Mini Gadgets BB2DVDCover Manuale utente

1 Version 2.0

Bush Baby DVD Cover

Camera

SKU: BB2DVDCover

2 Version 2.0

THANK YOU FOR PURCHASING THE BUSH BABY 2 DVD COVER

Home surveillance is a top priority for anyone. Whether you are

gone just for one day at work or a few weeks on vacation, you

want to make sure your home is being watched. Your

neighborhood may even be facing a string of break-ins and you

want an eye on your home at all times. After all, it is much

easier to catch a thief when you know what they look like. Don’t

let your home and all your possessions go unwatched for

another day; Get the BB2DVDCover!

Your purchase should include:

1 x BB2DVDCover

1 x Remote Control

1 x Removable Battery

1 x Charging Cable

1 x AC Adapter

1 x Instruction Booklet

3 Version 2.0

GET FAMILIAR WITH THE BUSH BABY 2 DVD COVER

4 Version 2.0

Camera

5 Version 2.0

BEFORE YOU START

To preserve battery power, your device will come with the

battery connector disconnected. Before attempting to use the

device be sure to connect the battery’s connector to the circuit

board power lead.

OPERATING THE BUSH BABY 2 DVD COVER

IMPORTANT NOTICE: Allow the device to charge 6 –8 hours

before using.

MICROSD CARD SLOT

To access the MicroSD Card Slot you must open the DVD case.

1. Gently push the MicroSD Card into the slot. The gold

contacts on the card will be inserted first, and they

should face the main circuit board. You will feel some

spring resistance before the card clicks in to place.

2. Never force the card into the Card Slot under any

circumstances, otherwise the DVD cover unit or the

MicroSD card itself will be damaged.

6 Version 2.0

3. To remove the SD card, gently push the card in so that

it clicks.

4. The internal spring tension will eject the card.

REMOVING AND CHARGING THE BATTERY

1. Remove battery from the inside of the DVD cover.

2. Disconnect the battery connector that is connecting

the battery to the circuit board. Be careful not to pull

on the wires as that could damage them.

3. Connect the connector on the battery to the connector

on the charging adapter.

4. Plug the provided USB cable into the other end of the

charging adapter.

5. Plug the other end of the USB cable into the wall AC

adapter and plug it into the wall.

6. Wait 6 to 8 hours or until the indicator light turns from

red to green. Until the light is green, the unit is not

fully charged.

a. The larger the battery capacity, the longer it

takes to charge.

7 Version 2.0

HOW TO TURN ON THE BUSHBABY DVD COVER CAMERA

1. Press the Power Button on the remote control one

time. The blue indicator light on the inside of the DVD

Cover, near the battery will be on. The device is now in

Standby mode.

HOW TO RECORD VIDEO ON THE BUSHBABY DVD COVER CAMERA

1. In standby mode, press the Video button on the

remote control one time. The blue indicator light on

the back of the device will flash three times and then

turn off. Videos will be recorded continuously and

saved in 20 minute intervals.

HOW TO SET UP MOTION DETECTION

1. In Standby mode, press the Motion Detection button

one time. The blue indicator light will flash three times

and then turn off. In Motion Detection mode, when

there is no movement, the light will blink rapidly. Once

the detector finds movement, the light will blink three

times and the indicator will turn off. The DVD cover will

record video in 3 minute intervals

8 Version 2.0

HOW TO STOP RECORDING

1. To stop recording, you will need to press the same

button you used to begin recording. If you pressed the

Video button, press the Video button once more. If you

pressed the Motion button, press the Motion button

once more. The device will reenter Standby mode

(solid blue light).

HOW TO TAKE A PICTURE

1. While in Standby mode, press the Picture Button one

time. When the indicator light flashes one time, 1

picture will be taken accordingly. The device returns to

Standby mode once 1 picture has been taken.

OPTIONS FOR ACCESSING THE REMOVABLE STORAGE

1. Remove the MicroSD card and insert the card into a

reader directly on your computer if available.

2. Use an external MicroSD card reader.

9 Version 2.0

64GB and 128GB microSD cards will require special formatting

to work. The device will not function with these cards if they

are not properly formatted beforehand.

Visit www.mgidownloads.com/Software and download the

“guiformat.zip” file. Extract the files and follow the instructions

in the “64GB SD Card Formatting.pdf” document.

IMPORTANT NOTICE: Ensure that the DVD cover is off before

inserting the MicroSD card, otherwise potential corruption of the

card file(s) may occur.

RETRIEVE THE FILES TO YOUR PC

1. Connect the MicroSD card to your computer using the

MicroSD card USB adapter

2. Locate “Removable Disk” inside the (My) Computer

folder.

AutoPlay Removable Disk > Open folder to view files

10 Version 2.0

Or…

Go to Start > Computer > Removable Disk

3. Open the Removable Disk drive.

4. Open the DCIM folder.

5. Open the folder featuring a sequence of numbers.
