MicroLux ML880BK Manuale utente

REFRIGERATOR

INSTRUCTION

ANUAL

Model No.:

ML880BK /

ML880WH

Table of contents

SAFETY PRECAUTIONS 3

PARTS AND FEATURES 6

INSTALLING YOUR REFRIGERATOR 7

UNPACKING YOUR REFRIGERATOR 7

LEVELING YOUR REFRIGERATOR 7

PROPER AIR CIRCULATION 7

ELECTRICAL REQUIREMENT 8

USE OF EXTENSION CORDS 8

INSTALLATION LIMITATIONS 8

DOOR ALIGNMENT 9

REVERSING THE DOOR 9

REFRIGERATOR FEATURES AND USE 11

ADJUSTABLE TEMPERATURE DIAL 11

FREEZER COMPARTMENT / USE OF ICE CUBE TRAYS 11

REFRIGERATOR INTERIOR SHELVES 12

USING THE DISPENSE-A-CAN™ 12

CRISPER 12

DEFROSTING YOUR REFRIGERATOR 13

FOOD STORAGE INFOR ATION 14

NOR AL OPERATING SOUNDS YOU AY HEAR 15

PROPER REFRIGERATOR CARE AND CLEANING 15

DOOR GASKETS 15

LIGHTBULB REPLACE ENT 15

POWER INTERRUPTIONS 16

VACATIONS AND OVING CARE 16

TROUBLESHOOTING 17

SAFETY PRECAUTIONS

WARNING: Read all of the instructions before using this appliance.

When using this appliance, always exercise basic safety precautions,

including the following:

NOTE: If the refrigerator/freezer has been placed in a horizontal or tilted position

for any period of time wait 24 hours before plugging the unit in.

1. Only use this appliance for its intended purpose as described in this manual.

2. This refrigerator/freezer must be properly installed in accordance with the

installation instructions before it is used. See grounding instructions in the

installation section.

3. This refrigerator/freezer should not be recessed or built-in an enclosed

cabinet. It is designed for freestanding installation only.

4. Repair or replace immediately, all electric service cords that have become

frayed or otherwise damaged. Do not use a cord that shows cracks or

abrasion damage along its length, the plug or the connector end. Never

unplug your refrigerator/ freezer by pulling on the power cord. Always grasp

the plug firmly and pull straight out from the outlet.

5. If your old refrigerator/freezer is not being used, we recommend that you

remove the doors. This will reduce the possibility of danger to children.

6. WARNING: After your refrigerator/freezer is in operation, do not touch the

cold surfaces in the freezer compartment, particularly when hands are damp

or wet. Skin may adhere to these extremely cold surfaces.

7. Do not refreeze foods, which have been thawed completely. The United

States Department of Agriculture in Home and Garden Bulletin No. 69 reads:

"…You may safely refreeze frozen foods that have thawed if they still contain ice

crystals or if they are still cold-below 40°F…Thawed ground meats, poultry, or fish

that have any off-odor or offcolor should not be refrozen and should not be eaten.

Thawed ice cream should be discarded. If the odor or color of any food is poor or

questionable, discard it. The food may be dangerous to eat. Even partial thawing and

re-freezing reduce the eating quality of foods, particularly fruits, vegetables, and

prepared foods. The eating quality of red meats is affected less than that of many

other foods. Use refrozen foods as soon as possible, to save as much of their eating

quality as you can."

SAFETY PRECAUTIONS CONTD.

8. Do not use any electrical device or any sharp instrument in defrosting your

refrigerator.

9. Unplug your refrigerator/freezer before cleaning or before making any

repairs. Note: If for any reason this product requires service, we strongly

recommend that a certified technician perform service.

10. Do not operate your refrigerator in the presence of explosive fumes.

SAVE THESE INSTRUCTIONS

DANGER

Risk of child entrapment. Before you throw away your old refrigerator

or freezer, take off the doors. Leave the shelves in place so that children

may not easily climb inside.

Thank you for purchasing our product. This easy-to-use manual will guide

you in getting the best use of your appliance. Remember to record the model and

serial number. They are on a label in back of the appliances.

Model number: _________________________________

Serial number: _________________________________

Date of purchase: _______________________________

Staple your receipt to your manual. You will need it to obtain warranty service.

PARTS AND FEATURES

1. Interior Light

2. Temperature Control

3. Refrigerator Shelves

4. Crisper

5. Front Leveling Legs

6. Refrigerator Door Shelves

7."Dispense-A-Can™" Storage

8. Freezer Door Shelf

9. Ice Cube Tray

10. Ice Scraper

Installing Your Refrigerator

Unpacking Your Refrigerator

1. Remove all packaging material. This includes the foam base and all

adhesive tape holding the refrigerator accessories inside and outside.

2. Inspect and remove any remains of packing, tape or printed materials before

powering on the refrigerator.

Leveling Your Refrigerator

•Your refrigerator has two leveling legs which are located in the front bottom

corners of your refrigerator. After properly placing your refrigerator in its final

position, you can level your refrigerator.

•Leveling legs can be adjusted by turning them counterclockwise to raise

your refrigerator or by turning them clockwise to lower your refrigerator. The

refrigerator door will close easier when the leveling legs are extended.

Proper Air Circulation

•To ensure your refrigerator works at the maximum efficiency it was designed

for, you should install it in a location where there is proper air circulation,

plumbing, and electrical connections.

•The following are recommended clearances around the refrigerator:

Sides……………3/4" (19mm)

Top....................2" (50mm)

Back..................2" (50mm)

WARNING: ELECTRICAL REQUIRE ENT - SHOCK HAZARD

Electrical Requirement

•Make sure there is a suitable power outlet (120 volts, 15 amp outlet) with

proper grounding to power the refrigerator.

•Avoid the use of three prong adapters or cutting off the third grounding

prong in order to accommodate a two prong outlet. This is a dangerous

practice since it provides no effective grounding for the refrigerator and may

result in shock hazard.

WARNING: USE OF EXTENSION CORDS- POTENTIAL SAFETY HAZARD

Use of Extension Cords

Avoid the use of an extension cord because of potential safety hazards under

certain conditions. If it is necessary to use an extension cord, use only a 3-wire

extension cord that has a 3-blade grounding plug and a 3-slot outlet that will

accept the plug. The marked rating of the extension cord must be equal to or

greater than the electrical rating of the appliance.

DO NOT USE AN EXTENSION CORD LONGER THAN 12 FT.

Installation Limitations

•Do not install your refrigerator in any location not properly insulated or

heated, e.g. garage, etc. Your refrigerator was not designed to operate in

temperature settings below 55° Fahrenheit.

•Select a suitable location for the refrigerator on a hard even surface away

from direct sunlight or heat source, e.g. radiators, baseboard heaters,

cooking appliances, etc. Any floor unevenness should be corrected with the

leveling legs located on the front bottom corners of the refrigerator.

Door Alignment

Freezer Door: (see fig. #1)

1. Remove the top hinge cover.

2. Loosen the top hinge screws using a phillips

head screwdriver.

3. Adjust the door or put a spacer in between

and then tighten the screws.

4. Replace the top hinge cover.

Reversing the Door (See Fig. #4 On Next Page)

1. Remove the top hinge cover. (See Fig. #1)

2. Using screwdriver, loosen and remove the

screws holding the top hinge in place.

3. Remove top hinge and carefully lift off the

freezer door.

4. Remove the screw hole plugs from the

opposite side and insert the plugs in the screw

hole openings of the just removed screws.

5. Open refrigerator Door and unscrew 2 screws

from the center hinge bracket while holding

the open door in place. (See Fig. #2)

6. Remove bracket and lift off refrigerator door

7. While doors are removed unscrew the door stoppers and reinsert on

opposite side of door. (See Fig. #3)

8. Remove the screw hole plugs from the opposite side and insert the plugs in

the screw hole openings of the just removed screws.

9. Remove any loose items in the refrigerator and carefully tilt refrigerator and

lean against wall. Remove both leveling legs and place in a secure area.

10. Loosen the screws holding the lower hinge bracket to the refrigerator door

and remove screws and bracket. Remove leveling leg

11. Remove screws from the other side and insert in the previously removed

screw holes. Remove leveling leg.

12. Remove door pin by turning counter clockwise and reinsert to the underside

of the bracket and tighten.

13. Align bracket and insert (2) remaining screws into the holes provided.

Tighten all the way. Replace leveling legs and place refrigerator upright.

14. Replace washers and cap over pin. Align hole in the refrigerator door with

the door pin and gently push down until firm.

15. Insert pin from center hinge bracket into refrigerator door hole and align

center hinge bracket holes to the screw holes in the cabinet.

16. Insert 2 screws and tighten.

17. Place washers on the center hinge bracket pin and align the freezer door

holes and insert into pin.

18. Replace screws on the top hinge cover, align door and tighten screws.

19. Replace top hinge cover.
