Installation & Operations Manual

Master-Bilt Products

908 Highway 15 North

New Albany, MS 38652

Phone: (800) 684-8988

PN 071-90000

Rev 03/06/08

TABLE OF CONTENTS

INTRODUCTION………………………………….……………………………………………………………………4

STORE CONDITIONS / LOCATION..………….…..………………………………………………………………..4

WARNING LABELS AND SAFETY INSTRUCTIONS………..…..……………………………………………… 5

PRE-INSTALLATION INSTRUCTIONS………………………..…..………………………………….……………6

Inspection for ShippingDamage……………………………………………………………….……………6

INSTALLATION INSTRUCTIONS………………………………………………………………………………….. 6

General Instructions………………………………………………………………………………………….6

Thermometer Installation…………………………………………………………………………………….6

Condensate Evaporator...……………………………………………………………………………………8

Power Toggle Switch…...…………………………………………………………………………………… 8

Electrical……..…………………………………………………………………………..…………………….8

STARTING PROCEDURE…………………………………………………………………………………………….8

FINAL CHECK LIST…………………………………………………………………………………….……………..8

LOADING………………………………………………………………………………………………………………..9

CLEANING……………………………………………………………………………………………………………...9

SERVICE INSTRUCTIONS (Trouble Shooting Guide)………………………….……………………………….9

MASTER-BILT PART NUMBERS……………………………………………………………………………………9

ACCESSORIES LIST………………………………………………………………………………………………….10

SALE AND DISPOSAL………………………………………………………………………………………………..11

WIRING DIAGRAMS………….…………………………………………………………….…………………….......12

INTRODUCTION

Thank you for purchasing a Master-Bilt cabinet. This manual contains important instructions for installing,

using and servicing a Master-Bilt MPM/QMPM series open air case. Read all these documents carefully

before installing or servicing your equipment. This manual should be left in the care of the store owner or

manager.

STORE CONDITIONS / LOCATION

The Master-Bilt MPM/QMPM cases are designed to operate in the controlled environment of an air conditioned

store. The store temperature should be at or below 75°F and a relative humidity of 55% or less. At higher

temperature or humidity conditions, the performance of these cases may be affected and the capacity

diminished. It is not uncommon in a newly constructed store for the temperature and humidity to be above

design conditions. These excessive conditions may produce sweating in the case until the store is operational

and the ambient environment is more desirable.

The Master-Bilt MPM/QMPM should not be positioned where it is directly exposed to rays of the sun or near a

direct source of radiant heat or air flow. No HVAC return or supply air ducts may be located near case

openings. This will adversely affect the case air flow and will result in poor performance. Do not open windows

or doors that will affect the case air flow. The maximum air velocity near the case air return is 50 FPM. If this

case is to be located against a wall there should be at least a 6” space between the wall and the back of the

case. The cabinet also requires a clearance of 10” at the top. This space will allow for the circulation of air

behind the case.

These cases should always be loaded properly. This unit will operate differently when loaded or unloaded.

Consult the section of this manual that specifies loading procedures on page 6.

A P-trap is included with each case. It is important that each case has a P-trap installed. Check drain tubing to

insure that it is traped and routed into the condensate pan.

NOTICE

Read this manual before installing your cabinet. Keep the manual and refer to it before doing any

service on the equipment. Failure to do so could result in personal injury or damage to the cabinet.

DANGER

Improper or faulty hook-up of electrical components of the refrigeration units can result in severe

injury or death.

All electrical wiring hook-ups must be done in accordance with all applicable local, regional or national

standards.

NOTICE

Installation and service of the refrigeration and electrical components of the cabinet must be

performed by a refrigeration mechanic and/or a licensed electrician.

CAUTION!

GROUND REQUIRED

FOR SAFE OPERATION

The portion of this manual covering refrigeration and electrical components contains technical instructions

intended only for persons qualified to perform refrigeration and electrical work. This manual cannot cover every

installation, use or service situation. If you need additional information, call or write us:

Customer Service Department

Master-Bilt Products

908 Highway 15 North

New Albany, MS 38652

Phone: 800-684-8988

Fax: 866-882-7629

WARNING LABELS AND SAFETY INSTRUCTIONS

This symbol is the safety-alert symbol. When you see this symbol on your cabinet or in

this manual, be alert to the potential for personal injury or damage to your equipment.

Be sure you understand all safety messages and always follow recommended precautions

and safe operating practices.

NOTICE TO EMPLOYERS

You must make sure that everyone who installs, uses or services your cabinet is thoroughly familiar

with all safety information and procedures.

Important safety information is presented in this section and throughout this section and throughout the

manual. The following signal words are used in the warnings and safety messages:

DANGER: Severe injury or death will occur if you ignore the message.

WARNING: Severe injury or death can occur if you ignore the message.

CAUTION: Minor injury or damage to your cabinet can occur if you ignore the message.

NOTICE: This is important installation, operation or service information. If you ignore the

message, you may damage your cabinet.

The warning and safety labels shown throughout this manual are placed on your Master-Bilt Products

cabinet at the factory. Follow all warning label instructions. If any warning or safety labels become

lost or damaged, call your customer service department at (662) 534-9061 for replacements.

This label is located on top of the electrical control This label is attached to the cabinet power cord

label and on the wiring channel. on models with a power cord.

PRE-INSTALLATION INSTRUCTIONS

INSPECTION FOR SHIPPING DAMAGE

You are responsible for filing all freight claims with the delivering truck line. Inspect all cartons and crates for

damage as soon as they arrive. If damage is noted to shipping crates or cartons or if a shortage is found, note

this on the bill of lading (all copies) prior to signing.

If damage is discovered when the cabinet is uncrated, immediately call the delivering truck line and follow up

the call with a written report indicating concealed damage to your shipment. Ask for an immediate inspection of

your concealed damage item. Crating material must be retained to show the inspector from the truck line.

INSTALLATION INSTRUCTIONS

GENERAL INSTRUCTIONS

1. Be sure the equipment is properly installed by competent service people.

2. Keep the equipment clean and sanitary so it will meet your local sanitation codes. Wipe up all spills,clean

with water and a mild detergent, then rinse with clean water. A reservoir is provided to contain interior spills.

Peridocially inspect reservoir and clean as needed.

3. Rotate your stock so that older stock does not accumulate. A "First-In, First-Out" rotation practice will keep

the products in good salable condition.

4. Product should not be put in the case for at least 6 hours after it is started.

5. Stock cases as quickly as possible, exposing only small quantities to store temperatures for short periods of

time.

6. When replacing burned out fluorescent tubes, be sure that the electrical power to the lighting circuit is

turned off. INSTALLATION INSTRUCTIONS

To comply with N.S.F. requirements, this cabinet must be mounted on casters or the base must be sealed to

the floor with NSF listed silicone sealant. Optional casters screw into the holes from which the shipping bolts

were removed. Minimum clearance as follows: 10” air space at top, 6” at the rear, and 0” air space at each side

required for compliance. This space will allow for the circulation of air behind the case which will prevent

condensation on the exterior surfaces.

Before moving cabinet into place, route cabinet plumbing with P-trap to store drain line or install optional

condensate pan.

THERMOMETER INSTALLATION

ANSI/NSF 7, requires that the provided thermometer be installed in the warmest part of the case. Testing has

shown that the sides of the refrigerated space near the load line is the warmest, place see figure 1.1 below.

Remove the tape backing and press the thermometer in place.

SAFE

PRODUCT

LEVEL

FIGURE 1.1

(MPM SHOWN – Typical for QMPM)

CONDENSATE EVAPORATOR

The MPM/QMPM is designed to operate in an environment of 75°ambient and 55% relative humidity. When

the conditions are applicable for condensation such as high temperature and high humidity, a large capacity

condensate evaporator has been installed in the MPM/QMPM to ensure proper evaporation.

POWER TOGGLE SWITCH

The toggle switch turns the power ON or OFF and is accessible through a slot at the back of the MPM/QMPM-

36 and MPM/QMPM-48 cabinet.

NOTICE TO STORE OWNERS / MANAGERS

Moisture or liquid around or under the cabinet is a potential slip/fall hazard for persons walking by or

working in the general area of the cabinet. Any cabinet malfunction or housekeeping problem that

creates a slip/fall hazard around or under the cabinet should be corrected immediately.

If moisture or liquid is observed around or under a Master-Bilt cabinet, an immediate investigation should be

made by qualified personnel to determine the source of the moisture or liquid. The investigation made should

determine if the cabinet is malfunctioning or if there is a drain pipe leaking.

ELECTRICAL

WARNING

Before servicing electrical components in the case make sure all power to case is off. Always use a

qualified technician.

STARTING PROCEDURE

1. Start compressor and allow to run at least 6 hours before placing product into the MPM/QMPM.

DURING THIS TESTING PERIOD YOU SHOULD:

1. Check the temperature holding range against the the control setting.

2. Check the defrost control system to see that all ice is removed from the coil during each defrost cycle.

3. Check pressures.

FINAL CHECK LIST

A. Check setting of defrost timer:

1. Verify setting of four 34 minutes defrost

per 24 hours.

B. Check operating pressures.

C. Check electrical requirements of unit to

supply voltage.

D. Set temperature control for desired

temperature range.

E. Check system for proper defrost operation.

F. Check condensing unit for vibrating or

rubbing tubing. Dampen and clamp as

required.

G. All valves should be completeley open

counter-clockwise.

H. Check packing nuts on all service valves.

I. Replace all service valve caps and latch

unit covers

Do not place product in the case until 6 hours after it is started. Stock cases as quickly as possible, exposing only

small quantities to store temperatures for short periods of time. It is important to keep stock rotated properly so

that older stock does not accumulate. A “First-In, First-Out” rotation practice will keep the products in good salable

condition. Avoid loading the case so that product sticks out beyond the shelves or blocking the return air grille at

the bottom of the case. This will interfere with the air flow of the case and will result in diminished performance.

CLEANING

To avoid electrical shock, turn the power off before cleaning.

The QMVM series cabinets are designed so that spills will accumulate in a drain pan. The drain pan is located

underneath the return air grill. Be sure to clean all areas with a mild detergent and water periodically.

SERVICE INSTRUCTIONS (Trouble Shooting Guide)

1. High head pressure and high back pressure:

A. Condenser coil clogged or restricted.

B. Condenser fan motor defective.

2. Low back pressure and low head pressure:

A. Restriction in system.

B. Refrigerant undercharged.

C. Leak in system.

3. Pressures normal – cabinet warm:

A. Coil blocked with frost or ice (see #4).

B. Control set too warm.

C. Air screen disturbance.

4. Coil blocked with frost or ice:

A. Defective temperature control. E. P-trap in drain not installed.

B. Time clock not operating properly. F. Evaporator fan motor defective.

C. Improper time clock setting. G. Air screen disturbance.

D. Ambient conditions above 75 F/55

5. Compressor starts and runs – but cycles on overload:

A. Low voltage.

B. Dropped phase (3 phase).

C. Overload protector defective.

D. High head pressure (see#1).

E. Relay or Capacitor defective.

6. Compressor will not start – hums, but cycles on overload:

A. Low voltage.

B. Relay defective.

C. Overload protector defective.

D. Start capacitor defective.

E. High head preasure (see #1)

MASTER-BILT PART NUMBERS

The table below gives Master-Bilt part numbers. Use this chart when ordering replacement parts for your

MPM/QMPM cases.

All quantities are one each unless otherwise noted by parentheses.

Description MPM-36

QMPM-36 MPM-48

QMPM-48 MPM-72

QMPM-72

Anti-Sweat Heater-Side 17-09121 17-09122 17-09130

Anti-Sweat Heater-Front 17-09119 17-09120 17-09131

Condensate Pan Heater 17-09140 17-09140 17-09140

Condensing Unit 03-14234 01-01474 01-01477

Drier 09-09309 09-09307 09-09185

Evaporator Coil 07-13102 07-13103 07-13106

Evaporator Fan Blade 15-01184 15-01184 15-01184

Evaporator Fan Motor 13-00685 13-00685 13-00685

Expansion Valve 09-09548

Female Plug 21-00577 21-00577 21-00577

Power Cord 21-00312 21-01218

Temperature Control 19-13092 19-13092 19-13092

Timer 19-00819 19-00819 19-00819

Toggle Switch 19-01090 19-01090

ACCESSORIES LIST

PART NO. DESCRIPTION SHIP WT.

LB/KG

BUMPER KITS

A071-00100 White bumper for QMPM-36, QMVM-36 and QMVM-36L 5/2

A071-00200 Red bumper for QMPM-36, QMVM-36 and QMVM-36L 5/2

A071-00300 Green bumper for QMPM-36, QMVM-36 and QMVM-36L 5/2

A071-00400 Blue bumper for QMPM-36, QMVM-36 and QMVM-36L 5/2

A071-00500 Brown bumper for QMPM-36, QMVM-36 and QMVM-36L 5/2

A071-00600 Black bumper for QMPM-36, QMVM-36 and QMVM-36L 5/2

A072-00100 White bumper for QMPM-48, QMVM-48 and QMVM-48L 5/2

A072-00200 Red bumper for QMPM-48, QMVM-48 and QMVM-48L 5/2

A072-00300 Green bumper for QMPM-48, QMVM-48 and QMVM-48L 5/2

A072-00400 Blue bumper for QMPM-48, QMVM-48 and QMVM-48L 5/2

A072-00500 Brown bumper for QMPM-48, QMVM-48 and QMVM-48L 5/2

A072-00600 Black bumper for QMPM-48, QMVM-48 and QMVM-48L 5/2

A073-00100 White bumper for QMPM-72 and QMVM-72 5/2

A073-00200 Red bumper for QMPM-72 and QMVM-72 5/2

A073-00300 Green bumper for QMPM-72 and QMVM-72 5/2

A073-00400 Blue bumper for QMPM-72 and QMVM-72 5/2

A073-00500 Brown bumper for QMPM-72 and QMVM-72 5/2

A073-00600 Black bumper for QMPM-72 and QMVM-72 5/2

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Master Bilt Frigorifero

Master Bilt

Master Bilt DC-10D Manuale utente

Master Bilt

Master Bilt TAC-27HDSA Manuale utente

Master Bilt

Master Bilt R290 SERIES Manuale utente

Master Bilt

Master Bilt SMB-330 Manuale utente

Master Bilt

Master Bilt MPM-36 Manuale utente

Master Bilt

Master Bilt IM-60 s Manuale utente

Master Bilt

Master Bilt CMICL-156 Manuale utente

Master Bilt

Master Bilt TAC-27 Manuale utente

Master Bilt

Master Bilt TMG-27 Manuale utente

Master Bilt

Master Bilt TLG-27HD Manuale utente

Master Bilt

Master Bilt Fusion BSD-24SFA Manuale utente

Master Bilt

Master Bilt GT-30 Manuale utente

Master Bilt

Master Bilt SPT-28 Manuale utente

Master Bilt

Master Bilt ATMC-124DSS Manuale utente

Master Bilt

Master Bilt TAF-27 ERC2 s Manuale utente

Master Bilt

Master Bilt BGR-14 Manuale utente

Master Bilt

Master Bilt IHC-27 Manuale utente

Master Bilt

Master Bilt BGR15 Manuale utente

Master Bilt

Master Bilt WCR-23SR Manuale utente

Master Bilt

Master Bilt PPT-67 Manuale utente

Master Bilt

Master Bilt QMVM-72 Manuale utente

Master Bilt

Master Bilt TEL-2-30 Manuale utente

Master Bilt

Master Bilt IHC-27 Manuale utente

Master Bilt

Master Bilt J - Version GT-50 s Manuale utente

Manuali Frigorifero popolari di altre marche

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuale utente

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuale utente

Sharp

Sharp SJ-BA31IEXW2-EU Manuale utente

CORBERO

CORBERO CC2300MCW Manuale utente

KitchenAid

KitchenAid 2205264 Manuale utente

Stengel

Stengel KU 1101 A++ Manuale utente

NEFF

NEFF KI181 Series Manuale utente

Hoshizaki

Hoshizaki Reach-In Manuale utente

Amana

Amana ASD2524VES00 Manuale utente

BOMANN

BOMANN KGC 213 Manuale utente

Danby

Danby DAR044A1SLDD Istruzioni per il montaggio

Samsung

Samsung RF323TE Manuale utente

Beko

Beko CSA31022 Manuale utente

IKEA

IKEA FROSTIG C 185 E Manuale utente

Electrolux

Electrolux ER 6821 D Manuale utente

True

True TS-28 Manuale utente

Frigidaire

Frigidaire FSC23R5DW9 Manuale utente

Beko

Beko LSP4579W Manuale utente
