Logitech IK1041 Manuale utente

Setup Guide | 设置指南

Keys-To-Go

Ultra-portable keyboard iK1041 超便携键盘

Keys-To-Go - Ultra-portable keyboard

Contents / 目录

English. . . . . . . . . . . . . . . . . . 3 简体中文 . . . . . . . . . . . . . . . . .11

Keys-To-Go - Ultra-portable keyboard

English 3

Know your product

www.logitech.com/support/keystogo-ipad

PDF

OFF

1 2

1 2 3

1 2

2.5 h

Keys-To-Go

Ultra-portable keyboard iK1041 超便携键盘

1. Hot keys

2. Keyboard

3. Bluetooth® connect key

4. Battery check key

5. Bluetooth and battery status light

6. On/o switch

7. Micro-USB charging port

8. Micro-USB charging cable

9. Documentation

Keys-To-Go - Ultra-portable keyboard

4 English

Set up your product

1. Turn on the keyboard:

Bluetooth discovery starts automatically

and continues for 15 minutes. The status

light blinks blue.

If the status light brieﬂy turns red,

charge the battery. For more

information, see “Charge the battery.”

2. Establish Bluetooth connection:

Keys-To-Go

On your iPad, make sure Bluetooth is on.

Select Settings > Bluetooth > On.

Select “Keys-To-Go” from the Devices

menu.

Tip: If “Keys-To-Go” isn’t in the list, try pressing

and holding the Bluetooth connect key on

your keyboard for 2 seconds.

Keys-To-Go - Ultra-portable keyboard

English 5

Charge the battery

You should charge the battery when:

• the status light turns red brieﬂy when

you turn on the keyboard, or

• the status light blinks red when you press

the battery check key:

A fully charged battery provides about

3 months of power when the keyboard

is used about two hours a day.

Charging your battery

1. Use the micro-USB charging cable

provided to connect the keyboard to

your computer or a USB power adaptor.

The status light blinks green while

the keyboard is charging.

USB

2. Charge your keyboard until the status

light turns solid green.

Each minute of charging gives you about

two hours’ use.

Note: This ratio is approximate and is based

on the standard user experience. Your result

may vary.

It takes 2.5 hours to fully charge

the battery.

Keys-To-Go - Ultra-portable keyboard

6 English

Hot keys

Home = iPad Home screen

Switch applications

Type keywords in the search bar

for contacts, music, notes, events,

mail, web, Wikipedia, and more

Switch language

Switches the keyboard language

Virtual keyboard

Shows/hides the virtual keyboard

Screen Shot

Previous track

Play/Pause

Next track

Mute

Volume down

Volume up

Bluetooth connect

Battery check

Function keys

Fn + X = Cut

Fn + C = Copy

Fn + V = Paste

Fn + Left cursor = Select left

Selects text on the left,

word by word

Fn + Right cursor = Select right

Selects text on the right,

word by word

Note:

• To select a function key, press and hold the Fn key, and then press the key indicated above.

Keys-To-Go - Ultra-portable keyboard

English 7

Use your product

Status light indications

Light Description

Blinking green The battery is charging.

Solid green When charging, indicates that the battery

is fully charged (100%).

When you press the battery check key,

solid green for 2 seconds indicates that

the battery power is good (above 20%).

Blinking red Battery power is low (less than 20%).

Recharge the battery.

Solid red When you ﬁrst turn on your keyboard,

the status light shows solid red brieﬂy

if battery power is low.

Blinking blue Fast: The keyboard is in discovery mode,

ready for pairing.

Slow: The keyboard is trying to reconnect

to your iPad.

Solid blue Bluetooth pairing or reconnection

is successful.

Connecting to a dierent iOS device

1. Make sure the keyboard is turned on.

2. On your iOS device, check that Bluetooth is turned on.

Select Settings > Bluetooth > On.

3. Press and hold the Bluetooth connect key on

the keyboard for 2 seconds. The keyboard turns

discoverable for 3 minutes.

4. Select “Keys-To-Go” from the Devices menu.

Keys-To-Go - Ultra-portable keyboard

8 English

When you’ve ﬁnished using your product

When not in use, turn o the keyboard to conserve battery power.

OFF

Note:

• The keyboard enters sleep mode if powered on and not used for 2 hours. To exit sleep mode,

press any key.

Keys-To-Go - Ultra-portable keyboard

English 9

Battery disposal at product end of life

1. Cut along the fabric at the top edge of

the keyboard:

2. Use a screwdriver to pry the fabric away

from the area around the on/o switch:

3. Separate the inner and outer fabric layers,

and pull them away from the corner:

4. Pull back the yellow plate to reveal

the battery and remove it:

5. Dispose of the battery according

to local laws.

Keys-To-Go - Ultra-portable keyboard

10 English

Visit Product Support

There’s more information and support

online for your product. Take a moment

to visit Product Support to learn more

about your new Bluetooth keyboard.

Browse online articles for setup help,

usage tips, and information about

additional features. If your Bluetooth

keyboard has optional software, learn

about its beneﬁts and how it can help you

customize your product.

Connect with other users in our Community

Forums to get advice, ask questions,

and share solutions.

At Product Support, you’ll ﬁnd a wide

selection of content including:

• Tutorials

• Troubleshooting

• Support community

• Online documentation

• Warranty information

• Spare parts (when available)

Go to:

www.logitech.com/support/keystogo-ipad

Troubleshooting

The keyboard does not work

• Press any key to wake the keyboard from

sleep mode.

• Turn the keyboard O and then back On.

• Recharge the internal battery. For more

information, see “Charge the battery.”

• Re-establish the Bluetooth connection

between the keyboard and your iPad:

• On your iPad, check that Bluetooth

is turned on.

• Press and hold the Bluetooth connect

key on your keyboard for 2 seconds.

• Choose “Keys-To-Go” from the

Devices menu on your iPad.

The status light brieﬂy turns blue after

the Bluetooth connection is made.

What do you think?

Thank you for purchasing our product.

Please take a minute to tell us what you think of it.

www.logitech.com/ithink
