Mitko JEHLAN Alu (Static) Mini 1 Manuale utente

JEHLAN Alu (Stac) Mini 1, Mini 2, Mini 3

JEHLAN Alu (Stac) Base 1, Base 2, Base 2 Stage, Base 3

EN lDE lNL lLT lCZ lPL

MANUAL l GEBRAUCHSANWEISUNG l MONTAGEHANDLEIDING l

INSTRUKCIJA l NÁVOD l INSTRUKCJA

2/52

JEHLAN – MANUAL ___________________________ 3

JEHLAN – GEBRAUCHSANWEISUNG _______________ 11

JEHLAN - MONTAGEHANDLEIDING ________________ 19

JEHLAN – INSTRUKCIJA ________________________ 27

JEHLAN – NÁVOD____________________________ 35

JEHLAN – INSTRUKCJA MONTAŻU ________________ 43

3/52

ENGLISH

JEHLAN – MANUAL

WE RECOMMEND

1. Becauouswhilefoldingandunfoldingtheframe.

2. Beforespreadingthetent,pleasereadtheinstallaoninstruconscarefully.

3. Formounnganddismounngthetent,youneedappropriately:forone-pole

tent–2persons,two-poletent–2persons,three-poletent–3persons.

4. Beforedisassemblingthestructure,itmustbethoroughlycleaned.TheProducer

isnotliableforanydamageresulngfrommulpleassembly/disassemblyof

thedirtystructure.

5. Thefabric(roofandsidewalls)shouldbecleanedanddriedbeforepackingit

intotransportbags.TheProducerdoesnotbearanyresponsibilityforpossible

stainsarisenasaresultofstoringwetordirtyfabric.

6. Withrecurringgustsofwind,anchoringshouldbecheckedsystemacally.

7. Toremovethepinsandanchors,werecommendthatyouuseaninstrument

(thatisnotincludedinthestandardtentequipment)

SAFETY

1. JEHLANtentisnotintendedforuseduringastrongwind,blizzards,hail,storms,

etc.

2. Thetentmustnotbelewithoutanysupervision.

3. Thetentsarenotadaptedtoexploitaonundersnowload.Oneshouldremove

thesnowgatheringontheroof,ifthelayerofthesnowis2cmorhigher.

4. Waterlingeringontheroofshouldbeimmediatelyremoved.

5. TheProducerstatesthatpolyesterfabricsmarkedwithOG/FRsymbolarere

resistantandthattheymeetrequirementsofPN-EN13501-1norm.

6. TentsJEHLANAlu(Stac)insizesMini1,Mini2,Mini3,Base1,Base2,Base2

Stage,Base3,maybeusedwithwindupto28m/s(100km/h)provideditis

protectedagainstwindgustsasdescribedintableno.2.

 Duringstrongerwind,itisrecommendedinallcasestodisassemblethetent

(rstremovethewallandthenfoldtheroof).Mechanicaldamageresulng

fromfailuretofollowtheaboverecommendaonsarenotcoveredbythe

warranty.

4/52

ENGLISH

Elementsofthetent

Thenumberofpiecesinaset

Mini1 Mini2 Mini3 Base1 Base2 Base2

Stage Base3

Polyesterfabric 1111111

Mastbasealuminum 1 2 3 1 2 — 3

Polebase 1231223

Anchorstakes

xingthebaseof

atent

Lenght:460mm

3693669

Endofthemastwithrollers 1231223

Setsofropesusedtopulithe

fabricup(insideofthemast) 1231223

Stakesfromthe

trysquarewith

snap-hooks,

Lenght:450mm

810 14 8 14 10 18

Hammer2kg 1111111

Legs-arrangingtool 1111111

Carrybags

(+onebagforwalls) 3(4) 4(5) 6(7) 3(4) 4(5) 4(5) 6(7)

Table1.ComponentsofJEHLANAlu(Stac)tents

5/52

ENGLISH

Table2.WaysofanchoringJEHLANAlu(Stac)tents

Tent

Elementsofthetent

(thenumberingof

armsaccordingto

gure1,point4)

Wind

speed

[km/h]

Concreteground

–numberoffasteners

Landground

–numberoffasteners

Anchor

12x120***

AnchorHil

HLC-EC****

460mm

longpin*

450mm

longanchor

Mini1

polebase 50–100 3 — 3 —

arm1–8 <50 — 1 — 1*

arm1–8 50–100 — 1 — 2**

Mini2

polebase 50–100 3 — 3 —

arm1–10 <50 — 1 — 1*

arm1–10 50–100 — 1 — 2**

Mini3

polebase 50–100 3 — 3 —

arm11,12 <50 — 1 — 2*

arm1–10 <50 — 1 — 1*

arm11,12 50–100 — 2 — 3**

arm1–10 50–100 — 1 — 2**

Base1

polebase 50–100 3 — 3 —

arm1–8 <50 — 1 — 1*

arm1–8 50–100 — 1 — 2**

Base2

polebase 50–100 3 — 3 —

arm3,5,8,10 <50 — 1 — 2*

arm1,2,4,6,7,9 <50 — 1 — 1*

arm3,5,8,10 50–100 — 2 — 3**

arm1,2,4,6,7,9 50–100 — 1 — 2**

Base2

Stage

polebase 50–100 3 — 3 —

arm3,7 <50 — 1 — 2*

arm1,2,4,5,6,8 <50 — 1 — 1*

arm3,7 50–100 — 2 — 3**

arm1,2,4,5,6,8 50–100 — 1 — 2**

Base3

polebase 50–100 3 — 3 —

arm3,5,8,10,11,12 <50 — 1 — 2*

arm1,2,4,6,7,9 <50 — 1 — 1*

arm11,12 50–100 — 2 — 4**

arm3,5,8,10 50–100 — 2 — 3**

arm1,2,4,6,7,9 50–100 — 1 — 2**

*Tent’sstandardequipment

**Non-standardtentequipmentaccessory

***Kwikbolt12x120-Non-standardtentequipmentaccessory

****HilHLC-EC16x100–Art.oeredbyHil(www.hil.pl)

6/52

ENGLISH

Fig.1.JEHLANtentmeasuring

7/52

ENGLISH

Fig.2.JEHLANtentinstallaonprocess

8/52

ENGLISH

MONTAGE

Figure1and2presentmeasuringandinstallaonprocessoftwo-poletentwithwalls.In

thecaseofhigherorlowernumberofpoles,proceedsimilarlywitheachpole.

1. Pulloutallthecomponentsandcheckthatthecontentsofthebagsarein

accordancewiththelistofcomponents.

2. Setthebaseofthepoleonaatsurfaceandaachitwith460mmpinstothe

ground.

3. Onthebaseofthetube,fastenthebeltoftheinstrumenttomeasurearms.

4. Usingtheinstrument,markthespotswhereyouwanttoinsert450mm

anchors.Inthecaseoftentswithtwoormorepoles,marktherstspot(1)

withastringalongthecenter-lineofthepoles(A,B,C)andstretchitinto

atrianglebyreceivingthesecondspot(2).Measurefurtherspotsbyshiing

thecornerofinstrument’striangle(1)onthepreviouslyinsertedanchor(2),

whilethesecondcornerofthemeasuringtriangle(2)willsetoutthenextspot

fortheanchor(3).

5. Theinstrumenttomeasurethedistancebetweenthepoleshasstringswith

stripes.Tomeasurethedistancebetweenanchorsandpoles,usethestrings

withwheels.

6. Insert450mmanchorsinthedesignatedspots

7. Aermeasuringandinserngalltheanchors,foldthepole(poles).Notethat

thestringtopulltheroofin,runsinthemiddleofthepole.

8. Coverthefoldedpolewitharoof.

9. Insertthepieceofstringsckingoutofthepoletothebaseofthetube.

10.Pulloutthestringfromtheboom,leanitagainstthereelandentertheendof

thestringtotheholeinratchetmechanism.

11.Checkiftheratchetmechanismisin„lock”posion.Theratchetsecuresthe

winchagainstrelease

12.Putthe„cap”onthepole.Throughtheholesinthe„cap”threadtheearsof

roof’scrown.Fastenthehookswithstringstotheears.

13.Embedthepoleinthepipe.

14.Buckleupthearmsofthetentbyusingfences,topreviouslymeasuredand

insertedanchors.

15.Rollthewinchtolitheroof.

16.Litheroofuptoabout3/4oftheheightofthepole.

17.Buckleupthewallstothefencessupporngthearmsoftheroof.

18.Pullupthezippers.

19.Aerzippingallthewalls,litheroofbyrollingthewinchunlyousense

resistance.SecuretheratchetwithPVCbelt.

9/52

ENGLISH

DISASSEMBLY

1.Removealltheitemsunderthetent.

2. Releasetheratchet(g.2,point12)to„unlock”posion,besuretoholdthe

winchwithyourotherhand.

PLEASENOTE!Ifyoureleasethewinchwithoutholdingit,youmaybehit.

Slowlyrollthewinchtolowertheroofto3/4ofheight.Slidetheratchetof

themechanismto„lock”posion.

3. Detachandfoldthewalls;putthemintothebag.

4. Lowertheroofenrely.

5. Unpinthearmsofthetentfromtheanchors.

7. Removethepolefromthebaseandremovethestringfromthebaseofthe

mechanism

8. Taketheroofdown,foldthepole(poles).

9. Removethebasepinsandarms’anchorsfromthegroundandremovethe

remnantsofgroundfromthem.

10.Putallitemstoappropriatebags.

POLYESTER MATERIALS CARE LABEL

1. Chemicalwashingisforbidden.

2. Donotuseawashingmachine.

3. Waterhandwashing-trytokneadsoly,donotrub,donotwring.

4. Surfacewashing-dirtyplacesshouldbewashedwithasponge.

5. Washingtemperature-maximum40°C.

6. Washingdetergent,intendedforsynthecmaterials,shouldbeusedasper

labelledproporons.

7. Rins2to3mesinthewarmwaterandonceinthecoldwater.

8. Donotswirl.Donotwring.

9. Dryinthevercalposionattheroomtemperature(allowwaterdripping).

10.Irontheoutsideofthematerial(uncoated)withtheironinthehighest

temperatureof110°C.

11.Washingwithorganicsolventsisforbiddenaswellaslocalstainswashing.It

isbecausesuchmaterialsarenotresistanttosolvents.Donotletbiggrime

toappear.Donotdisinfectwithchlorine.Donotbleach.

12.Keepawayfromre.Incaseofaminguptrytoputthereoutwiththe

water,drypowderorcarbondioxideexnguisher(ABCorBC).

Fig.3.Rulesforpolyestertexlesconservaon

10/52

ENGLISH

COATED MATERIALS (ECO-LEATHER, POLYESTER FABRIC PVC COATED, PVC)

CARE LABEL

1. Chemicalwashingisforbidden.

2. Donotuseawashingmachine.

3. Waterhandwashing-trytokneadsoly,donotrub,donotwring.

4. Surfacewashing-dirtyplacesshouldbewashedwithasponge.

5. Washingtemperature-maximum40°C.

6. Washingdetergent,intendedforsyntecmaterials,shouldbeusedasper

labelledproporons.

7. Rins2to3mesinthewarmwaterandonceinthecoldwater.

8. Donotswirl.Donotwring.

9. Dryinthevercalpossionattheroomtemperature(allowwaterdripping).

10.Donotiron.

11.Washingwithorganicsolventsisforbiddenaswellaslocalstainswashing.

Itisbecausesuchmaterialsarenotresistanttosolvents.Donotletbiggrime

toappear.Donotdisinfectwithchlorine.Donotbleach.

12.Keepawayfromre.Incaseofaminguptrytoputthereoutwiththewater,

drypowderorcarbondioxideexnguisher(ABCorBC).

Fig.4.Rulesforcoatedtexlesconservaon

TheProducerreservestherighttoimplementchangestoaboveinformaon.

THE PRODUCER:

MITKOSp.zo.o.

Osiedle1Maja16G|44-304WodzisławŚląski|Poland|TIN:PL6470509572

Tel.+48324446616|Fax:+48327570920|kontakt@mitko.pl|www.mitko.pl
