Metrologic Eclipse MS5145 Manuale utente

MS5145 Eclipse

Honeywell’s MS5145 EclipseTM is a low cost laser-based alternative to

CCD scanners.Its compact form factor and high end feature set simplify

its use in a variety of applications at the press of a button.

Eclipse is a single-line, hand-held laser scanner. Equipped with Honeywell’s

patented CodeGate

®technology, Eclipse can be used in a wide variety

of applications. CodeGate

®technology allows the user to easily target

the desired bar code and complete data transmission with the press of a

single button.This makes Eclipse a perfect selection

for menu scanning,

point-of-sale, document processing and inventory control.

With Honeywell’s state-of-the-art scanning technology, the MS5145

Eclipse has a longer working range and a wider scan ﬁeld than a typical

CCD. The width of the scan line grows as the scanner moves further

away from bar codes.

CodeSense

®is a unique feature employed by Eclipse in the absence

of infrared object detection. It provides the user with a pulsing laser

line for bar code detection. When a bar code is detected, the laser line

switches to a constant state to allow for scanning via CodeGate

®.

For more information on the MS5145 Eclipse single-line laser scanner,

please visit www.honeywell.com/aidc

Single-Line Laser Scanner

Code• Gate: Zero in on desired code and complete data

transmission with the push of a single button—ideal for

menu scanning applications

Code• Sense: Automatically wakes scanner from sleep

mode when a bar code is detected

Powerlink Cables:• Uses the same user-replaceable

cables and power supplies as Voyager®and Orbit®

Flash ROM:• Protects POS investment with free ﬁrmware

updates via MetroSet2 software and standard PC

OPOS and JPOS System Compatible:• Easily adaptable

to any end-user system environment

Features

Security & Data Collection

Honeywell Scanning & Mobility

Honeywell

90 Coles Road

Blackwood, NJ 08012

856.228.8100

www.honeywell.com

For more information:

www.honeywell.com/aidc

RoHS

2002/95/EC

MS5145 Eclipse Technical Speciﬁcations

Operational

Light Source Visible Laser Diode 650 nm ± 10 nm

Audible Indicators 7 tones or no beep

Visual Indicators Green = ready to scan; Red = good read

Host System Interfaces USB, RS232, Keyboard Wedge, IBM 468xx (RS485)

Mechanical

Dimensions (LxWxH) 169 mm x 63 mm x 51 mm (6.7˝ x 2.5˝ 2.0˝)

Weight 100 g (3.5 oz)

Electrical

Input Voltage 5 VDC ± 0.25 V

Operating Power 675 mW (125 mA @ 5 V) - typical

DC Transformers Class 2: 5.2 VDC @ 1 A

Laser Class Class 1: IEC60825-1, EN60825-1

EMC FCC Part 15, ICES-003, EN55022 Class B

Environmental

Operating Temperature 0°C to 40°C (32°F to 104°F)

Storage Temperature -40°C to 60°C (-40°F to 140°F)

Humidity 5% to 95% relative humidity, non-condensing

Drop Designed to withstand 1.5 m (5´) drops

Environmental Sealing Sealed to resist airborne particulate contaminants

Light Levels 4842 Lux (450 foot-candles)

Scan Performance

Scan Pattern Single scan line

Scan Speed 72 scan lines per second

Scan Angle Horizontal: 50°

Print Contrast 35% minimum reﬂectance difference

Tilt, Pitch, Skew 42°, 68°, 52°

Decode Capability Code 39, Code 93, Code 128, UPC/EAN/JAN, Code 2 of 5, Code 11, Codabar, MSI Plessey, GS1 DataBar,

Telepen, Trioptic

Typical Performance*

Narrow Width Depth of Field

5.2 mil 0 mm - 51 mm (0˝ - 2.0˝)

7.5 mil 0 mm - 76 mm (0˝ - 3.0˝)

10.4 mil 0 mm - 108 mm (0˝ - 4.0˝)

13 mil 0 mm - 140 mm (0˝ - 5.5˝)

26 mil 25 mm - 178 mm (1.0˝ - 7.0˝)

*Resolution: 4 mil (0.102 mm)

*Performance may be impacted by bar code

quality and environmental conditions
