Microbit AS-1289 Manuale utente

USER MANUAL

m crob t

AS-1289

Ba-AS1289-PA1 (reparerad)

User manual

Rev. PA1 –2014 feb 17

1 of 46

AS-1289

Remote controlled Antenna switch

Preliminary

USER MANUAL

m crob t

AS-1289

Ba-AS1289-PA1 (reparerad)

User manual

Rev. PA1 –2014 feb 17

2 of 46

Table of contents

Statement of Conditions..............................................................................3

General Description.....................................................................................4

Step by step AS-1289 setup ........................................................................5

Hardware ....................................................................................................7

Back ............................................................................................................. 7

Front ............................................................................................................ 8

Configuration with Microbit Setup Manager ..............................................10

FW/HW ....................................................................................................... 11

FW update................................................................................................... 12

Setup ......................................................................................................... 13

Net info....................................................................................................... 14

Initial IP setup ..........................................................................................15

Configuration with WEB-interface .............................................................19

Set Antennas ............................................................................................... 21

Temperature/RH .......................................................................................... 22

IP Settings .................................................................................................. 23

Antenna settings .......................................................................................... 26

Serial Settings ............................................................................................. 27

Advanced settings ........................................................................................ 28

Dynamic DNS setting.................................................................................... 30

Remoterig dynamic dns service...................................................................... 31

DynDNS dynamic DNSservice ........................................................................ 33

Ping Settings ............................................................................................... 35

Radio RRC Settings....................................................................................... 37

Antenna selection......................................................................................... 38

Application firmware upgrade ........................................................................ 39

Bootloader firmware upgrade......................................................................... 40

Restart device.............................................................................................. 40

Networks and Firewalls.............................................................................41

Portforwarding ............................................................................................. 42

Appendix D - Technical Data .....................................................................44

Appendix E - Safety and Regulatory Information ......................................45

FCC Statement ............................................................................................ 45

Safety Notice ............................................................................................... 45

Disclaimer ................................................................................................... 46

FCC / CE - Declaration of conformity............................................................... 46

USER MANUAL

m crob t

AS-1289

Ba-AS1289-PA1 (reparerad)

User manual

Rev. PA1 –2014 feb 17

3 of 46

Statement of Conditions

In the interest of improving internal design, operational function, and/or reliability, Microbit

2.0 AB reserves the right to make changes to the product described in this document without

notice. Microbit does not assume any liability that may occur due to the use or application of

the product(s) or circuit layout(s) described herein.

All parts of the software are property of Microbit 2.0 AB. The hardware design, schematics

PCB layout, concept, graphics, user manual, etc. are property of Microbit 2.0 AB. The device

may not be disassembled, copied or reversed engineered.

Microbit 2.0 AB

USER MANUAL

m crob t

AS-1289

Ba-AS1289-PA1 (reparerad)

User manual

Rev. PA1 –2014 feb 17

4 of 46

General Description

The Antenna switch is designed specially to be used for remote (over the Internet) controlled

systems, but can of course be used in other applications also. The switch can be manually

controlled via an internal web interface. The switch is connected to the Internet primarily via

10 or 100 Mbit Ethernet and fixed connections like DSL, cable and WLAN or 3G/4G Mobile

systems. The Switch is easily configured via modern USB and WEB based user interfaces.

Together with Remoterig RRC-1258 it can be setup to automatically follow your band

changes. The switch connects to the RRC over IP, no serial port is needed. It’s powered with

12V DC. The switch should be placed indoor on a table/shelf or mounted on the wall. It’s

normally delivered with SO-239 connectors, but can be ordered with N-connectors, both with

PTFE dielectric.

USER MANUAL

m crob t

AS-1289

Ba-AS1289-PA1 (reparerad)

User manual

Rev. PA1 –2014 feb 17

5 of 46

Step by step AS-1289 setup

Below follows a recommendation about how to proceed when setting up the system.

1. Spend some time to read thru this user manual to get familiar with the product.

2. Remove the top cover of your Antenna Switch.

3. Check that the Jumper JMPx is in the EXT position.

4. Apply 12V DC (good stabilized power) to the unit, either via the 2.1/5,5 DC-jack (see

hardware chapter)

5. Connect the unit with a CAT5 patch cables to the same Ethernet switch or router as

your PC which you will use to setup the system is connected. Do not bother with the

cables through the inlet in the bottom of the Antenna switch until you have set it up

and tested that you can control it via the web browser.

6. Download the Microbit Setup Manager and the latest firmware from

http://www.remoterig.com to your PC. Follow the instructions about how to install the

Microbit Setup Manager (see chapter Configuration with Microbit Setup Manager).

7. Find out how your network is configured and configure the AS-1289 to fit into your

network (see chapter Initial IP Setup) with the Microbit Setup Manager.

8. Check the installed firmware version. If the one you downloaded from Remoterig is

newer, update the unit with the new firmware. (see chapter FW/HW about how to

update).

9. When you have configured the unit to fit into your network, Start your Web browser

and connect to the unit by entering the IP-address. If you get in contact with the

internal web server everything is OK.

10. Make the basic software configuration for your system which is described the later in

this user manual.

11. After preparing the cables connect them to the controlled equipment. Connect the

power to all equipment. Check with your web browser again that you are in contact

with unit and can control the connected equipment.

12. When everything works as it should on your local network it’s time to setup your

Internet router so you can reach the unit from the outside world over the Internet. If

you already have other equipment that you remote control you can go direct to 14 as

you don’t need to use a separate Dynamic DNS service.

13. The first thing is to determine if your Internet Service Provider (ISP) are providing you

with a fixed or dynamic IP-address. Fixed IP:s are rare so you probably have a

dynamic IP-address if you are not paying extra for a fixed one. A dynamic IP is no

USER MANUAL

m crob t

AS-1289

Ba-AS1289-PA1 (reparerad)

User manual

Rev. PA1 –2014 feb 17

6 of 46

problem but you need to use a dynamic DNS service. You can use Remoterigs free

dynamic DNS service or a DynDNS account. New DynDNS account are no longer free.

For detailed information about Dynamic DNS services see the Dynamic DNS chapters

under Configuration with WEB-Interface.

14. Configure the units Dynamic DNS settings (see chapter Dynamic DNS Setting).

15. Now it’s time to configure your remote router. We recommend that you first enable the

remote configuring of your router, you may need it later. After that’s done configure

port forwarding (see chapter Network and Firewalls). When this is done your remote

control unit should be reachable over the Internet.

16. When back at the Control QTH try to browse to the Dynamic DNS address “Own host

name” you registered and entered into the remote control unit. You should get in

contact with the Antenna Switch internal web server exactly as it was local, remember

to use :port number after the dynamic dns address if you have changed the webserver

port from 80 for example http://sm2oan.dnsalias.com:8000.

Enjoy the remote controlling.

USER MANUAL

m crob t

AS-1289

Ba-AS1289-PA1 (reparerad)

User manual

Rev. PA1 –2014 feb 17

7 of 46

Hardware

Back

On the bottom side the antenna connectors are located according to the pictures above. The

antenna switch is normally delivered with SO-239 jack but can also be ordered with N

connectors.

Power

The Antenna switch should be powered via the 2.1/5.5 DC jack on the back of the AS1289.

Pin no

PWR

+ 12-15VDC (centre)

GND

12V DC

USER MANUAL

m crob t

AS-1289

Ba-AS1289-PA1 (reparerad)

User manual

Rev. PA1 –2014 feb 17

8 of 46

Front

USB

The USB-interface is used to initially set up the IP parameters. It can also be used for

downloading new software (can also be done via the WEB-interface). A USB-cable is included

with the product.

ETHERNET

The unit can be connected to both 10 and 100 Mbit/s Ethernet based TCP/IP network. The

Antenna Switch can be configured for different connection types for Ethernet port, Auto,

10HDX, 10FDX, 100HDX, 100FDX and Auto-with-preferred-10FDX. Default is Auto-with-

preferred-10FDX which works best in most cases. Use good quality screened cable (FTP).

Ethernet (RJ45)

Orange/white

Out [+]

Orange

Out [-]

Green/White

In [+]

Blue

Blue /White

Green

In [-]

Brown/White

Brown

USER MANUAL

m crob t

AS-1289

Ba-AS1289-PA1 (reparerad)

User manual

Rev. PA1 –2014 feb 17

9 of 46

ANT 1-5 LED

A red LED indicate the selected antenna

ANT5/ON LED

A Green flashing LED is indicating normal status. (Visible through ANT5 hole)

LINK LED

A yellow LED besides the Ethernet connector indicates the status of the Ethernet interface

LNK

Yellow LED indicates link OK, flashing LED indicates traffic

USER MANUAL

m crob t

AS-1289

Ba-AS1289-PA1 (reparerad)

User manual

Rev. PA1 –2014 feb 17

10 of 46

Configuration with Microbit Setup Manager

The initial settings of the network parameters are easiest done with the Microbit Setup

Manager. The Setup Manager is a software which runs under Windows on a PC and connects

to the RC via USB (an USB cable is supplied with the AS-1289).The Setup Manager can be

used for:

IP Settings and verification

oIP-address

oNetmask

oGateway

oDNS

oDHCP

Firmware upgrade

oApplication

oBootloader

oFactory default reset

Start with downloading the Microbit Setup Manager from the homepage www.remoterig.com.

Install the Setup Manager by following the instructions which shows up. If you have an older

Windows version where Netframework 2.0 is not installed, the installer will guide you through

the installation of Netframework. When you have finished the installation a new shortcut to

Microbit Setup Manager will show up on the desktop. Click on the icon to start Microbit Setup

Manager

Connect your AS1289 to 12V and connect the USB-cable between your computer and the USB

jack on the AS1289. Windows will automatically install the necessary drivers. When it's done

the text in the bottom field will change from "Device not connected" to "Device connected"

which is an indication that you are in connection with the unit.
