Mac allister MPRM 46HP Manuale utente

Lawn mower

171503990/0

148 cc Pedestrian

MPRM 46HP - MPRM 46SP

Barcode: 8008984511316 - 8008984511415

Pedestrian lawn mower

Assembly

Montaggio

GB-IE

Pedestrian controlled lawnmower

MPRM 46HP / 46SP

Rasaerba con operatore a piedi

MPRM 46HP / 46SP

Istruzioni originali

Translation of the original instructions

Let’s

get started...

These instructions are for your safety. Please read through them thoroughly

before use and retain them for future reference.

Getting started... 5

Identiﬁcation 6

Controls 7

Safety 8

In more detail... 11

Grass cutting 12

Routine Maintenance 14

Troubleshooting 15

Environmental protection 16

Technical speciﬁcations 17

Warranty 18

Assembly 35

MPRM 46HP / 46SP by MacAllister

Getting

started...

Identiﬁcation 6

Controls 6-7

Training 8

Preliminary Operations 8

During Use 9

Maintenance and Storage 10

Transportation and Handling 10

Getting started...

MPRM 46HP / 46SP by MacAllister

Identiﬁcation

10. Identiﬁcation Label 11. Chassis 12. Engine 13. Blade (Blade) 14. Stone-guard 15. Grass-catcher

16. Handle 17. Throttle control 18. Engine brake lever 19. Drive engagement lever

Symbols

SAFETY REQUIREMENTS -Your lawnmower must be used carefully.

Symbols have therefore been placed on various parts of the machine

to remind you of the main precautions to be taken. Their meaning is

explained below.You are also asked to carefully read the safety regu-

lations in the speciﬁc chapter of this manual.

41. Warning: Read the instruction manual before using the machine.

42. Risk of thrown objects. Keep all persons away from the work area

whilst mowing.

43. Danger of cutting yourself. Moving blades. Do not put hands or

feet near or under the opening of the blade housing. Disconnect

the spark plug cap and read the instructions before carrying out

any maintenance or repairs.

44. Only for lawnmowers with electric motor.

45. Only for lawnmowers with electric motor.

Symbols on the controls

21. Slow 22. Fast 23. Choke

24. Engine stop 25. Drive on

Acoustic power level according to

directive 2000/14/EC

Article Code

Machine model

Manufacturer’s model of reference

Motor power and speed

Mass in kilograms

Machine use

European article code

Year of manufacture

Serial number

Name and address of Manufacturer

Conformity marking according to

directive 2006/42/EC

10.1

10.2

10.3

10.4

10.5

10.6

10.7

10.8

10.9

10.10

10.11

10.12

11 13 12

14 15

18 19

10.2 10.110.3

10.1210.9 10.1110.10

10.510.6 10.4

10.710.8

Identiﬁcation

MPRM 46HP / 46SP by MacAllister

Getting started...

[1] Throttle control

The throttle is controlled by the lever (1).

Lever positions are indicated on the relevant plate.

Some models have a ﬁxed speed with no need for a throttle.

[2] Blade brake lever

The blade brake is controlled by the lever (1) which must be held against the handle for

ignition and during lawnmower operations.

The engine stops when the lever is released.

[3] Drive engagement lever (only for Mod. MPRM 46SP)

On power-driven models, push the lever (1) toward the handle for forward movement.

The lawnmower stops moving forward when the lever is released.

[4] Cutting height adjustment

The cutting height is adjusted by the levers (1).

The four wheels must be adjusted to the same height.

DO THIS WHEN THE BLADE IS STOPPED.

Controls

[1]

[3]

[2]

[4]

Controls

Getting started...

MPRM 46HP / 46SP by MacAllister

Training

Preliminary operations

1) Read the instructions carefully. Become familiar with the controls and the proper use

of the lawnmower. Learn how to stop the engine quickly.

2) Only use the lawnmower for the purpose for which it was designed, namely mowing and

collecting grass. Any other usage may be hazardous and harm persons and/or damage

things. Examples of improper use may include, but are not limited to:

– transporting persons, children or animals on the machine;

– letting oneself be transported by the machine;

– using the machine to tow or push loads;

– using the machine for leaf or debris collection;

– using the machine to trim hedges, or for cutting vegetation other than grass;

– use of the machine by more than one person;

– using the blades on surfaces other than grass.

3 Never allow children or persons unfamiliar with these instructions to use the lawnmower.

Local regulations can restrict the minimum age of the operator.

4) Never use the lawnmower:

– when people, especially children or pets are nearby;

– if the operator has taken medicine or substances that may impair his ability to react and

be attentive.

5) Bear in mind that the operator or user is responsible for accidents or unexpected events

occurring to other people or their property.

1) While mowing, always wear sturdy footwear and long trousers. Do not operate the lawn-

mower when barefoot or wearing open sandals.

2) Thoroughly inspect the entire work area and remove anything that could be thrown by the

machine or damage the cutting unit or engine (stones, branches, iron wire, bones, etc.).

3) WARNING: DANGER! Petrol is highly ﬂammable.

– store the fuel in suitable containers;

– add fuel using a funnel, only outdoors; never smoke while doing this and whenever fuel

is handled;

– add petrol before starting the engine; never add petrol or remove the petrol tank cap

while the engine is running or when it is hot;

– if you have spilt some fuel, do not attempt to start the engine but move the lawnmower

away from the area of spillage to avoid creating any source of ignition until the fuel has

evaporated and fuel vapours have dissipated.

– always put the tank and fuel container caps back on and tighten well;

4) Replace faulty silencers

5) Before use, always inspect generally and in particular to see that the blade, screws and

cutting unit are not worn or damaged. Replace damaged or worn blades and screws to

preserve balance.

6) Before starting work, ﬁt the exit guards (grass-catcher or stone-guard).

Safety

MPRM 46HP / 46SP by MacAllister

Getting started...

1) Do not operate the engine in a conﬁned space where dangerous carbon monoxide fumes

can develop.

2) Mow only in daylight or good artiﬁcial light.

3) If possible, avoid mowing wet grass.

4) Make sure you have a steady foothold on slopes.

5) Never run, always walk; do not let the lawnmower pull you.

6) Always mow transversely on slopes and never up and down.

7) Be extremely carefully when changing directions on slopes.

8) Do not mow on land that slopes more than 20°.

9) Be extremely careful when pull the lawnmower toward you.

10) Immobilise the blade if the lawnmower must be inclined for transport, when moving over

surfaces other than grass and when the lawnmower is transported from or to an area that

must be cut.

11) Never operate the lawnmower with damaged guards or without the grass-catcher or

stone-guard.

12) Do not change the engine settings or overspeed the engine.

13) On power-driven models, disengage wheel drive before starting up the engine.

14) Start up the engine carefully according to the instructions, keeping feet away from the

blade.

15) Do not incline the lawnmower for start up. Start up the machine on a ﬂat surface without

obstacles or high grass.

16) Never place your hands and feet near or under rotating parts. Always keep away from the

discharge opening.

17) Do not lift or transport the lawnmower when the engine is running.

18) Stop the engine and disconnect the spark plug cable:

– before making any adjustments under the cutting deck or before unclogging the chute:

– before checking, cleaning or working on the lawnmower;

– after striking a foreign object. Inspect the machine for any damage to the lawnmower

and make the necessary repairs before using it again;

– if the lawnmower begins to vibrate abnormally (Immediately look for the cause of the

vibrations and take it to a Specialised Centre for necessary inspections).

19) Stop the engine:

– whenever you leave the lawnmower unattended. Also remove the key on models with

electric start up;

– before refuelling;

– whenever you remove or reattach the grass-catcher;

– before adjusting the cutting height.

20) Reduce the throttle setting before stopping the engine. Shut oﬀ the fuel supply when

mowing is done, following the instructions in the engine manual.

21) When mowing, always keep a safe distance from the rotary blades, given by the length of

the handle.

During use

Safety

Getting started...

MPRM 46HP / 46SP by MacAllister

Maintenance and storage

Transportation and handling

1) Keep all nuts and screws tight to be sure the equipment is in safe working condition. Rou-

tine maintenance is essential for safety and for maintaining a high performance level.

2) Do not store the lawnmower with fuel in the tank in an area where fuel vapours could

reach an open ﬂame, a spark or a strong heat source.

3) Allow the engine to cool before storing the lawnmower in any enclosure.

4) To reduce ﬁre hazards, keep the engine, silencer, battery compartment and petrol stor-

age area free of grass, leaves, or excessive grease.Never leave containers with cut grass

inside a storage area.

5) Check the stone-guard and grass-catcher frequently for wear or deterioration.

6) If the fuel tank has to be emptied, this should be done outdoors once the engine has

cooled down.

7) Wear work gloves for disassembling and reassembling blades.

8) Keep the blade balanced during sharpening. All work on the blade (disassembly, sharp-

ening, balancing, reassembly and/or replacing) are demanding jobs that require special

skill as well as special tools. For safety reasons, these jobs are best carried out at a spe-

cialized centre.

9) For safety reasons, never use the machine when it has worn or damaged parts. Parts

must be replaced and not repaired. Use original spare parts.Parts that are not of the same

quality can damage the equipment and impair your safety.

1) Whenever the machine is to be handled, lifted, transported or tilted you must:

– wear sturdy work gloves;

– grasp the machine at the points that oﬀer a safe grip, taking account of the weight and

its distribution;

– use an appropriate number of people for the weight of the machine and the character-

istics of the vehicle or the place where it must be placed or collected.

2) During transport, fasten the machine securely with cables or chains.

Safety

MPRM 46HP / 46SP by MacAllister

Getting started...

Altri manuali per MPRM 46HP

Questo manuale è adatto per i seguenti modelli

Indice

Lingue:

Altri manuali Mac allister Taglia erba

Mac allister

Mac allister MLMP575SP46 Manuale utente

Mac allister

Mac allister Solo MLM3641-Li Manuale utente

Mac allister

Mac allister MLMP300HP46 Manuale utente

Mac allister

Mac allister MLMP475iSSP46-M&S-2 Manuale utente

Mac allister

Mac allister MPRM 42SP Manuale utente

Mac allister

Mac allister MLM1841 Manuale utente

Mac allister

Mac allister MLM1334 Manuale utente

Mac allister

Mac allister SOLO MLM1834-Li Manuale utente

Mac allister

Mac allister SOLO MLM3637-Li Manuale di istruzioni

Mac allister

Mac allister MLMP170H51 Manuale utente

Mac allister

Mac allister MLMP300H40 Manuale utente

Mac allister

Mac allister Titan TTK550LWM Manuale utente

Mac allister

Mac allister MLMP450HP40 Manuale utente

Mac allister

Mac allister MLM1737 Manuale utente

Mac allister

Mac allister MPRM 46HP Manuale utente

Mac allister

Mac allister MAC1700RMA Manuale di installazione

Manuali Taglia erba popolari di altre marche

RHINO

RHINO 1958 Manuale utente

Wolf Garten

Wolf Garten Compact plus 40 B Manuale utente

Cub Cadet

Cub Cadet LTX 1045 Manuale utente

Craftsman

Craftsman 917.378461 Manuale utente

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Manuale utente

Challenge

Challenge CH18V2 Istruzioni operative

TALEN TOOLS

TALEN TOOLS AVR HGM30 Manuale utente

DEWEZE

DEWEZE ATM-725 Manuale operativo

Weed Eater

Weed Eater 180083 Manuale utente

Husqvarna

Husqvarna Poulan Pro PP185A42 Manuale utente

Better Outdoor Products

Better Outdoor Products Quick Series Manuale utente

Cub Cadet

Cub Cadet 23HP Z-Force 60 Manuale operativo

MTD

MTD 795, 792, 791, 790 Manuale utente

Toro

Toro Groundsmaster 3505-D Manuale utente

Dennis

Dennis FT 610 Manuale utente

AIRFORCE

AIRFORCE F-15 Gen 3 Manuale utente

MTD

MTD 126-220-000 Manuale utente

Toro

Toro 74806 Manuale utente
