Minka Group MinkaAire CONCEPT III Guida

INSTRUCTION MANUAL WARRANTY CERTIFICATE

CONCEPT III

Patents, Trademark, and/or Copyright Laws.

The Minka-Aire® warranty is for one (1) year from the date of purchase from an authorized Minka-Aire® dealer.

This warranty is only valid to the original purchaser or user against all defects in material and workmanship (light bulbs

excluded) for one (1) full year. Additionally, Minka-Aire® warrants the motor only for the lifetime of the Minka Aire ceiling

fan (excluding wall controls and electrical components), to the original purchaser or user.

* The warranty is voided with the use of any non- Minka-Aire®electrical devices, E.g., wall controls or electrical dimmer switches, etc…

* The warranty is void once the original purchaser or user ceases to own the fan or the fan is moved from its original point of installation.

* The warranty is void with the use of any hanger bracket (non-Minka Aire or non-fan specific) other than the hanger bracket supplied & installed

with this specific fan.

Date Purchased Store Purchased Model Number Serial Number

F467L

Warranty Service Information

To obtain warranty service during the warranty period, the purchaser should return the fan with the sales receipt to the original place of

purchase. The authorized Minka-Aire® dealer, at its sole discretion, will either repair or replace the fan after verifying the legitimacy of the warranty

claim. Replacement is subject to availability of the same model. If the model is unavailable it will be replaced by one of equal value. This is a

limited warranty; the original purchaser or user is responsible for the cost of removal and reinstallation of repaired or replacement product.

To obtain the name of the Minka-Aire® authorized dealer nearest you call the Minka-Aire® customer care department at 1-800-307-3267, or

contact Minka-Aire® through www.minkagroup.net and select FAQ to answer any questions or if you require additional assistance submit the

question form found there.

CONTENTS

INSTALLING THE LED LIGHT KIT

......................................................

INSTALLING THE GLASS SHADE

......................................................

OPERATING THE REMOTE CONTROL........

....................................

ENJOY YOUR SMART CEILING FAN

...............................................

CARE OF YOUR FAN..............................................................................

TROUBLESHOOTING............................................................................

SPECIFICATIONS....................................................................................

SAFETY RULES....................................................................................

PACKAGE CONTENTS.....................................................................

INSTALLING THE MOUNTING BRACKET..............................

ELECTRICAL CONNECTIONS.......................................................

FINISHING THE INSTALLATION................................................

BLADE INSTALLATION...................................................................

INSTALLING THE MOUNTING PLATE

.....................................

1151 W. Bradford Court, Corona, CA 92882 For Customer Assistance Call: 1-800-307-3267

SAFETY RULES

1. Before you begin installing the fan, shut power off at the circuit breaker of the fuse box.

2. Be cautious! Read all instructions and safety information before installing your new fan. Review accompanying assembly diagrams.

3. Make sure that all electrical connections comply with local codes, ordinances, or National Electrical Codes. Hire a qualified electrician or consult a

do-it-yourself wiring handbook if you are unfamiliar with installing electrical wiring.

4. Make sure the installation site you choose allows the fan blades to rotate without any obstructions. Allow a minimum clearance of 7 feet from the

floor and 18 inches from the tip of the blades to the wall.

5. If you are mounting the fan to a ceiling fan outlet box, use a U.L. Listed metal octagonal outlet box marked "Acceptable for Fan Support". Secure the

box directly to the building structure. The outlet box and its support must be able to support the moving weight of the fan (at least 50 pounds) Do

not use a plastic box.

6. CAUTION:

CAUTION:

To reduce the risk of injury use only the screws provided with the outlet box in conjunction with the lock washers provided with the fan.

7. If you are mounting the fan to a joist, make sure it is able to support the moving weight of the fan (at least 50 pounds).

8. After you install the fan, make sure that all mounting components are secured to prevent the fan from falling.

9. Do not insert anything into the fan blades while the fan is operating.

10. Turn the fan off and wait for the blades to stop completely before performing any maintenance or cleaning. SUITABLE FOR USE IN

WET LOCATIONS

WARNING

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR OTHER PERSONAL INJURY, MOUNT FAN ONLY TO A U.L. LISTED OUTLET BOX OR SUPPORTING SYSTEM MARKED

ACCEPTABLE FOR FAN SUPPORT AND USE MOUNTING SCREWS PROVIDED WITH THE OUTLET BOX IN CONJUCTION WITH THE LOCK WASHERS PROVIDED WITH

THE FAN. MOST OUTLET BOXES COMMONLY USED FOR FAN SUPPORT OF LIGHTING FIXTURES ARE NOT ACCEPTABLE FOR FAN SUPPORT AND NEED TO BE

REPLACED. CONSULT A QUALIFIED ELECTRICIAN IF IN DOUBT.

TO REDUCE THE RISK OF PERSONAL INJURY, DO NOT BEND THE BLADE HOLDERS WHILE INSTALLING, BALANCING THE BLADES OR CLEANING THE FAN. DO NOT

INSERT FOREIGN OBJECTS BETWEEN ROTATING FAN BLADES.

TO REDUCE THE RISK OF FIRE OR ELECTRONIC SHOCK, THIS FAN CAN ONLY USE AL158-RM351HF70001 SOLID-STATE SPEED CONTROL WITH

RC1000 REMOTE CONTROL ONLY

NOTE:

The important safeguards and instructions appearing in this manual are not meant to cover all possible conditions and situations that may

occur. It must be understood that common sense, caution and care are factors which can not be built into this product. These factors must be

supplied by the person (s) installing, caring for and operating the unit.

NOTE:

READ AND SAVE ALL INSTRUCTIONS!

1. Fan Blades (3)

2. Mounting bracket

3. Decorative ring

4. Fan motor/housing assembly

5. Mounting plate

6. 30W LED light kit

7. Glass shade

8. Receiver

9. Remote control with holder and

2 mounting screws

10. 1.5V AAA battery (2)

10. Balancing kit

A. Mounting hardware:

#10 x 1.5" Wood screws (2 PCs.)

#8 x 3/4" Machine screws (2PCs.)

Lock washers (2 PCs.)

4mm Star washers (2 PCs.)

Washers (2 PCs.)

Wire nuts (3 PCs. ),

B. Blade removal tool

PACKAGE CONTENTS

Unpack your fan and check the contents. You should have the following items:

Tools Required: Phillips screw driver; slotted screw driver; step-ladder; wire cutters; electrical tape.

INSTALLING THE MOUNTING BRACKET

WARNING:

All of the parts, hardware and components such as the hanger bracket and hanger ball have

been provided for your safety and the proper installation of your new ceiling fan. The use of other parts,

hardware or components not supplied by Minka Aire

with the fan will void the Minka Aire

Warranty.

REMEMBER To turn off the power. Follow the steps below to hang your fan properly.

Step 1. Attach the mounting bracket to the outlet box with two screws and washers provided. Make sure

the bracket is tight and secured. (Fig. 1)

Step 2. Remove the double-sided tape on the mounting bracket and stick the receiver on the mounting

bracket. (Fig. 1)

Step 3. Place decorative ring onto the fan motor/housing assembly. Lift fan into position by hanging the

motor assembly onto the hook from the ceiling mounting bracket allowing it to hang freely. (Fig. 1)

Fig. 1

DECORATIVE

RING

MOUNTING

BRACKET

RECEIVER

ELECTRICAL CONNECTIONS

WARNING:

To avoid possible electrical shock be sure electricity is

turned off at the main fuse or breaker box before wiring.

NOTE:

The Aire Control

System is equipped with a learning frequency

function which has 1024 code combinations to prevent potential

interference from other remote units. The frequency on your Transmitter

units have been preset at the factory. (Fig. 2) No frequency change is

necessary, should you desire to install another fan within the same

home or area with a seperate frequency code please see the "frequency

interference" troubleshooting section of this instruction manual to learn

how to change the frequency.

NOTE:

fan must be installed from a maximum distance of 40 feet from

the transmitting unit for proper signal transmission between the

transmitting unit and the fan's receiving unit.

Step 1. Motor to receiver electrical connections: Be sure to snap together

the 2-PIN, 4-PIN connectors and sansor wire connector from the receiver

and fan. (Fig. 3 & 4)

Step 2. Receiver to house supply wires electrical connections: connect

the white wire (neutral) from the outlet box to the white wire marked

"AC in N" from the receiver. Connect the black wire (hot) from the outlet

box to the black wire marked "AC in L" from the receiver. Secure all wire

connections with the plastic wire nuts provided. (Fig. 3 & 4)

Step 3. If your outlet box has a ground wire (green or bare copper)

connect this wire to the mounting bracket and receiver ground wires. If

your outlet box does not have a ground wire, then connect the mounting

bracket and receiver ground wires together. Secure wire connection with

the plastic wire nut provided. (Fig. 4)

After all splices are made, check to make sure there are no loose strands.

As an additional precaution we suggest to secure the plastic wire

connectors to the wires with electrical tape.
