LIVARNO LUX 284923 Specifiche tecniche

LED DESK LAMP

IAN 284923

LED-TISCHLEUCHTE

Montage-, Bedienungs- und Sicherheitshinweise

LED DESK LAMP

Assembly, operating and safety instructions

GB/IE/NI Assembly, operating and safety instructions Page 5

DE/AT / CH Montage-, Bedienungs- und Sicherheitshinweise Seite 11

Before reading, unfold both pages containing illustrations and familiarise yourself with all functions of the

device.

Klappen Sie vor dem Lesen die beiden Seiten mit den Abbildungen aus und machen Sie sich anschließend

mit allen Funktionen des Gerätes vertraut.

14100602L

14121402L

4 1211 11

5GB/IE/NI

Table of contents

List of pictograms used........................................................................................................Page 6

Introduction...................................................................................................................................Page 6

Intended use........................................................................................................................................Page 6

Scope of delivery................................................................................................................................Page 6

Parts description..................................................................................................................................Page 6

Technical Data ....................................................................................................................................Page 7

Safety.................................................................................................................................................Page 7

Safety notices ......................................................................................................................................Page 7

Start-up .............................................................................................................................................Page 8

Assembly..............................................................................................................................................Page 8

Switching the light on/off..................................................................................................................Page 8

Adjusting the reflector or spotlight .....................................................................................................Page 8

Maintenance and Cleaning..............................................................................................Page 8

Disposal............................................................................................................................................Page 9

Warranty and Service..........................................................................................................Page 9

Warranty .............................................................................................................................................Page 9

Service address...................................................................................................................................Page 9

Declaration of conformity...................................................................................................................Page 9

Manufacturer.......................................................................................................................................Page 9

6 GB/IE/NI

Introduction/SafetyIntroduction

List of pictograms used

Read the instructions! Observe the warnings and safety

notices!

This light is only suitable for indoor

use in dry and enclosed spaces. Warning! Danger of electric shock!

Volt (AC) For your safety

Hertz (frequency) This lamp is not suitable for dimmer or

electronic switches.

Watt (eﬀective power) Caution - hot surfaces!

Safety class II

Dispose of the packaging and device

in an environmentally-friendly manner!

LED Desk Lamp

Introduction

Congratulations on your new product. You

have selected a high quality product. The

instructions for use are a part of the prod-

uct. They contain important information about safety,

use and disposal. Before using the product, please

familiarise yourself with all the operating and safety

instructions. Only use the product as described and

for the indicated purpose. When passing this product

on to others, please be sure to include all its docu-

mentation. Before using this product for the ﬁrst time

verify the correct voltage and that all parts are prop-

erly installed.

Intended use

This light is only suitable for indoor use

in dry and enclosed spaces. This product

is intended for private household use only.

Scope of delivery

Check immediately after unpacking that the parts

are complete and that the product is in proper

condition.

1 LED Desk lamp, model 14100602L/

14121402L

1 Base

1 Washer (14100602L)

1 Nut (14100602L)

1 Base mat (14100602L)

1 Mains supply (14100602L)

1 Toothed washer (14100602L)

1 Tool (14100602L)

2 Allen key (14121402L)

2 Screws (14121402L)

1 Instructions for assembly and use

Parts description

1Reﬂector

2ON/OFF switch

3Base

4Mains lead

5Mains supply (14100602L)

6Rods (14100602L)

7GB/IE/NI

Introduction/SafetyIntroduction

7Washer (14100602L)

8Nut (14100602L)

9Mains plug (14121402L)

10 Toothed washer (14100602L)

11 Allen key (14121402L)

12 Locating screw (14121402L)

13 Screw (14121402L)

14 Tool (14100602L)

Technical Data

Model no.: 14100602L/14121402L

Operating voltage: 230–240V∼, 50Hz

Bulb: model 14121402L:

1 LED module, 3.5W

power factor (PF): 0.85

rated current: 20mA

model 14100602L:

1 LED module, 3.5W

power factor (PF): 0.45

rated current: 45mA

Protection class: II /

Safety

Safety notices

Damage due to failure to comply with these operat-

ing instructions will invalidate the warranty! We

assume no liability for consequential damage! We

assume no liability for material damage or personal

injury due to improper handling or failure to comply

with the safety instructions!

RISK OF FAT

INJURY AND ACCIDENT HAZ-

ARD FOR TODDLERS AND SMA

CHILDREN! Never leave children unattended

with the packaging material. The packaging

material represents a danger of suﬀocation.

Children frequently underestimate the dangers.

This device may be used by children aged

8 years and up, as well as by persons with re-

duced physical, sensory or mental capacities,

or lacking experience and/or knowledge, when

supervised or instructed in the safe use of the

device and they understand the associated risks.

Do not allow children to play with the device.

Cleaning and user maintenance must not be

performed by children without supervision.

RISK OF INJURY! Do not leave the lamp or

packaging material lying unattended. Plastic

ﬁlm or bags, Styrofoam etc. can become

dangerous toys for children.

Avoid the risk of fatal injury

from electric shock

Always check the mains supply and the mains

plug for damage before connecting the light to

the mains. Never use the light if it shows any

signs of damage.

The illuminant in this light is not replaceable;

if the illuminant has reached the end of its life,

replace the entire light (model 14121402L/

14100602L).

In the event of damage, repairs or other prob-

lems with the light, please contact the service

centre or an electrician.

Ensure that the light does not come into contact

with water or other liquids under any circum-

stances.

Never open or insert anything into electrical

ﬁttings or equipment (e.g. switches, ﬁtting socket).

This will pose a risk of fatal injury from electric

shock.

Only touch the insulated area of the mains sup-

ply and the mains plug when connecting to or

disconnecting from the mains!

The ﬂexible outer cable is not replaceable; if

the cable is damaged, the lamp must be dis-

posed of.

Before every use, verify the available mains

voltage matches the required operating voltage

of the light (see „Technical Data“).

Always unplug the mains supply or the plug,

respectively, from the mains prior to assembly,

disassembly, cleaning, or when the light will

not be used for extended periods.

This light is not suitable for dimmers

or electronic switches.

8 GB/IE/NI

Disposal/Warranty and Service

Safe working

Position the lamp so it is protected from moisture

and dirt.

Always be attentive! Always pay attention to

what you are doing and use common sense.

Do not cover the lamp with objects. Excessive

heat can result in ﬁre.

Do not look into the LED from a close distance

during operation.

Do not look into the LED with an optical instrum

ent

(e.g. magniﬁer).

In order to disconnect the light completely from

the power supply, the mains plug or power

supply must be removed from the socket.

The ﬁxed LED module is not replaceable. If the

LED module is damaged, please dispose of the

light.

Start-up

Assembly

14100602L:

Carefully pull the cable 4out through the

lamp base 3.

Push the tube 6through the lamp base 3.

Place the washer 7, toothed washer 10 and

the nut 8over the thread and tighten with the

tool 14 .

Attach the reﬂector 1to the tube 6.

Turn the reﬂector 1into the desired direction.

14121402L:

Place the tube 6onto the lamp base 3

and screw it from below using the supplied

screws 13 .

Switching the light on/ oﬀ

14100602L:

Plug the power supply 5into a properly

installed socket.

Switch the lamp on or oﬀ using the ON/OFF

switch 2.

14121402L:

Plug the mains plug 9into a properly installed

socket.

Switch the lamp on or oﬀ using the ON/OFF

switch 2.

Adjusting the reﬂector

or spotlight

Note: Only change the position of the reﬂector

1if the lamp is turned oﬀ.

Allow the light to cool oﬀ completely.

14121402L:

Adjust the reﬂector 1to the desired position.

Tighten the locating screw 12 using the Allen

key 11 .

Hold the locating screw 12 from the other side

using the second Allen key 11 while you retigh-

ten the locating screw 12 .

14100602L:

Turn the reﬂector 1to the desired position.

Angle the reﬂector 1to your liking.

Maintenance and Cleaning

Note: The device is maintenance-free.

The LEDs are not replaceable.

RISK OF ELECTRIC SHOCK!

Unplug the mains supply or the mains plug from

the socket.

CAUTION! RISK OF BURNS DUE TO

HOT SURFACES! Allow the lamp to cool down

completely.

RISK OF ELECTRIC SHOCK!

For electrical safety, never clean the light with

water or other liquids, or immerse it in water.

Do not use solvents, benzene or similar sub-

stances. They could damage the light.

Unplug the mains supply 9or the mains

plug 5from the socket.

Only use a dry, lint-free cloth for cleaning.

Safety/Start-up/Maintenance and Cleaning

9GB/IE/NI

Disposal/Warranty and Service

Disposal

The packaging is made entirely of recy-

clable materials, which you may dispose

of at local recycling facilities. The Green

Dot is not valid for Germany.

Observe the marking of the packaging

materials for waste separation, which

are marked with abbreviations (a) and

numbers (b) with following meaning:

1–7: plastics/ 20–22: paper and ﬁbre-

board/ 80–98: composite materials.

The product and packaging materials

are recyclable, dispose of it separately

for better waste treatment. The Triman

logo is valid in France only.

Contact your local refuse disposal author-

ity for more details of how to dispose of

your worn-out product.

To help protect the environment, please

dispose of the product properly when it

has reached the end of its useful life and

not in the household waste. Information

on collection points and their opening

hours can be obtained from your local

authority.

Warranty and Service

Warranty

You receive a 36 month warranty on this product,

valid from the date of purchase. The appliance has

been carefully produced under strict quality control.

Within the warranty period we shall rectify without

charge all material and manufacturing defects. In

the event of a defect during the warranty period,

please send the appliance to the listed Service

Centre address, referencing the following item num-

ber: 14100602L/14121402L.

Wear parts (such as bulbs) and damage caused

by improper handling, non-observance of the

operating instructions or unauthorised interference

are excluded from the warranty. The performance

of services under the warranty does not extend or

renew the warranty period.

Service address

Briloner Leuchten GmbH

Im Kissen 2

DE-59929 Brilon

GERMANY

Tel.: +49 (0) 29 61/97 12–800

Fax: +49 (0) 29 61/ 97 12–199

E-Mail: [email protected]

www.briloner.com

IAN 284923

Please have your receipt and the item number

(e.g. IAN 12345) ready as your proof of purchase

when enquiring about your product.

Declaration of conformity

This product fulﬁls the requirements of the applica-

ble European and national directives. Conformity

has been demonstrated. The relevant declarations

and documents are held by the manufacturer.

Manufacturer

Briloner Leuchten GmbH

Im Kissen 2

DE-59929 Brilon

GERMANY

Safety/Start-up/Maintenance and Cleaning

Inhaltsverzeichnis

Altri manuali per 284923

Indice

Lingue:

Altri manuali LIVARNO LUX Luce esterna

LIVARNO LUX

LIVARNO LUX C122016-8 Specifiche tecniche

LIVARNO LUX

LIVARNO LUX 291038 Specifiche tecniche

LIVARNO LUX

LIVARNO LUX 279054 Specifiche tecniche

LIVARNO LUX

LIVARNO LUX 3433-025L Specifiche tecniche

LIVARNO LUX

LIVARNO LUX HG02014A Specifiche tecniche

LIVARNO LUX

LIVARNO LUX HG00394A Specifiche tecniche

LIVARNO LUX

LIVARNO LUX 315252 Specifiche tecniche

LIVARNO LUX

LIVARNO LUX HG04245A Specifiche tecniche

LIVARNO LUX

LIVARNO LUX 54515 Manuale utente

LIVARNO LUX

LIVARNO LUX 14101504L Specifiche tecniche

LIVARNO LUX

LIVARNO LUX 54313 Manuale utente

LIVARNO LUX

LIVARNO LUX LSL 10 A4 Manuale utente

LIVARNO LUX

LIVARNO LUX 313271 1904 Specifiche tecniche

LIVARNO LUX

LIVARNO LUX HG01045 Specifiche tecniche

LIVARNO LUX

LIVARNO LUX LSLB 30 A1 Scheda informativa del prodotto

LIVARNO LUX

LIVARNO LUX 30866 Manuale utente

LIVARNO LUX

LIVARNO LUX 104775 Manuale utente

LIVARNO LUX

LIVARNO LUX LSLB 100 A1 Scheda informativa del prodotto

LIVARNO LUX

LIVARNO LUX 10346A Specifiche tecniche

LIVARNO LUX

LIVARNO LUX 93673 Manuale utente

LIVARNO LUX

LIVARNO LUX HG03444A Specifiche tecniche

LIVARNO LUX

LIVARNO LUX 273603 Specifiche tecniche

LIVARNO LUX

LIVARNO LUX KH4246-01/11-V2 Manuale utente

LIVARNO LUX

LIVARNO LUX 300535 Specifiche tecniche

Manuali Luce esterna popolari di altre marche

Sealey

Sealey LED37 Manuale utente

nordlux

nordlux VEJERS Guida utente

SImx

SImx ELITE LED LHTC637 Manuale utente

GEV

GEV CAROLINE 10833 Manuale utente

NEBO

NEBO NEB-LSP-0020 Manuale utente

WE-EF

WE-EF PFL540 LED Manuale utente

Lindby

Lindby 9949029 Manuale utente

HEPER

HEPER DOGO Side LW6048.585-US Istruzioni per l'installazione e il funzionamento

HEPER

HEPER LW8034.003-US Istruzioni per l'installazione e il funzionamento

Maretti

Maretti VIBE S 14.6080.04.A Manuale utente

BEGA

BEGA 84 253 Manuale

HEPER

HEPER MINIMO Istruzioni per l'installazione e il funzionamento

LIGMAN

LIGMAN BAMBOO 3 Manuale utente

Maretti

Maretti TUBE CUBE WALL 14.4998.04 Manuale utente

Maxim Lighting

Maxim Lighting Carriage House VX 40428WGOB Manuale utente

urban ambiance

urban ambiance UQL1273 Manuale utente

TotalPond

TotalPond 52238 Manuale utente

Donner & Blitzen

Donner & Blitzen 0-02661479-2 Manuale utente
