Mitsubishi 2015 OUTLANDER Guida utente
Owner’s Handbook
ACAD-P08000 (6/14)
www.mitsubishicars.com
2015 OUTLANDER
2015 OUTLANDER
Dieline -DO NOT PRINT!
PLEASE PLACE COPIES OF THE FOLLOWING ITEMS IN THE POCKET BELOW:
1. Pre-Delivery Inspection Form (Customer Copy)
2. Triple Diamond Delivery Checklist (Customer Copy)
3. Salesperson or Key Dealership Contact’s Business Card
Owner’s Handbook
ACAD-P08000 (6/14)
www.mitsubishicars.com
2015 OUTLANDER
2015 OUTLANDER
Dieline -DO NOT PRINT!
1
Thank you for buying a Mitsubishi Outlander. There’s no doubt you’ve already realized how
well your car drives on the open road. What you may not know is all the great features that
help your car perform the way it does. In the pages ahead we’re going to run through the
basics and prepare you for the road.
We’d also love to hear from you about your overall Mitsubishi experience. If you haven’t
already, please log on to www.MitsubishiSSIsurvey.com and tell us how we did. This will help
us make sure your next visit is that much better.
We hope you will visit the Mitsubishi Owner’s site where we store the latest Mitsubishi news
and special offers. Here you can also keep track of your car’s warranty and servicing needs,
get Roadside Assistance Information and tap into other owner-centric details. Just log on to
www.Mitsubishicars.com/ownersonly.
Driver’s View ..................... Page 2-3
Controls ............................ Page 4-5
Own the Road................... Page 6
Switches ........................... Page 7
ECO Driving ...................... Page 8
Folding and Stowing
the Second and Third
Row Seat .......................... Page 9
Technology ...................... Page 10
Audio System.................... Page 11
Display Audio System
(if equipped)..................... Page 12-13
Bluetooth®........................ Page 14
FAQ’s................................ Page 15-16
Table of Contents
2
2
14
9
16
3
7
Driver’s View
1 Climate Controls................................... Page 4
2 Headlights ........................................... Page 4
3Side
Mirror Adjustment
......................... Page 5
4Windshield Wiper Lever........................ Page 5
5 Adaptive Cruise Control (if equipped) ... Page 6
6 AWC (All Wheel Control) Button............ Page 6
7 Paddle Shifters (GT only) ..................... Page 6
8 Seat Heater Switch (if equipped) ......... Page 6
9 Lane Departure Warning (LDW) and
Forward Collision Mitigation (FCM)
(if equipped)........................................ Page 7
10 Power Liftgate Main Switch
(if equipped)........................................ Page 7
11 ECO Mode Switch ................................ Page 8
12 Multi Information Display (MID)............ Page 10
13 Start/Stop Engine Switch
(if equipped with F.A.S.T.-key).............. Page 10
14 Audio Remote Control Buttons ............. Page 11
15 Display Audio/Navigation
(if equipped)........................................ Page 12-13
16 Bluetooth®Controls.............................. Page 14
3
5
4
12
15
1
10
8
11
13
7
6
A- Push to select the desired temperature
B- Push to select outside air (Indicator light off) or recirculated air (Indicator light
on)
C- Push for air conditioning ON/OFF
D- Push to select the blower speed
E- Push to select the position of air flowing from the vents
F- Push to defog windshield.
G- When the AUTO switch is pushed, the settings are automatically controlled.
Passenger’s side temperature will be changed to the same temperature set as the
driver’s side
H- Push to defog the rear windows.
4CONTROLS
Regular Headlights Automatic Headlights (if equipped)
Headlights and other lights on.
Parking, tail, front and rear sidemarker lights, license plate and instrument panel lights on.
Headlights and other lights turn on and off automatically in accordance with outside light level.
All lights off
Pull lever toward driver to activate high beams.
AUTO
OFF
Dual-Zone Automatic Climate Controls (if equipped)
AA
B GF H
D EC
5
The outside rearview mirrors can be
adjusted when the ignition switch is in the
“ON” or “ACC” position or the operation
mode is put in ON or ACC.
Move the lever (A) to the same side as the
mirror you wish to adjust.
Windshield Wipers
The wipers will operate once.
INT: Intermittent intervals can be
adjusted by turning the knob A
AUTO: The wipers will be operated
automatically by rain sensor
(if equipped).
Slow
Fast
Rear Window Wiper and Washer
A
Adjust switch
Turn the knob Bto operate the rear
window wiper.
The wiper operates continuously
for several seconds then operates
intermittently at intervals of about 8
seconds.
Washer fluid is sprayed, the wiper will
automatically operate 2 or 3 times.
Side Mirror Adjustment
CONTROLS (continued)
6
A - CANCEL: To deactivate the ACC or
cruise control
B - RES +: To increase the set speed or
resume control after cancelling the
ACC or cruise control function.
C-SET-: To set the desired speed and
to reduce the set speed.
D-ON / OFF: To turn cruise control ON or OFF
E - ACC Distance Switch - Used to set or change the following distance between your vehicle and the vehicle in
front of you.
To set a cruising speed
1. Press Dand the “ACC” (if equipped) or “CRUISE” indicators will appear in the multi information display.
2. Accelerate or decelerate to your desired speed (above 25 mph). Press Cand remove your
foot from the accelerator pedal.
To accelerate or decelerate speed
Push up Bto increase set cruising speed.
Push down Cto decrease set cruising speed.
To cancel the cruising speed Press Aor press brake pedal, or press D .
OWN THE ROAD
– :SHIFT DOWN + :SHIFTUP
Paddle Shifters (GT only)
Seat Heater Switch (if equipped)
Position - Action
(HI) - For quick heating
(NEUTRAL) - Heater off
(LO) - To keep the seat warm
Drive Mode Selector (if equipped)
The drive mode can be switched
by pressing the drive mode button
while the ignition switch is in the ON
position.
Pressing the button will change the
drive mode in order to:
AWC ECO, NORMAL, SNOW, LOCK
Adaptive Cruise Control (if equipped)
AB
C
D
E
Simply upshift or
downshift with a tap of
your fingers – without
moving your hands from
the steering wheel.
You can return to the “D”
operation by pulling the +
(SHIFT UP) side paddle
shifter rearwards (toward
the driver) and holding for
over 2 seconds.
7
SWITCHES
Active Stability Control (ASC) Off Switch Lane Departure Warning (LDW) Switch (if equipped)
Power Liftgate Switch (if equipped)
Power Liftgate Main Switch (if equipped)
Forward Collision Mitigation (FCM) Switch (if equipped)
You can deactivate the system by
pressing down the “ASC OFF” switch for
3 seconds or longer.
When the ASC is deactivated, the
display/indicator will turn on. To
reactivate the ASC, momentarily press
the “ASC OFF” switch; the display/
indicator is turned off.
When you press the LDW switch, the “LDW” indicator on the
information screen of the multi information display turns OFF
and the LDW system is inactive.
Press the switch again, the system will activate.
The power liftgate can be opened by
pressing the Power Liftgate Switch.
When the power liftgate main switch (located in the
lower center dash area) is ACTIVE, the power liftgate
can be operated using either the power liftgate switch
on the F.A.S.T.-key, the driver’s side power liftgate
switch or the open/close switches on the power
liftgate.
Every time the operation mode is turned to “ON”, the FCM
will automatically be turned on.
To turn off the FCM, press and hold the FCM switch. A buzzer
will sound and the “FCM OFF” message and
indicator will appear in the multi information
display.
To change the warning distance mode, briefly
press the FCM switch.
8ECO DRIVING
ECO Drive Assist
ECO drive level
Low High
Multi information
display switch
ECO indicator
ECO mode switch
ECO Score
ECO drive level
Low High
Momentary fuel consumption display
This indicator will be displayed when fuel
efficient driving is achieved.
ECO mode is an eco-driving support
system which automatically controls
the engine, air conditioning system,
4WD system (if equipped) and
S-AWC (if equipped) to improve
fuel efficiency.
To activate, press the ECO mode
switch.
While driving, the momentary fuel
consumption is shown with a bar
graph.
The “
” mark in the momentary
fuel gauge shows the average fuel
consumption.
When the momentary fuel consumption surpasses the average fuel
consumption, the momentary fuel consumption is displayed with a green
bar graph.
Maintaining your fuel consumption above the average fuel consumption
point will help increase your mileage per gallon.
To show, press the multi information display switch.
This function displays how fuel-
efficiently you are driving under
different driving conditions.
To show, press the multi
information display switch.
ECO score indicates the points
you have scored on fuel-efficient
driving by the number of leaves.
To show, press the multi
information display switch.
Tire Pressure Monitoring System (TPMS)
The Tire Pressure Monitoring System light illuminates
when one or more of your tires is significantly under
inflated. Please note that changes in the outside
temperature may decrease tire pressure causing the
TPMS light to turn on. If the TPMS light remains
illuminated, check your tire pressure.
If the warning light illuminates, take the necessary measures referring to the
owner’s manual.
