Logitech® Illuminated Living-Room
Keyboard K830
Setup Guide
Guide d’installation
Logitech Illuminated Living-Room Keyboard K830
English 3
Know your product
7
11
8
9
1
12
13
2 3
45 6
10
Logitech® Illuminated Living-Room
Keyboard K830
Setup Guide
Guide d’installation
1. Left mouse click
2. Micro-USB charging port
3. On/o power switch
4. Function keys
5. Automatic light sensor
6. Battery indicator
7. Hot keys
8. Touchpad
9. Mouse click buttons
10. Product documentation
11. Unifying receiver
12. USB extender cable
13. Micro-USB charging cable
Logitech Illuminated Living-Room Keyboard K830
4 English
Setting up your keyboard
1. Plug in the Unifying receiver into your laptop or desktop computer. You can use
the USB extender cable provided to position the Unifying receiver away from metallic objects
or devices that may cause interference.
USB
Note: You can also use your keyboard to control a TV. Refer to the documentation supplied by your TV
manufacturer for compatibility information and further connection details.
2. Turn on your keyboard.
Software for your keyboard
Download and install the Logitech software for your keyboard to:
• Customize the function keys.
• Adjust your touchpad experience. You can
modify the pointer speed, adjust scrolling,
and disable touchpad tap.
• Connect additional devices to
your Unifying receiver.
• View videos explaining gestures
and providing information about
your keyboard’s behavior.
• Reverse the requirement to press
the Fn key when using function keys.
Go to www.logitech.com/support/k830.
Logitech Illuminated Living-Room Keyboard K830
English 5
Using your keyboard
Keyboard backlighting
When you start using your keyboard,
the automatic light sensor detects the light
level in the room and adjusts the keyboard
backlight intensity accordingly. There are three
intensity levels:
• In bright light: no keyboard illumination.
• In poor light: full intensity backlight.
• In the dark: half intensity backlight.
You can manually override the automatic
backlighting setting. Press the key to cycle
between the three intensity levels.
Please note:
• When your battery charge level is low,
backlighting turns o automatically to
conserve battery power.
• Automatic backlight control is restored
automatically if the keyboard is idle for
30 minutes or more, or after turning
the keyboard o and back on.
Touchpad gestures
12
34
To point, scroll and click:
1. Point and slide one finger anywhere on
the touchpad to move the screen pointer.
2. Scroll with two fingers, up or down.
3. Press for left mouse click.*
4. Press for right mouse click.
*You can also tap the touchpad surface to perform
a click.
Note: To disable gestures and touchpad tap, press the
Fn key plus the left mouse click button. To re-enable
gestures and touchpad tap, press the Fn key plus the
left mouse click button again.
Logitech Illuminated Living-Room Keyboard K830
6 English
Recharging your keyboard
Your keyboard is rechargeable. There are no batteries to be replaced.
A three-hour charge provides up to 10 days of use when you type about two hours a day with
backlight on, or about one year without backlight.
Note: The use you get between charges may vary depending on your usage pattern.
When you turn on the keyboard the battery
indicator shows the charge level.
Indicator Explanation
Blinking green The battery is charging.
Solid green The battery has adequate charge, or charging is complete.
Blinking red Battery power is low. Recharge the battery.
To charge the battery, connect the keyboard
to a computer using the Micro-USB charging
cable supplied.
The battery indicator blinks green while charging
takes place. Charge until the indicator light stops
blinking.
You can use the keyboard while it charges.
Note: If the battery power is low (indicator blinking red), the keyboard backlight is disabled.
USB
Logitech Illuminated Living-Room Keyboard K830
English 7
Function keys
Adjust backlight intensity
Minimize window
Maximize window
Close window
Switch screen
For example, show laptop display
on TV screen
Show desktop
Windows search
Launch Web browser
Launch media player
Previous track
Play/pause track
Next track
Fn + ins: Switch applications
Fn + del: Sleep mode
Fn + backspace: Print screen
Fn + caps lock: Scroll lock
Fn + : Page up
Fn + : Page down
Fn + : Home
Fn + : End
Note:
• For keys F1 to F12:
• Press just the key to select the feature: ‘Adjust backlight intensity’, ‘Minimize window’...
• Press both Fn and the key to select the function key: F1, F2...
• For all other function keys, press both Fn and the key to select the feature.
• You can use the Logitech software to reverse the requirement to press the Fn key.
Hot keys
Mute
Volume down
Volume up
Logitech Illuminated Living-Room Keyboard K830
8 English
The Logitech® Unifying receiver
Plug it. Forget it. Add to it.
Your new Logitech product ships with
a Unifying receiver. Did you know you can
add a compatible Logitech wireless device
that uses the same receiver as your current
Logitech Unifying product?
Are you Unifying-ready?
If you have a Logitech wireless device
that’s Unifying-ready, you can pair it with
additional Unifying devices. Just look
for the orange Unifying logo on the new
device or its packaging. Build your ideal
combo. Add something. Replace something.
It’s easy, and you’ll use only one USB port
for up to six devices.
Getting started is easy
If you’re ready to pair your device(s)
via Unifying, here’s what you need to do:
1. Make sure your Unifying receiver
is plugged in.
2. If you haven’t already, download and install
the Logitech software for your keyboard
(see “Software for your keyboard”).
3. Start the software and follow
the on-screen instructions to pair the new
wireless device with your existing Unifying
receiver.
Logitech Illuminated Living-Room Keyboard K830
English 9
Visit Product Central
There’s more information and support online
for your product. Take a moment to visit
Product Central to learn more about your new
keyboard.
Browse online articles for setup help, usage
tips, or information about additional features.
If your keyboard has optional software, learn
about its benefits and how it can help you
customize your product.
Connect with other users in our Community
Forums to get advice, ask questions,
and share solutions.
At Product Central, you’ll find a wide selection
of content:
• Tutorials
• Troubleshooting
• Support community
• Software downloads
• Online documentation
• Warranty information
• Spare parts (when available)
Go to www.logitech.com/support/k830.
Troubleshooting
Keyboard not working
• Check your is keyboard powered on.
• Restart the keyboard by turning it o
then back on.
• If the battery indicator flashes red,
recharge the batteries. See “Recharging
your keyboard.”
• Check the Unifying receiver connection.
• Use the USB extender cable provided
to position the Unifying receiver as close
as possible to your keyboard, and remove
any metallic objects between the receiver
and keyboard.
• Try plugging the Unifying receiver into
a dierent port.
• If the Unifying receiver is plugged
into a USB hub, try plugging it directly
into your computer.
What do you think?
Please take a minute to tell us.
Thank you for purchasing our product.
www.logitech.com/ithink
Logitech Illuminated Living-Room Keyboard K830
10 English
Battery disposal at product end of life
12
4
3
5
1. Remove the four feet and eight screws
from the keyboard bottom.
2. Separate the top and bottom cases.
3. Disconnect the flat and battery cables
from the main circuit board.
4. Remove the battery from the bottom case.
5. Dispose of the battery and product
according to local laws.
