PremAir cylinder vacuum cleaner

Please read and keep these instructions

getting the best from

your new cleaner...

If your cleaner isn’t picking up as

well as it should, please check

• Dustbags

It is important to replace them, otherwise the performance

of the cleaner will be impaired

• Filters

It is important that the filters are cleaned regularly or

replaced to allow air through the appliance

• Blockages

Check the nozzle, tubes and hose for blockages

www.morphyrichards.co.uk

Important safety

instructions

The use of any electrical appliance

requires the following of common sense

safety rules.

Primarily there is danger of personal

injury and secondly danger of damage to the

appliance and property. These are indicated

in the instructions text by the following two

conventions:

WARNING: Danger of personal injury

IMPORTANT: Damage to the appliance

In addition we offer the following

essential safety advice.

Location

• Do not use or keep this product outside

when it is raining.

• Do not store the appliance near hot

ovens or heating appliances.

Mains lead

• Do not allow the mains lead to become

strained or run this appliance over it.

• If the electrical cable becomes damaged

the complete cable assembly must be

replaced. Do not attempt this task

yourself, contact Morphy Richards using

the helpline number.

Children

• Children do not understand the dangers

associated with operating electrical

appliances. Never allow children to use

this appliance.

Other safety considerations

• Never use in the presence of explosive

liquids or vapours.

• Never pick up inflammable or poisonous

liquids such as petrol, copier toner, or

other volatile substances. Never pick up

acids, asbestos or asbestos dust.

• Always disconnect the appliance from the

mains supply after use or prior to

cleaning or replacing dust bags.

• The appliance should never be left

running unsupervised.

Product safety

• Never use the appliance without the filter

installed.

• Never use the appliance to vacuum hot

ashes, broken glass, sharp objects or

liquids.

• Never modify the cleaner in any way.

• Repairs to electrical appliances are only

to be undertaken by trained personnel.

Unprofessional repairs can be dangerous

for users.

• Use only genuine Goblin spare parts and

accessories.

Electrical

requirements

Check that the voltage on the rating plate

of your appliance corresponds with your

house electricity supply which must be A.C.

(Alternating Current).

If the socket outlets in your home are not

suitable for the plug supplied with this

appliance, the plug should be removed and

the appropriate one fitted.

WARNING: The plug removed from

the mains lead, if severed, must be

destroyed as a plug with bared flexible

cord is hazardous if engaged into a live

socket outlet.

Should the fuse in the 13 amp plug

require replacement, a BS1362 13 amp fuse

must be fitted.

Features

⁄›

‹

‚

‡

„

‰

ËÈ



ﬂ

ﬁ

⁄Dust compartment cover

¤Opening for suction hose

‹Dust compartment lock button

›Tool storage compartment cover

ﬁPaper dustbag

ﬂDustbag holder

‡Motor protection filter

·Dustbag safety lock

‚Slot for attaching dustbag holder

„Variable power control

‰On/off foot switch

ÂCable rewind foot switch

ÊExhaust filter

Á‘Bag full’ indicator

ËSuction hose with air flow control*

ÈSuction hose with comfi-grip handle*

ÍFloor nozzle

ÎTwo metal tubes*

ÏTelescopic metal tubes*

ÌTube standby slot

ÓTube park (not shown)

ÔCarrying handle

Hard floor brush*

ÒTurbo brush*

* certain models only

Certain models only

Standard

accessories Application

Curtains and

delicate

fabrics

Textiles and

upholstery

Shelves and

hard surfaces

Carpets and

other textile

floor coverings

(brushes up)

Settings for

heavy dirt and

smooth floors

(brushes down)

Tools and

accessories

Standard floor nozzle

This nozzle is suitable for general

purpose cleaning on a wide variety of floor

coverings.

Turbo brush (certain models only)

This nozzle is suitable for cleaning and

rejuvenating cut pile carpets and is ideal for

picking up stubborn dirt and pet hairs.

Hard floor brush (certain models only)

Designed specifically for use on wood,

tiles and all other hard floor types.

Tool storage

The upholstery nozzle and the crevice

tool are stored in the internal storage

compartment.

Operation

Suction hose

Snap the 360° rotating head on the

suction hose into the suction hose

opening on the vacuum cleaner.

The appropriate cleaning tool can be

attached directly to the other end of the

suction hose or the connecting tube can

be used between the suction hose and the

tool.

Switching on

Always pull out the supply cable to its

maximum length. Plug the appliance into

the mains supply. Ensure that the

electronic suction power control is set to

minimum by turning the dial anti-

clockwise as far as it will go. Push the

on/off foot switch to start the motor.

Power setting Application

Curtains

and delicate

fabrics

Textiles and

upholstery

Floor

coverings

such as

rugs or economy

setting for carpets

Carpets or

hard floor

coverings

Open Closed

Controlling suction power

The suction power can be varied to suit

the surface being cleaned, by using the

variable power control. See table for

guideline settings.

Certain models only

The suction power can also be adjusted

using the fingertip control on the handle.

Closed: full suction

Open: low suction

Overheating protection

In the event of a motor overload, your

vacuum cleaner will switch off automatically.

If this occurs, press the on/off switch,

disconnect from the mains supply and leave

for 15 minutes to allow the motor cool down.

The vacuum cleaner cuts out

automatically when:

• The floor nozzle or tubes become

blocked

• Using the vacuum cleaner with a full

dustbag

• The motor protection filter is very dirty

• The exhaust filter is very dirty.

Check and rectify before attempting to

reuse your vacuum cleaner.

IMPORTANT: Do not use your vacuum

cleaner without the filters fitted.

Tube standby

During short breaks in cleaning the tubes

can be held in an upright, ‘standby’ position,

whilst you move furniture for instance.

IMPORTANT: Ensure that the appliance is

never left unattended whilst it is switched on.

Switching off

Switch off the appliance. Remove the

plug from the mains supply and rewind the

power cable using the cable rewind foot

switch.

WARNING: When using the cable

rewind, always hold the plug as the

cable will rewind quickly.

Storage

Tube park

The vacuum cleaner can be stored in an

upright position. Rotate the floor nozzle until

the lug on the back of it can be fitted into the

tube park slot on the base of the appliance.

aaa

Changing the

dustbag

If suction power is reduced or if the ‘dust

bag full’ indicator is permanently on, the dust

bag needs changing. Also check whether the

suction hose, tube or nozzle are blocked.

To access the dust bag, press the dust

compartment release button to open the

cover.

1Pull the tab on the dust bag to one side

so that the opening is hygienically sealed.

2Pull out the dust bag holder and dust bag

in an upward direction.

3Pull the bag sideways out of the holder.

4Dispose of the bag with your household

waste.

5Insert a new dust bag in the holder.

6Replace the dust bag holder and close

the cover.

IMPORTANT: The dust bag compartment

cover can only be closed once a dust bag

has been correctly inserted.

Changing the motor

protection filter

The motor protection filter varies by

model. It is accessible from the dust

compartment only when the dust bag has

been removed first.

IMPORTANT: Never use the appliance

without the motor protection filter installed,

otherwise damage to the motor may occur

which would not be covered by the

guarantee.

PremAir model with standard

micro hygiene filter

1Open the flap on the filter holder.

2Take out the filter and clean (by shaking)

or replace.

3Close the filter holder.

It is recommended that this filter is

cleaned everytime the dustbag is changed,

and is replaced every 5 dustbag changes.

PremAir models with 3-layer

hygiene filter cassette

1Pull out the filter cassette in an upward

direction and clean by tapping gently or

dispose of it with your household waste.

2Put in a new filter cassette.

It is recommended that this filter should

be cleaned everytime the dustbag is

changed and replaced every 6 months, or

sooner if it starts to give an unpleasant

odour or if the dust bag has been damaged.

IMPORTANT: The filter material is

sensitive. Do not press the surface or you

may damage the filter material.

Insert the dust bag and close the dust

bag compartment cover.

aaa

Changing the

exhaust air filter

The exhaust air filter should be cleaned

by shaking every time the dustbag is

changed. This filter can also be washed in

warm water (no detergents added) and

allowed to dry naturally.

IMPORTANT: The filter must be totally dry

before putting it back into the cleaner.

Cleaning and

maintenance

Unplug from the mains before cleaning.

The vacuum cleaner, especially the dust

compartment and all accessories can be

cleaned using a damp cloth or a non-

abrasive domestic cleaner and wiped dry.

To keep the underside of the floor nozzle

clean, vacuum it at regular intervals using the

crevice tool.

Purchasing

replacement filters

Use only Morphy Richards replacement

filters which can be purchased from specialist

retailers or by calling the number on the front

page of this leaflet.

Helpline

If you have any difficulty with your

appliance, do not hesitate to call us. We’re

more likely able to help than the store from

where you bought it.

Please have the following information

ready to enable our staff to deal with your

query quickly:

• Name of the product

• Model number as shown on the

underside of the appliance

• Serial number

The British Allergy Foundation considers that these products may, in proper use, reduce

exposure to both House Dust Mite (Der p 1) and Cat Allergen (Fel d 1).

Assessment carried out by BAF indicate that an individuals exposure can be reduced but

this does not mean that an individuals allergic symptoms will necessarily diminish. BAF’s

opinion applies only to the products and allergen stated. The product should be used only for

its intended purpose and strictly in accordance with the manufacturers instructions at all times.

Exposure to allergen can be dangerous. If you believe that you may suffer from an allergy

you should seek medical advice.

The British Allergy Foundation is a national charity (Charity reg. no. 1003726) founded in

1991 with the aim of improving awareness, prevention and treatment of allergy. The

Foundation encompasses all types of allergy and is managed by medical specialists from a

variety of disciplines including dermatology, ENT surgery, respiratory medicine, paediatrics,

ophthalmology, immunology and gastroenterology.

The Foundation is continuously striving to help sufferers to help themselves, often seeking

ways to avoid, or reduce exposure to, relevant allergens. The Seal of Approval Scheme forms

a part of this initiative.

PremAir 1800 and

PremAir 1800 Trio

cylinder vacuum

cleaners

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Morphy Richards Aspirapolvere

Morphy Richards

Morphy Richards GOBLIN 1400W WET AND DRY CLEANER Manuale utente

Morphy Richards

Morphy Richards 732000 Supervac Manuale utente

Morphy Richards

Morphy Richards 73313 Manuale utente

Morphy Richards

Morphy Richards 71077 VACUUM CLEANER Manuale utente

Morphy Richards

Morphy Richards Essentials Bag Vacuum Cleaner Manuale utente

Morphy Richards

Morphy Richards Storm hard floor cylinder vacuum cleaner Manuale utente

Morphy Richards

Morphy Richards PerformAir Upright Vacuum Manuale utente

Morphy Richards

Morphy Richards Bagless Cylinder Vacuum Cleaner Manuale utente

Morphy Richards

Morphy Richards PremAir Cyclonic 70035 Manuale utente

Morphy Richards

Morphy Richards Storm Manuale utente

Morphy Richards

Morphy Richards IB71050 Manuale utente

Morphy Richards

Morphy Richards IB73180 Manuale utente

Morphy Richards

Morphy Richards Topo compact vacuum cleaner Manuale utente

Morphy Richards

Morphy Richards Bagless Vacuum Cleaner Manuale utente

Morphy Richards

Morphy Richards SuperVac 732102 Manuale utente

Morphy Richards

Morphy Richards LOX VACUUM CLEANER Manuale utente

Morphy Richards

Morphy Richards 732000 Supervac Manuale utente

Morphy Richards

Morphy Richards ESSENTIALS CYCLONIC BAGLESS UPRIGHT VACUUM CLEANER - REV... Manuale utente

Morphy Richards

Morphy Richards VC7341DMUK Manuale utente

Morphy Richards

Morphy Richards Supervac gold Manuale utente

Morphy Richards

Morphy Richards PerformAir Upright Vacuum Manuale utente

Morphy Richards

Morphy Richards ORB CYCLONE VACUUM CLEANER - REV 3 Manuale utente

Morphy Richards

Morphy Richards VORTICITY Manuale utente

Morphy Richards

Morphy Richards Storm pets cylinder vacuum cleaner Manuale utente

Manuali Aspirapolvere popolari di altre marche

Bissell

Bissell LittleGreen Proheat 1425 Series Manuale utente

Panasonic

Panasonic MC-YL637S147-AE Manuale utente

NEFF

NEFF N17XH10 0 Series Manuale utente

LG A9 Series Manuale utente

Oreck

Oreck Cordless Captura BK51700 Series Manuale utente

Kogan

Kogan KAVACROBVWA Manuale utente

Kränzle

Kränzle VENTOS 50 ID Guida utente

EVVO

EVVO Ai35 Manuale utente

DeWalt

DeWalt DWH200D Manuale utente

Pontec

Pontec Pondomatic Vacuum Cleaner Manuale utente

Cleanmaxx

Cleanmaxx PC-P007E Manuale utente

Exido

Exido 240-114 Manuale utente

RIDGID

RIDGID WD1685AU0 Manuale utente

Ezviz

Ezviz RE4P Manuale utente

STG global

STG global TANVAC HDV3000 Manuale utente

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manuale utente

Factory

Factory M3340 Manuale utente

Shop-Vac

Shop-Vac VN92 SERIES Manuale utente
