EN NO FROST

COMBI REFRIGERATOR

Freezer - Fridge

User manual

MAB385C

Index

BEFORE USING THE APPLIANCE................................. 4

General warnings...................................................................... 4

Old and out-of-order fridges...................................................... 6

Safety warnings ........................................................................ 7

Installing and operating your fridge freezer .............................. 7

Before using your fridge freezer ............................................... 9

Information on No-Frost technology ......................................... 9

THE PARTS OF THE APPLIANCE AND THE

COMPARTMENTS .......................................................... 10

USAGE INFORMATION.................................................. 12

Temperature settings ............................................................... 12

Warnings about temperature adjustments............................... 12

Accessoires ............................................................................. 13

Ice tray ................................................................................. 13

CLEANING AND MAINTENANCE.................................. 14

Defrosting ................................................................................ 15

Replacing the light bulb ........................................................... 15

Replacing LED lighting ............................................................ 15

ARRANGING FOOD IN THE APPLIANCE..................... 16

Refrigerator compartment........................................................ 16

Freezer compartment .............................................................. 17

TRANSPORTATION AND CHANGING OF INSTALLATION

POSITION........................................................................ 22

Repositioning the door............................................................. 22

BEFORE CALLING YOUR AFTER SALES SERVICE ... 23

TIPS FOR SAVING ENERGY.......................................... 26

4BEFORE USING THE APPLIANCE

General warnings

WARNING: Keep ventilation openings, in the appliance

enclosure or in the built-in structure, clear of obstruction.

WARNING: Do not use mechanical devices or other

means to accelerate the defrosting process, other than

those recommended by the manufacturer.

WARNING: Do not use electrical appliances inside the

food storage compartments of the appliance, unless

they are of the type recommended by the manufacturer.

WARNING: Do not damage the refrigerant circuit.

WARNING: To avoid a hazard due to the instability of

the appliance, it must be xed in accordance with the

instructions.

• If your appliance uses R600a as a refrigerant (this

information will be provided on the label of the cooler)

you should take care during transportation and

installation to prevent the cooler elements from being

damaged. R600a is an environmentally friendly and

natural gas, but it is explosive. In the event of a leak

due to damage of the cooler elements, move your

fridge away from open ames or heat sources and

ventilate the room where the appliance is located for

a few minutes.

• While carrying and positioning the fridge, do not

damage the cooler gas circuit.

• Do not store explosive substances such as aerosol

cans with a ammable propellant in this appliance.

• This appliance is intended to be used in household

and domestic applications such as:

- staff kitchen areas in shops, ofces and other working

environments.

BEFORE USING THE APPLIANCE

- farm houses and by clients in hotels, motels and

other residential type environments.

- bed and breakfast type environments;

- catering and similar non-retail applications.

• If the socket does not match the refrigerator plug,

it must be replaced by the manufacturer, a service

agent or similarly qualied persons in order to avoid

a hazard.

• A specially grounded plug has been connected to the

power cable of your refrigerator. This plug should be

used with a specially grounded socket of 13 amperes.

If there is no such socket in your house, please have

one installed by an authorised electrician.

• This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved. Children

shall not play with the appliance. Cleaning and user

maintenance shall not be made by children without

supervision.

• If the supply cord is damaged, it must be replaced

by the manufacturer, an authorised service agent or

similar qualied persons, in order to avoid a hazard.

• This appliance is not intended for use at altitudes

exceeding 2000 m.

Old and out-of-order fridges

• If your old fridge has a lock, break or remove the lock

before discarding it, because children may get trapped

inside it and may cause an accident.

• Old fridges and freezers contain isolation material and

refrigerant with CFC. Therefore, take care not to harm

environment when you are discarding your old fridges.

Disposal of your old appliance

This symbol on the product or package implies that the product

should not be treated as domestic waste. Instead, it should

be delivered to applicable waste collection places recycling

electrical and electronic equipment. You will contribute to

avoid potential negative results regarding environment and

human health, which will arise due to wrong waste procedure

for the product by ensuring that this product is annihilated

properly. Recycling materials will help natural resources be

preserved. For more detailed information regarding recycling

of this product, please contact local municipality, domestic

waste annihilation service or the shop you have purchased

the product.

Please ask your municipal authority about the disposal of the

WEEE reuse, recycle and recovery purposes.

Notes:

• Please read the instruction manual carefully before

installing and using your appliance. We are not

responsible for the damage occurred due to misuse.

• Follow all instructions on your appliance and instruction

manual, and keep this manual in a safe place to resolve

the problems that may occur in the future.

• This appliance is produced to be used in homes and it

can only be used in domestic environments and for the

specied purposes. It is not suitable for commercial or

common use. Such use will cause the guarantee of the

appliance to be cancelled and our company will not be

responsible for losses incurred.

• This appliance is produced to be used in houses and it is

only suitable for cooling / storing food. It is not suitable for

commercial or common use and/or for storing substances

BEFORE USING THE APPLIANCE

except for food. Our company is not responsible for losses

to be incurred in the contrary case.

Safety warnings

• Do not connect your fridge freezer to the mains electricity

supply using an extension lead.

• Do not plug in damaged, torn or old plugs.

• Do not pull, bend or damage the cord.

• This appliance is designed for use by adults, do not allow

children to play with the appliance or let them hang off the

door.

• Never touch the power cord/plug with wet hands as this

could cause a short circuit or electric shock.

• Do not place glass bottles or beverage cans in the ice-

making compartment as they can burst as the contents

freeze.

• Do not place explosive or ammable material in your fridge

freezer. Place drinks with high alcohol content vertically in

the fridge compartment and make sure that their tops are

tightly closed.

• When removing ice from the ice-making compartment, do

not touch it. Ice may cause frost burns and/or cuts.

• Do not touch frozen goods with wet hands. Do not eat ice-

cream or ice cubes immediately after you have taken them

out of the ice-making compartment.

• Do not cover the body or top of fridge freezer with lace.

This affects the performance of your fridge freezer.

• Secure any accessories in the fridge freezer during

transportation to prevent damage to the accessories.

Installing and operating your fridge freezer

Before starting to use your fridge freezer, you should pay

attention to the following points:

8BEFORE USING THE APPLIANCE

• The operating voltage for your fridge freezer is 220-240 V

at 50Hz.

• The plug must be accessible after installation.

• Your fridge freezer may have a smell when it is operated

for the rst time. This is normal and the smell will fade

away when your fridge freezer starts to cool.

• Before connecting your fridge freezer, ensure that the

information on the data plate (voltage and connected load)

matches that of the mains electricity supply. If in doubt,

consult a qualied electrician.

• Insert the plug into a socket with an efcient ground

connection. If the socket has no ground contact or the

plug does not match, we recommend that you consult a

qualied electrician for assistance.

• The appliance must be connected with a properly installed

fused socket. Power supply (AC) and voltage at the

operating point must match with the details on the name

plate of the appliance (name plate is located on the inside

left of the appliance).

• We do not accept responsibility for any damages that

occur due to ungrounded usage.

• Place your fridge freezer where it will not be exposed to

direct sunlight.

• Your fridge freezer should never be used outdoors or

exposed to rain.

• Your appliance should be at least 50 cm away from stoves,

gas ovens and heater cores, and at least 5 cm away from

electrical ovens.

• When your fridge freezer is placed next to a deep freezer,

there should be at least 2 cm between them to prevent

humidity forming on the outer surface.

• Do not place heavy items on the appliance.

• Clean the appliance thoroughly, especially the interior,

before use (see Cleaning and Maintenance).

• The installation procedure into the kitchen unit is given

in the installation manual. This product is intended to be

used in proper kitchen units only.

• Use the adjustable front legs to make sure your appliance

BEFORE USING THE APPLIANCE

is level and stable. You can adjust the legs by turning them

in either direction. This should be done before placing food

in the fridge freezer.

• Before using your fridge freezer, wipe all parts with

a solution of warm water and a teaspoon of sodium

bicarbonate, then rinse with clean water and dry.

Place all parts in the fridge after cleaning.

• Install the plastic distance guide (the part with black vanes

at the rear) by turning it 90° (as shown in the gure) to

prevent the condenser from touching the wall.

• The fridge freezer should be placed against a wall with a

free space not exceeding 75 mm.

Electrical connection (For UK type plug)

For your safety please read the following information

Warning: This appliance must be earthed.

This appliance operates from 220-240 volts and should be

protected by a 13 amp fuse in the plug.

The appliance is supplied with a standard 13 amp 3-pin

mains plug tted with a 13-amp fuse. Should the fuse require

replacement, it must be replaced with a fuse rated at 13 amp

and approved to BS1362.

If the mains plug which is tted is unsuitable for the socket

outlet in your home or is removed for any other reason, please

follow the instructions below on how to wire a 13 amp 3 pin

plug..

How to wire a 13 amp plug.

Important

The wires in the mains lead on

this appliance are coloured in

accordance with the following

code:

Green and Yellow - Earth

Blue – Neutral

Brown – Live

As the colours may not correspond with the markings

GREEN/YELLOW

Earth

BROWN

Live

FUSE

13 Amps

Cord Clamp

BLUE

Neutral

identifying the terminals in your plug proceed as follows.

The green and yellow wire must be connected to the terminal

in the plug which is marked with the letter E or with the earth

symbol or coloured green and yellow.

The blue wire must be connected to the terminal marked N.

The brown wire must be connected to the terminal marked L.

You must make sure the lead is rmly secured under the cord

clamp.

Before using your fridge freezer

• When using your fridge for the rst time, or after

transportation, keep it in an upright position for at least 3

hours before plugging into the mains. This allows efcient

operation and prevents damage to the compressor.

• Your fridge may have a smell when it is operated for the

rst time. This is normal and the smell will fade away when

your fridge starts to cool.

Information on No-Frost technology

No-frost refrigerators differ from other static refrigerators in

their operating principle.

In normal fridges, the humidity entering the fridge due to

opening the door and the humidity inherent in the food causes

freezing in the freezer department. To defrost the frost and ice

in the freezer compartment, you are periodically required to

turn off the fridge, place the food that needs to be kept frozen

in a separately cooled container and remove the ice gathered

in the freezer department.

The situation is completely different in no-frost fridges. Dry

and cold air is blown into the fridge and freezer compartments

homogeneously and evenly from several points via a blower

fan. Cold air dispersed homogeneously and evenly between

the shelves cools all of your food equally and uniformly, thus

preventing humidity and freezing.

Therefore your no-frost fridge allows you ease of use, in

addition to its huge capacity and stylish appearance.

Indice

Altri manuali montpellier Frigorifero

montpellier

montpellier MAB550C Manuale utente

montpellier

montpellier MIFF5051F Manuale utente

montpellier

montpellier MAB2030 Manuale utente

montpellier

montpellier MFF170K Manuale utente

montpellier

montpellier MFF152 Manuale utente

montpellier

montpellier MFF152W Manuale utente

montpellier

montpellier MAB365R Manuale utente

montpellier

montpellier MFF185DW Manuale utente

montpellier

montpellier MAB551C Manuale utente

montpellier

montpellier MAB341K Manuale utente

montpellier

montpellier MAB148 Manuale utente

montpellier

montpellier MFD600X Manuale utente

montpellier

montpellier MITL294 Manuale utente

montpellier

montpellier MICL88 Manuale utente

montpellier

montpellier MS171W/K Manuale utente

montpellier

montpellier MLA48W-1 Manuale utente

montpellier

montpellier MBUR201 Manuale utente

montpellier

montpellier MON-MRF48W Guida all'installazione

montpellier

montpellier MFF183DW Manuale utente

montpellier

montpellier MLA54BK Manuale utente

montpellier

montpellier MNF1860X Manuale utente

montpellier

montpellier MAB340C Manuale utente

montpellier

montpellier MITL88 Manuale utente

montpellier

montpellier MLA54W/BK Manuale utente

Manuali Frigorifero popolari di altre marche

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuale utente

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuale utente

Sharp

Sharp SJ-BA31IEXW2-EU Manuale utente

CORBERO

CORBERO CC2300MCW Manuale utente

KitchenAid

KitchenAid 2205264 Manuale utente

Stengel

Stengel KU 1101 A++ Manuale utente

NEFF

NEFF KI181 Series Manuale utente

Hoshizaki

Hoshizaki Reach-In Manuale utente

Amana

Amana ASD2524VES00 Manuale utente

BOMANN

BOMANN KGC 213 Manuale utente

Danby

Danby DAR044A1SLDD Istruzioni per il montaggio

Samsung

Samsung RF323TE Manuale utente

Beko

Beko CSA31022 Manuale utente

IKEA

IKEA FROSTIG C 185 E Manuale utente

Electrolux

Electrolux ER 6821 D Manuale utente

True

True TS-28 Manuale utente

Frigidaire

Frigidaire FSC23R5DW9 Manuale utente

Beko

Beko LSP4579W Manuale utente

montpellier MAB385C Manuale utente

Manuali Frigorifero popolari di altre marche
