Manhattan 703253 Manuale utente

HI-SPEED

USB 2.0

EXTERNAL

ENCLOSURE

USER

MANUAL

Model 703253

MAN-703253-UM-0308-01

Thank you for purchasing the MANHATTAN

Hi-Speed USB 2.0, 3.5”

External Enclosure, Model 703253.

These easy-to-follow instructions help make installation of the enclosure

quick and simple, so you’ll soon be enjoying the benets of these features:

• Supports Hi-Speed USB 2.0 data transfer rates up to 480 Mbps

• Lightweight, compact design increases portability

• Sturdy aluminum case protects drive and facilitates cooling

• Fits standard 3.5” PATA (IDE) drives with easy, quick installation

• Windows and Macintosh compatible, Plug and Play, hot swappable

• Power switch and LED indicator

• Available space for optional cooling fan; not included (maximum

dimensions, 2.5 x 2.5 x 1.0 cm)

• Lifetime Warranty

INSTALLATION

NOTE: Before connecting the IDE drive, set it to Master mode. Make an

extra copy of your original data prior to installation to avoid any data

loss should a mistake be made during the procedure. (Otherwise,

MANHATTAN cannot be held responsible for any lost data.)

1. Remove the 3.5” chassis from

the enclosure.

2. Connect the 40-pin IDE cable

and 12 V power cable to the

HDD. Fix in place with the

included screws.

3. Re-insert the chassis into the

enclosure.

4. Tighten the screws on the

back cover to complete the

installation.

Windows 98SE Driver Installation

1. Place the included driver CD in the CD-ROM drive and click on the

le “M110E-win98-driver.”

2. Double-click the Setup icon to run the program.

3. When “Win98 USB Driver” displays, click “Next.”

4. When the “Restart my computer now!” prompt displays, click “Finish”

to restart your computer. After the restart, connect the external

enclosure to your computer.

NOTE: Windows Me/2000/XP/Vista32/Vista64 already have the

additional driver installed. Windows XP needs to be updated with SP2.

SPECIFICATIONS

Standards & Certications

• Hi-Speed USB 2.0, USB 1.1, FCC, CE

General

• Connections

- 40-pin IDE & 4-pin Molex internal

- Hi-Speed USB 2.0 B-type external

• M110E chipset

• DC power input jack, 12 V / 2 A (AC

adapter included)

• 22 x 12 x 3 cm (8.5 x 4.7 x 1.3 in.)

• 448 g (16 oz.)

System Requirements

• Pentium 266 MHz or higher

• 64 MB RAM

• Windows 98/Me/2000/XP/Vista or

Mac 10.0.4-10.1.3 / 9.2.2 and above

Package Contents

• External Enclosure with stand

• USB A-type male to B-type male cable,

1.2 m (4 ft.)

• AC power adapter with cable, 2.7 m (9 ft.)

• User manual, CD driver, screws

All products mentioned are trademarks or registered trademarks of their respective owners.

www.manhattan-products.com

MANHATTAN®offers a complete line

of PC Components, Peripherals, Cables and Accessories.

Ask your local computer dealer for more information

or visit us online at
