Microsemi PD96XX Series

PD-9606G & PD-9612G

PD-RPS-1000

User Guide

Rev.B01 CPG –Poe BU

One Enterprise Aliso Viejo, CA 92656 USA

Note:

The information contained herein is believed to be accurate and reliable

at the time of printing. However, due to ongoing product improvements

and revisions, Microsemi cannot accept responsibility for inadvertent

errors, inaccuracies, subsequent changes, or omissions of printed

material.

Microsemi reserves the right to make changes to products and to their

specifications as described in this document, at any time, without prior

notice. Do not photocopy or reproduce this material without permission.

Disclaimer

Microsemi assumes no responsibility or liability arising from the use

of Midspans, as described herein, nor does it convey any license

under its patent rights or the rights of others. Applications that are

described herein for any of these products are for illustrative

purposes only. Microsemi makes no representation or warranty that

such applications will be suitable for the specified use without further

testing or modification.

Note:

The information in this guide refers to PD-96xx series of Power over

Ethernet Midspans, unless otherwise stated.

Note that Midspan is designed for indoor use only.

This document is subject to change without notice.

Rev.B01 CPG –Poe BU

One Enterprise Aliso Viejo, CA 92656 USA

Contents

1FRONT MATERIAL..............................................................................5

1.1 Model Numbers Definition:.................................................................... 5

1.2 Electrical Compatibility Approvals ......................................................... 5

1.3 Safety Standard Approvals.................................................................... 5

1.4 CE Marking ........................................................................................... 5

2SAFETY INFORMATION.......................................................................6

2.1 General Guidelines ............................................................................... 6

2.2 Warnings............................................................................................... 6

2.3 Power Cord........................................................................................... 7

2.4 Power Cord Specifications by Country.................................................. 7

3ABOUT THE POWER OVER ETHERNET MIDSPAN..................................9

3.1 10/100/1000BASE-TX Ports Definition................................................ 10

3.1.1 Data Input Ports .................................................................10

3.1.2 Data and Power Output Ports............................................10

3.2 Indicators............................................................................................. 11

3.2.1 Power Indicator LED ..........................................................11

3.2.2 Port Indications...................................................................11

3.3 Connectors.......................................................................................... 13

4POWER OVER ETHERNET MIDSPAN INSTALLATION............................15

4.1 Background Information...................................................................... 15

4.2 Verifying Kit Contents.......................................................................... 15

4.3 Rack Mounting Brackets ..................................................................... 16

4.4 Installation Factors.............................................................................. 16

Rev.B01 CPG –Poe BU

One Enterprise Aliso Viejo, CA 92656 USA

4.5 Connecting Ethernet Cables................................................................17

4.6 Connecting Power Cables....................................................................17

4.7 Powering Up the Unit...........................................................................18

5TROUBLESHOOTING.........................................................................19

5.1 Preliminary Steps.................................................................................19

5.2 Troubleshooting Steps.........................................................................20

6SPECIFICATIONS..............................................................................22

6.1 Physical Specifications ........................................................................22

6.2 Environmental Specifications...............................................................22

6.3 Electrical Specifications .......................................................................23

7MICROSEMI’S POWERVIEW PRO ......................................................24

8POWER BACKUP AND POWER REDUNDANCY CONNECTION ...............26

8.1 Power Redundancy..............................................................................26

8.2 Power Backup......................................................................................26

8.3 Connectors...........................................................................................27

8.4 Connecting Backup and Redundancy Connectors...............................28

8.5 Power Backup and Power Redundancy Indications.............................30

Rev.B01 CPG –Poe BU

One Enterprise Aliso Viejo, CA 92656 USA

1 Front Material

1.1 Model Numbers Definition:

PD-96xxG/ACDC/M: 4 Pairs AC and DC Input family,

where:

oxx: Represents number of ports (6 or 12)

oAC: Midspan has AC input

oDC: Midspan has DC input, current sharing, and power backup

features between two Midspans

oM: Midspan includes PowerView Pro (refer to Section 7)

PD-RPS-AAAA: Redundant Power Supply,

where AAAA represents available power in Watts.

1.2 Electrical Compatibility Approvals

Microsemi 96xxG series complies with the following standards:

FCC Part 15; class UTP cabling

EN 55022 (CISPR 22); class B with UTP cabling

EN 55024 (CISPR 24)

Canadian ICES-003, class B

1.3 Safety Standard Approvals

Microsemi meets the following safety standards:

UL/cUL per CSA/UL 60950-1

GS mark per IEC60950-1

1.4 CE Marking

CE marking on this product indicates this product complies with

89/336/EEC (EMC Directive) and 73/23/EEC (Low Voltage Directive).

Rev.B01 CPG –Poe BU

One Enterprise Aliso Viejo, CA 92656 USA

2 Safety Information

Read the following safety information before using your Power over

Ethernet Midspan unit.

2.1 General Guidelines

Read the following safety information before carrying out any installation,

removal, or maintenance procedure on the Power over Ethernet Midspan.

Warnings contain directions to be followed for the safety of personal and

product. Follow all directions carefully.

2.2 Warnings

Read installation instructions in Section 4 before

connecting Power over Ethernet Midspan to its power

source.

Read instructions in Section 4 before connecting

Midspan-to-Midspan power backup.

Midspan must use a grounded power cord, as defined in

Section 2.3.

This product relies on the building installation for short-

circuit (over-current) protection. Use only a fuse or circuit

breaker not higher than 15A for 120VAC (U.S.), or 10A

for 230VAC (international).

Do not work on the system, connect, or disconnect

cables during periods of lightning.

A voltage mismatch can cause equipment damage and

can pose a fire hazard. If voltage indicated on the label is

different from power outlet voltage, do not connect Power

over Ethernet Midspan to this outlet.

For shelf-mounted equipment, verify surface is stable and

strong enough to support equipment. Do not stack more

than four Power over Ethernet Midspan units.

When disposing this product, follow all local laws and

regulations.

Rev.B01 CPG –Poe BU

One Enterprise Aliso Viejo, CA 92656 USA

"DATA" and "DATA & POWER" ports of the Power over

Ethernet Midspan are shielded RJ-45 data sockets. They

cannot be used as Plain Old Telephone Service (POTS)

sockets. Only connect RJ-45 data connectors to these

sockets.

Associated Ethernet wiring shall be limited to the inside

of the building.

2.3 Power Cord

In case power cord is replaced, replacement must meet local

requirements.

To ensure a reliable connection to an AC mains supply,

equipment provides an appliance IEC60320 inlet used for

connecting a detachable power supply cord.

Power socket outlet must be located near Midspan and

easily accessible. The only way of removing power from

unit is by disconnecting the power cord from the outlet

This unit operates under SELV (Safety Extra Low

Voltage) conditions, according to EN60950-1/IEC60950-

1. Conditions are maintained only if the equipment to

which unit is connected also operates under SELV

conditions.

2.4 Power Cord Specifications by Country

U.S.A. and

Canada

Cord must be UL-approved or CSA certified.

Minimum specification for flexible cord is:

oNo. 18 AWG

oType SV or SJ

oThree-conductor

Cord set must have a rated current capacity

of at least 13A for PD-9612G/ACDC/M, PD-

9606G/ACDC/M;

Attachment plug must be an earth-grounding

type with a NEMA 5-15P (15A, 125V) or

NEMA 6-15P (15A, 250V) configuration.

Rev.B01 CPG –Poe BU

One Enterprise Aliso Viejo, CA 92656 USA

Denmark

Supply plug must comply with section 107-2-D1, standard

DK2-1a or DK2-5a.

Switzerland

Supply plug must comply with SEV/ASE 1011.

France and

Peru

IT supplies cannot power this unit. If your supplies are an

IT type, unit must be powered by 230V (2P+T) via an

isolation transformer with a 1:1 ratio, and with secondary

connection point labeled Neutral and connected directly to

ground.

U.K

Power over Ethernet Midspan is covered by General

Approval NS/G/12345/J/100003, for indirect connection to

a public telecommunications system.

Rev.B01 CPG –Poe BU

One Enterprise Aliso Viejo, CA 92656 USA

3 About the Power over Ethernet

Midspan

Microsemi’s family of Power over Ethernet Midspans 96xx inject power

over data-carrying Ethernet cabling. Employing these devices reduces the

need for AC outlets, local UPS and AC/DC adapters near PDs.

PD-9606G/9612G Midspans support 6 and 12 ports respectively, in a

10/100/1000BaseTx Ethernet network, over TIA/EIA-568 category 5/5e/6

cabling. 96xxG family can provide up to 95W according to the new PoH

(Part of HDBaseT) standard. 96xxG series implements a Twin High (TH)

PSE system, delivering 47.5W over 2 pairs (total 95W). DC power is fed

over both spare and data pairs of wires within a cable (1/2, 3/6, 4/5, and

7/8) to terminal units.

RPS family can provide backup or additional power to PD-96xxG

products.

Power over Ethernet Midspan normally powers devices that are Power

over Ethernet enabled or are equipped to receive power over Ethernet.

These devices are called Powered Devices (PDs).

Features of the Power over Ethernet Midspan include:

Safe and reliable power over an existing Ethernet

infrastructure

Remote management using Web control and/or SNMPv3

Highest level of network security

Safe solution that protects network infrastructure

Standards compliant: PoH and 802.3at

Provides safe Power + Data over a single RJ45 cable

Rev.B01 CPG –Poe BU

One Enterprise Aliso Viejo, CA 92656 USA

3.1 10/100/1000BASE-TX Ports Definition

The following sections detail 96xxG ports and their functions.

3.1.1 Data Input Ports

Midspan has 6 or 12 10/100/1000Base-T Data In ports, located on PoE

front panel (Figure 3-1), configured in a non-crossover manner (straight-

wired).

These ports are designed to carry Ethernet data only (Tx/Rx) over:

Standard 4-wire pairs (pins 1/2, 3/6, 4/5 and 7/8)

(1000Base-T)

2-wire pairs (pins 1/2 and 3/6) (10/100Base-T)

3.1.2 Data and Power Output Ports

Midspan has 6 or 12 10/100/1000Base-T Data & Power Out ports,

located on the front panel (see Figure 3-1). These ports are configured in

a non-crossover manner (straight-wired) and carry Ethernet data over:

Standard 4-wire pairs (pins 1/2, 3/6, 4/5, and 7/8)

(1000Base-T)

2-wire pairs (pins 1/2 and 3/6) (10/100Base-T)

PD-96xxG series carry DC power over 4-wire pairs (pins

4/5, 7/8 and pins 1/2, 3/6)

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Microsemi Attrezzature da laboratorio

Microsemi

Microsemi PWR-INJ60GO/AC-NA Manuale utente

Manuali Attrezzature da laboratorio popolari di altre marche

Qiagen

Qiagen DML 3000 Manuale utente

Queensgate

Queensgate NANOSCAN OP400 Manuale di programmazione

Conviron

Conviron GEN1000-GE Manuale utente

Parr Instrument

Parr Instrument 4560 Manuale di istruzioni

IKA

IKA IC control Manuale utente

Integra

Integra DOSE IT Manuale utente

Agilent Technologies

Agilent Technologies 5800 ICP-OES Manuale utente

Endress+Hauser

Endress+Hauser Cleanfit CPA875 Manuale utente

NI PXI-5422 Manuale

Collomix

Collomix Aqix Manuale utente

SPEX SamplePrep

SPEX SamplePrep 6875 Freezer/Mill Series Manuale utente

Ocean Insight

Ocean Insight FLAME-NIR+ Manuale utente

Parker

Parker ALIGN-MG-NA Manuale utente

BD 644787 Manuale utente

DENTAURUM

DENTAURUM Compact Megaplus Manuale utente

Biuged Laboratory Instruments

Biuged Laboratory Instruments BGD 626 Manuale utente

VWR

VWR SAS Super IAQ Manuale utente

illumina

illumina MiSeqDx Manuale utente
