Harmony Touch

User Guide

Harmony Touch User Guide

Harmony Touch at a Glance . . . . . . . . . . . . . . . . .1

How your Harmony Touch Works . . . . . . . . . . . . . .1

Devices . . . . . . . . . . . . . . . . . . . . . . . .1

Activities . . . . . . . . . . . . . . . . . . . . . . . .1

Inputs . . . . . . . . . . . . . . . . . . . . . . . . .1

Favorites . . . . . . . . . . . . . . . . . . . . . . . 2

Myharmony.com . . . . . . . . . . . . . . . . . . . . . 2

Know your Harmony Touch . . . . . . . . . . . . . . . . 2

Harmony Touch First Time Setup . . . . . . . . . . . . . . 3

Your Myharmony.com Account . . . . . . . . . . . . . . 3

Installing the Setup Plugins . . . . . . . . . . . . . . . . 4

Connecting your Harmony Touch to your Computer . . . . . . 4

Setting up Devices to Control . . . . . . . . . . . . . . . 5

Copying Setup Information for an Existing Remote . . . . . . . . . . . 6

Adding Devices . . . . . . . . . . . . . . . . . . . . 6

Using the Teach Commands Function to Add a Device . . . . . . . . . . 7

Adding an Unknown Device . . . . . . . . . . . . . . . . . . 7

Setting up Activities . . . . . . . . . . . . . . . . . . 9

Adding a Watch TV Activity . . . . . . . . . . . . . . . . . . 9

Setting up Favorites . . . . . . . . . . . . . . . . . . 10

Setting up Favorites When Your Provider is not Listed . . . . . . . . . . . 12

Setting up Favorites Manually . . . . . . . . . . . . . . . . . 13

Syncing your Harmony Touch . . . . . . . . . . . . . . . 14

Upgrading your Harmony Touch ﬁrmware . . . . . . . . . . 14

Testing your Setup . . . . . . . . . . . . . . . . . . . 14

Changing your Setup . . . . . . . . . . . . . . . . . . 15

Syncing Your Remote Back to Myharmony.com . . . . . . . . 15

Adding or Deleting Devices. . . . . . . . . . . . . . . . 16

To Add a Device . . . . . . . . . . . . . . . . . . . . . 16

To Delete a Device . . . . . . . . . . . . . . . . . . . . 16

Modifying Device Settings . . . . . . . . . . . . . . . . . . 16

Adding or Deleting Activities . . . . . . . . . . . . . . . 17

To Add an Activity . . . . . . . . . . . . . . . . . . . . 17

To View Activity Settings. . . . . . . . . . . . . . . . . . . 17

To Change Activity Settings . . . . . . . . . . . . . . . . . . 18

To Delete an Activity . . . . . . . . . . . . . . . . . . . . 18

Managing your Favorites. . . . . . . . . . . . . . . . . 18

Changing Your Location or Channel Provider . . . . . . . . . . . . . 18

Adding, Modifying and Reordering Favorites . . . . . . . . . . . . . 19

Channel Tuning Settings . . . . . . . . . . . . . . . . . . . 21

Sync Your Remote . . . . . . . . . . . . . . . . . . . . 21

Using your Harmony Touch . . . . . . . . . . . . . . . . 22

Using your Activities . . . . . . . . . . . . . . . . . . 22

Switching Between Activities . . . . . . . . . . . . . . . . . 22

Activity Commands . . . . . . . . . . . . . . . . . . . . 23

Number Entry . . . . . . . . . . . . . . . . . . . . . . 23

Gesture Control . . . . . . . . . . . . . . . . . . . . . 24

Using Favorites . . . . . . . . . . . . . . . . . . . . 25

Managing Your Favorites . . . . . . . . . . . . . . . . . . . 25

Using Devices . . . . . . . . . . . . . . . . . . . . . 26

Turning your system o . . . . . . . . . . . . . . . . . 26

Using Help . . . . . . . . . . . . . . . . . . . . . . 27

Advanced Help . . . . . . . . . . . . . . . . . . . . 27

Charging your Remote . . . . . . . . . . . . . . . . . 27

Settings . . . . . . . . . . . . . . . . . . . . . . . . 28

Remote Settings . . . . . . . . . . . . . . . . . . . . 28

Activity Settings . . . . . . . . . . . . . . . . . . . . 28

Inputs . . . . . . . . . . . . . . . . . . . . . . . . 29

Reorder Activities. . . . . . . . . . . . . . . . . . . . . 29

Set Icons . . . . . . . . . . . . . . . . . . . . . . . 29

Device Delay Settings . . . . . . . . . . . . . . . . . . 30

To Access Your Delay and Speed Settings From Your Harmony Touch . . . . . . 30

Resetting your Remote . . . . . . . . . . . . . . . . . 31

Advanced Features . . . . . . . . . . . . . . . . . . . 32

Activity Sequences . . . . . . . . . . . . . . . . . . . 32

Button Sequences . . . . . . . . . . . . . . . . . . . 33

Device Settings . . . . . . . . . . . . . . . . . . . . 34

Adding/Fixing Device Commands . . . . . . . . . . . . . . . . 34

Device Power Settings . . . . . . . . . . . . . . . . . . . 35

Device Input Settings . . . . . . . . . . . . . . . . . . . . 36

Changing or Fixing Button Operations . . . . . . . . . . . 36

To Change or Fix Screen Options . . . . . . . . . . . . . . . . 36

Support . . . . . . . . . . . . . . . . . . . . . . . . 38

Troubleshooting Harmony Touch . . . . . . . . . . . . . 38

Harmony Touch is not Detected by my Computer . . . . . . . . . . . . 38

Devices do not Respond to Harmony Touch at All . . . . . . . . . . . . 38

Harmony Touch does not Charge . . . . . . . . . . . . . . . . 38

Harmony Touch does not Control Devices Properly . . . . . . . . . . . 39

Solving Common Problems Using Your Harmony Touch . . . . . . . . . . 39

Get Support . . . . . . . . . . . . . . . . . . . . . 39

Contacting Customer Support . . . . . . . . . . . . . . . . . 39

Finding Answers to Questions . . . . . . . . . . . . . . . . . 39

Getting Help with Online Setup . . . . . . . . . . . . . . . . . 39

Using the On-Remote Help . . . . . . . . . . . . . . . . . . 39

Logitech’s Harmony Remote User Forums . . . . . . . . . . . . . . 39

Logitech Harmony Touch

Harmony Touch at a Glance

The Harmony Touch Universal Remote brings the ﬂexibility and convenience of touch screen controls to your

home entertainment system. Using the Activities feature, you can control all of your devices from one location.

Switching between activities such as watching TV or listening to music is a quick and easy operation.

Setup is also made quick and easy using the guided online setup on myharmony.com. In addition to the Setup

Guide provided with your remote, this User Guide is designed to answer your questions and point you in the

right direction to get any additional help you need.

How your Harmony Touch Works

Harmony Touch is an activity-based Infrared (IR) universal remote control. Using the myharmony.com web-

based setup, you can control up to 15 dierent devices. Using its Smart State technology, the Harmony Touch

keeps track of the devices it controls, which allows it to always know which devices are on and o, and what

input each device is currently set to.

Some key concepts for Harmony Touch operation include:

Devices

Devices are the components of your entertainment system. Examples of devices are:

đƫ TV set

đƫ Cable or Satellite set top box

đƫ Audio Visual (AV) receiver

đƫ DVD player

đƫ Game system

Activities

Activities deﬁne the way you use your remote controlled devices. Examples of activities are:

đƫ Watching TV

đƫ Listening to Music

đƫ Watching a DVD

đƫ Playing a Game

To create an activity, you need to know how you use each device that is involved in that activity. For example,

to create a basic Watch TV activity, you need to know the following:

đƫ Which devices you will use. In most cases, you need at least the following devices:

ƫ–A TV set

ƫ–A programming source, such as a cable or satellite set top box

đƫ Which device is used to control the volume

đƫ Which device is used to change channels

đƫ What input is used on the TV set.

Inputs

Inputs determine how your devices are connected. For example, if your DVD player is connected to the

Video 2 input on your TV, then the TV must be set to Video 2 to display the DVD’s picture.

Logitech Harmony Touch

Favorites

Favorites are your favorite TV channels. Using the myharmony.com website you can select up to 50 favorite

channels to display on the remote. Selecting a favorite channel will start your “Watch TV” activity, if it’s not

already started, and tune directly to that channel. Using the touch screen, you can add, remove and reorder

your favorite channels right on the remote.

Myharmony.com

http://myharmony.com is the website where you conﬁgure your Harmony Touch. By connecting your

Harmony Touch to your Mac or Windows computer and following the instructions at myharmony.com,

you can enter your device information, create activities and choose your favorites. With this information,

myharmony.com will conﬁgure your Harmony Touch to control your entertainment system. Your can return

to myharmony.com any time to update your conﬁguration, although many settings can also be maintained

directly on Harmony Touch as well.

Know your Harmony Touch

āċƫûƫ100+* Power o your current activity

Ăċƫ1 %+ĥ2% !+ƫ+*0.+(/ Perform standard AV

functions

ăċƫ2+.%0!/ Display the Favorites screen on the

remote

ąċƫƫ0+1$ƫ/.!!* View, launch and edit activities

and favorites, use the onscreen number pad, change

settings, and get Help

Ćċƫ%.!0%+*(ƫ*2%#0%+* Navigate up, down, left and

right in menus on your TV screen

ćċƫ4%0 Leave a listing or menu on your TV screen

Ĉċƫ OK Press to select an option on your TV screen

ĉċƫ+(1)!ƫ+*0.+(

Ċċƫ10!

āĀċƫ0!((%0!ĥ(!ƫ+*0.+(/ DVR opens the record/

play menu. Guide opens satellite or cable program

listings. Info provides program information

āāċƫ+(+.ƫ+ ! ƫ*2%#0%+*ƫ100+*/ Perform cable,

satellite or Blu-ray functions

āĂċƫ+)! Display your activities on the remote screen

āăċƫ!*1 Display the menu on your TV screen

āąċƫ$**!(ƫ+*0.+(

āĆċƫ.!2%+1/ Tune to the previous channel

āćċƫƫ%* +3 “Learn” IR (infrared) commands from

another remote

āĈċƫ%.+ġƫ,+.0 Connect Harmony Touch to your

computer to program it

Logitech Harmony Touch

Harmony Touch First Time Setup

The easiest way to complete the ﬁrst time setup is using a laptop computer in the same spot where you

will use your remote. That will give you access to all of the devices you want to control using your Harmony

Touch. During the ﬁrst time setup process, you will connect your remote to the computer using the USB

cable provided.

The following operating system/browser combinations are supported:

!/'0+,ƫ.+3/!. Mac PC

Internet Explorer 8+ D

Chrome 16+ D

Firefox 11+ DD

Safari 4+ D

*Windows Vista and XP support 32 bit browsers

* Windows 7 and 8 support both 32 and 64 bit browsers

Your Myharmony.com Account

To use your Harmony Touch, you will need an account where you can enter the details for your devices,

activities and favorites.

Using your web browser, go to http://myharmony.com

If this is your ﬁrst time using myharmony.com, click the Create an Account button on the left. Follow the

instructions to enter your name and email address to create your account.

If you already have a myharmony.com account, you can add your Harmony Touch to that account. Enter your

account information in the “Existing Users—Sign In” section on the right. When you log in to your account, you

will see the “Remote Gallery” page from where you can access your existing Harmony remotes, or choose to

add your new Harmony Touch.

Logitech Harmony Touch

Installing the Setup Plugins

If you are creating a new account or accessing an existing account on a new computer for the ﬁrst time, you

will need to install two plugins.

āċƫClick the Silverlight plugin button and follow the instructions to complete the Microsoft Silverlight

installation.

ĂċƫClick the MyHarmony plugin button and follow the instructions to complete the MyHarmony plugin

installation.

ăċƫWhen both plugins are installed, your browser will automatically refresh and continue the set up process.

Connecting your Harmony Touch to your Computer

Whether you are creating a new account or adding Harmony Touch to an existing account, you will be asked

to connect Harmony Touch to your computer using the USB cable provided.

Once connected, it may take several seconds for Harmony Touch to be detected by myharmony.com before

you can proceed.

When the Welcome page appears, click Next to begin adding device information.

Logitech Harmony Touch

Setting up Devices to Control

The ﬁrst step to setting up Harmony Touch is to tell myharmony.com what devices you have in your

entertainment system that you want to control.

Using the Setup Guide that came with your Harmony Touch, gather the manufacturer, model and connection

information for each device. Having this information collected ahead of time will make setup much easier.

Click Next when you are ready to begin.

TV Manufacturerƫ

___________________________________________________________
