Long Range Systems 9 T9560 EZ User Manual
the next steps
If ALL pagers are affected and none of them will page:
• Check the Restaurant ID on the T9560 to ensure that it
matches the Restaurant ID for the pagers (please call LRS
if you do not have this information on file)
• If the Restaurant ID is correct, all pagers are appropriately
charged yet none of the pagers page, please contact LRS
Pager(s) not c arging
When placed in the charging base, do all pagers have a single red charge
light lit up?
If no pagers have a charge light, this may be an issue with the
power supply (please contact LRS)
If only some pagers have a charge light that is lit, please do the
following:
• Remove the main power supply and all jumper wires (all pagers
will go off at once and this is ok)
• Insert the power supply into each individual row (or base
for Coasters) to see if the pagers on that row/Coaster base
all light up
• If all pagers on that row or Coaster base light up, please
test the next row/base with the
power supply until you have tested each one
• If some of the pagers do not light up but those specific
pagers light up on other rows/bases, please call LRS to
have this row/base replaced
If all pagers have the charge light lit up as you test the individual
rows/bases, you may have a jumper wire that is not connecting
properly or causing a short. Please contact LRS to purchase ad-
ditional jumper wires to replace ones that are not working as
they should.
Note Regarding Pagers: Please be sure that all pagers are plugged in and
charging when not in use. Please also note that a maximum of 60 Coasters or 25
Paddle Pagers or 30 Lobster Pagers or 30 Pizza Pagers can be on one 10V power
supply. If you are exceeding any of these limits, it may have long term effects on
your pagers’ ability to charge properly. Please contact LRS to purchase additional
charging bases to supplement your entire inventory.
