Miele TDA 150 Manuale utente

Operating instructions

for condenser dryers

To avoid the risk of accidents or damage to the appliance it is essential

to read these instructions before it is installed and used for the first time.

en-GB M.-Nr. 09 938 570

Caring for the environment

Disposal of the packing

material

The packaging is designed to protect

the appliance from damage during

transportation. The packaging materials

used are selected from materials which

are environmentally friendly for disposal

and should be recycled.

Recycling the packaging reduces the

use of raw materials in the

manufacturing process and also

reduces the amount of waste in landfill

sites.

Disposal of your old appliance

Electrical and electronic appliances

often contain valuable materials. They

also contain materials which, if handled

or disposed of incorrectly, could be

potentially hazardous to human health

and to the environment. They are,

however, essential for the correct

functioning of your appliance. Please

do not therefore dispose of it with your

household waste.

Please dispose of it at your local

community waste collection / recycling

centre.

Ensure that it presents no danger to

children while being stored for disposal.

Energy saving tips

To avoid unnecessarily long drying

times and high consumption of energy:

– Make sure that your laundry is

thoroughly spun before drying. The

higher the spin, the greater the

savings that can be made in energy

and time during drying.

– Load according to the optimum

amount of laundry recommended for

the programme being used.

Underloading is uneconomical.

Overloading gives a poorer quality of

drying and may cause unnecessary

creasing.

– Make sure the room temperature is

not too high. If there are other heat

producing appliances in the room in

which the dryer is located, make sure

the room is well ventilated and switch

the other appliances off, if possible.

– After every cycle remove the fluff

from the fluff filters in the door and in

the door opening.

– Check the condenser unit once a

year and clean it if necessary.

Contents

Caring for the environment .................................................................................. 2

Warning and Safety instructions ......................................................................... 5

Operating the tumble dryer................................................................................. 13

Control panel.......................................................................................................... 13

Before using for the first time................................................................................. 14

Laundry care......................................................................................................... 15

How to dry correctly ............................................................................................ 16

Brief instructions .................................................................................................... 16

Changing the programme sequence ................................................................. 18

Programme chart ................................................................................................. 19

Cleaning and care................................................................................................ 22

Emptying the condensed water container............................................................. 22

Cleaning the fluff filters .......................................................................................... 23

Cleaning them whilst dry .................................................................................. 23

Cleaning them with water ................................................................................. 24

Replacing them................................................................................................. 24

Tumble dryer .......................................................................................................... 25

Cleaning the condenser unit.................................................................................. 26

Removing the condenser unit........................................................................... 26

Checking the condenser unit ........................................................................... 27

Cleaning the condenser unit ............................................................................ 27

Replacing the condenser unit .......................................................................... 29

Problem solving guide......................................................................................... 30

Check and fault messages .................................................................................... 30

Unsatisfactory drying results ................................................................................. 32

Other problems ...................................................................................................... 33

Changing the lamp................................................................................................. 35

After sales service ............................................................................................... 36

Repairs................................................................................................................... 36

Optional accessories ............................................................................................. 36

Guarantee: U.K....................................................................................................... 36

Guarantee: Other countries.................................................................................... 36

Installation and connection................................................................................. 37

Front view............................................................................................................... 37

Rear view ............................................................................................................... 38

Contents

Installation site ....................................................................................................... 38

Transporting the tumble dryer to its installation site......................................... 38

Building under a continous worktop / in a kitchen run..................................... 38

Washer-dryer stack........................................................................................... 38

Levelling the dryer............................................................................................. 39

Room in which the dryer is located .................................................................. 39

Before moving the tumble dryer again (e.g. when moving house) ................... 39

Electrical connection U.K....................................................................................... 40

External condensed water outlet ........................................................................... 41

Arranging the drain hose................................................................................... 41

External drainage via a sink or gully ................................................................. 42

Installation conditions requiring a non-return valve.......................................... 43

Consumption data ............................................................................................... 45

Technical data ...................................................................................................... 46

Programmable functions..................................................................................... 48

Altering the residual moisture level in the Cottons programme............................. 48

Altering the residual moisture level in the "Minimum iron" programme................. 49

Anti-crease............................................................................................................. 50

Switching the buzzer on/off ................................................................................... 51

Altering the standard drying level in the"Automatic plus" programme.................. 52

Extending the cooling down time .......................................................................... 53

Standby.................................................................................................................. 54

Changing the function of the airways indicator ..................................................... 56

Adjusting the dryer's electronics for very soft water ............................................. 57

Warning and Safety instructions

 It is essential to read these instructions.

This tumble dryer complies with current safety requirements.

Inappropriate use can, however, lead to personal injury and

damage to property.

To avoid the risk of accidents and damage to the tumble dryer,

please read these instructions carefully before using it for the first

time. They contain important information on its safety, installation,

use and maintenance.

Keep these instructions in a safe place and ensure that new users

are familiar with the content. Pass them on to any future owner.

Correct application

 This tumble dryer is intended for use in domestic households and

similar working and residential environments.

 This tumble dryer is not intended for outdoor use.

 It must be used only as a domestic appliance to dry items which

have been washed in a water solution and which are marked on the

manufacturer's care label as being suitable for tumble drying. If

using dry cleaning kits, do so at your own risk, and follow the

instructions provided on the packaging.

Any other applications may be dangerous. Miele cannot be held

liable for damage resulting from incorrect or improper use or

operation.

Warning and Safety instructions

 This tumble dryer can only be used by people with reduced

physical, sensory or mental capabilities, or lack of experience or

knowledge, if they are supervised whilst using it or have been shown

how to use it in a safe way and understand and recognise the

consequences of incorrect operation.

Safety with children

 Children under 8 years of age must be kept away from the tumble

dryer unless they are constantly supervised.

 Children 8 years and older may only use the tumble dryer

unsupervised if they have been shown how to use it safely and

recognise and understand the consequences of incorrect operation.

 Children must not be allowed to clean or maintain the tumble

dryer unsupervised.

 Please supervise children in the vicinity of the tumble dryer and

do not let them play with it.

Warning and Safety instructions

Technical safety

 Before setting up the tumble dryer, check it for any externally

visible damage.

Do not install or use a damaged tumble dryer.

 Before connecting the tumble dryer, ensure that the connection

data on the data plate (fuse rating, voltage and frequency) match the

mains electricity supply. If in any doubt, consult a qualified

electrician.

 Reliable and safe operation of this tumble dryer can only be

assured if it has been connected to the mains electricity supply.

 The electrical safety of this tumble dryer can only be guaranteed

when correctly earthed. It is essential that this standard safety

requirement is met. If in any doubt, please have the household

wiring system tested by a qualified electrician. Miele cannot be held

liable for the consequences of an inadequate earthing system (e.g.

electric shock).

 Do not connect the appliance to the mains electricity supply by an

extension lead, multi-socket adapter or similar. These can overheat

and are a fire hazard.

 If the electrical connection cable is faulty it must only be replaced

by a Miele authorised service technician to protect the user from

danger.

 Unauthorised repairs could result in unforeseen dangers for the

user, for which Miele cannot accept liability. Repairs should only be

undertaken by a Miele approved service technician, otherwise any

subsequent damage will not be covered by the guarantee.

 Faulty components must only be replaced by genuine Miele

original spare parts. The manufacturer can only guarantee the safety

of the appliance when Miele replacement parts are used.

 The tumble dryer must be isolated from the electricity supply in

the event of a fault and during cleaning and maintenance.

Warning and Safety instructions

 This tumble dryer must not be used in a non-stationary location

(e.g. on a ship).

 Do not make any alterations to the tumble dryer, unless

authorised to do so by Miele.

 Please observe the instructions in "Installation and connection"

and the "Technical data".

 The accessibility of the plug must always be ensured, in order to

disconnect the tumble dryer from the mains.

 Do not block the gap between the bottom of the tumble dryer and

the floor with plinth facings, deep pile carpet etc. This would hinder

a sufficient flow of air to the dryer.

 Make sure the dryer door can be opened without hindrance after

installation.

Correct use

 The maximum load for this tumble dryer is 7.0 kg (dry weight).

The maximum recommended loads for individual programmes are

given in the Programme chart.

 To prevent the risk of fire, do not connect the tumble dryer via a

controllable socket (e.g. a timer or a peak-load switch-off device).

If the drying programme is interrupted before the end of the cooling

down phase, this could cause the laundry to self-ignite.

Warning and Safety instructions

 To prevent the risk of fire, the following textiles must not be dried

in this tumble dryer:

– Items which have not been washed.

– Items, such as workwear, which have not been thoroughly

cleaned and which are still soiled with grease, oil or other

deposits (such as cosmetics, lotions etc). If items have not been

thoroughly cleaned there is a danger that these might ignite when

heated, even after they have been removed from the dryer at the

end of the programme.

– Items (e.g. mops and floor cloths) which have been treated with

inflammable cleaning agents or which contain residues of

acetone, alcohol, benzene, petrol, kerosene, stain remover,

turpentine, wax and wax remover or other chemicals.

– Items which have been splashed with hair lacquer, hair spray, nail

varnish remover or similar substances.

When washing such heavily soiled items ensure that you use

sufficient detergent and select a high temperature. If in doubt,

wash the items several times.

 Remove all items from pockets (e.g. lighters, matches).

 Warning: Do not switch the dryer off before the drying

programme has finished. If this is done, the laundry must be hung

up or spread out to cool it down.

 Fabric conditioner and similar products must be used according

to the instructions on the manufacturer's packaging.

Warning and Safety instructions

 To prevent the risk of fire, the following textiles must not be dried

in this tumble dryer:

– Items which have been cleaned using chemicals (e.g.

professional dry-cleaning agents).

– Items which contain a large proportion of rubber, foam rubber or

rubber-like materials. For example, products made from latex

foam rubber, shower caps, waterproof textiles, rubberised articles

and items of clothing and pillows with foam rubber filling.

– Damaged items which contain padding or fillings (e.g. pillows,

jackets). When damaged, the filling can get out with the risk of it

igniting in the dryer.

 In many programmes, the heating phase is followed by a cooling

down phase to ensure that the items are not too hot to handle when

you remove them (this also avoids the danger of the laundry self-

igniting). The programme is not finished until the cooling down

phase has been completed.

As soon as the programme has finished, remove all laundry from the

drum.

 Do not let anyone sit or lean on the door, as this can cause the

tumble dryer to tip up.

 Always close the door after use. This way you will avoid the

danger of:

– Children climbing onto or into the dryer or hiding things in it.

– Pets or other small animals climbing into it.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Miele Asciugatrice

Miele

Miele T 1322C CONDENSER DRYER Manuale utente

Miele

Miele Touchtronic T 1339 C Manuale utente

Miele

Miele TWC220WP Manuale utente

Miele

Miele T 1050 VENT ED DRYER - OPERATING Manuale utente

Miele

Miele TKG 450 WP Manuale utente

Miele

Miele T 4362 Manuale utente

Miele

Miele T 294 C Manuale utente

Miele

Miele TXI 680 WP Manuale utente

Miele

Miele TOUCHTRONIC T 1312 Manuale utente

Miele

Miele T 8826 WP Manuale utente

Miele

Miele TCE 620 WP Manuale utente

Miele

Miele T 4659 C Manuale utente

Miele

Miele PDR 910 G Manuale utente

Miele

Miele T 1515 VENT ED DRYER - OPERATING Manuale utente

Miele

Miele TDA 150 C Manuale utente

Miele

Miele T 4804 C Allerdry Manuale utente

Miele

Miele TSB 143 WP Manuale utente

Miele

Miele TWB 140 WP Manuale utente

Miele

Miele T 4859 Ci SUPERTRONIC Manuale utente

Miele

Miele T 1036 VENT ED DRYER - OPERATING Manuale utente

Miele

Miele TWF160WP Manuale utente

Miele

Miele PT 5136 OS Manuale utente

Miele

Miele T 7734 Manuale utente

Miele

Miele TEH 785 WP Manuale utente

Manuali Asciugatrice popolari di altre marche

Bosch

Bosch WTA79200GB Manuale utente

Amana

Amana W10233410A Manuale utente

Asko

Asko T760 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manuale utente

Bosch

Bosch Logixx 10 WTB76556GB Scheda tecnica

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Manuale di istruzioni

Electrolux

Electrolux EW2H328R2 Manuale utente

Beko

Beko DS8433RX1M Manuale utente

Dawlance

Dawlance Spinner DS 6000 C Manuale utente

Electrolux

Electrolux TP5080TW Manuale utente

AEG

AEG TR838P4OB Manuale utente

Indesit

Indesit IDV 75 Manuale utente

Infiniton

Infiniton SD-DG85C Manuale utente

BOMANN

BOMANN WT 5019 Manuale utente

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manuale utente

Asko

Asko T793C Manuale utente

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manuale utente

Frigidaire

Frigidaire CAQE7077KW0 Manuale del proprietario
