Lowrance IFINDER GO Manuale utente

Pub. 988-0148-622

www.lowrance.com

iFINDER Go

Handheld Mapping GPS Receiver

Operation Instructions



offered by www.Busse-Yachtshop.de email: [email protected] Tel: +49 (0)4347 908234

No part of this manual may be copied, reproduced, republished, transmitted or

distributed for any purpose, without prior written consent of Lowrance

Electronics. Any unauthorized commercial distribution of this manual is

strictly prohibited. Lowranceand iFINDERGO are registered trademarks

of Lowrance Electronics, Inc.

eXitSource Database, copyright 2001-2005 Zenrin Co. Ltd. Exit

Authorityand eXitSourceare trademarks of Zenrin Co. Ltd.

Lowrance Electronics may find it necessary to change or end our policies,

regulations and special offers at any time. We reserve the right to do so without

notice. All features and specifications subject to change without notice. All

screens in this manual are simulated.

For free owner's manuals and other information,

visit our web site:

www.lowrance.com

Lowrance Electronics Inc., 12000 E. Skelly Dr., Tulsa, OK USA 74128-2486

WARNING!

A CAREFUL NAVIGATOR NEVER RELIES ON ONLY ONE METHOD TO

OBTAIN POSITION INFORMATION.

CAUTION

When showing navigation data to a position (waypoint), a GPS unit will show the shortest,

most direct path to the waypoint. It provides navigation data to the waypoint regardless of

obstructions. Therefore, the prudent navigator will not only take advantage of all available

navigation tools when traveling to a waypoint, but will also visually check to make sure a

clear, safe path to the waypoint is always available.

WARNING!

When a GPS unit is used in a vehicle, the vehicle operator is solely responsible for

operating the vehicle in a safe manner. Vehicle operators must maintain full

surveillance of all pertinent driving, boating or flying conditions at all times. An

accident or collision resulting in damage to property, personal injury or death

could occur if the operator of a GPS-equipped vehicle fails to pay full attention to

travel conditions and vehicle operation while the vehicle is in motion.

offered by www.Busse-Yachtshop.de email: [email protected] Tel: +49 (0)4347 908234

Introduction

Welcome to the exciting world of GPS satellite navigation! We know

you're anxious to begin finding your way with this amazing technology,

but we have a favor to ask. Before you grab the batteries and head

outside, please give us a moment or two to explain how our manual can

help you get the best performance from this remarkable little GPS unit.

First, we want to thank you for buying an iFINDER. Whether you're a

first-time user or a professional navigator, you'll discover that the

iFINDER is a true pocket-sized, full-featured mapping GPS receiver.

Our goal for this book is to get you on the road or out to the woods and

water fast, with a minimum of fuss. Like you, we'd rather spend more

time traveling, and less time reading the manual! In the following

pages you can find instructions on how to use all of the iFINDER's

basic functions.

NOTE:

For the power users out there, the iFINDER Go also has an

Advanced Mode, which allows you an even greater degree of control

over your device's settings. For details on Advanced Mode

Operation, look for the iFINDER Go Advanced User's Guide on our

web site, www.lowrance.com.

If you would like to know more about GPS and its companion system

WAAS, visit our web site and check out the GPS Product Guide section

(www.lowrance.com/Support/gps.asp). It includes a GPS tutorial,

frequently asked questions and a glossary.

Batteries

The unit requires two 1.5-volt AA batteries. Do not mix different

battery types. Mixing battery types may cause leakage.

The following page contains an 11-step quick reference for Easy Mode

operation. If you don't want to carry the manual with you as you

practice with iFINDER, you might consider photocopying this quick

reference page and tucking it into your pocket.

offered by www.Busse-Yachtshop.de email: [email protected] Tel: +49 (0)4347 908234

iFINDER Easy Mode Quick Reference

1. Install two AA batteries in the battery compartment on back of case.

2. To turn on iFINDER, press and release PWR key.

3. Opening screen displays map of North America at the 4,000 mile

zoom range. Rotate through the three main Page screens (Map Page,

Satellite Status Page, Navigation Page) by repeatedly pressing PAGES

key. Switch Pages to display Satellite Status Page.

4. Wait while unit locates satellites and calculates current position. Process

is visible on Satellite page. This takes an average of 1 minute or less under

clear sky conditions (unobstructed by terrain or structures). When the unit

acquires position, a position acquired message appears.

5. With position acquired, press PAGES key to display Map Page, which

shows a bird's eye view of the earth. You can move around the map by:

Zoom in closer to see greater detail: press ZIN (zoom in key.)

Zoom out to see more area, less detail: press ZOUT (zoom out key.)

Scroll map north, south, east or west using arrow keys ↑↓→←.

To stop scrolling and return to current position on map, press EXIT key.

6. Set Home waypoint at your current position so you can navigate back

here: press ENT|ENT.

7. Zoom/scroll map to find a nearby object or location. Use arrow keys to

center cursor cross-hair over the map object or location.

8. To navigate to the selected location: press MENU|ENT|EXIT. Follow

steering arrow on Map Page or compass bearing arrow on Navigation Page.

9. At destination, Arrival Alarm goes off; to clear it, press EXIT. Cancel

navigation: press MENU|↓to CANCEL NAVIGATION|ENT|←to YES|ENT.

10. Navigate back home by Go To Home or Navigate Trail. Go Home:

press FIND|ENT; follow navigation arrows. Trail: press MENU|↓to

NAVIGATE TRAIL|ENT. Wait while route is calculated, then follow arrows.

11. Back home, Arrival Alarm goes off; press EXIT. Cancel navigation:

press MENU|↓to CANCEL NAVIGATION|ENT|←to YES|ENT.

offered by www.Busse-Yachtshop.de email: [email protected] Tel: +49 (0)4347 908234

Easy Mode Operation

This section addresses Easy Mode operation for iFINDER's main GPS

functions. The principles are the same in both operating modes, so this

discussion also serves as a good introduction to Advanced Mode work.

The iFINDER Keypad

You'll control the iFINDER Go with its keyboard, which includes:

PWR/LIGHT (Power & Light) – The PWR key turns the unit on and off

and activates the backlight. Turn off the unit by pressing and holding

the PWR key for 3 seconds.

PAGES – Pressing this key switches the unit between the three

different page screens in Easy Mode. (Satellite, Navigation and Map.)

Each page represents one of the unit's major operation modes.

MENU – Press this key to show the menus, which allow you to select or

adjust a feature from a list.

ARROW KEYS – These keys are used to navigate through the menus,

make menu selections, move the map cursor and enter data.

ENT/SAVE (Enter & Save) – This key allows you to save data, accept

values or execute menu commands.

EXIT – The Exit key lets you return to the previous screen and clear

data or close menus.

FIND – The Find key launches the iFINDER search menus.

ZOUT and ZIN – (Zoom Out and Zoom In) – These keys let you zoom

the screen in or out to see either a larger geographic area on the map,

or greater detail in a smaller map area. You can press ZOUT and ZIN at

the same time to create a Man Overboard waypoint at your current

location and begin navigating back to it.

Main Menu

Easy Mode has a single Main Menu, which contains the commands you'll

use to operate your iFINDER. Some important Main Menu commands

and their functions are:

offered by www.Busse-Yachtshop.de email: [email protected] Tel: +49 (0)4347 908234

Screen command: changes the contrast or brightness of the display.

Software Info command: shows the product name and software version

of the unit's operating system software, as well as copyright notices.

Advanced Mode command: used to switch to Advanced Mode operation.

Pages

Easy Mode has three Page displays that represent the three major

operating modes. They are the Satellite Status Page, the Navigation

Page and the Map Page. They are accessed by pressing the PAGES key,

which cycles among them.

Navigation Page

This Page has a compass rose. It shows your direction of travel and the

direction to a recalled waypoint. The navigation screen looks like the

one in the following image when you're not navigating to a waypoint or

other destination. Your position is shown by an arrow in the center of

the screen. Your trail history, or path you've taken, is depicted by the

line extending from the arrow.

The Navigation Page looks like this when iFINDER is not navigating.

When navigating to a waypoint or following a route, the Navigation

screen looks like the one shown in the following image.

Compass

rose

Navigation

information

display

Present position

arrow

Trail line

offered by www.Busse-Yachtshop.de email: [email protected] Tel: +49 (0)4347 908234

Navigation Page, backtracking a trail.

Satellite Status Page

This Page, shown in the following images, provides detailed

information on the status of iFINDER's satellite lock-on and position

acquisition. To get to the Satellite Status Page: press PAGES repeatedly

until the page you want appears.

This page shows you the quality and accuracy of the current satellite

lock-on and position calculation.

Satellite Page shown at left with no position and no satellites, in center

with satellites acquired (but no lock), and at right with a 3D position lock.

Waypoint

symbol

Bearing

arrow

Trail line

Current track or

heading, shown

in degrees

Compass bearing

to destination

Navigation

information

display

Destination

name

offered by www.Busse-Yachtshop.de email: [email protected] Tel: +49 (0)4347 908234

WARNING:

Do not begin navigating with this unit until the numbers

have stopped flashing! On any display page, a flashing

current position indicator/question mark symbol and

flashing GPS data displays indicate that satellite lock has

been lost and there is no position confirmed.

Map Page

The map screens show your course and track from a "bird's-eye" view.

By default, this unit shows the map with north always at the top of the

screen. If you're navigating to a waypoint, the map also shows your

starting location, present position, course line and destination.

Using the map is as simple as pressing the PAGES key. A screen similar

to those in the following images appears. The arrow flashing in the

center of the screen is your present position. It points in the direction

you're traveling. The solid line extending from the arrow is your plot

trail, or path you've taken.

Map Page screen and various zoom levels.

Use the Zoom In and Zoom Out keys to enlarge or reduce the map's

coverage area and the amount of mapping detail shown.

The map data loaded in your iFINDER Go contains a low-detail world

map and a medium detail USA map. The Go2 model contains the same

maps plus high detail USA lake, river and coastal shoreline data.

offered by www.Busse-Yachtshop.de email: [email protected] Tel: +49 (0)4347 908234

The low-detail world map contains some large cities and most country

political boundaries. The medium-detail U.S. map contains: all

incorporated cities; shaded metropolitan areas; county boundaries;

some major city streets; Interstate, U.S. and state highways; lakes and

streams and more than 60,000 navigation aids and 10,000 wrecks and

obstructions in U.S. coastal and Great Lakes waters. The map also

contains exit services information for Interstate highways.

The iFINDER Go2 International contains a worldwide reference map

with basic coverage of country political boundaries, major lakes, rivers

and coastal waters, plus key cities, and major and minor highways.

Moving Around the Map: Zoom & Cursor Arrow Keys

The map is presented from a bird's eye view perspective. The current

zoom range shows in the lower left corner of the screen.

1. Press the ZIN key (zoom in) to move in closer and see greater detail in a

smaller geographic area.

2. Press the ZOUT key (zoom out) to move farther away and see less map

detail, but a larger geographic area.

When you are walking or riding in a vehicle, the map will automatically

move as you move. This keeps your current location roughly centered

on the screen.

You can manually pan or scroll the map northward, southward,

eastward or westward by using the arrow keys, which launches the

cross-hair map cursor. This allows you to look at map places other than

your current position. To clear the cursor, press EXIT, which jumps the

map back to the current position or the last known position.

Selecting Any Map Item with the Cursor

1. Use the zoom keys and the arrow keys to move around the map and

find the item you wish to select.

2. Use the arrow keys and center the cursor cross-hair on the desired

object. On most items, a pop-up box will give the name of the selected item.

You will also notice a black ring surrounds the item as it becomes

offered by www.Busse-Yachtshop.de email: [email protected] Tel: +49 (0)4347 908234

selected. Once that happens, if you press FIND the Find Menu will pop

up with an extra option at the top of the list: SELECTED ITEM. Press ENT to

see the Waypoint Information screen for the selected item.

Set Home Waypoint

A waypoint is simply an electronic "address," based on the latitude and

longitude of a position on the earth. Easy Mode allows you to save two

waypoints (Home and Man Overboard). To save a Home Waypoint: 1.

Press and release ENT. 2. The SAVE AS HOME WAYPOINT?menu appears,

with YES highlighted. To accept yes, press ENT. The waypoint appears

on the map as an X, named "Home."

Save Home Waypoint menu, left. At right, Home waypoint, with X

symbol and name. When selected by the cursor, the pop-up box appears.

The example shows waypoint set at the cursor location. If cursor was

not active, the point would be placed at the current position.

Caution:

Saving a new "Home" waypoint will overwrite and erase the

previous "Home" waypoint.

Navigate Back Home

This command will automatically take you back to the "Home"

waypoint you created.

1. Press FIND|ENT; then follow navigation arrows on the Map Page or

the compass rose on the Navigation Page.

To stop navigating to the waypoint, use the Cancel Navigation command.

Pop-up box

offered by www.Busse-Yachtshop.de email: [email protected] Tel: +49 (0)4347 908234

Altri manuali per iFINDER GO

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Lowrance GPS

Lowrance

Lowrance Lowrance IWAY 350C Manuale di istruzioni

Lowrance

Lowrance GlobalMap 3000MT Manuale di istruzioni

Lowrance

Lowrance M52i S/GPS Manuale utente

Lowrance

Lowrance HDS Gen2 Touch Manuale utente

Lowrance

Lowrance iFINDER Manuale utente

Lowrance

Lowrance Lowrance IWAY 350C Manuale utente

Lowrance

Lowrance GlobalMap 4000M Dimensioni

Lowrance

Lowrance GlobalMap 5150C Manuale utente

Lowrance

Lowrance XOG Manuale utente

Lowrance

Lowrance StructureMap HDS Gen 2 Manuale utente

Lowrance

Lowrance GlobalMap Baja 840C Manuale utente

Lowrance

Lowrance iWAY 250C Manuale utente

Lowrance

Lowrance GlobalMap Sport Manuale utente

Lowrance

Lowrance GlobalMap 4000M Manuale utente

Lowrance

Lowrance GlobalNav 212 Manuale utente

Lowrance

Lowrance Lowrance iWAY 500C Guida rapida

Lowrance

Lowrance GlobalMap 5200C Manuale utente

Lowrance

Lowrance LMS-334c iGPS Manuale utente

Lowrance

Lowrance AirMap 300 Manuale utente

Lowrance

Lowrance LCX-104C Manuale utente

Lowrance

Lowrance GlobalMap 4000M Manuale utente

Lowrance

Lowrance iFINDER PhD Manuale utente

Lowrance

Lowrance Endura Out&Back Manuale utente

Lowrance

Lowrance GlobalNav GlobalNav Manuale utente

Manuali GPS popolari di altre marche

Raven

Raven Cruizer II Manuale

Hama

Hama 53118 Manuale utente

Garmin

Garmin SOUNDER 125 Manuale utente

Garmin

Garmin DEZL 580 Manuale utente

Jigabot

Jigabot EX Manuale utente

Pointer

Pointer Cellocator CelloTrack XT LTE Guida all'installazione

Queclink

Queclink GV55LITE Manuale utente

Voxson

Voxson Voxtrack GPS500 Manuale di istruzioni

Garmin

Garmin ECHOMAP PLUS Manuale utente

Starcom Systems

Starcom Systems Kylos Compact Manuale utente

Garmin

Garmin 15 H Series Manuale utente

Cobra

Cobra Marine MC 600Ci Manuale utente

Cellocator

Cellocator CelloTrack T Manuale utente

Enfora

Enfora Mini-MT GSM2228UG001 Manuale utente

Magellan

Magellan eXplorist 100 Manuale utente

LTE

LTE G50B Manuale utente

Garmin

Garmin DEZL OTR500 Manuale utente

SkyGolf

SkyGolf SkyCaddie SG1 Manuale utente

Lowrance iFINDER GO Manuale utente

Manuali GPS popolari di altre marche
