7ENGLISH

ENGLISH (Original instructions)

SPECIFICATIONS

Model: DBO480 DBO481 DBO482

Pad size Square pad 112 mm x 102 mm

Triangular pad 112 mm x 190 mm

Rectangular pad 112 mm x 168.5 mm

Abrasive paper For square pad (Hook and loop) 114 mm x 102 mm

For square pad (Clamp) 114 mm x 140 mm

For triangular pad Rectangular paper: 114 mm x 102 mm

Triangular paper: 96 mm

For rectangular pad 112 mm x 168.5 mm, 112 mm x 66 mm

Orbits per minute High 14,000 min-1

Low 11,000 min-1

Overall length (with BL1860B) 171 mm

Rated voltage D.C. 18 V

Net weight 1.4 - 1.7 kg 1.4 - 1.8 kg

* Thestandardpaddi󰀨ersfromcountrytocountry.

• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange

without notice.

• Specicationsandbatterycartridgemaydi󰀨erfromcountrytocountry.

• Theweightmaydi󰀨erdependingontheattachment(s),includingthebatterycartridge.Thelightestandheavi-

est combinations, according to EPTA-Procedure 01/2014, are shown in the table.

Applicable battery cartridge and charger

Batterycartridge BL1815N / BL1820B / BL1830B / BL1840B / BL1850B / BL1860B

Charger DC18RC / DC18RD / DC18RE / DC18SD / DC18SE / DC18SF /

DC18SH

• Someofthebatterycartridgesandchargerslistedabovemaynotbeavailabledependingonyourregionof

residence.

WARNING: Only use the battery cartridges and chargers listed above.Useofanyotherbatterycartridges

andchargersmaycauseinjuryand/orre.

Intended use

Thetoolisintendedforthesandingoflargesurfaceof

wood, plastic and metal materials as well as painted

surfaces.

Noise

ThetypicalA-weightednoiseleveldeterminedaccord-

ing to EN62841-2-4:

Model DBO480

Sound pressure level (LpA) : 75 dB(A)

Uncertainty(K):3dB(A)

Model DBO481

Sound pressure level (LpA) : 75 dB(A)

Uncertainty(K):3dB(A)

Model DBO482

Sound pressure level (LpA) : 75 dB(A)

Uncertainty(K):3dB(A)

Thenoiselevelunderworkingmayexceed80dB(A).

NOTE: The declared noise emission value(s) has

been measured in accordance with a standard test

methodandmaybeusedforcomparingonetoolwith

another.

NOTE: The declared noise emission value(s)

mayalsobeusedinapreliminaryassessmentof

exposure.

WARNING: Wear ear protection.

WARNING: The noise emission during actual

use of the power tool can di󰀨er from the declared

value(s) depending on the ways in which the

tool is used especially what kind of workpiece is

processed.

WARNING: Be sure to identify safety mea-

sures to protect the operator that are based on an

estimation of exposure in the actual conditions of

use (taking account of all parts of the operating

cycle such as the times when the tool is switched

o󰀨 and when it is running idle in addition to the

trigger time).

8ENGLISH

Vibration

The vibration total value (tri-axial vector sum) deter-

mined according to EN62841-2-4:

Model DBO480

Work mode: sanding metal plate (square base)

Vibration emission (ah) : 2.5 m/s2or less

Uncertainty(K):1.5m/s2

Work mode: sanding metal plate (louver base)

Vibration emission (ah) : 4.1 m/s2

Uncertainty(K):1.5m/s2

Model DBO481

Work mode: sanding metal plate (square base)

Vibration emission (ah) : 2.5 m/s2or less

Uncertainty(K):1.5m/s2

Model DBO482

Work mode: sanding metal plate (square base)

Vibration emission (ah) : 3.4 m/s2

Uncertainty(K):1.5m/s2

NOTE: The declared vibration total value(s) has been

measured in accordance with a standard test method

andmaybeusedforcomparingonetoolwithanother.

NOTE:Thedeclaredvibrationtotalvalue(s)mayalso

beusedinapreliminaryassessmentofexposure.

WARNING: The vibration emission during

actual use of the power tool can di󰀨er from the

declared value(s) depending on the ways in which

the tool is used especially what kind of workpiece

is processed.

WARNING: Be sure to identify safety mea-

sures to protect the operator that are based on an

estimation of exposure in the actual conditions of

use (taking account of all parts of the operating

cycle such as the times when the tool is switched

o󰀨 and when it is running idle in addition to the

trigger time).

EC Declaration of Conformity

For European countries only

TheECdeclarationofconformityisincludedasAnnexA

to this instruction manual.

SAFETY WARNINGS

General power tool safety warnings

WARNING: Read all safety warnings, instruc-

tions, illustrations and specications provided

with this power tool.Failuretofollowallinstructions

listedbelowmayresultinelectricshock,reand/or

seriousinjury.

Save all warnings and instruc-

tions for future reference.

Theterm"powertool"inthewarningsreferstoyour

mains-operated(corded)powertoolorbattery-operated

(cordless) power tool.

Sander safety warnings

1. Always use safety glasses or goggles.

Ordinary eye or sun glasses are NOT safety

glasses.

2. Hold the tool rmly.

3. Do not leave the tool running. Operate the tool

only when hand-held.

4. This tool has not been waterproofed, so do not

use water on the workpiece surface.

5. Ventilate your work area adequately when you

perform sanding operations.

6. Some material contains chemicals which may

be toxic. Take caution to prevent dust inhala-

tion and skin contact. Follow material supplier

safety data.

7. Use of this tool to sand some products, paints

and wood could expose user to dust contain-

ing hazardous substances. Use appropriate

respiratory protection.

8. Be sure that there are no cracks or breakage

on the pad before use. Cracks or breakage

may cause a personal injury.

9. Watch your footing and maintain your balance

with the tool. Make sure there is no one below

when working in high locations.

SAVE THESE INSTRUCTIONS.

WARNING: DO NOT let comfort or familiarity

with product (gained from repeated use) replace

strict adherence to safety rules for the subject

product. MISUSE or failure to follow the safety

rules stated in this instruction manual may cause

serious personal injury.

Important safety instructions for

battery cartridge

Before using battery cartridge, read all instruc-

tions and cautionary markings on (1) battery

charger, (2) battery, and (3) product using battery.

2. Do not disassemble or tamper with the battery

cartridge.Itmayresultinare,excessiveheat,

or explosion.

3. If operating time has become excessively

shorter, stop operating immediately. It may

result in a risk of overheating, possible burns

and even an explosion.

4. If electrolyte gets into your eyes, rinse them

out with clear water and seek medical atten-

tion right away. It may result in loss of your

eyesight.

5. Do not short the battery cartridge:

(1) Do not touch the terminals with any con-

ductive material.

(2) Avoid storing battery cartridge in a con-

tainer with other metal objects such as

nails, coins, etc.

(3) Do not expose battery cartridge to water

or rain.

A battery short can cause a large current

ow, overheating, possible burns and even a

breakdown.

9ENGLISH

6. Do not store and use the tool and battery car-

tridge in locations where the temperature may

reach or exceed 50 °C (122 °F).

7. Do not incinerate the battery cartridge even if

it is severely damaged or is completely worn

out. The battery cartridge can explode in a re.

8. Do not nail, cut, crush, throw, drop the battery

cartridge, or hit against a hard object to the

battery cartridge.Suchconductmayresultina

re,excessiveheat,orexplosion.

9. Do not use a damaged battery.

10. The contained lithium-ion batteries are subject

to the Dangerous Goods Legislation require-

ments.

Forcommercialtransportse.g.bythirdparties,

forwardingagents,specialrequirementonpack-

aging and labeling must be observed.

Forpreparationoftheitembeingshipped,consult-

inganexpertforhazardousmaterialisrequired.

Pleasealsoobservepossiblymoredetailed

national regulations.

Tapeormasko󰀨opencontactsandpackupthe

batteryinsuchamannerthatitcannotmove

around in the packaging.

11. When disposing the battery cartridge, remove

it from the tool and dispose of it in a safe

place. Follow your local regulations relating to

disposal of battery.

12. Use the batteries only with the products

specied by Makita. Installing the batteries to

non-compliantproductsmayresultinare,exces-

siveheat,explosion,orleakofelectrolyte.

13. If the tool is not used for a long period of time,

the battery must be removed from the tool.

14. During and after use, the battery cartridge may

take on heat which can cause burns or low

temperature burns. Pay attention to the han-

dling of hot battery cartridges.

15. Do not touch the terminal of the tool imme-

diately after use as it may get hot enough to

cause burns.

16. Do not allow chips, dust, or soil stuck into the

terminals, holes, and grooves of the battery

cartridge.Itmaycauseheating,catchingre,

burstandmalfunctionofthetoolorbatterycar-

tridge,resultinginburnsorpersonalinjury.

17. Unless the tool supports the use near

high-voltage electrical power lines, do not use

the battery cartridge near high-voltage electri-

cal power lines.Itmayresultinamalfunctionor

breakdownofthetoolorbatterycartridge.

18. Keep the battery away from children.

SAVE THESE INSTRUCTIONS.

CAUTION: Only use genuine Makita batteries.

Useofnon-genuineMakitabatteries,orbatteriesthat

havebeenaltered,mayresultinthebatterybursting

causingres,personalinjuryanddamage.Itwill

alsovoidtheMakitawarrantyfortheMakitatooland

charger.

Tips for maintaining maximum

battery life

1. Charge the battery cartridge before completely

discharged. Always stop tool operation and

charge the battery cartridge when you notice

less tool power.

2. Never recharge a fully charged battery car-

tridge. Overcharging shortens the battery

service life.

3. Charge the battery cartridge with room tem-

perature at 10 °C - 40 °C (50 °F - 104 °F). Let

a hot battery cartridge cool down before

charging it.

4. When not using the battery cartridge, remove

it from the tool or the charger.

5. Charge the battery cartridge if you do not use

it for a long period (more than six months).

FUNCTIONAL

DESCRIPTION

CAUTION: Always be sure that the tool is

switched o󰀨 and the battery cartridge is removed

before adjusting or checking function on the tool.

Installing or removing battery

cartridge

CAUTION: Always switch o󰀨 the tool before

installing or removing of the battery cartridge.

CAUTION: Hold the tool and the battery car-

tridge rmly when installing or removing battery

cartridge.Failuretoholdthetoolandthebattery

cartridgermlymaycausethemtoslipo󰀨yourhands

andresultindamagetothetoolandbatterycartridge

andapersonalinjury.

►Fig.1: 1. Red indicator 2. Button 3.Batterycartridge

Toremovethebatterycartridge,slideitfromthetool

whileslidingthebuttononthefrontofthecartridge.

Toinstallthebatterycartridge,alignthetongueonthe

batterycartridgewiththegrooveinthehousingandslip

itintoplace.Insertitallthewayuntilitlocksinplace

withalittleclick.Ifyoucanseetheredindicatoras

showninthegure,itisnotlockedcompletely.

CAUTION: Always install the battery cartridge

fully until the red indicator cannot be seen.Ifnot,

itmayaccidentallyfalloutofthetool,causinginjuryto

youorsomeonearoundyou.

CAUTION: Do not install the battery cartridge

forcibly.Ifthecartridgedoesnotslideineasily,itis

notbeinginsertedcorrectly.

10 ENGLISH

Indicating the remaining battery

capacity

Only for battery cartridges with the indicator

►Fig.2: 1. Indicator lamps 2. Check button

Pressthecheckbuttononthebatterycartridgetoindi-

catetheremainingbatterycapacity.Theindicatorlamps

lightupforafewseconds.

Indicator lamps Remaining

capacity

Lighted O󰀨 Blinking

75% to 100%

50% to 75%

25% to 50%

0% to 25%

Charge the

battery.

Thebattery

mayhave

malfunctioned.

NOTE:Dependingontheconditionsofuseandthe

ambienttemperature,theindicationmaydi󰀨erslightly

fromtheactualcapacity.

NOTE:Therst(farleft)indicatorlampwillblinkwhen

thebatteryprotectionsystemworks.

Tool / battery protection system

Thetoolisequippedwithatool/batteryprotectionsys-

tem.Thissystemautomaticallycutso󰀨powertothe

motortoextendtoolandbatterylife.Thetoolwillauto-

maticallystopduringoperationifthetoolorbatteryis

placedunderoneofthefollowingconditions:

Overload protection

Whenthetoolorbatteryisoperatedinamannerthat

causesittodrawanabnormallyhighcurrent,thetool

automaticallystopswithoutanyindication.Inthissit-

uation,turnthetoolo󰀨andstoptheapplicationthat

caused the tool to become overloaded. Then turn the

tool on to restart.

Overheat protection

Whenthetoolorbatteryisoverheated,thetoolstops

automatically.Inthiscase,letthetoolandbatterycool

beforeturningthetoolonagain.

Overdischarge protection

Whenthebatterycapacityisnotenough,thetoolstops

automatically.Inthiscase,removethebatteryfromthe

toolandchargethebattery.

Protections against other causes

Protectionsystemisalsodesignedforothercausesthatcould

damagethetoolandallowsthetooltostopautomatically.

Takeallthefollowingstepstoclearthecauses,whenthetool

hasbeenbroughttoatemporaryhaltorstopinoperation.

Turnthetoolo󰀨,andthenturnitonagaintorestart.

2. Chargethebattery(ies)orreplaceit/themwith

rechargedbattery(ies).

3. Letthetoolandbattery(ies)cooldown.

Ifnoimprovementcanbefoundbyrestoringprotection

system,thencontactyourlocalMakitaServiceCenter.

Switch action

CAUTION: Avoid turning the tool on while it

is placed on the workpiece or on your workbench.

Itmaycausepersonalinjuryordamage.

Turning the tool on and o󰀨

Press the power/speed select button to start the tool.

The tool starts to run at its highest orbital speed.

Press the stop button to stop the tool.

►Fig.3: 1. Power/speed select button 2. Stop button

Changing the tool speed

The orbital speed can be changed in two modes; high and low.

Choose either mode depending on the application and workload.

Press the power/speed select button to switch speed

mode while the tool is running.

►Fig.4: 1. Power/speed select button

Speed settings table

Speed level Orbital per minute

2 (High) 14,000 min-1 (/min)

1 (Low) 11,000 min-1 (/min)

NOTICE: If the tool is operated continuously

at low speeds for a long time, the motor will get

overloaded, resulting in tool malfunction.

NOTICE:

Select an appropriate speed range for

your sanding operations to avoid overheating and

melting the workpiece. Sanding at high orbital speed

mayheatworkpieceandmeltitatthepointofcontact.

ASSEMBLY

CAUTION: Always be sure that the tool is

switched o󰀨 and the battery cartridge is removed

before carrying out any work on the tool.

Installing and removing abrasive paper

CAUTION: Always make sure that a sheet of

abrasive paper is installed securely before use.

Thepapermayotherwisebeloosened,removed

easilyandsubjecttoslippage,resultinginuneven

sanding operation.

Altri manuali per DBO480

Indice

Manuali Levigatrice popolari di altre marche

Oliver

Oliver 6305 Manuale utente

Jet

Jet 22-44 Pro-3 Manuale di servizio

Craftsman

Craftsman 351.215131 Manuale utente

Clarke

Clarke Woodworker CBS1-5B Manuale di istruzioni

Chicago Pneumatic

Chicago Pneumatic CP9778 Manuale utente

Nitto Kohki

Nitto Kohki BB-20 Manuale utente

Ferm

Ferm FEOS-135 Manuale utente

Unior

Unior 1510 Manuale utente

stayer

stayer ls1200 Manuale utente

Jet

Jet JSG-96 Manuale di servizio

Parkside

Parkside PDS 290 B2 Manuale utente

Status

Status XPA Series Manuale utente

Clarke

Clarke EZ Sand Manuale utente

Craftsman

Craftsman 113.22521 Manuale utente

Craftsman

Craftsman 113.225831 Manuale utente

CLAS

CLAS OP 1429 Manuale utente

Parkside

Parkside PEXS 270 Al Manuale utente

Flex

Flex ST 1005 VE Manuale utente
