Mitsubishi Electric CX series Guida utente

COMPACT

CX SERIES

Owner’s Handbook

CX SERIES

OWNER’S HANDBOOK

DESKTOP (KL) EDITION

Microsoft, MS-DOS, Windows and Windows NT are registered trademarks of

Microsoft Corporation in the US and other countries.LANDesk is a registered

trademark of Intel Corporation.

LANDesk is a registered trademark of Intel Corporation.

Other trademarks mentioned within this document and not listed above are the

properties of their respective owners.

Information contained in this document is subject to change without notice and does

not represent a commitment on the part of Apricot Computers Limited. Any software

described in this manual is furnished under a license agreement. The software may be

used or copied only in accordance with the terms of this agreement. It is against the law

to copy any disk supplied for any purpose other than the purchaser’s personal use.

No part of this manual may be reproduced or transmitted in any form or by any means

electronic or mechanical including photocopying and recording, for any purpose,

without the express written permission of the publishers.

Published by:

Apricot Computers Limited

3500 Parkside

Birmingham Business Park

Birmingham, England

B37 7YS

http://www.mitsubishi-computers.com

Printed in the United Kingdom

NOTICES/i

SAFETY AND REGULATORY NOTICES

General

Electrical

The system employs a safety ground

Das System benötigt aus Sicherheitsgründen einen Masseanschluß

Le système doit être mis à la terre

Dette system bruger en sikkerhedsjordforbindelse

Apparaten skall anslutas till jordat uttag när den anslutas till ett nätverk

The system unit AC power cord is its ‘disconnect device’. Ensure that the system

unit is positioned close to the AC power outlet and that the plug is easily accessible.

The power cord packed with the computer complies with the safety standards

applicable in the country in which it is first sold. Use only this power cord. Do not

substitute a power cord from any other equipment.

To prevent fire and electric shock, do not expose any part of the computer to rain or

moisture. Turn off the computer and unplug all power cords before moving or

cleaning the system unit, or removing the system unit top cover.

Battery

This product contains a lithium battery.

Do not use a metal or other conductive implement to remove the battery. If a short-

circuit is made between its positive and negative terminals the battery may explode.

Replace a discharged battery with one of the same type; another type may explode

or ignite. Follow the instructions contained in the Owner’s Handbook to replace the

battery. Dispose of a discharged battery promptly and in accordance with the

battery manufacturer’s recommended instructions. Do not recharge, disassemble or

incinerate the discharged battery. Keep away from children.

Laser products

Any CD-ROM drive fitted in this system is classified as a CLASS 1 LASER

PRODUCT according to IEC825 Radiation Safety of Laser Products (Equipment

Classification: Requirements and User's Guide). The CLASS 1 LASER PRODUCT

label is located on the underside of the system unit.

The CD-ROM drive contains a laser system which is harmful to the eyes if exposed.

Do not attempt to disassemble the CD-ROM drive; if a fault occurs, call an

authorised maintainer.

Use the CD-ROM drive only as described in this manual. Failure to do so may

result in exposure to hazardous radiation.

Safety & Regulatory Notices

NOTICES/ii

Ergonomic

When positioning the system unit, monitor and keyboard, take into account any

local or national regulations relating to ergonomic requirements.

Anti-static precautions

Warning

Static electricity can cause permanent damage to electronic components. You

should be aware of this risk, and take precautions against the discharge of static

electricity into the computer.

The computer is at risk from static discharge while the top cover is off. This is

because the electronic components of the motherboard are exposed. Memory

modules, expansion cards and replacement processors are examples of electrostatic

sensitive devices (ESSDs).

All work that involves removing the cover must be done in an area completely free

of static electricity. We recommend using a Special Handling Area (SHA) as defined

by EN 100015-1: 1992. This means that working surfaces, floor coverings and

chairs must be connected to a common earth reference point, and you should wear

an earthed wrist strap and anti-static clothing. It is also a good idea to use an ionizer

or humidifier to remove static from the air.

When installing any upgrade, be sure you understand what the installation

procedure involves before you start. This will enable you to plan your work, and so

minimise the amount of time that sensitive components are exposed.

Do not remove the system unit cover, nor the anti-static bag or wrapping of any

upgrade, until you need to.

Handle static-sensitive items with extreme care. Hold expansion cards and add-on

components only by their edges, avoiding their electrical contacts. Never touch the

components or electrical contacts on the motherboard or on expansion cards. In

general, do not handle static-sensitive items unnecessarily.

Keep all conductive material, and food and drink, away from your work area and the

open computer.

Thermalcote bonding compound

The thermal bonding compound used between the system processor and its heat

sink can cause skin irritation and stain clothing. Avoid prolonged or repeated

contact with skin. Wash thoroughly with soap and water after handling. Avoid

contact with eyes and inhalation of fumes. Do not ingest.

Safety & Regulatory Notices

NOTICES/iii

Maintenance

Switch off and disconnect all cables before attempting to clean the computer.

Do not use sprays, solvents or abrasives that might damage the system unit surface.

Do not use cleaning fluids or sprays near air vents, ports, or the diskette and CD-

ROM drives.

Occasionally wipe the system unit with a soft, slightly damp, lint-free cloth.

Occasionally wipe over the air vents on the rear and sides of the system unit. Dust

and fluff can block the vents and limit the airflow.

Occasionally clean the diskette and CD-ROM drives using a proprietary head

cleaner.

Occasionally wipe the monitor with a soft, slightly damp, lint-free cloth. It is best to

use anti-static glass cleaner on the monitor screen, but do not spray glass cleaner

directly onto the screen; it could run down inside the case and damage the circuitry.

Transporting

Use common sense when handling the computer; hard disks in particular can be

damaged if the computer is dropped or handled roughly. As a precaution, back up

the contents of the hard disks to tape or diskettes before moving the computer.

Switch off and disconnect all cables before attempting to move the computer,

particularly do not try to move the computer while it is plugged into the AC power

supply.

When lifting and carrying the computer, use the metal sides of the system unit and

never attempt to lift the system unit with a monitor still on top.

If you need to transport the computer any great distance, use the original packing

materials.

If you are planning to use the computer in another country, it may not be suitable,

check with your supplier, particularly on the availability of the correct AC power

cords.

Note

Any existing maintenance or warranty agreement may not be supportable in another

country. The system may have to be returned to the supplier.

Safety & Regulatory Notices

NOTICES/iv

Legalities

This equipment complies with the relevant clauses of the following European

Directives (and all subsequent amendments):

Low Voltage Directive 73/23/EEC

EMC Directive 89/336/EEC

Telecommunications Directive 91/263/EEC

CE Marking Directive 93/68/EEC

Important

This system, when supplied, complies with the CE Marking Directive and its strict

legal requirements. Use only parts tested and approved by Mitsubishi Electric PC

Division. All expansion cards, drives and peripherals should carry the CE mark.

Standards

Safety

This product complies with the International Safety Standard IEC950 and

additional requirements thereto to comply with European Safety Standard

EN60950.

Electro-magnetic Compatibility (EMC)

This product complies with the following European EMC standards:

Emissions EN50022 Class B

Immunity EN50082-1

This product also complies with the following International EMC standards:

VCCI (Japan) Class B

Notes

All interconnecting cables (for example, signal and communication cables) should

be less than 2 metres in length. If cable extensions are used, ensure adequate earth

connections are provided and screened cables are used.

If any metal casework components are removed, during upgrade work for example,

ensure that all metal parts are correctly re-assembled and all internal and external

screws are re-fitted and correctly tightened.

This system has an on-board network connection. If you add an additional network

card, any attempt to use two network connections simultaneously may result in the

product no longer being compliant with the CE Marking Directive. Consult your

Mitsubishi Electric PC dealer for up to date information.

Safety & Regulatory Notices

NOTICES/v

Power Connection

Typical AC plugs

250V

125V

250V

BS1363A SHUCO NEMA 5-15P SRAF 1962/DB16/87 ASE 1011

U. K. Austria Belgium Taiwan Denmark Switzerland

Finland France Thailand

Italy Germany Japan

Sweden Norway USA

Holland Canada

Checking the AC power supply

When this product is delivered, it is ready for the commercial AC power supply

generally available in the country in which it is first sold. It has been set for the

correct voltage range, and is supplied with an AC power cord and plug which

comply with the relevant safety standards.

Before using the product in a country other than that in which it was originally

sold, you must check the voltage and frequency of that country’s AC power supply,

and the type of power cord required there. Check the power rating labels on the rear

of the computer’s system unit and its monitor to ensure that they are compatible

with the AC power supply.

The computer can function within two alternative AC power supply ranges,

according to the position of the voltage selection switch on the rear of the system

unit:

Switch setting AC power supply (voltage and frequency)

115 100 - 120 volt AC, 50 - 60 Hz

230 220 - 240 volt AC, 50 - 60 Hz

The voltage setting of the monitor must always be the same as the voltage setting of the

system unit. See the User’s Guide that accompanies the monitor or consult your

supplier to find out how to change the voltage setting.

Caution

It is imperative that the computer is set to the correct voltage range before use. If not,

the machine may be irreparably damaged.

Safety & Regulatory Notices

NOTICES/vi

Connecting to the AC power supply

Important

Any peripheral equipment that requires an AC power cord must be earthed.

Use the following guidance to connect the components together. It is important

that you take each step in the order indicated.

1. Before connecting any components, ensure that the AC power supply is

switched off or disconnected, and that the system unit, the monitor, and any

peripherals are turned off.

2. Connect the component signal cables to their respective ports on the system

unit: keyboard, mouse, monitor, audio (where appropriate) and any other

peripherals.



Where appropriate, connect the computer to the network.

3. Connect the component power cords: system unit, monitor to system, plus

any other peripherals to nearby, grounded AC power outlets. (Never

substitute a power cord from any other appliance). Then switch on or

connect the AC power supply.

4. Turn on the system unit first, then the monitor, then other peripherals.

Warning

The Owners Handbook contains procedures which require opening of the system unit.

Ensure all cables (including modem and network cables) are disconnected before the

system unit is opened.

Power Cable Connections - UK ONLY

This equipment is supplied with an AC power cord that has a non-removable

moulded plug.

Always replace the fuse with one of the same type and rating which is BSI or ASTA

approved to BS1362. Always refit the fuse cover, never use the plug with the fuse

cover omitted.

External Speakers (where supplied)

Always switch off or disconnect the AC supply before disconnecting any of the

speaker leads, whether audio or power. Disconnect the AC supply from the speaker

power unit when not in use for any period of time.

To prevent the risk of electric shock, do not remove speaker covers.

Connecting the speaker power cord to any other cords or joining cords together can

cause fire and risk of electric shock.

Contents

OWNER’S HANDBOOK I

CONTENTS

1 Welcome

Unpacking 1/1

Pictorial guide to the system unit 1/2

General advice 1/6

Connecting the components 1/7

2 Getting Started

Turning on the PC 2/1

Power management 2/2

Power management and Windows 2/2

Shutting down the PC 2/4

Using the computer for the first time 2/5

Backing-up the pre-installed software 2/5

Improving your display settings 2/6

If your hard disk is larger than 2 gigabytes 2/7

3 Diskettes and CDs

Diskette drive 3/1

CD-ROM drive (optional) 3/3

4 Expansion Cards

Configuring the card 4/2

Installing the card 4/5

Reserving ISA legacy resources 4/6

Telling Windows about the new hardware 4/7

Indice

Altri manuali Mitsubishi Electric Scrivania

Mitsubishi Electric

Mitsubishi Electric Apricot FT1200 Guida utente

Mitsubishi Electric

Mitsubishi Electric MC100 Manuale utente

Mitsubishi Electric

Mitsubishi Electric apricot XEN-LS Manuale utente

Mitsubishi Electric

Mitsubishi Electric Apricot XEN pentium Guida utente

Mitsubishi Electric

Mitsubishi Electric MC300 Manuale utente

Mitsubishi Electric

Mitsubishi Electric Apricot LS Guida utente

Mitsubishi Electric

Mitsubishi Electric APRICOT 340 Guida utente

Mitsubishi Electric

Mitsubishi Electric apricot ls/vs550 Guida utente

Mitsubishi Electric

Mitsubishi Electric MXZ-18TV -E1 Manuale utente

Mitsubishi Electric

Mitsubishi Electric Apricot VS 550 Guida utente

Mitsubishi Electric

Mitsubishi Electric MXZ-24UV -E2 Manuale utente

Mitsubishi Electric

Mitsubishi Electric A1 S64TCTT Manuale utente

Mitsubishi Electric

Mitsubishi Electric Apricot VS Guida utente

Mitsubishi Electric

Mitsubishi Electric Apricot LS Guida utente

Mitsubishi Electric

Mitsubishi Electric APRICOT FT4200 Guida utente

Mitsubishi Electric

Mitsubishi Electric APRICOT LS340 Guida utente

Mitsubishi Electric

Mitsubishi Electric Apricot Guida utente

Mitsubishi Electric

Mitsubishi Electric Apricot LS700 Guida utente

Mitsubishi Electric

Mitsubishi Electric APRICOT FT//EX Manuale utente

Mitsubishi Electric

Mitsubishi Electric apricot MS660 Guida utente

Mitsubishi Electric

Mitsubishi Electric Apricot LS660 Guida utente

Mitsubishi Electric

Mitsubishi Electric Apricot FT S Pentium Series Manuale utente

Mitsubishi Electric

Mitsubishi Electric LS Pro Manuale per l'uso e la cura

Mitsubishi Electric

Mitsubishi Electric Apricot LS Manuale utente

Manuali Scrivania popolari di altre marche

HP m9060n - Pavilion - Elite Scheda tecnica

Asus

Asus E210 Series Manuale utente

Dell

Dell Inspiron 600m Manuale utente

Dell

Dell Inspiron 3662 Manuale utente

TotalFlow

TotalFlow uFLO Manuale utente

HP Presario SV7000 - Desktop PC Manuale utente

HP ProDesk 400 G5 Manuale

Logitech

Logitech MK320 Manuale utente

Dell

Dell XPS 730 H2C Manuale utente

Sony

Sony Vaio Series Manuale utente

Sony

Sony VGC-LT32E - Vaio All-in-one Desktop Computer Manuale utente

Alto

Alto MD 250 Manuale utente

Lenovo

Lenovo ThinkCentre Edge 72 Manuale

Lenovo

Lenovo ThinkStation D20 Manuale

Arbor Technology

Arbor Technology FPC-7800 Series Manuale utente

Sony

Sony VAIO VGX-TP1 Series Manuale utente

Asus

Asus Eee Box B204 Manuale utente

Dell

Dell Optiplex 9010 All In One Manuale utente
