4 5
TOOLS INCLUDED:
F5 mm Allen Wrench
F4 mm T-Wrench
PARTS INCLUDED:
F1 Safety Key
F2 Frame Extention Tubes
F1 Console Assembly
F2 Console Masts
F1 Water Bottle Holder
F2 Hand Grips
F1 Deck Lock Pin
F2 End Caps
F4 Hardware Bags
F1 Bottle of Silicone Lubricant
(for 2 applications)
If you have questions or if
there are any missing parts,
contact Customer Tech
Support. Contact information
is located on the back panel
of this manual.
DO NOT ATTEMPT TO LIFT THE TREADMILL! Do not move or lift treadmill
from packaging until specified to do so in the assembly instructions. You may
remove the plastic wrap from console masts.
WARNING
UNPACKING
Place the treadmill carton on a level flat surface. It is recommended that you place a
protective covering on your floor. Take CAUTION when handling and transporting this
unit. Never open box when it is on its side. Once the banding straps have been removed,
do not lift or transport this unit unless it is fully assembled and in the upright folded
position, with the lock latch secure. Unpack the unit where it will be used. Never grab
hold of any portion of the incline frame and attempt to lift or move the treadmill.
FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN INJURY!
WARNING
NEED HELP?
NOTE: During each assembly step, ensure that ALL nuts and bolts are in place and
partially threaded in before completely tightening any ONE bolt.
NOTE: A light application of grease may aid in the installation of hardware. Any grease,
such as lithium bike grease is recommended.
PRE ASSEMBLY
GRIP PULSE HANDRAILS
ON/OFF SWITCH
CIRCUIT BREAKER
TRANSPORT WHEEL
FRAME EXTENSION TUBE
CUSHIONING
POWER CORD
RE ADING RACK
TOUCH PAD PANEL
ATTACHSAFETY KEY CLIP TO CLOTHING BEFORE STARTING. TO
AVOID INJURY,STAND ON THE SIDE RAILS BEFORE STARTING
TREADMILL. READ AND FOLLOW ALL INSTRUCTIONS BEFORE
OPERATING. KEEP CHILDREN AWAYFROM THIS EQUIPMENT.
REMOVE SAFETY KEY WHEN NOT IN USE AND STORE OUT OF
REACH OF CHILDREN. CONSULTA PHYSICIAN BEFORE USING
THIS EQUIPMENT.STOP EXERCISING IF YOU FEEL PAIN, FAINT,
DIZZY OR SHORT OF BREATH.FOR CONSUMER USE ONLY.
WARNING
CAUTION AVERTISSEMENT PRECAUCIÓN
KEEP HANDS AND FEET
AWAYFROM THIS AREA.
GARDER LES MAINS ET LES
PIEDS LOIN DE CETTE REGION.
MANTENGA LAS MANOS Y LOS
PIES LEJOS DE ESTA AREA.
CAUTION AVERTISSEMENT PRECAUCIÓN
HOLD ONTO DECK WHEN
LATCH IS RELEASED.
GARDER LES MAINS ET LES PIEDS
LOIN DE CETTE RÉGION.
SUJETE LA PLATAFORMA
CUANDO VAYABAJANDO.
WATE R BOTTLE HOLDER
CONSOLE
SAFETY KEY PLACEMENT
RUNNING BELT / RUNNING DECK
SIDE R AIL
ROLLE R END CAP
CONSOLE MAST
HANDLEBARS
RE AR ROLLER
ADJUSTMENT BOLTS
MOTOR COVER
DECK LOCK PIN
SUJETE LA LLAVE DE SEGURIDAD A SU ROPAANTES DE COMENZAR.
PARA EVITARACCIDENTES PARESE EN LO RIELES ANTES DE
COMENZAR. LEA CUIDADOSAMENTE EL MANUAL DE USUARIO Y
CONSULTEA SU MEDICO ANTES DE COMENZAR. MANTENGA EL
PRODUCTO FUERA DEL ALCANZE DE LOS MENORES. QUITE LA LLAVE DE
SEGURIDAD CUANDO NO ESTE EN USO. CONSULTARCON UN MEDICO
ANTES DE USAR ESTE EQUIPO. SI SIENTE ALGUN DOLOR O FATIGAPARE
DE INMEDIATO. ESTE EQUIPO ES SÓLO PARAEL USO DEL CONSUMIDOR.
ATTACHERLA PINCE DE LA CLÉ DE SÉCURITÉ AUX VÊTEMENTS AVANT DE COMMENCER.
POUR ÉVITER TOUTES BLESSURES, SE TENIR SUR LES RIDELLES AVANTDE DÉMARRER
LE TAPIS ROULANT.AVANT USAGE, LIRE LE GUIDE D’UTILISATEUR. NE PAS LAISSER CET
ÉQUIPEMENT À LA PORTÉE DES ENFANTS.ENLEVER LA CLÉ DE SÉCURITÉ LORSQUE LE
TAPIS ROULANT N’EST PASUTILISÉ ET LA RANGER HORS DE LA PORTÉE DES ENFANTS.
CONSULTERUN MÉDECIN AVANT D’UTILISER CET ÉQUIPEMENT. ARRÊTER D’UTILISER
L’APPAREILEN CAS DE DOULEUR, D’ÉVANOUISSEMENT, DE VERTIGE OU
D’ESSOUFFLEMENT.POUR USAGE DOMESTIQUE UNIQUEMENT.
PRECAUCIÓN
AVERTISSEMENT
