Mini Gadgets BB2WallFreshenerStone Manuale utente
1 Version 1.5
BushBaby2 Wall Freshener
SKU: BB2WallFreshenerStone
2 Version 1.5
THANK YOU FOR PURCHASING THE BUSH BABY 2
WALL FRESHENER HIDDEN CAMERA
Please read this manual before operating the camera
and keep it handy.
Your purchase should include:
1 x BushBaby2 Wall Freshener
1 x Charger Assembly
1 x User Manual
1 x Remote
1 x SD Card (8GB)
3 Version 1.5
GET FAMILIAR WITH YOUR WALL FRESHENER CAMERA
4 Version 1.5
NOTICE: To turn the device ON, turn the switch to the left. To turn
the device OFF, turn the device to the right.
5 Version 1.5
BEFORE YOU START
To preserve battery power, your device will come with master
power switch pictured on page 4 of this manual in the off
position. Before attempting to use the device be sure to turn
that switch on.
OPERATING THE BUSHBABY CAMERA
IMPORTANT NOTICE: Allow the device to charge 6 –8 hours
before using.
MICROSD CARD SLOT
1. To access the MicroSD Card Slot you must open the
BB2AirFreshener by pressing the button located on the
top of the product and then pull the sides so that it
opens.
2. Gently push the MicroSD Card into the slot. The gold
contacts on the card will be inserted first, and they
should face the main circuit board. You will feel some
spring resistance before the card clicks in to place.
a. Never force the card into the Card Slot under
any circumstances, otherwise the unit or the
MicroSD card itself will be damaged.
6 Version 1.5
3. To remove the SD card, gently push the card in so that it
clicks.
4. The internal spring tension will eject the card.
CHARGING THE BATTERY
1. To charge the battery plug the usb cable into the usb
port on the circuit board and into the wall using the
provided ac adapter.
2. Wait roughly 10 hours for it to charge.
a. The larger the battery capacity, the longer
it takes to charge. If you are not getting
the battery life you expect, charge the
device for longer.
HOW TO TURN ON THE BUSHBABY CAMERA
1. Press the Power Button on the remote control one
time. Your device is on when the led indicator turns on.
The device is now in Standby mode.
HOW TO RECORD VIDEO ON THE BUSHBABY CAMERA
1. In standby mode, press the Video button on the remote
control one time. The indicator light inside of the device
will flash three times and then turn off. Videos will be
recorded continuously and saved in 20 minute intervals.
7 Version 1.5
HOW TO SET UP MOTION DETECTION
1. In Standby mode, press the Motion Detection button
one time. The indicator light will flash three times and
then turn off. In Motion Detection mode, when there is
no movement, the light will blink rapidly. Once the
detector finds movement, the light will blink three times
and the indicator will turn off. The unit will record video
in 3 minute intervals
HOW TO STOP RECORDING
1. To stop recording, you will need to press the same
button you used to begin recording. If you pressed the
Video button, press the Video button once more. If you
pressed the Motion button, press the Motion button
once more. The device will reenter Standby mode (solid
light).
HOW TO TAKE A PICTURE
1. While in Standby mode, press the Picture Button one
time. When the indicator light flashes one time, 1
picture will be taken accordingly. The device returns to
Standby mode once 1 picture has been taken.
8 Version 1.5
OPTIONS FOR ACCESSING THE REMOVABLE STORAGE
1. Remove the MicroSD card and insert the card into a
reader directly on your computer if available.
2. Use an external MicroSD card reader.
64GB and 128GB microSD cards will require special formatting
to work. The device will not function with these cards if they
are not properly formatted beforehand.
Visit www.mgidownloads.com/Software and download the
“guiformat.zip” file. Extract the files and follow the instructions
in the “64GB SD Card Formatting.pdf” document.
IMPORTANT NOTICE: Ensure that the device is off before inserting
the MicroSD card, otherwise potential corruption of the card file(s)
may occur.
RETRIEVE THE FILES TO YOUR PC
1. Connect the MicroSD card to your computer using the
MicroSD card USB adapter
2. Locate “Removable Disk” inside the (My) Computer
folder.
9 Version 1.5
AutoPlay Removable Disk > Open folder to
view files
Or…
Go to Start > Computer > Removable Disk
3. Open the Removable Disk drive
4. Open the DCIM folder.
10 Version 1.5
5. Open the folder featuring a sequence of numbers.
6. Double click the file you want to view.
VLC Player is recommended for watching
videos
TROUBLESHOOTING
THE DEVICE WON’T TURN ON
Make sure the power cable is securely plugged into a
functioning electrical outlet or the battery is charged
THE DEVICE HAS CRASHED
Press the reset button one time while the device is on
DEVICE CONTINUALLY RECORDS IN MOTION MODE
Motion detection is measured by changing pixels
during recording. Any kind of motion including shifting
shadows or changing lighting conditions can set off
motion detection. Try adjusting the motion detection
sensitivity via the setup menu
OTHER PROBLEMS
Call our technical support at 770–694–6923
