a system where

N2KServer is running on a PC then you should read paragraphs 2, 2.1 and 2.3 (skip paragraph

2.2).

Linksys® E2000 Wireless-N Router Configuration Guide

2 Configuring the WiFi/Router

The settings in the WiFi/Router are changed using a web browser such as Internet Explorer,

Safari, or Mozilla Firefox.

2.1 Connecting to the WiFi/Router

Connect the WiFi/Router to your PC using the blue Ethernet cable supplied in the box. Use the

supplied AC adapter to power the WiFi/Router.

Open your Internet browser and type 192.168.1.1 in the address field, and then press Enter. If

you connect successfully to the router, the browser will display a screen requesting a

username and password.

For Mozilla Firefox, this would look like:

and for Internet Explorer the corresponding screens would be:

Page 6 Revision 1.1

®®

From now on, we will just show the screens from Firefox – the screens from other browsers will

be very similar.

Leave the User name blank, and enter the default Password, which is admin and press the

OK button.

You may see the following message:

Cisco connect is a utility that comes with the router. It generalizes the setup procedures, but

we will not be using it to configure the WiFi/Router, so press the OK button to remove the

message.

Revision 1.1 Page 7

Linksys® E2000 Wireless-N Router Configuration Guide

You are now connected to the WiFi/Router, and should see the following basic setup screen.

Page 8 Revision 1.1

®®

Whenever you make a change to the configuration, you will see the following message:

You can press Continue whenever this message is displayed to get back to the configuration

screens.

2.2 Adding an IPG100 to the Network.

Connect Maretron’s Internet Protocol Gateway (IPG100) to the WiFi/Router using an Ethernet

Cable. The cable plugs into one of the blue Ethernet sockets at the back of the router. Reset

the IPG100 by removing the NMEA2000 cable and re-attaching it. This forces the IPG100 to

connect to this router, and removes previously allocated addresses.

Now we want to get the MAC address of the IPG100, so that we can reserve an IP Address for

it. Having a constant, reserved IP Address for the IPG100, makes it easy for N2KView®clients

to find the IPG100 on the network. We will choose to use the address 192.168.1.3 for the

IPG100. Note that if you have more than one IPG100 or PC-based N2KServer®, then each one

must have a unique reserved address, but this is beyond the scope of these instructions, so

please contact Maretron Technical Support for assistance.

Inside the WiFi/Router is a DHCP Server, which is responsible for assigning IP addresses to

other network devices that request them. DHCP stands for Dynamic Host Configuration

Protocol.

The IPG100 on the network will be identified by the Client Name of IPG100_<serial number>.

Revision 1.1 Page 9

Linksys® E2000 Wireless-N Router Configuration Guide

From the Basic Setup page, open the DHCP Reservation Table by pressing the DHCP

Reservation button.

The DHCP Reservation table is displayed as shown below:

If you do not see an IPG100 in the top part of the table, then it has not requested an address

from the DHCP Server. Ensure that DHCP is set to Yes in the device configuration of the

IPG100 (refer to the IPG100 manual).

Page 10 Revision 1.1
