MENEGOTTI MPT 36 Manuale utente

Point your cell phone or tablet camera

to access the updated version of

Technical Manuals

and

Parts

Catalogs

online, or click the link below

to access the website.

QR-Code:

www.sites.google.com/view/menego-engenharia-docs

MENEGOTTI TECHNICAL MANUAL

Attention:

Illustrave images.

POWER TROWEL

MPT 36 | MPT 46

40730148 - Power Trowel MPT 36 without Engine (Prepared for Honda GX160 Engine)

40730149 - Power Trowel MPT 36 with Menego 200 6,5hp Engine

40730158 - Power Trowel MPT 46 with Menego 270 9,0hp Engine

40730159 - Power Trowel MPT 46 without Engine (Prepared for Honda GX270 Engine)

Before operate

Menego

equipament, read this

Technical Manual

, itself will inform and instruct the

operator about the operaon.

By the way, you avoid possible working accidents

and early maintenance on at the equipment.

Discount-Equipment.com

We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman,

Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto, Power

Blanket, Nifty Lift, Atlas Copco, Chicago Pneumatic, Allmand, Miller Curber, Skyjack, Lull,

Skytrak, Tsurumi, Husquvarna Target, Stow, Wacker, Sakai, Mi-T-M, Sullair, Basic, Dynapac,

MBW, Weber, Bartell, Bennar Newman, Haulotte, Ditch Runner, Menegotti, Morrison, Contec,

Buddy, Crown, Edco, Wyco, Bomag, Laymor, EZ Trench, Bil-Jax, F.S. Curtis, Gehl Pavers, Heli,

Honda, ICS/PowerGrit, IHI, Partner, Imer, Clipper, MMD, Koshin, Rice, CH&E, General Equip-

ment ,Amida, Coleman, NAC, Gradall, Square Shooter, Kent, Stanley, Tamco, Toku, Hatz,

Kohler, Robin, Wisconsin, Northrock, Oztec, Toker TK, Rol-Air, APT, Wylie, Ingersoll Rand /

Doosan, Innovatech, Con X, Ammann, Mecalac, Makinex, Smith Surface Prep,Small Line,

Wanco, Yanmar

Discount-Equipment.com is your online resource for

commercial and industrial quality parts and equipment sales.

561-964-4949

visit us on line @ www.discount-equipment.com

TO PURCHASE THIS PRODUCT PLEASE CONTACT US

Select an option below to find your Equipment

Equipment Financing and

Extended Warranties Available

Discount-Equipment.com

Index

Aenon: For beer comodity, store and keep this manual in a properly

spot so it can be easily checked.

Aer sales Departament

and Technical Assistance MENEGOTTI.

With the highest quality, projected and built especially to serve your

needs.

This manual was elaborated to provides the informaons and key instruc-

ons to use and mantain our product, in addicon presents their technical

characteriscs.

Before use the product for the ﬁrst me, read and pay aenon at the

informaons in this manual.

The product durability only depends the way you treat it in service (opera-

on) and the sasfactory working is consequence of yours regular work

carefully.

Menego is preparaded to oﬀer you all technical assistance, and aend

all your needs about replacement parts.

Welcome, you are part of the huge Menego “customers familiy”.

Congratulaons, you have just purchased a Menego product!

Menego Group

The Product

Safety Informaon

Component and Control Localizaon

Product Dimensions

Technical Speciﬁcaons

Machine Inspecon

Assembly and Installaon of the Components

Starng the Engine

Turning oﬀ the Engine

Machine Operaon

Periodic Maintenance Plan

Machine Transport

Machine Lubricaon

Troubleshoong

Product Warranty

Warranty Term

Discount-Equipment.com

The Product

Menego is reference in the development of soluons in machines and tools for the Construcon

machinery, Handling and Lawn | Garden Segments.

A Brazilian company, present in more than 40 countries, has its headquarters in Jaraguá do Sul, Santa

Catarina, units in Brazil and in the United States.

With more than 80th years of history, it is in the fourth generaon of consistent and successful family

management.

Naonal leader in sales of concrete and cement mixers, it stands out in the resale and rental market.

Through its Innovaon Program, it fosters creavity and compeveness, with disrupve acons and

partnerships, aimed at connuous professional and business growth.

With an organizaonal culture that values and encourages its constant professional and personal develop-

ment, Menego is acve in sustainable projects, which make its purpose of contribute “to build a beer

and more sustainable world”, a reality.

Menego Group

The Power Trowel MPT was developed exclusively for smoothing and ﬁnishing concrete ﬂoors where greater speed and uniformity in the surface ﬁnish is

required. The equipment performs the smoothing and straightening of the concrete ﬂoor by means of the circular rotaon of the trowel blades.

• Menego reserves the right to make changes to the products without prior noce. Illustraons may include oponal equipment and accessories, which

may not be included in all standard equipment. If any informaon in this manual is not consistent with the physical product, consider the current product

and manual for reference only.

For more up-to-date informaon, just access our website: hps://sites.google.com/view/menego-engenharia-docs, or use the QR code on the cover

of this manual.

Main features:

* Construcve shape of the gearbox guarantees a long service life;

* Its more robust design guarantees a superior ﬁnish;

* Adjustable handlebar height, ensuring operator comfort and ease of equipment control;

* It has a handle for liing and a front carrying handle which allows the machine to be carried by only 2 people (with the other person liing by the operang

handlebar);

* It has a safety switch, which allows the engine to stop in case the operator loses control of the equipment;

* It has adjustment of the posioning of the straightening blades.

Discount-Equipment.com

Safety Informaon

See in more detail some features of this equipment:

a) SAFETY SWITCH: Its purpose is to stop the engine in an unstable situaon. Example: if the operator releases the operang handlebars;

b) ADJUSTABLE THROTTLE: This speed control (''push-pull'' buon) can provide a speed between 50 and 130 rpm on the trowels;

c) BLADE FIXING ARM ADJUSTMENT: Allows the blades to be adjusted if the blade ﬁxing arms are damaged, caused by a fall or misuse of the equipment. It

can be easily adjusted in the ﬁeld for a uniform ﬁnish;

d) BLADES PROTECTION GRID: protects the operator and the machine, providing a lower center of gravity, which contributes to the stability and

performance of the trowel;

e) BLADES FIXING ARM SUPPORT: it is more robust to ensure alignment. It also contributes to lowering the center of gravity or increasing blade performance;

f) ADJUSTMENT OF OPERATING HANDLEBAR: can be posioned to provide comfort and control for any operator height;

g) BLADES ANGLE ADJUSTMENT KNOB: adjusts the angle of the blades for diﬀerent stages and condions of concrete curing. Turning the handle clockwise

increases the angle of the blades to the concrete. Turning the handle counterclockwise ﬂaens or decreases the angle of the blades.

This equipment, if not observed the safety recommendaons, presents risks of intoxicaon, burns, crushing and cuts of limbs.

This manual contains notes, cauons and warnings that must be followed to avoid the possibility of misuse, damage to the machine or personal injury.

NOTES: Contains addional informaon for important procedures.

CAUTIONS: Important informaon to prevent errors that could damage the machine or its components.

WARNINGS: Alert you to condions or pracces that could lead to personal injury or even death!

Operaonal Security

For the safe operaon of the equipment, the operator must be trained or qualiﬁed.

Equipment operated improperly, or by unauthorized persons, can be dangerous. Training is the responsibility of the employer and must be provided by a

qualiﬁed professional.

Discount-Equipment.com

* NEVER allow untrained people to operate the equipment;

* ALWAYS read, understand and follow the Instrucon Manual procedures before operang the equipment;

* ALWAYS make sure that the operator is familiar with proper safety precauons and operang techniques before using the equipment.

* NEVER operate the trowel in applicaons it is not intended for;

* NEVER change or disable operaonal and safety funcons;

* NEVER use accessories not recommended by Menego for the trowel. It can cause damage to the equipment and/or injury to the user;

* Menego will NOT be responsible for any accident due to equipment modiﬁcaons. Such changes will void the warranty;

* ALWAYS use cauon and common sense when operang the trowel.

* ALWAYS in case of damaged or missing parts, contact Menego immediately, for replacement;

* ALWAYS with the machine oﬀ, carry out a daily inspecon of the parts of the equipment. In case of problems, immediately contact the

Menego Authorized Service.

* ALWAYS avoid contact with hot surfaces, contact with these areas can cause severe burns;

* ALWAYS before performing any operaon or maintenance, allow the engine to cool down.

* NEVER use the equipment in closed places (without venlaon). Engine exhaust gases contain carbon monoxide; exposure to carbon

monoxide can cause loss of consciousness and can lead to death;

* NEVER ingest fuel or inhale its vapors, and avoid skin contact. In case of skin contact, wash the aﬀected surface immediately. If fuel comes

into contact with operator's eyes, ﬂush immediately with water and seek medical aenon as soon as possible.

* NEVER leave the machine running unaended;

* ALWAYS wear protecve clothing when operang equipment. Wear safety glasses or goggles, ear protecon and safety shoes;

* ALWAYS keep hands, feet and loose clothing away from the moving parts of the equipment.

Discount-Equipment.com

* DO NOT refuel the engine when it is hot or running;

* DO NOT refuel near a conﬁned area, areas with sparks, ﬂames, smoke or any restricted area;

* DO NOT spill fuel when refueling the engine. Always clean up any fuel spills.

* DO NOT smoke when operang the trowel and/or refueling the engine;

* DO NOT smoke near a conﬁned area, areas with sparks, ﬂames, smoke or any restricted area.

* ALWAYS replace the fuel tank cap aer refueling;

* ALWAYS check the fuel hoses, fuel tank cap and fuel tank for leaks before starng the engine. Do not start the machine if there are fuel

leaks or the fuel tank cap or tank is loose.

* ALWAYS turn oﬀ the engine when the trowel is not being operated;

* ALWAYS ALWAYS avoid contact with the exhaust and engine parts, and wait unl it has cooled down before doing any maintenance or

service;

* NEVER use the choke to stop the engine.

WARNINGS:

Services security:

Poorly maintained equipment can become a safety hazard! In order for the equipment to operate safely and properly for a long period of me, periodic

maintenance and occasional repairs are necessary.

* DO NOT aempt to clean or repair the equipment while it is in operaon;

* DO NOT operate the equipment without safety devices and protecons or without operang condions;

* DO NOT operate the equipment without the air ﬁlter;

* DO NOT remove the air ﬁlter element, pre-ﬁlter or air ﬁlter cover while the equipment is operang, as this may damage the engine;

* DO NOT allow anyone to stand or lean on the machine during operaon;

* ALWAYS stop the engine and disconnect the spark plug wire before doing any procedure;

* ALWAYS keep the safety switch set and in good operang condion at all mes. Do not use the Power Trowel if this switch is not working. The equipment

will automacally stop if the operator loses control of it;

* ALWAYS make sure the safety stop switch has the lever released (in the down posion) before starng to use the Power Trowel. Keep your hands ﬁrmly

on the operang handlebars while operang the equipment;

*ALWAYS perform periodic maintenance as recommended in the Instrucon Manual.

WARNINGS:

Discount-Equipment.com

BLADE HEIGHT

ADJUSTMENT RATCHET

BLADE LOAD ADJUSTMENT

OPERATING

HANDLEBAR

RATCHET

HANDLEBARS

(OPTIONAL - SOLD SEPARATELY)

Component and Control Localizaon

*In case of losing machine control or

emergency, acvate the safety switch, it

will stop the engine automacally.

The safety switch, has an automac

actuaon system in case of losing control

of the machine.

FRONT

CARRYING

HANDLE

TROWELS BLADES

PROTECTION

GRID

THROTTLE ERGONOMIC HANDLEBAR

OPERATING

HANDLEBAR

ERGONOMIC

HANDLEBAR

ADJUSTMENT

*SAFETY

SWITCH

BLADES ANGLE

ADJUSTMENT KNOB

Discount-Equipment.com

Product Dimensions

1085

1024

601

2078

SIDE VIEW

MPT 36

TOP VIEW

1100

711

1183

2184

MPT 46

SIDE VIEW

TOP VIEW

Discount-Equipment.com

Inspecon must be performed before each operaon of the equipment and in accordance with the maintenance plan. For more informaon, consult the

maintenance secon. If one of the following items is found, the error must be corrected before using the equipment.

1. Read the trowel manual and also the engine manual equivalent to the equipment purchased;

2. Analyze if there are signs or defects present in the equipment, verify that all protecons are posioned in their correct places;

3. Check the engine and gearbox oil level, top up if necessary. The engine will not start without oil. The Power Trowel blades are already lubricated;

4. Check the fuel level and top up if necessary. Always use clean fuel. The use of adulterated fuel can damage the fuel system, make an adequate supply to

avoid a risk of ﬁre. Do not mix oil with gasoline;

5. Check for oil and fuel leaks;

6. Check that the air ﬁlter is clean. Excessive dust in the ﬁlter will cause the engine to not work under normal condions and cause damage to the engine;

7. Check if the blades are correctly ﬁxed;

8. Perform a visual inspecon of the trowel. Check that all screws are ght and the mechanical components are in perfect working order;

9. The safety stop switch must operate freely and must always be kept in that state;

10. With the key in the OFF posion, the engine must not start or run.

Machine Inspecon

Technical Speciﬁcaons

SPECIFICATIONS
