Matias FK304 Scheda tecnica
1
Opening & closing the keyboard
To open, slide the open switch down.
To close, fold and press the two ends
together.
REMEMBER to turn the keyboard OFF
before you close it.
Insert batteries
Batteries are included in the box. The battery compartment is
located on the underside of the keyboard.
On/Off Button
Press the On/Off button to turn the
keyboard on – the blue light flashes.
Press again to turn the keyboard off –
the yellow light flashes.
If the red light flashes, your batteries are low.
Bluetooth
®setup
Please turn to page 4.
Matias Bluetooth Folding Keyboard for Mac – US Layout (FK304)
quick setup
1
2
3
2
4
For more information, please visit:
Technical support:
www.matias.ca/foldingkeyboard/support
Injury prevention and health:
www.matias.ca/health
Warranty information:
please turn to page 14.
Matias Corporation
129 Rowntree Dairy Road, Unit #20
Vaughan, Ontario, L4L 6E1
Canada
Telephone: 1-905-265-8844
www.matias.ca
Copyright © 2008 Matias Corporation. All rights reserved. Matias Folding Keyboard, Matias
Bluetooth Folding Keyboard, Matias, and the Matias logo are trademarks of the Matias
Corporation. Mac and Mac OS are trademarks of Apple, Inc. The Bluetooth
®word mark and
logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by
Matias is under license. Other names may also be trademarks and their owners are respectfully
acknowledged. Patent Pending. Made in China.
2
Using the fn key
Fn key commands are printed on the keys in italic.
The fn key works just like Shift or Ctrl.
Hold down fn and then press the key that has the command
you want.
Using the Eject key on Mac OS X
To Eject, simply hold down the F12 key until the Eject symbol
appears on the screen.
Using Caps Lock
To turn Caps Lock on/off, simply hold down the fn key
and press the / ? caps lock key 2:
3
1
2
Bluetooth
®Setup Instructions
Open System Preferences.
Click on Keyboard & Mouse.
4
1
2
Click on Bluetooth.
5
3
4
Click on Set Up New Device...
6
6
5
Press the On/Off button 5to turn the keyboard on.
The blue light will flash briefly.
If the yellow light flashes, then press the button again.
If the red light flashes or no light flashes, then you need to
insert new batteries.
With a pen or similar pointed object, press the pairing button 6
until the blue light flashes.
7
Click Continue.
Click on Keyboard.
Click Continue.
8
7
8
9
8
9
After the keyboard appears in the list, click Continue.
Type the number shown on your screen using the keyboard,
and then press the Enter key on the keyboard.
9
10
11
10
If the following window appears, click Continue.
If this window does NOT appear, then proceed to step 17.
10
12
12
