Mini Gadgets CAMSTICK1000MVA Manuale utente

MOTION AND VOICE

ACTIVATED CAMSTICK

SKU: CAMSTICK1000MVA

THANK YOU FOR PURCHASING THE MOTION AND VOICE

ACTIVATED CAMSTICK

Please read this manual before operating the Motion and Voice

Activated CamStick and keep it handy.

The CamStick1000MVA is a completely updated design of one of our

hottest selling items! Not only does this version include a sturdy all

metal body, it also has motion and voice activation! This easily

portable unit sits securely in its clip and can be placed quickly

anywhere you need low-profile and long-term surveillance.

Simple to use. The CamStick1000MVA is easy to use with its clearly

labeled buttons and automatic functions. All you need to do is turn

the unit on and place it facing the area you want to record. The high-

end motion detection sensors will activate automatically whenever

they sense motion. Unless further motion is detected, the device

preserves battery life by returning to standby.

Your purchase should include:

1 x Motion-Activated Camstick 1000 MVA

1 x USB Cable

1 x AC Adapter

1 x Clip

1 x Instruction Booklet

GET FAMILIAR WITH YOUR MOTION AND VOICE

ACTIVATED CAMSTICK

Mode

Switch

M (Manual)

A (Auto)

Record

Button

MicroSD

Card Slot

Function

Switch

Camera

Lens

USB Port

Mic

Camera

Button

Indicator

Light

Motion

Detector

OPERATING THE MOTION AND VOICE ACTIVATED

CAMSTICK

IMPORTANT NOTICE: Allow the device to charge 4 –6 hours before

using.

HOW TO CHARGE YOUR CAMSTICK USING YOUR COMPUTER

1. Insert the USB cable into the USB port on the CamStick

2. Insert the USB cable into the USB port on your computer

The red indicator light will turn on while charging

HOW TO CHARGE YOUR CAMSTICK USING THE ADAPTER

1. Insert the USB cable into the USB port on the CamStick

2. Insert the USB cable into the USB port on the Adapter

3. Plug the Adapter into a power source

The red indicator light will turn on while charging

TIP: You can use your CamStick while it is charging

HOW TO TURN YOUR CAMSTICK ON/OFF

1. To turn the CamStick ON move the Function Switch into the

Rec or USB position

The blue indicator light will turn on

2. To turn the CamStick OFF move the Function Switch into the

Off position

The blue indicator light will turn off

HOW TO RECORD VIDEO USING MOTION/AUDIO DETECTION

1. Move the Mode Switch into the A (Auto) position

2. Move the Function Switch into the Rec position

The blue indicator lights will turn on

When motion or audio is detected the Camstick will

beep and the green indicator light will flash

3. To stop and save your recording press the Record Button

When motion is detected the CamStick will resume

recording

HOW TO RECORD VIDEO MANUALLY

1. Move the Mode Switch into the M (Manual) position

2. Move the Function Switch into the Rec position

The blue indicator light will turn on

3. Press the Record Button

The green indicator light will flash while recording

4. To stop and save your recording press the Record Button

again

The blue indicator light will turn on

HOW TO TAKE PHOTOS

1. Move the Mode Switch into the M (Manual) position

2. Move the Function Switch into the Rec position

The blue indicator light will turn on

3. Press the Camera Button

The CamStick will beep

oYour photo has been saved

HOW TO RESET THE TIME AND DATE STAMP

1. Visit www.mgidownloads.com

2. Click on the Software directory

3. Click on the “camstick1000mva.exe” file

4. Let the file download onto your computer

5. Locate the file in your computer’s downloads directory

6. Click the file

7. Click “Run”

8. Ensure the time and date are current

9. Click “OK”

RETRIEVE THE FILES TO YOUR PC

1. Move the Function Switch into the USB position

2. Plug the device into your PC using the USB cable

3. Locate “Removable Disk” inside the (My) Computer folder

AutoPlay Removable Disk > Open folder to view files

Or…

Go to Start > Computer > Removable Disk

4. Open the Removable Disk drive

5. Open the VIDEO folder

6. Double click the file you want to view

VLC Player is recommended for watching videos

TROUBLESHOOTING

THE DEVICE WON’T TURN ON

Charge the device for at least 4 hours before the first use

Make sure the charging cable is securely inserted into the

device and into the power source

THE DEVICE ISN’T CHARGING

Replace the battery or charging cable

If you are charging via a wall power source, you may need to

charge via your PC. The AC adapter might be bad

MY COMPUTER DOESN’T RECOGNIZE THE DEVICE

Unplug the device from your PC and reboot the device

Unplug the device from your PC and reboot your PC

Try using a different USB slot on your PC

Replace the USB cable

THE SOUND OR VIDEO IS UNCLEAR

The device needs charging

OTHER PROBLEMS

Call our technical support at 770–694–6923

SPECIFICATIONS

Video Resolution

640*480

Video Format

AVI

Motion Detection

Yes

Photo Resolution

1600*1200

Photo Format

JPEG

Water Resistant

Battery Life

90 minutes

Type of Memory

MicroSD Card

Memory Capacity

32GB

Recording Capacity

2GB ≈ 1 hour

4GB ≈ 2 hours

8GB ≈ 4 hours

16GB ≈ 8 hours

32GB ≈ 16 hours

USB Interface

2.0 USB

Player Software

VLC recommended

Operating Systems

Windows 2000 –Windows 8

Mac OSX

Linux
