Manhattan 160735 Manuale utente

HI-SPEED

USB 2.0

SHARING

SWITCH

USER

MANUAL

Model 160735

MAN-160735-UM-0208-03

Thank you for purchasing the MANHATTAN®Hi-Speed USB 2.0

Sharing Switch, Model 160735.

Installation

Before installing the switch, make sure all computers and peripherals to

be connected are turned off.

1. Connect up to four computers to the PC1-4 ports on the switch

(cables included).

2. Connect the device port on the switch to the selected USB device.

3. Power on the computer(s) and the connected USB device.

Operation

This switch draws its power from the computer(s). Any connected USB

device will link to the rst connected computer that’s on.

Select button: Press the Select

button (located on the top of the

switch) to cycle through up to four

connected computers.

LEDs: The corresponding LED of

whichever one of the four PC ports

is connected to the USB device will

be lit. (Only one LED will light at any

given time.) NOTE: A ashing LED indicates that the corresponding

port is processing a redirect command and is not yet ready for activity.

Hot Key Control (PCs only): When the switch isn’t within easy reach to

press the Select button, the Hot Key function can be used: On your

keyboard, press the Scroll Lock key twice (within 2 seconds) to redirect

the USB device to the next PC port and its connected computer.

• If the next port is not connected or is connected to a computer that’s

turned off, the Select button will need to be used instead.

• Do not use the Hot Key shortcut to redirect the USB device to a PC in

Sleep mode or if a PC’s corresponding LED is ashing.

• If the connected USB device is a storage device (such as a hard drive or

CDRW), make sure the second computer completes the job in progress.

Select

PC4 PC3 PC2 PC1

Specications

Standards and Certications

• USB 1.1

• USB 2.0

• EHCI

• UHCI

• OHCI

• CE

• FCC

General

• Data transfer rate up to 12 Mbps

• Cypress chipset

• USB bus powered

• Switch control: keyboard hotkey (PC only); top-mount push button,

(PC and Mac)

• 4 LED active port indicators

• 4 USB type B female ports, upstream

• 1 USB type A female port, downstream

• 4 USB type A male to type B male cables, 1.8 m (6 ft.)

• Compatible with Windows 2000/XP/Vista and Mac OS 10 or above

Physical

• Dimensions: 119 x 84 x 21 mm (4.6 x 3.3 x 1 in.)

• Weight: 120 g (4.25 oz.)

• Housing material: plastic

Environmental

• Operation temperature: 0 – 50˚ C

• Storage temperature: -20 – 60˚ C

• Humidity: 0 – 80%, non-condensing

Package Contents

• Hi-Speed USB 2.0 Sharing Switch, 4x1 Ports, Dual Control

• USB cables

• User manual

All products mentioned are trademarks or registered trademarks of their respective owners.

www.manhattan-products.com

MANHATTAN®offers a complete line

of PC Components, Peripherals, Cables and Accessories.

Ask your local computer dealer for more information

or visit us online at
