MAJORITY LNG-DAB-BLK Manuale utente

User Guide

Majority Longstanton

DAB / DAB+ / FM Radio

LNG-DAB-BLK

Contents

Controls and Functions .............................................................

What’s in the box? .........................................................................

Instruction Guide ..........................................................................

Basic Operation .............................................................................

DAB Radio ........................................................................................

Set Up of the DAB Radio Preset Stations .........................

FM Radio ...........................................................................................

Set Up of the FM Radio Preset Stations ............................

Station information for DAB and FM Radio ....................

Clock and Date Setting .............................................................

Dual Alarm Setting and Alarm Snooze .............................

Other Functions .............................................................................

Technical Specications ...........................................................

Warranty .............................................................................................

Trouble Shooting Guide............................................................

Important Safety Information .............................................

Controls and Funcons

Top View

1. Standby/Mode

2. Info/Menu

3. Preset

4. Previous

5. Enter/Scan

6. Next

7. Alarm

8. Sleep

9. Snooze

10. Dimmer

11. Volume-

12. Volume+

Controls and Funcons

Back View

13. Antenna

14. Headphone Input

17. Display Screen

15. DC 5V In

16. USB Output

Front View

What’s in the box?

Majority Longstanton DAB / DAB+ /FM Radio

Clock UK Standard Plug DC5V 2A Power Supply

User Guide

Please note all (Ref.) refer to Page 1 Controls and Functions mapping guide.

Basic Operaon

Plug the connector into the back of the system labelled DC 5V

(Ref.15) and the power supply into the mains.

Ensure the antenna (Ref.13) is extended as far as possible so

that you can rotate it. This will enable you to get the best signal

possible.

Press the ‘Standby/Mode’ button to turn on the unit (Ref.1). It

will automatically take you to DAB radio mode or to the previous

mode that you were using. When DAB Radio is activated for the

rst time it will automatically start scanning and storing all

stations that have a good signal. If scanning does not

automatically start, press and hold the ‘Enter/Scan’ button

(Ref.5). To scroll through the stations use the ‘Previous’ or ‘Next’

buttons (Ref.4/6). Press the ‘Enter/Scan’ buttons (Ref.5) to listen

to a station.

To change the mode, press the ‘Standby/Mode’ button (Ref.1).

This will switch between DAB Radio, FM Radio.

Standby

To place the music system in standby, press the ‘Standby/Mode’

button (Ref.1). To turn o fully, press and hold the ‘Standby/

Mode’ button (Ref.1) and switch o at the mains. The cord must

be out of reach of children.

Instrucons Guide

DAB / DAB+ Radio

Press the ‘Standy/Mode’ button (Ref.1) to switch to DAB Radio.

On rst use it will automatically scan all stations and save them.

Fully extend the antenna (Ref.13).

To auto scan, press and hold the ‘Enter/Scan’ button (Ref.5) and

then release. This will start scanning up the frequency band and

store all stations that have good signal.

The radio will automatically save all the stations with a strong

signal, up to 240 MHz. After searching has nished it will

automatically play the rst station stored.

To listen to all stations that have been stored use the ‘Previous’

and ‘Next’ buttons (Ref.4/6) to scroll through. Press the‘Enter/

Scan’ button (Ref.5) when on the required station.

The radio will display station information when you press the

‘Info/Menu’ button (Ref.2). Press multiple times to view all

information available (See page 10).

When you turn the radio on again after it switching o, it will

automatically tune to the same station (DAB or FM) that was

last selected.

In DAB mode, the radio will synchronize with the time and date

of the station.

Instrucons Guide

How to store a preset station

Up to 10 stations can be set.

To store a station that you are currently playing:

Press and hold ‘Preset’ button (Ref.3). “<1: (Empty)” will show on

the display.

Use the ‘Previous’ or ‘Next’ buttons (Ref.4/6) to change the “<1”

to the number you want to store the station as. Then press the

‘Enter/Scan’ button (Ref.5) to save. The display will then show

“Preset [1] stored”.

How to play a preset radio station

Press the ‘Preset’ button (Ref.3).

Use the ‘Previous’ or ‘Next’ buttons (Ref.4/6) to scroll through

your preset stations. You can store up to 10.

Press ‘Enter/Scan’ button (Ref.5) to select your choice.

Instrucons Guide

FM Radio

Press the ‘Stanby/Mode’ button (Ref.1) multiple times to switch

between DAB and FM. The rst time you do this, the FM

frequency “87.5 MHz” will be displayed on the screen.

Fully extend the antenna (Ref.13).

To auto scan, press and hold then release the ‘Next’ button

(Ref.6). This will start scanning up the frequency band and play

the rst station it nds with a strong signal.

To scan down the frequency band, press and hold the ‘Previous’

button (Ref.4) for a few seconds.

The radio will display station information when you press the

‘Info/Menu’ button (Ref.2). Press multiple times to view all

information available (See page 11).

FM Scan Setting

Choose between scanning strong and weak signals (All) or only

the strong stations (Only).

Press and hold the ‘Info/Menu’ button (Ref.2). To make your

choice, use the ‘Previous’ or ‘Next’ buttons (Ref.4/6) to choose

your option.

Select “FM Scan Set” and press the ‘Enter/Scan’ button (Ref.5).

Use the ‘Previous’ or ‘Next’ button (Ref.4/6) to choose between

“All” or “Only”. Press the ‘Enter/Scan’ button (Ref.5) to conrm

your choice. 7

To tune a specic frequency manually

To listen to a specic frequency use the ‘Previous’ or ‘Next’

buttons (Ref.4/6) to search forward or back.

Mono and Stereo

In working mode, press the ‘Enter/Scan’ button (Ref.5), press

mutiple times to switch between‘Set to Mono’ or ‘Set to Stereo.

Instrucons Guide
