999 SERIES 1, 2, 3

Luffing Jib Raising Procedure

Luffing Jib No. 135 On Boom No. 82 or 22EL

Manitowoc Cranes, Inc.

8248-A, 2011-10-19

Manitowoc, Wisconsin 54220 U.S.A.

1/10

Recommended boom and luffing jib raising and lowering procedure:

999 SERIES 1 must be equipped with 149,000 lb (67 860 kg) crane counterweight, 999 SERIES 2 must be

equipped with 184,600 lb (83 730 kg) crane counterweight and 44,000 lb (19 960 kg) carbody counterweight and

999 SERIES 3 must be equipped with 219,600 lb (99 610 kg) crane counterweight and 80,000 lb (36 290 kg)

carbody counterweight for raising and lowering various boom and luffing jib combinations. Refer to luffing jib

rigging assembly No. 196199 (Boom No. 22EL) or No. 196200 (Boom No. 82) without intermediate fall or

No. A09286 (Boom No. 22EL) or No. A09287 (Boom No. 82) with intermediate fall for boom and luffing jib make-

up of inserts, pendants and miscellaneous parts, etc.

Three methods may be used to raise and lower boom and luffing jib combinations, depending on length.

A. Layout In-Line Method

Boom and luffing jib are assembled in layout, end-to-end, position. Slowly raise boom until luffing jib stop strut

is just clear of ground. Attach luffing jib stop pendants and unpin luffing jib stop inner strut from retracted

position. Slowly raise boom until luffing jib stop strut is fully extended and pins engaged (approximately 168

degree boom-to-luffing jib angle). Tighten luffing jib suspension with luffing jib hoist. Boom and luffing jib can

then be raised simultaneously using only the boom hoist. Luffing jib radius must be within capacity chart before

swinging over side of machine when raising over end of blocked crawlers. Reverse this procedure when

lowering boom and luffing jib.

Boom and luffing jib combinations in following tables may be raised and lowered using layout in-line method.

For jib lengths shown with (c), machine must be equipped with lowerworks jacking cylinders when boom

catwalks are attached.

WITH OR WITHOUT BOOM CATWALKS

999 SERIES 1

Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using In-Line Method

Without Intermediate Fall

Boom

Length

Over End of

Blocked Crawlers Over Side of Crawlers

Luffing Jib No. 135 Luffing Jib No. 135

Feet Meters Feet Meters Feet Meters

70 21,3 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8

80 24,4 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8

90 27,4 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8

100 30,5 70 - 170 21,3 - 51,8 70 - 150 21,3 - 45,7

110 33,5 70 - 170 21,3 - 51,8 70 - 120 21,3 - 36,6

120 36,6 70 - 140 21,3 - 42,7 70 - 90 21,3 - 27,4

130 39,6 70 - 120 21,3 - 36,6 70 21,3

140 42,7 70 - 90 21,3 - 27,4 — —

150 45,7 70(c) 21,3 — —

Load blocks, hook and weight ball on ground until boom and luffing jib are erected.

Intermediate fall must be completely removed for 999 SERIES 1 application.

REFERENCE

ONLY!

8248-A, 2011-10-19

Manitowoc Cranes, Inc.

2/10

Manitowoc, Wisconsin 54220 U.S.A.

999 SERIES 1, 2, 3

Luffing Jib Raising Procedure

Luffing Jib No.135 On Boom No. 82 or 22EL

WITH OR WITHOUT BOOM CATWALKS

999 SERIES 2

Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using In-Line Method

Without Intermediate Fall

Boom

Length

Over End of

Blocked Crawlers Over Side of Crawlers

Luffing Jib No. 135 Luffing Jib No. 135

Feet Meters Feet Meters Feet Meters

70 21,3 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8

80 24,4 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8

90 27,4 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8

100 30,5 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8

110 33,5 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8

120 36,6 70 - 170 21,3 - 51,8 70 - 160 21,3 - 48,8

130 39,6 70 - 160 21,3 - 48,8 70 - 140 21,3 - 42,7

140 42,7 70 - 150 21,3 - 45,7 70 - 120 21,3 - 36,6

150 45,7 70 - 120 21,3 - 36,6 70 - 90 21,3 - 27,4

160 48,8 70 - 100 21,3 - 30,5 — —

170 51,8 70 - 80 21,3 - 24,4 — —

Load blocks, hook and weight ball on ground until boom and luffing jib are erected.

WITH OR WITHOUT BOOM CATWALKS

999 SERIES 3

Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using In-Line Method

Without Intermediate Fall

Boom

Length

Over End of

Blocked Crawlers Over Side of Crawlers

Luffing Jib No. 135 Luffing Jib No. 135

Feet Meters Feet Meters Feet Meters

70 21,3 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8

80 24,4 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8

90 27,4 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8

100 30,5 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8

110 33,5 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8

120 36,6 70 - 170 21,3 - 51,8 70 - 170 21,3 - 51,8

130 39,6 70 - 160 21,3 - 48,8 70 - 160 21,3 - 48,8

140 42,7 70 - 150 21,3 - 45,7 70 - 150 21,3 - 45,7

150 45,7 70 - 120 21,3 - 36,6 70 - 120 21,3 - 36,6

160 48,8 70 - 100 21,3 - 30,5 70 - 100 21,3 - 30,5

170 51,8 70 - 80 21,3 - 24,4 70 - 80 21,3 - 24,4

Load blocks, hook and weight ball on ground until boom and luffing jib are erected.

REFERENCE

ONLY!

999 SERIES 1, 2, 3

Luffing Jib Raising Procedure

Luffing Jib No. 135 On Boom No. 82 or 22EL

Manitowoc Cranes, Inc.

8248-A, 2011-10-19

Manitowoc, Wisconsin 54220 U.S.A.

3/10

Boom and luffing jib combinations with intermediate fall in following tables may be raised and lowered using

in-line method.

WITH OR WITHOUT BOOM CATWALKS

999 SERIES 2

Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using In-Line Method

With Intermediate Fall

Boom

Length

Over End of

Blocked Crawlers Over Side of Crawlers

Luffing Jib No. 135 Luffing Jib No. 135

Feet Meters Feet Meters Feet Meters

70 21,3 110 - 170 33,5 - 51,8 110 - 170 33,5 - 51,8

80 24,4 110 - 170 33,5 - 51,8 110 - 170 33,5 - 51,8

90 27,4 110 - 170 33,5 - 51,8 110 - 170 33,5 - 51,8

100 30,5 110 - 170 33,5 - 51,8 110 - 170 33,5 - 51,8

110 33,5 110 - 170 33,5 - 51,8 110 - 170 33,5 - 51,8

120 36,6 110 - 160 33,5 - 48,8 110 - 150 33,5 - 45,7

130 39,6 110 - 150 33,5 - 45,7 110 - 120 33,5 - 36,6

140 42,7 110 - 130 33,5 - 39,6 — —

150 45,7 110 33,5 — —

Load blocks, hook and weight ball on ground until boom and luffing jib are erected.

WITH OR WITHOUT BOOM CATWALKS

999 SERIES 3

Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using In-Line Method

With Intermediate Fall

Boom

Length

Over End of

Blocked Crawlers Over Side of Crawlers

Luffing Jib No. 135 Luffing Jib No. 135

Feet Meters Feet Meters Feet Meters

70 21,3 110 - 170 33,5 - 51,8 110 - 170 33,5 - 51,8

80 24,4 110 - 170 33,5 - 51,8 110 - 170 33,5 - 51,8

90 27,4 110 - 170 33,5 - 51,8 110 - 170 33,5 - 51,8

100 30,5 110 - 170 33,5 - 51,8 110 - 170 33,5 - 51,8

110 33,5 110 - 170 33,5 - 51,8 110 - 170 33,5 - 51,8

120 36,6 110 - 160 33,5 - 48,8 110 -160 33,5 - 48,8

130 39,6 110 - 150 33,5 - 45,7 110 -150 33,5 - 45,7

140 42,7 110 - 130 33,5 - 39,6 110 - 130 33,5 - 39,6

150 45,7 110 33,5 110 33,5

Load blocks, hook and weight ball on ground until boom and luffing jib are erected.

REFERENCE

ONLY!

8248-A, 2011-10-19

Manitowoc Cranes, Inc.

4/10

Manitowoc, Wisconsin 54220 U.S.A.

999 SERIES 1, 2, 3

Luffing Jib Raising Procedure

Luffing Jib No.135 On Boom No. 82 or 22EL

B. Layout Jack-Knife Method:

(Longer boom and luffing jib combinations must be raised and lowered using this method)

Raising:

Boom and luffing jib are assembled in layout, end-to-end, position. Slowly raise boom until luffing jib stop strut

is just clear of ground. Attach luffing jib stop pendants and unpin luffing jib stop inner strut from retracted

position. Slowly raise boom until luffing jib stop strut is fully extended and pins engaged (approximately 168

degree boom-to-luffing jib angle). Boom is then raised while luffing jib point wheels are allowed to roll on

ground. Tension should be applied to luffing jib hoist to keep luffing jib strut off luffing jib during boom raising.

Boom up until boom-to-luffing jib angle reaches value specified in table below or vertical, whichever occurs first.

Tighten luffing jib suspension with luffing jib hoist. Boom and luffing jib are then raised together using boom

hoist until boom reaches desired boom operating angle. Luffing jib radius must be within capacity chart before

swinging over side of machine when raising over end of blocked crawlers.

Lowering:

Position boom at 75 degrees prior to lowering luffing jib. Lower luffing jib until boom-to-luffing jib angle reaches

value specified in table below. Lower boom until luffing jib point wheels contact ground. If luffing jib is hanging

vertical, raise luffing jib a few degrees forward of vertical. Continue to lower boom while luffing jib rolls along

ground. Keep enough tension on luffing jib hoist to keep luffing jib strut off luffing jib. Stop lowering boom when

luffing jib stop pendants start to go into tension (approximately 168 degree boom-to-luffing jib angle).

Disengage luffing jib stop strut pins and lower boom to retract luffing jib stop inner strut. Pin strut in retracted

position and unpin luffing jib stop pendants. Rotate luffing jib stop struts forward and lower boom and luffing jib

to ground.

REFERENCE

ONLY!

999 SERIES 1, 2, 3

Luffing Jib Raising Procedure

Luffing Jib No. 135 On Boom No. 82 or 22EL

Manitowoc Cranes, Inc.

8248-A, 2011-10-19

Manitowoc, Wisconsin 54220 U.S.A.

5/10

Boom and luffing jib combinations in following tables require layout jack-knifing to a specified boom-to-luffing jib

angle for raising and lowering. Boom lengths shown with (a) require only the middle two sheaves in lower boom

point. All other sheaves must be removed from lower boom point. Boom lengths shown with (b) require lower

boom point to be removed. For jib lengths shown with (c), machine must be equipped with lowerworks jacking

cylinders when boom catwalks are attached.

WITH OR WITHOUT BOOM CATWALKS

999 SERIES 1

Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using Jack-Knife Method

Without Intermediate Fall

Boom

Length

Over End of Blocked Crawlers Over Side of Crawlers

Luffing Jib No. 135

Boom to

Luffing Jib

Angle Luffing Jib No. 135

Boom to

Luffing Jib

Angle

Feet Meters Feet Meters Degrees Feet Meters Degrees

100 30,5 —— — 160 - 170 48,8 - 51,8 90

110 33,5 —— — 130 - 170 39,6 - 51,8 90

120 36,6 150 - 170 45,7 - 51,8 90 100 - 170 30,5 - 51,8 90

130 39,6 130 - 170 39,6 - 51,8 90 80 - 170 24,4 - 51,8 90

140 42,7 100 - 170 30,5 - 51,8 90 70 - 150 21,3 - 45,7 90

—— — 160 - 170 48,8 - 51,8 60

150 45,7 80 - 170 24,4 - 51,8 90 (c) 80 - 90 24,4 - 27,4 60

160 48,8 70 - 170(c) 21,3 - 51,8 60 — — —

(b) 170 51,8 80 - 150(c) 24,4 - 45,7 60 — — —

Load blocks, hook and weight ball on ground until boom and luffing jib are erected. Intermediate fall must be

completely removed for 999 SERIES 1 application.

REFERENCE

ONLY!

8248-A, 2011-10-19

Manitowoc Cranes, Inc.

6/10

Manitowoc, Wisconsin 54220 U.S.A.

999 SERIES 1, 2, 3

Luffing Jib Raising Procedure

Luffing Jib No.135 On Boom No. 82 or 22EL

WITH OR WITHOUT BOOM CATWALKS

999 SERIES 2

Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using Jack-Knife Method

Without Intermediate Fall

Boom

Length

Over End of Blocked Crawlers Over Side of Crawlers

Luffing Jib No. 135

Boom to

Luffing Jib

Angle Luffing Jib No. 135

Boom to

Luffing Jib

Angle

Feet Meters Feet Meters Degrees Feet Meters Degrees

120 36,6 — — — 170 51,8 90

130 39,6 170 51,8 90 150 - 170 45,7 - 51,8 90

140 42,7 160 - 170 48,8 - 51,8 90 130 - 170 39,6 - 51,8 90

150 45,7 130 - 170 39,6 - 51,8 90 100 - 170 30,5 - 51,8 90

160 48,8 110 - 170 33,5 - 51,8 90 70 - 170 21,3 - 51,8 90

170 51,8 90 - 170 27,4 - 51,8 90 70 - 170(c) 21,3 - 51,8 60

180 54,9 70 - 170 21,3 - 51,8 90 — ——

(a) 190 57,9 70 - 170 21,3 - 51,8 60 — ——

(b) 200 61,0 100 - 170(c) 30,5 - 51,8 60 — ——

Load blocks, hook and weight ball on ground until boom and luffing jib are erected.

WITH OR WITHOUT BOOM CATWALKS

999 SERIES 3

Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using Jack-Knife Method

Without Intermediate Fall

Boom

Length

Over End of Blocked Crawlers Over Side of Crawlers

Luffing Jib No. 135

Boom to

Luffing Jib

Angle Luffing Jib No. 135

Boom to

Luffing Jib

Angle

Feet Meters Feet Meters Degrees Feet Meters Degrees

130 39,6 170 51,8 90 170 51,8 90

140 42,7 160 - 170 48,8 - 51,8 90 160 - 170 48,8 - 51,8 90

150 45,7 130 - 170 39,6 - 51,8 90 130 - 170 39,6 - 51,8 90

160 48,8 110 - 170 33,5 - 51,8 90 110 - 170 33,5 - 51,8 90

170 51,8 90 - 170 27,4 - 51,8 90 90 - 170 27,4 - 51,8 90

180 54,9 70 - 170 21,3 - 51,8 90 70 - 170 21,3 - 51,8 90

(a) 190 57,9 70 - 170 21,3 - 51,8 90 70 - 150 21,3 - 45,7 60

(b) 200 61,0 70 - 170 21,3 - 51,8 90 — ——

Load blocks, hook and weight ball on ground until boom and luffing jib are erected.

REFERENCE

ONLY!

999 SERIES 1, 2, 3

Luffing Jib Raising Procedure

Luffing Jib No. 135 On Boom No. 82 or 22EL

Manitowoc Cranes, Inc.

8248-A, 2011-10-19

Manitowoc, Wisconsin 54220 U.S.A.

7/10

Boom and luffing jib combinations with intermediate fall in following tables may be raised and lowered using

jack-knife method.

WITH OR WITHOUT BOOM CATWALKS

999 SERIES 2

Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using Jack-Knife Method

With Intermediate Fall

Boom

Length

Over End of Blocked Crawlers Over Side of Crawlers

Luffing Jib No. 135

Boom to

Luffing Jib

Angle Luffing Jib No. 135

Boom to

Luffing Jib

Angle

Feet Meters Feet Meters Degrees Feet Meters Degrees

120 36,6 170 51,8 90 160 - 170 48,8 - 51,8 90

130 39,6 160 - 170 48,8 - 51,8 90 130 - 170 39,6 - 51,8 90

140 42,7 140 - 170 42,7 - 51,8 90 110 - 170 33,5 - 51,8 90

150 45,7 120 - 170 36,6 - 51,8 90 110 - 170 33,5 - 51,8 90

160 48,8 110 - 170 33,5 - 51,8 90 110 - 170 33,5 - 51,8 60

170 51,8 110 - 170 33,5 - 51,8 90 110 - 140(c) 33,5 - 42,7 60

180 54,9 110 - 170 33,5 - 51,8 60 — ——

(b) 190 57,9 110 - 170 33,5 - 51,8 60 — ——

(b) 200 61,0 110 - 150(c) 33,5 - 45,7 60 — ——

Load blocks, hook and weight ball on ground until boom and luffing jib are erected.

WITH OR WITHOUT BOOM CATWALKS

999 SERIES 3

Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using Jack-Knife Method

With Intermediate Fall

Boom

Length

Over End of Blocked Crawlers Over Side of Crawlers

Luffing Jib No. 135

Boom to

Luffing Jib

Angle Luffing Jib No. 135

Boom to

Luffing Jib

Angle

Feet Meters Feet Meters Degrees Feet Meters Degrees

120 36,6 170 51,8 90 170 51,8 90

130 39,6 160 - 170 48,8 - 51,8 90 160 - 170 48,8 - 51,8 90

140 42,7 140 - 170 42,7 - 51,8 90 140 - 170 42,7 - 51,8 90

150 45,7 120 - 170 36,6 - 51,8 90 120 - 170 36,6 - 51,8 90

160 48,8 110 - 170 33,5 - 51,8 90 110 - 170 33,5 - 51,8 90

170 51,8 110 - 170 33,5 - 51,8 90 110 - 170 33,5 - 51,8 90

180 54,9 110 - 170 33,5 - 51,8 60 110 - 170 33,5 - 51,8 90

(b) 190 57,9 110 - 170 33,5 - 51,8 60 110 - 130 33,5 - 51,8 60

(b) 200 61,0 110 - 150 33,5 - 45,7 60 — ——

Load blocks, hook and weight ball on ground until boom and luffing jib are erected.

REFERENCE

ONLY!

8248-A, 2011-10-19

Manitowoc Cranes, Inc.

8/10

Manitowoc, Wisconsin 54220 U.S.A.

999 SERIES 1, 2, 3

Luffing Jib Raising Procedure

Luffing Jib No.135 On Boom No. 82 or 22EL

C. Fold Under Jack-Knife Method:

Raising:

Boom and luffing jib are assembled in fold under position. Slowly raise boom; luffing jib point wheels will roll along

ground. When luffing jib hinge pin is 30 ft (9,1m) off ground, connect luffing jib pendants. Move luffing jib top wire rope

guide to working position. Tighten luffing jib suspension with luffing jib hoist. Slowly raise boom until luffing jib is vertical

and luffing jib point wheels are clear of ground. Tighten luffing jib suspension with luffing jib hoist. Boom and luffing jib

are then raised together using boom hoist until boom reaches desired boom operating range. Luffing jib radius must be

within capacity chart before swinging over side of machine when raising over end of blocked crawlers.

Lowering:

Position boom at 75 degrees prior to lowering luffing jib. Slowly lower luffing jib to vertical. Lower boom until luffing jib

point wheels are just clear of ground. Slowly boom down and assist luffing jib point wheels in fold under direction. Boom

down until luffing jib hinge pin is 30 ft (9,1m) off ground. Disconnect luffing jib pendants. Move luffing jib top wire rope

guide to stowed position. Raise luffing jib strut with luffing jib hoist until luffing jib strut is inline with luffing jib. Lower

boom and luffing jib to ground.

Boom and luffing jib combinations in following tables may be raised and lowered using fold under jack-knife method.

Boom length shown with (a) requires only the middle two sheaves in lower boom point. All other sheaves must be

removed from lower boom point. Boom lengths shown with a (b) require lower boom point to be removed. For jib

lengths shown with(c), machine must be equipped with lowerworks jacking cylinders when boom catwalks are attached.

WITH OR WITHOUT BOOM CATWALKS

999 SERIES 1

Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using Fold Under Jack-Knife Method

Without Intermediate Fall

Boom

Length

Over End of Blocked Crawlers Over Side of Crawlers

Luffing Jib No. 135 Luffing Jib No. 135

Feet Meters Feet Meters Feet Meters

90 27,4 70 21,3 70 21,3

100 30,5 70 - 80 21,3 - 24,4 70 - 80 21,3 - 24,4

110 33,5 70 - 90 21,3 - 27,4 70 - 90 21,3 - 27,4

120 36,6 70 - 100 21,3 - 30,5 70 - 100 21,3 - 30,5

130 39,6 70 - 110 21,3 - 33,5 70 - 110 21,3 - 33,5

140 42,7 70 - 120 21,3 - 36,6 70 - 120 21,3 - 36,6

150 45,7 70 - 130 21,3 - 39,6 (c) 80 - 90 24,4 - 27,4

160 48,8 70 - 140 21,3 - 42,7 — —

(b) 170 51,8 80 -150(c) 24,4 - 45.7 — —

Load blocks, hook and weight ball on ground until boom and luffing jib are erected. Intermediate fall must

be completely removed for 999 SERIES 1 application.

REFERENCE

ONLY!

999 SERIES 1, 2, 3

Luffing Jib Raising Procedure

Luffing Jib No. 135 On Boom No. 82 or 22EL

Manitowoc Cranes, Inc.

8248-A, 2011-10-19

Manitowoc, Wisconsin 54220 U.S.A.

9/10

WITH OR WITHOUT BOOM CATWALKS

999 SERIES 2

Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using Fold Under Jack-Knife Method

Without Intermediate Fall

Boom

Length

Over End of Blocked Crawlers Over Side of Crawlers

Luffing Jib No. 135 Luffing Jib No. 135

Feet Meters Feet Meters Feet Meters

90 27,4 70 21,3 70 21,3

100 30,5 70 - 80 21,3 - 24,4 70 - 80 21,3 - 24,4

110 33,5 70 - 90 21,3 - 27,4 70 - 90 21,3 - 27,4

120 36,6 70 - 100 21,3 - 30,5 70 - 100 21,3 - 30,5

130 39,6 70 - 110 21,3 - 33,5 70 - 110 21,3 - 33,5

140 42,7 70 - 120 21,3 - 36,6 70 - 120 21,3 - 36,6

150 45,7 70 - 130 21,3 - 39,6 70 - 130 21,3 - 39,6

160 48,8 70 - 140 21,3 - 42,7 70 - 140 21,3 - 42.7

170 51,8 70 - 150 21,3 - 45.7 70 - 150 21,3 - 45.7

180 54,9 70 - 160 21,3 - 48.8 ——

(a) 190 57,9 70 - 170 21,3 - 51,8 — —

(b) 200 61,0 100 - 170(c) 30.5 - 51,8 — —

Load blocks, hook and weight ball on ground until boom and luffing jib are erected.

WITH OR WITHOUT BOOM CATWALKS

999 SERIES 3

Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using Fold Under Jack-Knife Method

Without Intermediate Fall

Boom

Length

Over End of Blocked Crawlers Over Side of Crawlers

Luffing Jib No. 135 Luffing Jib No. 135

Feet Meters Feet Meters Feet Meters

90 27,4 70 21,3 70 21,3

100 30,5 70 - 80 21,3 - 24,4 70 - 80 21,3 - 24,4

110 33,5 70 - 90 21,3 - 27,4 70 - 90 21,3 - 27,4

120 36,6 70 - 100 21,3 - 30,5 70 - 100 21,3 - 30,5

130 39,6 70 - 110 21,3 - 33,5 70 - 110 21,3 - 33,5

140 42,7 70 - 120 21,3 - 36,6 70 - 120 21,3 - 36,6

150 45,7 70 - 130 21,3 - 39,6 70 - 130 21,3 - 39,6

160 48,8 70 - 140 21,3 - 42,7 70 - 140 21,3 - 42.7

170 51,8 70 - 150 21,3 - 45.7 70 - 150 21,3 - 45.7

180 54,9 70 - 160 21,3 - 48.8 70 - 160 21,3 - 48.8

(a) 190 57,9 70 - 170 21,3 - 51,8 70 - 150 21,3 - 45.7

(b) 200 61,0 70 - 170 21,3 - 51,8 — —

Load blocks, hook and weight ball on ground until boom and luffing jib are erected.

REFERENCE

ONLY!

8248-A, 2011-10-19

Manitowoc Cranes, Inc.

10/10

Manitowoc, Wisconsin 54220 U.S.A.

999 SERIES 1, 2, 3

Luffing Jib Raising Procedure

Luffing Jib No.135 On Boom No. 82 or 22EL

Boom and luffing jib combinations with intermediate fall in following tables may be raised and lowered using fold under

jack-knife method.

WITH OR WITHOUT BOOM CATWALKS

999 SERIES 2

Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using Fold Under Jack-Knife Method

With Intermediate Fall

Boom

Length

Over End of Blocked Crawlers Over Side of Crawlers

Luffing Jib No. 135 Luffing Jib No. 135

Feet Meters Feet Meters Feet Meters

130 39,6 110 33,5 110 33,5

140 42,7 110 - 120 33,5 - 36,6 110 - 120 33,5 - 36,6

150 45,7 110 - 130 33,5 - 39,6 110 - 130 33,5 - 39,6

160 48,8 110 - 140 33,5 - 42,7 110 - 140 33,5 - 42.7

170 51,8 110 - 150 33,5 - 45.7 110 - 140(c) 33,5 - 42.7

180 54,9 110 - 160 33,5 - 48.8 ——

(b) 190 57,9 110 - 170 33,5 - 51,8 ——

(b) 200 61,0 100 - 150(c) 33,5 - 45.7 — —

Load blocks, hook and weight ball on ground until boom and luffing jib are erected.

WITH OR WITHOUT BOOM CATWALKS

999 SERIES 3

Maximum Boom and Luffing Jib Lengths Lifted Unassisted Using Fold Under Jack-Knife Method

With Intermediate Fall

Boom

Length

Over End of Blocked Crawlers Over Side of Crawlers

Luffing Jib No. 135 Luffing Jib No. 135

Feet Meters Feet Meters Feet Meters

130 39,6 110 33,5 110 33,5

140 42,7 110 - 120 33,5 - 36,6 110 - 120 33,5 - 36,6

150 45,7 110 - 130 33,5 - 39,6 110 - 130 33,5 - 39,6

160 48,8 110 - 140 33,5 - 42,7 110 - 140 33,5 - 42.7

170 51,8 110 - 150 33,5 - 45.7 110 - 150 33,5 - 45.7

180 54,9 110 - 160 33,5 - 48.8 110 - 160 33,5 - 48.8

(b) 190 57,9 110 - 170 33,5 - 51,8 110 - 130 33,5 - 39,6

(b) 200 61,0 110 - 150 33,5 - 45.7 — —

Load blocks, hook and weight ball on ground until boom and luffing jib are erected.

REFERENCE

ONLY!

Questo manuale è adatto per i seguenti modelli

Altri manuali Manitowoc Attrezzature per l'edilizia

Manitowoc

Manitowoc Grove RT9130E Manuale utente

Manitowoc

Manitowoc Grove GMK6300L-1 Manuale utente

Manitowoc

Manitowoc Grove RT890E Manuale utente

Manitowoc

Manitowoc GROVE GMK5150L Manuale utente

Manitowoc

Manitowoc 18000 Manuale utente

Manitowoc

Manitowoc 777 Manuale utente

Manitowoc

Manitowoc NBT60XL Manuale utente

Manitowoc

Manitowoc Grove 5540F Manuale utente

Manitowoc

Manitowoc Grove RT765E-2 Manuale utente

Manitowoc

Manitowoc 4000W Manuale utente

Manitowoc

Manitowoc National Crane NBT40-1 Series Manuale utente

Manitowoc

Manitowoc Grove RT9150E Manuale utente

Manitowoc

Manitowoc National Crane NBT30H-2 Manuale utente

Manitowoc

Manitowoc MLC650 Manuale utente

Manitowoc

Manitowoc Grove GRT8100 Manuale utente

Manitowoc

Manitowoc Grove RT880E Manuale di installazione e d'uso

Manitowoc

Manitowoc Grove GMK 4100L-1 Manuale utente

Manitowoc

Manitowoc NATIONAL CRANE 900A Manuale utente

Manitowoc

Manitowoc GROVE GMK3060 Manuale utente

Manitowoc

Manitowoc GROVE GMK4090 Manuale utente

Manitowoc

Manitowoc 16000WA Manuale utente

Manitowoc

Manitowoc 16000 Manuale utente

Manitowoc

Manitowoc National Crane 1300A Manuale utente

Manitowoc

Manitowoc National Crane NBT60L Manuale utente

Manuali Attrezzature per l'edilizia popolari di altre marche

SASFORKS

SASFORKS EXTREME Manuale utente

Hailo

Hailo H-50 Manuale utente

Graco

Graco LineLazer ES 1000 Manuale per l'uso e la cura

Greenlee

Greenlee 555RSC Manuale utente

Lux Tools

Lux Tools A-FMR-20 Set Manuale utente

SIP

SIP 03683 Manuale utente

Volvo

Volvo L30G Manuale utente

Grizzly

Grizzly G8712 Manuale utente

Modulift

Modulift CMOD 12 Manuale utente

Case

Case DV201 Manuale utente

Sealey

Sealey SC10.V2 Manuale utente

Wacker Neuson

Wacker Neuson DT05 Manuale utente

HYVA

HYVA AMCO VEBA 81 Series Manuale utente

Atlas Copco

Atlas Copco Dynapac V5100TV Manuale utente

Toro

Toro 323 Manuale utente

SGS

SGS EC1500 Manuale utente

Saferoad

Saferoad VR Arcus Primus 90 Series Manuale utente

Turbosol

Turbosol BM 30 Manuale utente
