Art No. WL0156
Wi-Fi Storage Sharer
WL
0
1
5
1
The WL0156 is a perfect mobile Wi-Fi Storage Sharer for iPhone/ iPad, Android
Smart Phone/ Pad (such as Samsung, HTC, SONY, Moto, ASUS, LG, Acer, …),
Mac Computers, and Windows Computers to enhance the limited storage,
share the vast documents & media collections crossed through the different OS
platforms of iOS, Mac OS , Android, & Windows.
It’s simple to build up your PRIVATE CLOUD immediately, just download
our specific APP from Apple App Store or Google Play Store (Android), then
the iPhone/ iPad, Android Phone/ Pad are connected to WL0156 via Wi-Fi
connection. Plug your USB2.0 storage such as flash drive, external HDD, card
reader with memory cards, then your PRIVATE CLOUD is ready for streaming!
Moreover, it’s your UPnP multimedia server! Support UPnP ready Smart
TV, UPnP enabled Media Player
& Gaming Consoles through
Wi-Fi connection to WL0156. Enjoy
& share your private photos, Videos,
documents with a larger display!
Application
Supports iPhone, iPad; Mac Computers;
Android Smart Phone/ Pad; Windows
Computers; UPnP ready Smart TV,
UPnP enabled Media Player & Gaming
Consoles.
Best Connectivit
y
www.LogiLink.com
* The specifications and pictures are subject to change without notice.
*All trade names referenced are the registered namework of their respective owners.
- 2 -
Art No. WL0156
Wi-Fi Storage Sharer
WL
0
1
5
1
Features:
• Supports iOS (iPhone, iPad); Mac OS X (Mac Computers); Android (Smart Phone/
Tablet); Windows Computers; UPnP ready Smart TV, UPnP enabled Media Player &
Gaming Consoles
• Easy & Fast to build your PRIVATE CLOUD
• Simply build up UPnP multimedia server
• Directly plug your USB2.0 storage to Wi-Fi Sharer, & Play! No extra efforts for files
storing/restoring operation (USB2.0 storage is such as USB Flash drive, card reader,
external HDD.)
• Be your media center in living room for UPnP connecting to Smart TV , UPnP Media
Player & Gaming Consoles
• Expand your storage capacity of Smart Phone & Tablet by Wi-Fi connection!
• Supports 5 mobile devices streaming at the same time
• Ultra compact for mobile carry
• External Antenna for better Wi-Fi connection
• Support upload and download from external storage through Wi-Fi
• Auto-detect USB-PC-Link and Wi-Fi mode
• Support virtual AP for internet access
• Support data exchange between storage and mobile devices.
• Content support: Photo, Video player, Audio player, documents
Best Connectivity
www.LogiLink.com
* The specifications and pictures are subject to change without notice.
*All trade names referenced are the registered namework of their respective owners.
- 3 -
Art No. WL0156
Wi-Fi Storage Sharer
WL0151
Specification:
Main IC Ralink RT5350/ SDRAM / SPI Flash ROM 8MB
Wi-Fi Interface Wi-Fi: 802.11 b/g/n; 1T1R
Wi-Fi max connection: 5 (Let 5 mobile devices playback the contents
inside the USB2.0 storage at the same time.)
Wi-Fi range: 20 ~ 30 meters (depend on the environment)
Wi-Fi Encryption: WEP/ WPA/WPA2
Wi-Fi access performance: 3.5 MB/sec
AP client mode support
Software Spec Embedded Linux 2.6.21
Support File System : NTFS, FAT32, HFS+, EXFAT
Networking: DHCP, Static IP
Web UI: setting
Support multi languages: English, Traditional Chinese, Simple Chinese
are available now
Friendly GUI: SSID setting, Storage information (ex.: capacity & usage)
Web server
Firmware upgrade
Support Media stream
Dimension
(W x L x H)
Case: 42 x 88 x 13.5/15.4 mm (1.65 x 3.46 x 0.53/0.60 inches)
Antenna: external, L = 62 mm (2.44 inches)
Best Connectivit
y
www.LogiLink.com
* The specifications and pictures are subject to change without notice.
*All trade names referenced are the registered namework of their respective owners.
Mobile Devices Support:
• Apple
iOS iOS 4 and higher
iPad iPad, iPad 2, new iPad
iPhone iPhone 4, iPhone 4S, iPhone 5
iPod iPod touch 4th generation
Mac Mac Computers, Mac OS10.5 and higher
• Google Android
Android_ Phone Android Phone 2.1 and higher
Android_ Pad Android Pad 3.0 and higher
Smart Phone Samsung Galaxy series, HTC, Motorola, LG, ASUS, …
Tablet Samsung Tab, HTC, Moto, ASUS, Acer
• Windows PC, NB
Windows XP/ Vista/ 7 and higher
Format Supports
• iOS
Movie .mp4, .mov
Photo .jpg, .png
Music : .mp3, .wav, .aif
Documents .pdf, .txt, .doc, .docx, .xls, .xlsx, .ppt, .pptx
• Android
Movie .mp4, .3gp
Photo .jpg, .png, .bmp, .gif
Music .mp4, .3gp, .wav, .ogg, .imy, .aif
Documents .pdf, .txt, .doc, .docx, .xls, .xlsx, .ppt, .pptx
- 4 -
Art No. WL0156
Wi-Fi Storage Sharer
WL
0
1
5
1
Best Connectivit
y
www.LogiLink.com
* The specifications and pictures are subject to change without notice.
*All trade names referenced are the registered namework of their respective owners.
Configuration
Dimension (W x L x H): 42x88x13.5/15.4 mm
Package Contents:
• 1 x Wi-Fi Storage Sharer
• 1 x USB 2.0 cable A-micro B, (for DC IN 5V)
• 1 x User Manual
Packaging Information:
• Packing Dimension: mm
• Packing Weight: kg
• Carton Dimension: mm
• Carton Q'ty: pcs
• Carton Weight: kgs
