Copyright © 2007 LOREX Technology Inc.

FAQ GUIDE

Frequently Asked Questions

English Version 2.0

21” COLOR QUAD /

DVR COMBO

Model: SC21CD5444UQ-A80

FAQ Guide Overview

2

FAQ Guide Overview

The following questions are addressed in this FAQ Guide.

1. HOw do I get my system out of Demo Mode?

2. Are the Cameras Waterproof?

3. What is the maximum distance between the Cameras and the Observation System?

4. How many cameras can i connect to this System?

5. What types of Cameras can i use with my system,?

If you have any additional questions or technical issues, please contact the Sentinel CCTV Help

desk for further assistance at 1-888-425-6739 (Option 1 - 1) or mail your questions to

[email protected]

FAQ Guide Overview

3

1. How do I get my System out of Demo Mode?

My system seems to be in Demo Mode - how do I get my unit back into Regular Mode?

To exit from Demo mode, Press the ENTER on the REMOTE CONTROL 10 times - this will stop

Demo Mode. If the ENTER button is pressed 10 times in regular mode, the unit will enter Demo

Mode.

2. Are the Cameras Waterproof?

Can I put the cameras outside my house or office?

This system comes with two different types of cameras - Three (3) Bullet Cameras (Model

MC-117) and One (1) Dome Camera (MC-7125):

• The Bullet cameras are Weather Resistant (rated IP44) against dust and light water spray.

These cameras are not designed to be directly exposed to water and should ideally be placed

under an overhang or a protected area.

• The Dome camera is designed for indoor use only - this camera should NOT be placed

outdoors.

3. What is the maximum distance between the System and the

Cameras?

I would like to know what length of cable I can use with my System.

The maximum length of cable that can be used between the Camera and the Monitor is 300’

(91.5m) using High Performance DIN Cables.

4. How many cameras can I connect to this System?

I would like to know the maximum number of cameras I can use with this system.

Up to 4 Cameras can be connected to the Observation System. The Cameras can be viewed

individually, or in Quad Mode (4 cameras in split screen view).

5. What types of Cameras can I use with my system?

I would like to know what type of Cameras I can use with this system.

Additional DIN type cameras can be purchased and used with this system from the Sentinel

CCTV Website at http://www.sentinelcctv.com

It’s all on the web

Product Information

User Manuals

Quick Start Guides

Specification Sheets

Software Upgrades

Firmware Upgrades

Lorex Technology Inc.

VISIT

www.sentinelcctv.com

www.sentinelcctv.com
