This infrared printer allows test results to be printed at a distance up to
15 feet.
P9300 Infrared Printer
Instruction Manual
2650-1354-00
Mac Tools Inc.
505 N. Cleveland Ave.
Suite 200
Westerville, OH 43082
Phone: 1-800-MAC-TOOLS or 1-800-622-8665
Fax: 1-800-MAC-FAX5 or 1-800-622-3295
For Service Please Contact:
Auto Meter Products, Inc.
413 West Elm Street
Sycamore, IL 60178
Phone: 866-883-8378
Fax: 815-895-6786
test_service@autometer.com
2
3
1. Plug the AC adapter
in and turn the power
switch on The Red and
Green LED will light up.
2. Point the I/R receiver
that is on the front of the
printer, in the direction of the
vehicle or tester being used.
3. Perform the test using your
MAC Tools hand-held tester.
4. When the test is complete,
point the tester in the general
direction of the P9300 Infrared
Printer. Press the print key on
the tester panel. The test
number and results indicated
on the tester LCD will print
out on the P9300 printer.
5. To feed the paper manually,
Press the LF(Line Feed)
button to start feeding the
paper.(Green LED will go of
during line feed.) Press the LF
button again to stop feeding.
(Green LED will come back
on.) Printer will automatically
stop the feed in 10 seconds if
the LF button is not pressed
You are now ready to print.
OPERATION
CONGRATULATIONS
NOTE:
If the infrared receiver on the printer is exposed to
direct sunlight, the printer may not function properly.
Turn the printer so that the infrared receiver is not
exposed to direct sunlight and reduce the printing
distance from hand held testers.
PAPER INSTALLATION
Standard Thermal Paper Roll - (58 mm) Available from any ofce supply
AC Adapter - (120 VAC Output 7.5 VDC)
Printer Dimensions - 4.5” W 5.75” D 3.25” H
You have chosen the P9300 printer designed for use with BSA200 and BSA300
handheld testers. If you should have any questions about this product please
refer to the contact information on the back cover of this manual.
1. Open cover by placing
hands on both sides of
the cover and ipping up
on the nger tabs.
2. Drop in thermal paper roll
(as shown). Pull paper out
3” past the cover lid and
hold.
3. Close lid by pushing on
both sides of the printer
cover at the lid tabs until
you hear a snap. Paper is
loaded and ready to use.
NOTE: SEL button has no function.
