Linksys WTR54GS Manuale operativo

Model

Product Data

Wireless

WTR54GS (EU/LA)

A Wireless Network In Your Pocket!

Shares a wired or wireless Internet

connection with SpeedBooster,

Wireless-G and -B devices, and

an Ethernet wired PC

High security: Wi-Fi

Protected Access™

(WPA), wireless MAC

address filtering,

powerful SPI firewall

Create temporary,

personal, wireless access

in your hotel room or a

coffee shop hotspot --

pushbutton easy

Travel-friendly

design with built-

in power supply

and antenna

The Linksys Wireless-G Travel Router with SpeedBooster lets you carry a wireless

network wherever you go. There's a built-in access point, which lets you connect

SpeedBooster-enhanced and regular Wireless-G and Wireless-B devices to the

network. There's also an Ethernet port to connect your wired PC. The Router

function ties it together and lets your PCs share a wired or wireless Internet

connection.

The travel-friendly form factor includes a built-in power supply and antenna -- it

even comes with a travel case! Create a temporary, personal, wireless access

"bubble" in your hotel room. Just plug the Router directly into the wall, and

connect the hotel's fast Internet service cable. Then use the Router's push button

setup feature to easily connect and configure your wireless devices -- push the

button on the Router and on your other SecureEasySetup-enabled wireless

device to automatically create an encryption-secured wireless connection. You

can also create a shared-access bubble attached to a wireless Internet

connection to use multiple devices on a single hotspot account in a coffee

shop or airport lounge.

To protect your data and privacy, the Wireless-G Broadband Router can encode

all wireless transmissions with WEP or extra-strength WPA Personal encryption. The

Router can serve as a DHCP Server, has a powerful SPI firewall to protect your PCs

against intruders and most known Internet attacks, and supports VPN pass-

through. Configuration is a snap with the web browser-based configuration utility.

The Linksys Wireless-G Travel Router with SpeedBooster lets you bring the

convenience of wireless networking everywhere you go.

with SpeedBooster

Wireless-G Travel Router

Model No.

Product Data

Model

Linksys

Web: http://www.linksys.com/international

Linksys products are available in more than

50 countries, supported by 12 Linksys Regional

Offices throughout the world. For a complete list of

local Linksys Sales and Technical Support contacts,

visit our Worldwide Web Site at

www.linksys.com/international.

WTR54GS (EU/LA)

Package Contents

• Wireless-G Travel Router

• Setup CD-Rom with Symantec

Internet Security

• Ethernet Network Cable

• Power Cable (Europe and Asia)

Wireless-G Travel Router

Minimum Requirements

• 300 MHz or Faster Processor

• 128 MB or RAM

• Internet Explorer 5.0 or Netscape Navigator 6 or

Higher for Web-based configuration

• Windows 98SE, Me, 2000, or XP (Speedbooster

is only available with Windows 2000 and XP)

•NetworkAdapter

Specifications

Model Number WTR54GS

Standards IEEE 802.3, IEEE 802.3u, IEEE 802.11b, IEEE 802.11g

Ports/Button Internet: One 10/100 RJ-45 Port

LAN: One 10/100 RJ-45 Port

One Power slide (most of Western Hemisphere)

One Power Port (most of Europe and Asia only)

One Reset Button

One SES Button

Cable Type UTP CAT 5

LEDs Power, Wireless, Internet, Ethernet

Transmit Power 802.11g: 12.5 dBm Typical @Normal Temp Range (+/-1.5dBm);

802.11b: 16.5dBm@Normal Temp Range (+/-1.5dBm)

Receiver Sensitivity 11Mbps @ 90 dBm; 54Mbps @ -65dBm typical

UPnP able/cert Able

Security features Stateful Packet Inspection (SPI) Firewall, Internet Policy

Wireless Security Wi-Fi Protected Access™ (WPA), WEP, Wireless MAC Filtering

Environmental

Dimensions (W x H x D) 73 mm x 107 mm x 31 mm

Unit Weight 0,133 kg

Power Built-in

Certifications FCC, CE, IC-03, Wi-Fi (802.11b, 802.11g), WPA

Operating Temp. 0º~40ºC

Storage Temp. -20º~70ºC

Operating Humidity 20~85% Non-condensing

Storage Humidity 10~90% Non-condensing

Warranty 3 years

WTR54GS-DS-EMEA 51014 KL

Specifications are subject to change without notice. Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S. and certain other countries. Copyright © 2005

with SpeedBooster

Features

• Complies with 802.11g and

802.11b (2.4GHz) Standards

• High security with Wi-Fi Protected

Access™ (WPA/WPA2 Personal)

• increases wireless performance

by up to 35%

• Supports universal bridging

• Compact travel size router with

built-in antenna and power

adapter

• Supports Secure Easy Setup
