Measurement Computing USB-1208HS Manuale utente

USB-1208HS

High-Speed Analog Input and Digital I/O

Document Revision 4

July 2014

User's Guide

HM USB-1208HS.docx

Your new Measurement Computing product comes with a fantastic extra —

Management committed to your satisfaction!

Thank you for choosing a Measurement Computing product—and congratulations! You own the finest, and you can now enjoy

the protection of the most comprehensive warranties and unmatched phone tech support. It’s the embodiment of our mission:

To provide data acquisition hardware and software that will save time and save money.

Simple installations minimize the time between setting up your system and actually making measurements. We offer quick and

simple access to outstanding live FREE technical support to help integrate MCC products into a DAQ system.

Limited Lifetime Warranty: Most MCC products are covered by a limited lifetime warranty against defects in materials or

workmanship for the life of the product, to the original purchaser, unless otherwise noted. Any products found to be defective in

material or workmanship will be repaired, replaced with same or similar device, or refunded at MCC’s discretion. For specific

information, please refer to the terms and conditions of sale.

Harsh Environment Program: Any Measurement Computing product that is damaged due to misuse, or any reason, may be

eligible for replacement with the same or similar device for 50% of the current list price. I/O boards face some harsh

environments, some harsher than the boards are designed to withstand. Contact MCC to determine your product’s eligibility for

this program.

30 Day Money-Back Guarantee: Any Measurement Computing Corporation product may be returned within 30 days of

purchase for a full refund of the price paid for the product being returned. If you are not satisfied, or chose the wrong product by

mistake, you do not have to keep it.

These warranties are in lieu of all other warranties, expressed or implied, including any implied warranty of merchantability or

fitness for a particular application. The remedies provided herein are the buyer’s sole and exclusive remedies. Neither

Measurement Computing Corporation, nor its employees shall be liable for any direct or indirect, special, incidental or

consequential damage arising from the use of its products, even if Measurement Computing Corporation has been notified in

advance of the possibility of such damages.

Trademark and Copyright Information

Measurement Computing Corporation, InstaCal, Universal Library, and the Measurement Computing logo are either trademarks

or registered trademarks of Measurement Computing Corporation. Refer to the Copyrights & Trademarks section on

mccdaq.com/legal for more information about Measurement Computing trademarks. Other product and company names

mentioned herein are trademarks or trade names of their respective companies.

retrieval system, or transmitted, in any form by any means, electronic, mechanical, by photocopying, recording, or otherwise

without the prior written permission of Measurement Computing Corporation.

Notice

Measurement Computing Corporation does not authorize any Measurement Computing Corporation product for use

in life support systems and/or devices without prior written consent from Measurement Computing Corporation.

Life support devices/systems are devices or systems that, a) are intended for surgical implantation into the body, or

b) support or sustain life and whose failure to perform can be reasonably expected to result in injury. Measurement

Computing Corporation products are not designed with the components required, and are not subject to the testing

required to ensure a level of reliability suitable for the treatment and diagnosis of people.

Table of Contents

Preface

About this Manual.................................................................................................................................5

Conventions........................................................................................................................................................5

Where to find more information.........................................................................................................................5

Chapter 1

Introducing the USB-1208HS...............................................................................................................6

Functional block diagram...................................................................................................................................6

Chapter 2

Installing the USB-1208HS...................................................................................................................7

What comes with your shipment?.......................................................................................................................7

Hardware .......................................................................................................................................................................... 7

Software............................................................................................................................................................................ 7

Documentation.................................................................................................................................................................. 7

Unpacking...........................................................................................................................................................7

Installing the software ........................................................................................................................................7

Installing the hardware .......................................................................................................................................7

Calibrating the USB-1208HS.............................................................................................................................8

Chapter 3

Functional Details .................................................................................................................................9

Analog input acquisition modes .........................................................................................................................9

Software paced mode........................................................................................................................................................ 9

Hardware paced mode....................................................................................................................................................... 9

External components ..........................................................................................................................................9

Screw terminals................................................................................................................................................................10

USB connector.................................................................................................................................................................11

Activity LED ...................................................................................................................................................................11

Status LED.......................................................................................................................................................................11

Signal connections............................................................................................................................................11

Analog input....................................................................................................................................................................11

External clock I/O............................................................................................................................................................12

Digital I/O........................................................................................................................................................................12

Counter input...................................................................................................................................................................14

Timer output....................................................................................................................................................................14

Trigger input....................................................................................................................................................................14

Power output....................................................................................................................................................................15

Ground.............................................................................................................................................................................15

Chapter 4

Specifications......................................................................................................................................16

Analog input.....................................................................................................................................................16

Digital input/output...........................................................................................................................................17

External trigger.................................................................................................................................................18

External clock input/output...............................................................................................................................18

Counters............................................................................................................................................................19

Timer ................................................................................................................................................................19

Memory ............................................................................................................................................................19

Power................................................................................................................................................................20

USB specifications ...........................................................................................................................................20

Environmental ..................................................................................................................................................20

Mechanical .......................................................................................................................................................21

USB-1208HS User's Guide

Screw terminal connector and pinout ...............................................................................................................21

Declaration of Conformity..................................................................................................................23

Preface

About this Manual

This document describes the USB-1208HS data acquisition device and lists device specifications.

Conventions

For more information

Text presented in a box signifies additional information related to the subject matter.

Caution! Shaded caution statements present information to help you avoid injuring yourself and others,

damaging your hardware, or losing your data.

bold text Bold text is used for the names of objects on a screen, such as buttons, text boxes, and check boxes.

italic text Italic text is used for the names of manuals and help topic titles, and to emphasize a word or phrase.

Where to find more information

Additional information about USB-1208HS hardware is available on our website at www.mccdaq.com. You can

also contact Measurement Computing Corporation by phone, fax, or email with specific questions.

Knowledgebase: kb.mccdaq.com

Phone: 508-946-5100 and follow the instructions for reaching Tech Support

Fax: 508-946-9500 to the attention of Tech Support

Email: techsupport@mccdaq.com

Chapter 1

Introducing the USB-1208HS

The USB-1208HS is a high-speed analog input and digital I/O data acquisition device providing the following

features:

Eight 13-bit single-ended (SE) or four differential (DIFF) analog inputs

One external clock input and one external output for analog inputs

One digital trigger input

16 individually configurable digital I/O channels

Two 32-bit counter inputs

One 32-bit timer output

Screw terminals for field wiring connections

The device is powered by the +5 volt USB supply from your computer, and requires no external power.

The USB-1208HS is a USB 2.0 high-speed device supported under popular Microsoft®Windows®operating

systems. The USB-1208HS is compatible with both USB 1.1 and USB 2.0 ports (although the speed of the

module maybe limited when using USB 1.1 ports).

Functional block diagram

USB-1208HS functions are illustrated in Figure 1.

Figure 1. USB-1208HS functional block diagram

Chapter 2

Installing the USB-1208HS

What comes with your shipment?

The following items are shipped with the USB-1208HS:

Hardware

USB-1208HS

USB cable

Software

MCC DAQ CD

Documentation

In addition to this hardware user's guide, you should also receive the Quick Start Guide. This booklet provides

an overview of the MCC DAQ software you received with the device, and includes information about installing

the software. Please read this booklet completely before installing any software or hardware.

Unpacking

As with any electronic device, take care while handling to avoid damage from static electricity. Before

removing the USB-1208HS from its packaging, ground yourself using a wrist strap or touch either the computer

chassis or other grounded object to eliminate any stored static charge. If the device is damaged, notify

Measurement Computing Corporation immediately by phone, fax, or email.

Knowledgebase: kb.mccdaq.com

Phone: 508-946-5100 and follow the instructions for reaching Tech Support

Fax: 508-946-9500 to the attention of Tech Support

Email: techsupport@mccdaq.com

For international customers, contact your local distributor. Refer to the International Distributors section on our

web site at www.mccdaq.com/International.

Installing the software

Refer to the Quick Start Guide for instructions on installing the software on the MCC DAQ CD. This booklet is

available in PDF at www.mccdaq.com/PDFmanuals/DAQ-Software-Quick-Start.pdf.

Installing the hardware

Be sure you are using the latest system software

Before you install the device, run Windows Update to update your operating system with the latest USB drivers.

Install the MCC DAQ software before you install your board

The driver needed to run your board is installed with the MCC DAQ software. Therefore, you need to install the

software before you install your board. Refer to the Quick Start Guide for instructions.

To connect the USB-1208HS to your system, turn your computer on, and connect the USB cable to a USB port

on your computer or to an external USB hub connected to your computer. The USB cable provides power and

communication to the USB-1208HS.

When you connect the USB-1208HS for the first time, a Found New Hardware dialog opens when the

operating system detects the device. The Status LED turns on; this indicates that communication is established

between the device and the computer. Refer to Figure 2 on page 9 for the location of the Status LED. When the

dialog closes, the installation is complete.

USB-1208HS User's Guide Installing the USB-1208HS

Caution! Do not disconnect any device from the USB bus while the computer is communicating with the

USB-1208HS, or you may lose data and/or your ability to communicate with the USB-1208HS.

If the Status LED turns off

The Status LED turns off if communication is lost between the device and the computer. To restore

communication, disconnect the USB cable from the computer and reconnect it. The Status LED should turn on.

Calibrating the USB-1208HS

The USB-1208HS is shipped fully calibrated. Calibration coefficients are stored in EEPROM.

Return the device to Measurement Computing Corporation when calibration is required. The normal calibration

interval is once per year.

Chapter 3

Functional Details

Analog input acquisition modes

The USB-1208HS can acquire analog input data in two basic modes – software paced and hardware paced.

Software paced mode

You can acquire one analog sample at a time in software paced mode. You initiate the A/D conversion by

calling a software command. The analog value is converted to digital data and returned to the computer. You

can repeat this procedure until you have the total number of samples that you want.

The throughput sample rate in software paced mode is system-dependent, and can range from 33 S/s to

4000 S/s.

Hardware paced mode

You can acquire data from up to eight channels in hardware-paced mode. The analog data is continuously

acquired, converted to digital values, and written to an onboard FIFO buffer on the USB-1208HS until you stop

the scan. The FIFO buffer is serviced in blocks as the data is transferred from the USB-1208HS FIFO buffer to

the memory buffer on your computer.

The maximum sample rate is 1 MS/s aggregate over one-to-eight channels. You can start a continuous scan with

either a software command or with an external hardware trigger event.

External components

The USB-1208HS has the following external components, as shown in Figure 2.

Screw terminals

LED indicators

USB connector

1 Screw terminal pins 1 to 28 4 Activity LED

2 Screw terminal pins 29 to 56 5 USB connector

3 Status LED

Figure 2. External components

USB-1208HS User's Guide Functional Details

Screw terminals

The differential mode pinout is shown in Figure 3.

Figure 3. Differential mode pinout

The single-ended mode pinout is shown in Figure 4.

Figure 4. Single-ended mode pinout

Use 16 AWG to 30 AWG for signal connections.

Indice

Altri manuali Measurement Computing Sistema I/O

Measurement Computing

Measurement Computing USB-DIO96H Manuale utente

Measurement Computing

Measurement Computing USB-3106 Manuale utente

Measurement Computing

Measurement Computing USB-234 Manuale utente

Measurement Computing

Measurement Computing USB-1408FS-Plus Manuale utente

Measurement Computing

Measurement Computing USB-1208FS-Plus Manuale utente

Measurement Computing

Measurement Computing USB-DIO24 Manuale utente

Measurement Computing

Measurement Computing E-DIO24 Manuale utente

Measurement Computing

Measurement Computing PCI-DAC6702 Manuale utente

Measurement Computing

Measurement Computing USB 1024ls Manuale di istruzioni

Measurement Computing

Measurement Computing USB-1616FS Manuale utente

Measurement Computing

Measurement Computing USB-1608FS Manuale utente

Measurement Computing

Measurement Computing USB-1208FS Manuale utente

Measurement Computing

Measurement Computing USB-231-OEM Manuale utente

Measurement Computing

Measurement Computing PCIe-DIO24 Manuale utente

Measurement Computing

Measurement Computing PCI-DIO96 Manuale utente

Measurement Computing

Measurement Computing USB-1408FS-Plus-OEM Manuale utente

Measurement Computing

Measurement Computing PCI-DIO24 Manuale utente

Measurement Computing

Measurement Computing PCI-DAS4020/12 Manuale utente

Measurement Computing

Measurement Computing PCIM-DDA06/16 Manuale utente

Measurement Computing

Measurement Computing miniLAB 1008 Manuale utente

Measurement Computing

Measurement Computing PC-CARD-DAC08 Manuale utente

Measurement Computing

Measurement Computing PCI-DAS6013 Manuale utente

Measurement Computing

Measurement Computing E-DIO24-OEM Manuale utente

Measurement Computing

Measurement Computing USB-3103 Manuale utente

Manuali Sistema I/O popolari di altre marche

WAGO

WAGO 750-344 Manuale utente

Teknim

Teknim TWM-1887 Manuale di istruzioni

Intelligent Appliance

Intelligent Appliance IA-2662-E Manuale utente

BERGHOF

BERGHOF ECC DIO 16/16 Manuale di istruzioni

Advantech

Advantech PCM-27J3AU Manuale di installazione e funzionamento

Festo

Festo CP-E08-M12-CL Manuale utente

Hitachi

Hitachi HX-RIO3 Series Manuale utente

NUUO

NUUO SCB-A08 Manuale utente

M-system

M-system R3Y-RS8 Manuale utente

jablotron

jablotron JB-110N Manuale utente

Omron

Omron SYSMAC C200H Manuale utente

DOLD

DOLD SAFEMASTER M Manuale utente

ABB

ABB OPT-MF-001 Manuale utente

Omron

Omron SYSMAC C2000H Manuale utente

Helmholz

Helmholz TB20 Manuale utente

ICP DAS USA

ICP DAS USA tM-AD2 Manuale utente

Automationdirect.com

Automationdirect.com DL305 Manuale utente

WAGO

WAGO I/O-SYSTEM 750 Manuale utente
