Marantz SR6015 Manuale utente

AV Surround Receiver

SR6015

Owner’s Manual

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Accessories 8

Inserting the batteries 9

Operating range of the remote control unit 9

Features 10

High quality sound 10

High performance 12

Easy operation 16

Part names and functions 17

Front panel 17

Display 21

Rear panel 23

Remote control unit 27

Connections

Speaker installation 31

Connecting speakers 38

Before connecting speakers 38

Speaker configuration and “Amp Assign” settings 42

Connecting 5.1-channel speakers 44

Connecting 7.1-channel speakers 45

Connecting 9.1-channel speakers 49

Connecting 11.1-channel speakers 56

Connecting 7.1-channel speakers: Bi-amp connection of front

speakers 60

Connecting 7.1-channel speakers: Second pair of front speakers 61

Connecting multi-zone speakers 62

Connecting a TV 65

Connection 1 : TV equipped with an HDMI connector and

compatible with the ARC (Audio Return Channel) / eARC

(Enhanced Audio Return Channel) 66

Connection 2 : TV equipped with an HDMI connector and

incompatible with the ARC (Audio Return Channel) / eARC

(Enhanced Audio Return Channel) 67

Connection 3 : TV equipped without an HDMI connector 68

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Connecting a playback device 69

Connecting a set-top box (Satellite tuner/cable TV) 70

Connecting a DVD player or Blu-ray Disc player 71

Connecting a player device compatible with the 8K 72

Connecting a video camcorder or game console 73

Connecting a turntable 74

Connecting a device with a multi-channel output connector 75

Connecting a USB memory device to the USB port 76

Connecting FM/AM antennas 77

Connecting to a home network (LAN) 79

Wired LAN 79

Wireless LAN 80

Connecting an external control device 81

REMOTE CONTROL jacks 81

DC OUT jack 82

Connecting the power cord 83

Playback

Basic operation 85

Turning the power on 85

Selecting the input source 85

Adjusting the volume 86

Turning off the sound temporarily (Muting) 86

Playback a DVD player/Blu-ray Disc player 86

Playing a USB memory device 87

Playing files stored on USB memory devices 88

Listening to music on a Bluetooth device 91

Playing music from Bluetooth device 92

Pairing with other Bluetooth devices 93

Reconnecting to this unit from a Bluetooth device 94

Listening to audio on Bluetooth headphones 95

Listening to audio on Bluetooth headphones 96

Reconnecting to a Bluetooth headphones 97

Disconnecting Bluetooth headphones 97

Listening to FM/AM broadcasts 98

Listening to FM/AM broadcasts 99

Tuning in by entering the frequency (Direct Tune) 100

Changing the tune mode (Tune Mode) 101

Tuning in to stations and presetting them automatically (Auto

Preset Memory) 101

Presetting the current broadcast station (Preset Memory) 102

Listening to preset stations 102

Specify a name for the preset broadcast station (Preset Name) 103

Skipping preset broadcast stations (Preset Skip) 104

Cancelling Preset Skip 105

Listening to Internet Radio 106

Listening to Internet Radio 107

Playing back files stored on a PC or NAS 108

Playing back files stored on a PC or NAS 109

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Getting the HEOS App 112

HEOS Account 113

Playing from streaming music services 114

Listening to the same music in multiple rooms 117

AirPlay function 121

Playing songs from your iPhone, iPod touch or iPad 122

Playing iTunes music with this unit 122

Play a song from your iPhone, iPod touch or iPad on multiple

synced devices (AirPlay 2) 123

Spotify Connect function 124

Playing Spotify music with this unit 124

Convenience functions 125

Adding to HEOS Favorites 126

Playing back HEOS Favorites 126

Deleting a HEOS Favorites 127

Adjusting the volume of each channel to match the input source

(Channel Level Adjust) 128

Adjusting the tone (Tone) 129

Displaying your desired video during audio playback (Video

Select) 130

Adjusting the picture quality for your viewing environment (Picture

Mode) 131

Playing the same music in all zones (All Zone Stereo) 132

Changing the speaker settings to match the listening environment

(Speaker Preset) 133

Selecting a sound mode 134

Selecting a sound mode 135

Direct playback 136

Pure Direct playback 136

Auto surround playback 137

Description of sound mode types 138

Sound mode that can be selected for each input signal 143

HDMI Control function 148

Setting procedure 148

Smart Menu function 149

Sleep timer function 151

Using the sleep timer 152

Smart select function 153

Calling up the settings 154

Changing the settings 155

Panel lock function 156

Disabling all key button operations 156

Disabling all button operations except VOLUME 156

Canceling the Panel lock function 157

Remote lock function 158

Disabling the sensor function of the remote control unit 158

Enabling the remote sensor function 158

Web control function 159

Controlling the unit from a web control 159

Playback in ZONE2 (Another room) 161

Connecting ZONE2 161

Playback in ZONE2 164

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Settings

Menu map 166

Menu operations 170

Audio 171

Center Level Adjust 171

Subwoofer Level Adjust 171

Surround Parameter 172

M-DAX 177

Audio Delay 178

Volume 179

Audyssey®180

Graphic EQ 183

Video 185

Picture Adjust 185

HDMI Setup 187

Output Settings 192

On Screen Display 196

Screen Saver 197

4K/8K Signal Format 197

HDCP Setup 199

TV Format 199

Inputs 200

Input Assign 200

Source Rename 203

Hide Sources 203

Source Level 203

Speakers 204

Audyssey® Setup 204

Procedure for speaker settings (Audyssey® Setup) 206

Error messages 212

Retrieving Audyssey® Setup settings 214

Manual Setup 215

Amp Assign 215

Speaker Config. 221

Distances 225

Levels 227

Crossovers 228

Bass 229

Front Speaker 230

Speaker Preset 230

Network 231

Information 231

Connection 231

Wi-Fi Setup 232

Settings 234

Network Control 236

Friendly Name 236

Diagnostics 237

AirPlay 237

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

HEOS Account 238

You have not signed in 238

You have already signed in 238

General 239

Language 239

ECO 239

Bluetooth Transmitter 243

ZONE2 Setup 244

Zone Rename 246

Smart Select Names 246

Trigger Out 247

Front Display 247

Firmware 248

Information 251

Usage Data 253

Save & Load 253

Setup Lock 254

Reset 254

Limiting the operating zone with the remote control 255

Tips

Tips 257

Troubleshooting 259

Power does not turn on / Power is turned off 260

Operations cannot be performed through the remote control unit 261

Display on this unit shows nothing 261

No sound comes out 262

Desired sound does not come out 263

Sound is interrupted or noise occurs 266

No video is shown on the TV 267

The menu screen is not displayed on the TV 269

The color of the menu screen and operations content displayed

on the television is different from normal 269

AirPlay cannot be played back 270

USB memory devices cannot be played back 271

Bluetooth cannot be played back 272

The Internet radio cannot be played back 274

Music files on PC or NAS cannot be played back 275

Various online services cannot be played 276

The HDMI Control function does not work 276

Cannot connect to a wireless LAN network 277

When using HDMI ZONE2, the devices does not function properly 278

Update/upgrade error messages 279

Resetting factory settings 280

Resetting network settings 281

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Appendix

About HDMI 282

Video conversion function 286

Playing back a USB memory devices 288

Playing back a Bluetooth device 289

Playing back a file saved on a PC or NAS 290

Playing back Internet Radio 291

Personal memory plus function 291

Last function memory 291

Explanation of terms 292

Trademark information 301

Specifications 303

Index 309

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Thank you for purchasing this Marantz product.

To ensure proper operation, please read this owner’s manual carefully before using the product.

After reading this manual, be sure to keep it for future reference.

Accessories

Check that the following parts are supplied with the product.

Quick Start Guide Safety Instructions Notes on radio Warranty

(for USA/for CANADA)

Cable labels

Power cord FM indoor antenna AM loop antenna Sound calibration

microphone

Sound calibration

microphone stand

R03/AAA batteries External antennas for

Bluetooth/wireless

connectivity

Remote control unit

(RC042SR)

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Inserting the batteries

1Remove the rear lid in the direction of the arrow and

remove it.

2Insert two batteries correctly into the battery

compartment as indicated.

Batteries

3Put the rear cover back on.

NOTE

0To prevent damage or leakage of battery fluid:

0Do not use a new battery together with an old one.

0Do not use two different types of batteries.

0Remove the batteries from the remote control unit if it will not be in use for long

periods.

0If the battery fluid should leak, carefully wipe the fluid off the inside of the battery

compartment and insert new batteries.

Operating range of the remote control

unit

Point the remote control unit at the remote sensor when operating it.

30°

Approx. 23 ft/7 m

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Features

High quality sound

0Powerful 9-Channel Discrete Amplifier

Featuring discrete high-current power amplifiers on all channels, this

unit delivers 110W of power per channel (8 Ω/ohms, 20Hz-20kHz,

T.H.D.: 0.08%, 2ch drive). With low impedance driver capability, it offers

operational stability with a wide range of speakers for balanced, quality

sound.

Auto Eco Mode adjusts power output to speakers based on volume

level and on-screen eco meter, providing power consumption reduction

in real-time without sacrificing superb Marantz sound.

0Current feedback amplifier

This unit uses a high-speed current feedback amplifier circuit for its

preamplifier so that signals from a Blu-ray Disc player and other

equipment that support high-definition audio formats can be amplified

with high fidelity. The high-speed current feedback amplifier also

reproduces a natural sound space.

0Dolby Atmos (v p. 293)

This unit is equipped with a decoder that supports Dolby Atmos audio

format. The placement or movement of sound is accurately reproduced

by the addition of overhead speakers, enabling you to experience an

incredibly natural and realistic surround sound field.

0Speaker Virtualizer (v p. 174)

Speaker Virtualizer enables you to access a more immersive

entertainment experience from traditional channel based speaker

layouts through digital signal processing including Dolby Atmos height

virtualization and surround virtualization.

0Speaker Virtualizer is not for use when both height speakers and surround

speakers are connected.

0Height Virtualization may be applied when surround speakers are connected.

0DTS:X (v p. 296)

This unit is equipped with the DTS:X decoder technology. DTS:X brings

the home theater experience to new heights with its immersive object

based audio technology which removes the bounds of channels. The

flexibility of objects allows for sound to be scaled large or small and

moved around the room with greater accuracy than ever before leading

to a richer immersive audio experience.

Contents Connections Playback Settings Tips Appendix

Front panel Display Rear panel Remote Index

Altri manuali per SR6015

Altri manuali Marantz Ricevitore stereo

Marantz

Marantz SR6011 Manuale utente

Marantz

Marantz Slim-line NR1601 Manuale utente

Marantz

Marantz NR1504 Manuale utente

Marantz

Marantz 2270 Manuale utente

Marantz

Marantz NR1710 Manuale utente

Marantz

Marantz Slim-line NR1601 Manuale utente

Marantz

Marantz SR5009/U1B Manuale utente

Marantz

Marantz SR6005 Manuale utente

Marantz

Marantz SR9600 Manuale utente

Marantz

Marantz SR7011 Manuale utente

Marantz

Marantz SR-3000 Manuale utente

Marantz

Marantz SR-14EX Manuale utente

Marantz

Marantz NR1608 Manuale utente

Marantz

Marantz SR7000 Manuale utente

Marantz

Marantz SR9600U Manuale utente

Marantz

Marantz SR5002 Manuale utente

Marantz

Marantz SR6004 Guida rapida

Marantz

Marantz NR1711 Manuale utente

Marantz

Marantz SR5015OM Manuale utente

Marantz

Marantz SR19/K1G Manuale utente

Marantz

Marantz NR1711 Manuale utente

Marantz

Marantz SR8400 Manuale utente

Marantz

Marantz SR5008 Manuale utente

Marantz

Marantz NR1504 /U1B Manuale utente

Manuali Ricevitore stereo popolari di altre marche

Kenwood

Kenwood KMDX92 Manuale utente

Yamaha

Yamaha RX-830 Manuale utente

Pioneer

Pioneer AVH-Z7250BT Manuale utente

Yamaha

Yamaha RX-750 Manuale utente

Denon

Denon AVR-1311 Manuale utente

Denon

Denon AVR-S760H Manuale utente

Denon

Denon AVR-X7200W Manuale utente

Pioneer

Pioneer SC-LX904 Manuale

Sony

Sony XAV-1500 Manuale utente

Radio Shack

Radio Shack DX-399 Manuale utente

Sony

Sony STR-DE535 - Fm Stereo/fm-am Receiver Manuale utente

Pioneer

Pioneer SX-1000TA Manuale utente

Yamaha

Yamaha MusicCast TSR-5B3D Manuale utente

Sony

Sony STR-DE335 - Fm Stereo/fm-am Receiver Manuale utente

Sony

Sony STR-DG500 - Multi Channel Av Receiver Manuale utente

Panasonic

Panasonic AJSD955B - DVCPRO50 STUDIO DECK Manuale utente

Pioneer

Pioneer SX-838 Manuale utente

Sherwood

Sherwood S-2660CP Manuale tecnico
