Montpelier MICL88 Manuale utente
Integrated Larder Fridge - In Column
MICL88 - 88cm - Slider Fixings
Please read these instructions carefully before attempting to install or use this appliance.
We recommend that you keep these instructions in a safe place for future reference.
Installation and Operating Instructions
THE PERFECT BALANCE OF FUNCTION AND STYLE
LAUNDRY - DISHWASHING - COOKING - COOLING
EN - 2
Icon Type Meaning
WARNING Serious injury or death risk
RISK OF ELECTRIC SHOCK Dangerous voltage risk
FIRE Warning; Risk of re / ammable materials
CAUTION Injury or property damage risk
IMPORTANT Operating the system correctly
Thank you for choosing this Montpellier Integrated Larder Fridge.
Our refrigeration products have been designed to provide you with the best combination of style, reliability and
performance to give you years of trouble-free use.
You may be familiar with a similar product, but please take time to read these instructions carefully before installing
or using your Fridge to ensure you get the most from your purchase.
We recommend that you keep this manual in a safe place for future reference.
Your Integrated Larder Fridge is covered by a comprehensive 5 Year Parts &
Labour Guarantee. In the unlikely event that you experience a problem with
your Fridge, you can rest assured that you are fully protected against the cost
of repairs for the first 5 Years. Please note that any claim must be
accompanied by the model reference number, serial number and proof of
purchase.
To activate your guarantee, you will need your product serial number. This
can be found inside your appliance on the left hand wall on a small sticker.
There are two ways to register your Guarantee:
•Online: Visit the Support page on our website and complete the online Product
Registration form. www.montpellier-appliances.com
•By Post: Simply detach and ll in the form provided, attach a stamp and send
it in the post. Don’t forget to include your e-mail address so that we can send
conrmation through to you.
Welcome
Note: We are unable to take registrations over the phone.
ACROSS INTEGRATED COOLING
YEAR
GUARANTEE
PA R T S & L A B O U R
www.montpellier-appliances.com
EN - 3
CONTENTS
1 SAFETY INSTRUCTIONS ................................................................................. 4
1.1 General Safety Warnings ...............................................................................................4
1.2 Installation warnings.......................................................................................................7
1.3 Electrical information (For UK type plug)........................................................................7
1.4 During Usage..................................................................................................................8
2 DESCRIPTION OF THE APPLIANCE ............................................................... 9
3 USING THE APPLIANCE .................................................................................. 9
3.1 Thermostat Setting .........................................................................................................9
3.2 Temperature Settings Warnings .....................................................................................9
4 FOOD STORAGE ............................................................................................ 10
5 CLEANING AND MAINTENANCE .................................................................. 11
5.1 Defrosting .....................................................................................................................12
5.2 Replacing the Light Bulb...............................................................................................12
6 SHIPMENT AND REPOSITIONING................................................................. 13
6.1 Transportation and Changing Positioning ....................................................................13
7 BEFORE CALLING AFTER-SALES SERVICE............................................... 13
8 TIPS FOR SAVING ENERGY .......................................................................... 14
EN - 4
1 SAFETY INSTRUCTIONS
1.1 General Safety Warnings
Read this user manual carefully.
WARNING: Keep ventilation openings, in the
appliance enclosure or in the built-in structure, clear of
obstruction.
WARNING: Do not use mechanical devices or
other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
WARNING: Do not use electrical appliances inside
the food storage compartments of the appliance,
unless they are of the type recommended by the
manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: When positioning the appliance,
ensure the supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socket-
outlets or portable power supplies at the rear of the
appliance.
WARNING: In order to avoid any hazards resulting
from the instability of the appliance, it must be xed in
accordance with the following instructions:
If your appliance uses R600a as a refrigerant (this
information will be provided on the label of the cooler)
you should take care during transportation and
installation to prevent the cooler elements from being
damaged. R600a is an environmentally friendly and
EN - 5
natural gas, but it is explosive. In the event of a leak
due to damage of the cooler elements, move your
fridge away from open ames or heat sources and
ventilate the room where the appliance is located for a
few minutes.
• While carrying and positioning the fridge, do not
damage the cooler gas circuit.
• Do not store explosive substances such as aerosol
cans with a ammable propellant in this appliance.
• This appliance is intended to be used in household
and domestic applications such as:
–staff kitchen areas in shops, ofces and other
working environments.
–farm houses and by clients in hotels, motels and
other residential type environments.
–bed and breakfast type environments;
–catering and similar non-retail applications.
• If the socket does not match the refrigerator plug,
it must be replaced by the manufacturer, a service
agent or similarly qualied persons in order to avoid
a hazard.
• A specially grounded plug has been connected
to the power cable of your refrigerator. This plug
should be used with a specially grounded socket
of 13 amperes. If there is no such socket in your
house, please have one installed by an authorised
electrician.
EN - 6
• This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the
appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made
by children without supervision.
• Children aged from 3 to 8 years are allowed to load
and unload refrigerating appliances. Children are not
expected to perform cleaning or user maintenance
of the appliance, very young children (0-3 years old)
are not expected to use appliances, young children
(3-8 years old) are not expected to use appliances
safely unless continuous supervision is given, older
children (8-14 years old) and vulnerable people can
use appliances safely after they have been given
appropriate supervision or instruction concerning
use of the appliance. Very vulnerable people are
not expected to use appliances safely unless
continuous supervision is given.
• If the supply cord is damaged, it must be replaced
by the manufacturer, an authorised service agent or
similar qualied persons, in order to avoid a hazard.
• This appliance is not intended for use at altitudes
exceeding 2000 m.
EN - 7
1.2 Installation warnings
Before using your fridge for the rst time,
please pay attention to the following points:
• The operating voltage for your fridge is
220-240 V at 50Hz.
• The plug must be accessible after
installation.
• Your fridge may have an odour when it is
operated for the rst time. This is normal
and the odour will fade when your fridge
starts to cool.
• Before connecting your fridge, ensure
that the information on the data plate
(voltage and connected load) matches
that of the mains electricity supply. If in
doubt, consult a qualied electrician.
• Insert the plug into a socket with an
efcient ground connection. If the socket
has no ground contact or the plug does
not match, we recommend you consult a
qualied electrician for assistance.
• The appliance must be connected
with a properly installed fused socket.
The power supply (AC) and voltage at
the operating point must match with
the details on the name plate of the
appliance (the name plate is located on
the inside left of the appliance).
• We do not accept responsibility for any
damages that occur due to ungrounded
usage.
• Place your fridge where it will not be
exposed to direct sunlight.
• Your fridge must never be used outdoors
or exposed to rain.
• Your appliance must be at least 50 cm
away from stoves, gas ovens and heater
cores, and at least 5 cm away from
electrical ovens.
• If your fridge is placed next to a deep
freezer, there must be at least 2 cm
between them to prevent humidity
forming on the outer surface.
• Do not cover the body or top of fridge
with lace. This will affect the performance
of your fridge.
• Clearance of at least 150 mm is required
at the top of your appliance. Do not place
anything on top of your appliance.
• Do not place heavy items on the
appliance.
• Clean the appliance thoroughly before
use (see Cleaning and Maintenance).
• Before using your fridge, wipe all parts
with a solution of warm water and a
teaspoon of sodium bicarbonate. Then,
rinse with clean water and dry. Return all
parts to the fridge after cleaning.
• The installation procedure into a kitchen
unit is given in the installation manual.
This product is intended to be used in
proper kitchen units only.
1.3 Electrical information (For UK type
plug)
Warning! This appliance must be
earthed.
The mains lead of this appliance has been
tted with a specially earthed plug.
Important: Do not use the
appliance without the fuse cover in position.
Should the fuse need to be replaced, it
must be replaced with a 13A fuse, ASTA
approved to BS1362.
The plug must be used with a specially
earthed socket of 13 amperes. If there is
no such socket in your house, please have
one installed by an authorised electrician.
The mains lead of this appliance has been
tted with a BS 1363A 13A fused plug. To
change a fuse in this type of plug, follow
the steps below:
EN - 8
1. Remove the fuse cover and fuse.
2. Fit replacement 13A fuse, ASTA
approved to BS 1362 type, into the fuse
cover.
3. Replace fuse cover.
1.4 During Usage
• Do not connect your fridge to the mains
electricity supply using an extension lead.
• Do not use damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• Do not use plug adapter.
• This appliance is designed for use by
adults. Do not allow children to play with
the appliance or hang off the door.
• Never touch the power cord/plug with wet
hands. This may cause a short circuit or
electric shock.
• Do not place explosive or ammable
material in your fridge. Place drinks with
high alcohol content vertically in the
fridge compartment and make sure their
tops are tightly closed.
Old and Out-of-order Fridges
• If your old fridge or freezer has a
lock, break or remove the lock before
discarding it, because children may
get trapped inside it and may cause an
accident.
• Old fridges and freezers contain
isolation material and refrigerant with
CFC. Therefore, take care not to harm
environment when you are discarding
your old fridges.
CE Declaration of conformity
We declare that our products meet the
applicable European Directives, Decisions
and Regulations and the requirements
listed in the standards referenced.
Disposal of your old appliance
The symbol on the product or on
its packaging indicates that this
product may not be treated as
household waste. Instead it shall
be handed over to the applicable
collection point for the recycling of electrical
and electronic equipment. By ensuring
this product is disposed of correctly,
you will help prevent potential negative
consequences for the environment and
human health, which could otherwise be
caused by inappropriate waste handling
of this product. For more detailed
information about recycling of this product,
please contact your local city ofce, your
household waste disposal service or the
shop where you purchased the product.
Packaging and the Environment
Packaging materials protect
your machine from damage that
may occur during transportation.
The packaging materials are
environmentally friendly as they are
recyclable. The use of recycled material
reduces raw material consumption and
therefore decreases waste production.
Notes:
• Please read the instruction manual
carefully before installing and using your
appliance. We are not responsible for the
damage occurred due to misuse.
• Follow all instructions on your appliance
and instruction manual, and keep this
manual in a safe place to resolve the
problems that may occur in the future.
• This appliance is produced to be used
in homes and it can only be used in
domestic environments and for the
specied purposes. It is not suitable for
commercial or common use. Such use
will cause the guarantee of the appliance
to be cancelled and our company will
not be responsible for the losses to be
occurred.
• This appliance is produced to be used in
houses and it is only suitable for cooling
/ storing foods. It is not suitable for
commercial or common use and/or for
storing substances except for food. Our
company is not responsible for the losses
to be occurred in the contrary case.
EN - 9
2 DESCRIPTION OF THE
APPLIANCE
1
2
3
4
6
7
5
This presentation is only for
information about the parts of the
appliance. Parts may vary according to the
appliance model.
1) Thermostat box
2) Refrigerator shelves
3) Crisper cover
4) Crispers
5) Bottle shelf
6) Door shelves
7) Egg holder
3 USING THE APPLIANCE
3.1 Thermostat Setting
The fridge thermostat automatically
regulates the temperature of the
compartment. Fridge temperatures can
be obtained by rotating the knob to higher
numbers, 1 to 5.
Important note: Do not try to rotate
the knob beyond position 1, it will stop
your appliance from working.
Lamp cover
Thermostat knob
Thermostat Settings
• Set the knob to a low/medium position,
up to 3, for short-term storage of food in
the appliance.
• Set the knob to a medium position, 3 or
4, for long-term storage of food in the
appliance.
• For long-term storage of food in the
refrigerator, you can set knop maximum
position (4 - 5).
3.2 Temperature Settings Warnings
• The ambient temperature, temperature of
the freshly stored food and how often the
door is opened affects the temperature
in the fridge. If required, change the
temperature setting.
• It is not recommended that you operate
your fridge in environments colder than
10°C in terms of its efciency.
• When setting the thermostat, take into
consideration how often the appliance
door is opened and closed, how much
food is stored in the refrigerator, and the
environment in which the refrigerator is
located.
EN - 10
• When the appliance is rst switched on,
allow it to run for 24 hours in order to
reach operating temperature. During this
time, do not open the door and do not
keep a large quantity of food inside.
• Unplug your appliance during a power cut
to prevent damage to the compressor.
Once power is restored, delay plugging
in your appliance for 5 to 10 minutes.
This will help prevent damage to the
appliance's components.
• Your appliance is designed to operate in
the ambient temperature ranges stated
in the standards, according to the climate
class stated in the information label. It
is not recommended that your fridge is
operated in the environments which are
outside of the stated temperature ranges.
This will reduce the cooling efciency of
the appliance.
• Your appliance is designed to operate in
the ambient temperature (T/N = 16°C -
43°C) intervals stated in the standards,
according to the climate class displayed
on the information label. We do not
recommend operating your appliance out
of the stated temperature limits in terms
of cooling effectiveness.
Climate
Class Ambient Temperature oC
TBetween 16 and 43 (°C)
ST Between 16 and 38 (°C)
NBetween 16 and 32 (°C)
SN Between 10 and 32 (°C)
4 FOOD STORAGE
• To reduce humidity and avoid the
consequent formation of frost, always
store liquids in sealed containers in the
refrigerator. Frost tends to concentrate in
the coldest parts of the evaporating liquid
and, in time, your appliance will require
more frequent defrosting.
• Never place warm food in the
refrigerator. Warm food should be
allowed to cool at room temperature
and should be arranged to ensure
adequate air circulation in the refrigerator
compartment.
• Make sure no items are in direct contact
with the rear wall of the appliance as
frost will develop and packaging will stick
to it. Do not open the refrigerator door
frequently.
• We recommend that meat and clean sh
are loosely wrapped and stored on the
glass shelf just above the vegetable bin
where the air is cooler, as this provides
the best storage conditions.
• Store loose fruit and vegetable items in
the crisper containers.
• Store loose fruit and vegetables in the
crisper.
• Storing fruit and vegetables separately
helps prevent ethylene-sensitive
vegetables (green leaves, broccoli,
carrot, etc.) being affected by ethylene-
releaser fruits (banana, peach, apricot,
g etc.).
• Do not put wet vegetables into the
refrigerator.
• Storage time for all food products
depends on the initial quality of the food
and an uninterrupted refrigeration cycle
before refrigerator storage.
• To avoid cross-contamination do not
store meat products with fruit and
vegetables. Water leaking from meat
may contaminate other products in the
refrigerator. You should package meat
products and clean any leakages on the
shelves.
Indice
Altri manuali Montpelier Frigorifero
