Operating instructions

for condenser tumble dryer

T 7744 C

To avoid the risk of accidents

or damage to the appliance

it is essential to read these

instructions before it is installed

and used for the first time. M.-Nr. 06 737 070

en-GB

Disposal of the packing

material

The transport and protective packing

has been selected from materials which

are environmentally friendly for disposal

and can normally be recycled.

Ensure that any plastic wrappings,

bags etc. are disposed of safely and

kept out of the reach of babies and

young children. Danger of suffocation!

Rather than just throwing these

materials away, please ensure they are

offered for recycling.

Disposal of your old appliance

Electrical and electronic appliances

often contain materials which, if

handled or disposed of incorrectly,

could be potentially hazardous to

human health and to the environment.

They are, however, essential for the

correct functioning of your appliance.

Please do not therefore dispose of your

appliance with your household waste.

Please dispose of it at your local

community waste collection / recycling

centre and ensure that it presents no

danger to children while being stored

for disposal.

Energy saving tips

To avoid unnecessarily long drying

times and high consumption of energy:

–Make sure that your laundry is

thoroughly spun before drying.

The higher the spin, the greater the

savings that can be made in energy

and time during drying.

–Load according to the optimum

amount of laundry recommended for

the programme being used (see

Programme chart).

Underloading is uneconomical.

Overloading gives a poorer quality of

drying and may cause unnecessary

creasing.

–Make sure the room in which the

dryer is located is well ventilated.

–Make sure the fluff filters are clean

before using the dryer.

–Check the condenser unit from time

to time and clean it when necessary.

Caring for the environment

Caring for the environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Warning and Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Operating the tumble dryer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Control panel ......................................................9

Notes on laundry care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Care symbols.....................................................11

Tips on drying ....................................................11

How to dry correctly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Brief instructions ..................................................12

Extra options / Delay start. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Low temperature ..................................................15

Buzzer ..........................................................15

Delay start .......................................................15

Programme chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Changing the programme sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Changing a programme while it is running ..............................19

Cancelling a programme ............................................19

Interrupting a programme ...........................................19

Adding or removing laundry after a programme has started ................19

Electronic system lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Emptying the condensed

water container ...................................................21

Cleaning the fluff filters .............................................22

Cleaning them whilst dry .........................................22

Cleaning them with water .........................................23

Cleaning the tumble dryer ...........................................24

Cleaning the condenser unit .........................................25

Removing the condenser unit......................................25

Checking the condenser unit ......................................26

Cleaning the condenser unit.......................................26

Replacing the condenser unit......................................27

Problem solving guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Check and fault messages ..........................................28

Other problems ...................................................30

Changing the lamp ................................................33

Contents

After sales service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Repairs..........................................................34

Future updates (PC) ...............................................34

Guarantee .......................................................34

Optional accessories ...............................................34

Installation and connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Front view........................................................35

Rear view ........................................................36

Installation site ....................................................36

Transporting the machine to its installation site ........................36

Washer-dryer stack..............................................36

Levelling the machine............................................37

Room ventilation ................................................37

Before moving the machine again

(e.g. when moving house) ........................................37

External condensed water outlet ......................................38

Arranging the drain hose .........................................38

External drainage via a sink or gully ................................39

Installation conditions requiring a non-return valve .....................39

Electrical connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Electrical connection U.K. ...........................................41

Consumption data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Programmable functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Extending the range of the drying levels ................................45

Altering the volume of the buzzer .....................................46

Memory function ..................................................47

Extending the cooling down time .....................................48

Clean out airways indicator ..........................................49

Keypad tone .....................................................50

Adjusting the dryer's electronics for very soft water .......................51

Contents

This tumble dryer conforms to

current safety requirements.

Inappropriate use can, however,

lead to personal injury and damage

to property.

To avoid the risk of accidents and

damage to the tumble dryer, please

read these instructions carefully

before using it for the first time. They

contain important information on its

safety, installation, use and

maintenance.

Keep these instructions in a safe

place and ensure that new users are

familiar with the content. Pass them

on to any future owner.

Correct application

This tumble dryer is only intended

for drying fabrics which have been

washed in a water solution, and marked

on the manufacturer's care label as

being suitable for tumble drying.

"Dry cleaning kits" for freshening up

garments in a tumble dryer are

increasingly available on the market. If

using, do so at your own risk, and

follow the instructions provided on the

packaging.

Any other applications may be

dangerous. Miele cannot be held liable

for damage resulting from incorrect or

improper use or operation.

This tumble dryer is not intended

for use by persons (including

children) with reduced physical,

sensory or mental capabilities, or lack

of experience or knowledge, unless

they have been given supervision or

instruction concerning its use by a

person responsible for their safety.

Safety with children

Keep children away from the

tumble dryer at all times. It is not a

toy! To avoid the risk of injury do not

allow them to play on or near it or to

play with its controls. Supervise

children whilst you are using it.

Older children may only use it if its

operation has been clearly

explained to them, and they are able to

use it safely, recognising the dangers

of incorrect use.

Technical safety

Before setting up the tumble dryer,

check it for any externally visible

damage.

Do not install or use a damaged tumble

dryer.

Before connecting the tumble

dryer, ensure that the connection

data on the data plate (voltage and

connected load) match the mains

electricity supply. If in any doubt,

consult a qualified electrician.

Warning and Safety instructions

The electrical safety of this tumble

dryer can only be guaranteed

when continuity is complete between it

and an effective earthing system which

complies with current local and national

safety regulations. It is most important

that this basic safety requirement is

present and regularly tested, and

where there is any doubt the household

wiring system should be inspected by a

qualified electrician. Miele cannot be

held liable for the consequences of an

inadequate earthing system (e.g.

electric shock).

Do not connect the tumble dryer to

the mains electricity supply by an

extension lead. Extension leads do not

guarantee the required safety of the

machine (e.g. danger of overheating).

Unauthorised repairs could result

in unforeseen dangers for the user,

for which Miele cannot accept liability.

Repairs should only be undertaken by a

Miele approved service technician.

Ensure current is not supplied to the

machine until after maintenance or

repair work has been carried out.

Faulty components must only be

replaced by genuine Miele original

spare parts. Only when these parts are

fitted can the safety standards of the

machine be guaranteed.

If the connection cable is faulty it

must only be replaced by a Miele

approved service technician to protect

the user from danger.

In the event of a fault or for

cleaning purposes, the tumble

dryer is only completely isolated from

the electricity supply when:

–it is switched off at the wall socket

and the plug is withdrawn, or

–it is switched off at the mains, or

–the mains fuse has been withdrawn,

or the screw-out fuse removed (in

countries where this is applicable).

This tumble dryer may only be

used in mobile installations such as

ships if a risk assessment of the

installation has been carried out by a

suitably qualified engineer.

In countries where there are areas

which may be subject to infestation

by cockroaches or other vermin, pay

particular attention to keeping the

machine and its surroundings in a

clean condition at all times. Any

damage which may be caused by

cockroaches or other vermin will not be

covered by the guarantee.

Correct use

Do not let anyone sit or lean on the

door, as this can cause the tumble

dryer to tip up.

Always close the door after use.

This way you will avoid the danger

of:

–children climbing onto or into the

dryer or hiding things in it.

–pets or other small animals climbing

into it.

Warning and Safety instructions

The dryer must not be used without

the fluff filters in place or if the fluff

filters are damaged in any way.

The dryer must not be used without

the condenser unit in place.

The fluff filters must be thoroughly

dried after cleaning. Damp or wet

filters could cause operational faults.

Do not install the tumble dryer in a

room where there is a risk of frost

occurring. At temperatures around

freezing point the tumble dryer may not

be able to operate properly.

There is a risk of damage if the

condensed water is allowed to freeze in

the pump, hoses and / or condensed

water container.

The ambient room temperature should

be between +2°C and +35°C.

If the water is drained externally

through the drain hose instead of

being collected in the condensed water

container, make sure the drain hose is

securely attached if you hang it in a

sink or basin to avoid the hose slipping

and the water causing damage.

Condensed water is not drinking

water.

It can cause health problems in both

people and animals.

Always keep the area around the

tumble dryer free of dust and fluff.

Dust drawn into the machine can over

time cause blockages in the condenser

unit.

Warning and Safety instructions

To prevent the risk of fire, the

following textiles must not be

dried in this tumble dryer:

–fabrics which contain a large

proportion of rubber, foam rubber or

rubber-like materials.

–items which contain damaged

padding or fillings (e.g. pillows and

jackets).

If the filling comes out it could ignite

and cause a fire.

–items which have been treated with

inflammable cleaning agents.

–items which have been splashed with

hair lacquer, hair spray, nail varnish

remover or similar substances.

–items soiled with wax or other

chemicals (e.g. mops and floor

cloths).

–items, such as workwear, which have

not been thoroughly cleaned and

which are still soiled with grease, oil

or other desposits (such as

cosmetics, lotions etc).

If items have not been thoroughly

cleaned there is a danger that these

might ignite when heated, even after

they have been removed from the

dryer at the end of the programme.

When washing such heavily soiled

items: ensure that you use sufficient

detergent and select a high

temperature. If in doubt, wash the

items several times.

Accessories

Accessory parts may only be fitted

when expressly approved by

Miele. If non-Miele parts are used,

guarantee, performance and product

liability claims may be invalidated.

Miele cannot be held liable for

damage caused by non-compliance

with these Warning and Safety

instructions.

Warning and Safety instructions

Control panel

aDisplay

bDelay start button

This button is used for:

- Selecting the duration of the

Warm air and Cool air

programmes

- Delaying the start of a programme

cBuzzer button

An audible tone sounds at the end of

the programme.

dCheck lights

These indicator lights have various

functions. See "Problem solving

guide" / "After sales service" for

details.

eStart/Stop button

For starting the programme selected

and cancelling a programme once it

has started.

The button flashes while a

programme is being selected and

then is on constantly when the

programme has started.

fLow temperature button

Delicate fabrics are dried at a lower

temperature.

gDrying level button

with indicator lights

hProgramme selector

with indicator lights

iDoor button

Pressing this button will open the

door even when the machine is

switched off at the mains.

jI-On/0-Off button

For switching the dryer on and off.

Operating the tumble dryer

Display

The following are selected via the

display:

–Delay start

–Duration of the Cool air and Warm air

programmes

–Programmable functions

The display also shows:

–Programme duration

–Programme stage

Drying

Cooling down

Finish

–Check and fault messages

Programme duration / Estimated time

remaining

When a programme is selected, the

estimated duration (time remaining) will

appear in the display. Please be aware

that it is only an estimate!

The following factors all affect the

estimated time remaining: residual

moisture content after spinning; type of

fabric; size of load; room temperature;

fluctuations in power supply.

The electronics continually assess

conditions in the dryer and adjust the

estimated time remaining for a more

accurate reading. Because of this, the

time displayed can alter during the

course of a programme.

In the same way, the Woollens

handcare, Silks handcare and

Smoothing programmes can finish

earlier than expected if a certain

temperature is reached. This can

happen with particularly fine fabrics,

very small loads or if items were partly

dry beforehand.

Delay start

The delay start time selected will

appear in the display.

After the Start/Stop button has been

pressed, the delay start time will start

counting down.

Once the delay start time has elapsed,

the programme will begin and the

estimated programme duration will

appear in the display.

Programmable functions

The programmable functions can be

used to tailor drying programmes to suit

your individual requirements. In

programming mode, the display will

show the function selected.

Operating the tumble dryer

Altri manuali per T 7744 C

Indice

Altri manuali Miele Asciugatrice

Miele

Miele Novotronic T 220 Manuale utente

Miele

Miele T 1570CI CONDENSER DRYER - OPERATING Manuale utente

Miele

Miele T 8947 WP Manuale utente

Miele

Miele TDB130WP Eco Manuale utente

Miele

Miele T 442 C Manuale utente

Miele

Miele T 7944 C Manuale utente

Miele

Miele TDA 150 C Manuale utente

Miele

Miele VENTED DRYER T 1302 Manuale utente

Miele

Miele T 9822 Manuale utente

Miele

Miele TWR 780 WP Manuale utente

Miele

Miele T 8685 C Manuale utente

Miele

Miele T 1526 VENT ED DRYER - OPERATING Manuale utente

Miele

Miele PT 7186 Vario Manuale utente

Miele

Miele T 8322 Manuale utente

Miele

Miele PDR 510 EL Manuale utente

Miele

Miele TEJ 665 WP Manuale utente

Miele

Miele Novotronic T 220 Manuale utente

Miele

Miele TWF160WP Manuale utente

Miele

Miele PT 7186 EL Manuale utente

Miele

Miele TWB 120 WP Manuale utente

Miele

Miele PT 7186 EL Manuale utente

Miele

Miele T 366 VENT ED DRYER - OPERATING Manuale utente

Miele

Miele PDR 514 Manuale utente

Miele

Miele PDR 908 EL Manuale utente

Manuali Asciugatrice popolari di altre marche

Bosch

Bosch WTA79200GB Manuale utente

Amana

Amana W10233410A Manuale utente

Asko

Asko T760 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuale utente

Bosch

Bosch Logixx 10 WTB76556GB Scheda tecnica

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Manuale di istruzioni

Electrolux

Electrolux EW2H328R2 Manuale utente

Beko

Beko DS8433RX1M Manuale utente

Dawlance

Dawlance Spinner DS 6000 C Manuale utente

Electrolux

Electrolux TP5080TW Manuale utente

AEG

AEG TR838P4OB Manuale utente

Indesit

Indesit IDV 75 Manuale utente

Infiniton

Infiniton SD-DG85C Manuale utente

BOMANN

BOMANN WT 5019 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuale utente

Asko

Asko T793C Manuale utente

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuale utente

Frigidaire

Frigidaire CAQE7077KW0 Manuale del proprietario
