Lorex Road Warrior RW2S Manuale di installazione e funzionamento

Road Warrior 2S

2 CAMERA MOBILE DIGITAL VIDEO RECORDER

RW2S Road Warrior

www.lorexcctv.com

ROAD WARRIOR MOBILE SECURITY

Google Maps Support

Up to 32GB

175º

Wide-

Angle

Lens

•VIEW everything: 2 high resolution integrated color cameras record driver and

cabin views in real time with synchronized audio. Local live view and playback is

supported by external video output (monitor required).

•RECORD anywhere: Advanced H264 compression enables hours of accurate

real time recording of video, audio, GPS coordinates, speed, and events.

•LOCATE what matters: Advance integrated GPS, shock sensor and cameras

identify accurate video and tracking of vehicle movement including over-speed,

impact and excessive G-force (acceleration and deceleration).

•PLAYBACK multiple views: Live and recorded data can be viewed on

vehicle monitor (not included) or Internet connected PC. GPS functions (speed,

coordinated, time) can be viewed on Google Maps® Playback can be viewed

continuously or by event.

Mounts easily in any car and captures

two simultanious video views while

connected to GPS

Removable

DV R

Mobile

MOBILE DIGITAL VIDEO RECORDER

www.lorexcctv.com

MOBILE DIGITAL VIDEO RECORDER

Road Warrior 2S

2 CAMERA MOBILE DIGITAL VIDEO RECORDER

RW2S Road Warrior

•2 channel built-in camera Mobile Digital Video Recorder

•Integrated GPS, impact sensor and microphone data recorder

•4GB SD memory (included) with up to 8hr of real time recording

(32GB supported)

•H264 compression for efficient file recording and transmission

•2 High resolution low light cameras with 175 degree wide angle

lens

•IR LEDs for interior cabin night vision

•Digi-Viewer supports Google Maps® for GPS location, speed,

events. Windows™ Vista & 7 compatible

•Discrete emergency recording button

•DC 12/24V adapter for continuous vehicle power connection

•Window mount with removable connection

•Dimensions (2.5x5.5x1.2”/65x140x30mm)

Features: Multiple Applications:

1 - Date and vehicle info

2 - Street view

3 - Internal view (picture-in-picture view)

4 - Video controls

5 - Screen view options

6 - Speed (Miles or KM)

7 - File options

8 - Volume control

9 - Event log

10 - Google Maps© (map or satellite view)

Lorex Viewer Software:

Speciﬁcations:

2-07122009

Road Warrior 2S

2 CAMERA MOBILE DIGITAL VIDEO RECORDER

As our product is subject to continuous improvement, Lorex Technology &

subsidiaries reserve the right to modify product design, specifications &

prices without notice and without incurring any obligation. E&OE

Lorex Technology Inc.

250 Royal Crest Court, Markham,

Ontario L3R 3S1

Canada.

3700 Koppers Street

Baltimore, Maryland 21227,

USA.

Product Information:

Model#: RW2S: with 4GB SDHC Memory Card

UPC Code: 7-78597-20000-3

Weight: 0.61kg/1.35 lbS

Cube: 0.0028m / 0.099ft

Package Dimensions: 199mm x 195mm x 76mm

7.8” x 7.6” x 2.9” (W x H x D)

Includes: 1 x Lorex Road Warrior

1 x Mounting Bracket with Built-in GPS Sensor

1 x Monitor Cable (Video)

1 x Car Adapter (Cigar Jack)

1 x Panic Buton Extension Cable

1 x SDHC Memory Card

1 x SDHC Memory Card Reader

1 x Double Sided Adhesive, Zip Ties, Zip Tie Anchors

1 x Electronic Instruction Manual (Inside Cd)

1 x Quick Start Guide

1 x Software CD

Dimensions:

30mm

RW2S MOBILE DVR

140mm

65mm

Cameras: 2EA CMOS Built-in

In-Car Camera: 175° Field of View

Driver-View Camera: 176° Field of View

Video Input Digital 2 Channel Built-in

Video Compression H.264

Audio Compression ADPCM

Recording Resolution VGA 640 x 480

Recording Speed Maximum of 60 FPS (30 FPS per channel)

Recording Media SDHC memory card, Class 6. 32 Gigabyte maximum

Lens Curvature Driver-View Lens: 120° / Interior-View

Lens: 175° Wide Angle

IR LED 850n 7V ~ 16V -->12V ~24V with CDS sensor

Power Requirements DC 7V~26V

Operating Temperature 32° F ~ 113°F / (0° ~ 45°C)

Humidity Tolerance 10~95%

Weight 150g

Dimensions 65 (W) x 140 (D) x 30 (H) mm
