Ultralight cyclone vacuum cleaner

Please read and keep these

instructions

getting the best from

your new cleaner...

If your cleaner isn’t picking up as

well as it should, please check

• Dust canister

It is important to empty the canister when full, otherwise the

performance of the cleaner will be impaired.

• Filters

It is important that the filters are cleaned regularly to allow air

through the appliance. Wash the cannister filters regularly in

warm water and allow to air dry.

• Blockages

Check the hose, tubes and tools for blockages

• Belt

Check and replace damaged or broken belt

73313

8537 Upright Currys cyclone ib 12/05/2003 18:12 Page 1

Important safety

instructions

The use of any electrical appliance

requires the following of common sense

safety rules.

Primarily there is danger of personal

injury and secondly danger of damage to the

appliance and property. These are indicated

in the instructions text by the following two

conventions:

WARNING: Danger of personal injury

IMPORTANT: Damage to the appliance

In addition we offer the following

essential safety advice.

Location

•Do not use or keep this product outside

when it is raining.

•Do not store the appliance near hot

ovens or heating appliances.

Mains lead

•Do not allow the mains lead to become

strained or run this appliance over it.

•If the electrical cable becomes damaged

the complete cable assembly must be

replaced. Do not attempt this task

yourself, contact Morphy Richards using

the helpline number.

Children

•Children do not understand the dangers

associated with operating electrical

appliances. Never allow children to use

this appliance.

Other safety considerations

•Never use in the presence of explosive

liquids or vapours.

•Never pick up inflammable or poisonous

liquids such as petrol, copier toner, or

other volatile substances. Never pick up

acids, asbestos or asbestos dust.

•Never use the appliance without the

filters installed.

•Never use the appliance to vacuum hot

ashes, broken glass, sharp objects or

liquids.

•Never modify the cleaner in any way.

•Always disconnect the appliance from the

mains supply after use or prior to

cleaning or emptying.

•The appliance should never be left

running unsupervised.

•Repairs to electrical appliances are only

to be undertaken by trained personnel.

Unprofessional repairs can be dangerous

for users.

•Use only genuine Morphy Richards spare

parts and accessories

•Never over-extend the hose such that the

cleaner is pulled over. If the cleaner is

knocked over, switch off before

attempting to upright.

•Never pick the cleaner up by the floor

nozzle when connected to the mains, use

the carrying handle.

•WARNING: Keep loose clothing, hair,

fingers etc. away from the floor

nozzle whenever the cleaner is

connected to the mains.

•Disconnect from the mains supply before

attempting to clear blockages, clear the

brush or replace the belt.

Electrical

requirements

Check that the voltage on the rating plate

of your appliance corresponds with your

house electricity supply which must be A.C.

(Alternating Current).

If the socket outlets in your home are not

suitable for the plug supplied with this

appliance, the plug should be removed and

the appropriate one fitted.

WARNING: The plug removed from

the mains lead, if severed, must be

destroyed as a plug with bared flexible

cord is hazardous if engaged into a live

socket outlet.

Should the fuse in the 13 amp plug

require replacement, a BS1362 13 amp fuse

must be fitted.

8537 Upright Currys cyclone ib 12/05/2003 18:12 Page 2

Features

⁄Vari power slider (only on certain models)

¤Front cover release

‹Removable front cover

›Hepa exhaust filter

ﬁCarpet height adjustment knob

ﬂFloor nozzle with powered brush

‡Upper handle

·Flexible hose

‚Cord storage with quick release cleat

„On/Off switch

‰Carrying handle

ÂNested extension tubes (2)

ÊCrevice nozzle

ÁFurniture brush

ËMain body

ÈHandle release button

ÍHose connector

ÎDust canister release

ÏDust canister lid

ÌPleated circular filter

ÓFoam filter

ÔDust canister

Central canister filter

ÒDust release button

ÚSafety filter inter-lock

ÛCleaning brush (clipped inside canister)

ÙCanister handle

ıMotor protection filter (shown page 6)

ˆExhaust filter (page 6)

˜Belt cover (shown page 7)

¯Brush bar (page 7) 3

Accessories included Extension tubes

Crevice tool

Furniture brush

‡

ﬁ

›

ﬂ

‹

‚

‰

„

⁄



Cleaning brush

(stored in canister)

8537 Upright Currys cyclone ib 12/05/2003 18:13 Page 3

Assembly

Warning: Do not plug in the cleaner

until it is assembled.

1Carefully unpack all components.

2Lift cleaner body to upright position.

3Remove the two screws that are already

attached to the body.

4From the rear of the cleaner, align the

handle with groove and slide into the

body. If necessary, use thumb and finger

pressure to slide handle into position.

5Fasten the handle with the two screws.

Floor nozzle height

adjustment

Before using the cleaner the floor nozzle

height must be set to the correct height.

Choose the setting which most closely

matches your floor surface, ie deep carpet

pile, medium carpet pile, short carpet pile or

hard floor.

When using the attachments the cleaner

must only be used in the upright position

with the carpet height adjustment knob set

to deep carpet.

Variable power

certain models only

Slide the variable power control to the

right to increase the suction power or to the

left to decrease suction. This feature is most

useful when using the hose and accessories.

Use the minimum setting when vacuuming

delicate fabrics/curtains etc. When not using

the hose it is advisable to keep the variable

slider set to maximum.

Using on carpets

1Place cleaner in its upright position.

2Set the carpet height adjustment knob to

the desired position.

3Release the mains cable by revolving the

quick release cleat through 180º and

extend the cable fully.

4Plug the cable into the mains socket.

5Step on the handle release button to

release the handle to the desired position

6Press the on/off button to the ‘on’

position.

IMPORTANT: To prevent damage to

carpets, never leave the cleaner switched on

in one place for an extended period.

•Never have the brushes set too low such

that the cleaner is hard to push.

DEEP CARPET HARD FLOOR

Use attachments

Normal use

Floors

Clean under furniture

Flat position

min max

Certain models only

8537 Upright Currys cyclone ib 12/05/2003 18:13 Page 4

Using attachments

Follow previous steps 1-4 but set the

carpet height adjustment knob to the deep

carpet setting.

5Remove the hose connector from the rear

of the cleaner and push the required

attachment firmly onto the end of the

hose.

•If additional length is required, attach one

or both extension tubes between the

hose and tool.

6Switch on/off.

IMPORTANT: Never over extend the hose

such that the cleaner is pulled over.

Emptying the dust

canister

When the dust canister is full it should be

emptied immediately.

1Remove the front cover ‹by lifting the

cover release lever ¤.

2Lift-up the dust canister release Îand

pull the canister away from the main

body.

3Hold the canister by the handle Ù over a

dustbin and with your other hand press

the dust release button Ò. The bottom of

the canister will drop down to release the

dirt. To close press the flap firmly until it

clicks into place.

4Replace the canister by inserting the

base then pushing in the top. Replace the

front panel by aligning the bottom tabs

with the slots in the body, then pressing

in the top.

Cleaning the filters

To maintain suction, the filters must be

regularly taken out and cleaned. Failure to

clean the filters will reduce the suction and

will damage the motor if used for prolonged

periods. This may invalidate the guarantee. If

the filters become damaged they must be

replaced.

IMPORTANT: Do not operate the cleaner

without the filters in place.

Circular pleated & foam filters

IMPORTANT: The filters should be

cleaned regularly to maintain the

performance of the cleaner.

1Remove the front cover and the canister.

2Twist the canister lid Ï anti-clockwise

and lift off.

3Lift up the pleated circular filter Ì and

foam filter Ó beneath. The filters can be

cleaned using the brush Û clipped inside

ÏÛ

‹

8537 Upright Currys cyclone ib 12/05/2003 18:13 Page 5

the canister lid. The filters can be washed

in warm water then left to air-dry

naturally. IMPORTANT: Ensure the filters

are totally dry before re-fitting. Do not use

detergents.

Central filter

4Lift the central canister filter out of the

canister.

5Remove any attached dirt by using the

brush.

6Re-assemble by replacing the central

canister filter into the canister.

7Replace the foam filter then the pleated

circular filter into the top of the canister.

Replacing the canister lid

8Replace the canister lid by lining up the

arrows on the canister base and lid and

twisting clockwise to lock into place I.

The canister may be washed in water

only but must be totally dry before re-fitting.

The canister has a safety inter-lock that

prevents it from being fitted back into place

if the filters have not been fitted correctly.

Motor protection filter

The motor protection filter is located

underneath the dust canister

1Remove the dust canister.

2Lift out the filter and shake rigorously

over a dustbin.

The filter may also be washed in water

(no detergents) but must be totally dry before

re-fitting.

3Replace the filter

Hepa exhaust filter

The non-washable Hepa exhaust filter is

located below the dust canister

compartment.

1Remove the front cover.

2Remove the Hepa filter by pulling forward

at the top and lift it away.

3Shake vigorously over a dustbin and use

the filter cleaning brush to clean dust out

of the pleats. Do not wash. The Hepa

filter should be replaced every six months

or sooner if it becomes damaged.

4Replace the filter and the front cover.

Changing the belt

If the power brush stops rotating it is

likely that the drive belt has snapped (usually

because the brush has been stalled). A spare

belt is supplied. Replacement belts can also

be obtained from Morphy Richards or a

Service Agent.



8537 Upright Currys cyclone ib 12/05/2003 18:13 Page 6

ﬁ

Removing the floor nozzle

cover

1Disconnect the cleaner from the mains

supply.

2Place the cleaner upside down in the flat

position.

3Use a cross-head screwdriver to remove

the two screws at the front and the

central screw under the height

adjustment mechanism K.

4Turn the cleaner over and remove the

carpet height adjustment knob ﬁ.

5Remove the two screws at the rear and

lift the rear of the cover over the handle

release button and unclip the cover from

the front of the floor nozzle L.

Replacing the belt

6If the belt has broken, ensure all pieces

are removed.

7Lift off the belt cover ˜.

8Grasp the brush bar ¯ at both ends and

lift straight up.

9Place one end of the new belt over the

metal motor shaft pin and the other

around the pulley end of the brush N.

10 Align brush end plates with their guide

slots and push the brush bar down into

place.

11 Re-fit the belt cover.

12 Re-fit the floor nozzle cover. Push the

carpet height adjustment knob back on.

13 Replace the two screws on the top of the

floor nozzle cover and the three screws

underneath the floor nozzle - do not

overtighten.

Safety cut-out

If the cleaner overheats a motor

protection thermostat will automatically

switch the motor off. If this happens, switch

the cleaner off, unplug from the power

supply and leave the cleaner to cool for at

least 30 minutes. Check the airways for

blockages and clean the filters before

restarting.

Helpline

If you have any difficulty with your

appliance, do not hesitate to call us. We’re

more likely able to help than the store from

where you bought the product.

Please have the following information

ready to enable our staff to deal with your

query quickly:

•Name of the product

•Model number as shown on the

underside of the appliance.

8537 Upright Currys cyclone ib 12/05/2003 18:13 Page 7

Your two-year

guarantee

•It is important to retain the retailers

receipt as proof of purchase. Staple

your receipt to this back cover for future

reference.

Please quote the following information if

the product develops a fault. These numbers

can be found on the base of the product.

Model no. Serial no.

All Morphy Richards Products are

individually tested before leaving the factory.

In the unlikely event of any appliance proving

to be faulty within 28 days of purchase it

should be returned to the place of purchase

for it to be replaced.

If the fault develops after 28 days and

within 24 months of original purchase, you

should contact the helpline number quoting

model number and serial number on the

product, or write to Morphy Richards at the

address shown. You will be asked to return

the product (in secure, adequate packaging)

along with a copy of proof of purchase.

Subject to the exclusions set out below (1-6),

the faulty appliance will then be repaired or

replaced and dispatched usually within

seven working days of receipt.

If for any reason this item is replaced

during the 2-year guarantee period, the

guarantee on the new item will be calculated

from original purchase date. Therefore it is

vital to retain your original receipt or invoice

to indicate the date of initial purchase.

To qualify for the two-year guarantee the

appliance must have been used according to

the manufacturers instructions. For example

the filters shall have been regularly cleaned

as instructed.

Morphy Richards shall not be liable to

replace or repair the goods under the terms of

the Guarantee where:

1The fault has been caused or is attributable

to accidental use, mis-use, negligent use or

used contrary to the manufacturers

recommendations or where the fault has

been caused by power surges or damage

caused in transit.

2The appliance has been used on a voltage

supply other than that stamped on the

products.

3Repairs have been attempted by persons

other than our service staff (or authorised

dealer).

4Where the appliance has been used for hire

purposes or non-domestic use.

5Morphy Richards are not liable to carry out

any type of servicing work, under the

guarantee.

6Consumables such as the filters and belt

are not covered by the guarantee.

This guarantee does not confer any rights

other than those expressly set out above

and does not cover any claims for

consequential loss or damage. This

guarantee is offered as an additional benefit

and does not affect your statutory rights as a

consumer.

•This guarantee is valid in the UK and

Ireland only.

VC73313M Rev 2 05/03

The After Sales Division,

Morphy Richards Ltd, Mexborough,

South Yorkshire, England, S64 8AJ

Helpline (office hours)

UK (local rate) 0870 060 2603

Republic of Ireland 1800 409119

Morphy Richards products are

intended for household use only

Morphy Richards has a policy of

continuous improvement in product

quality and design. The Company,

therefore, reserves the right to change

the specification of its models at any

time.

8537 Upright Currys cyclone ib 12/05/2003 18:13 Page 8

Indice

Altri manuali Morphy Richards Aspirapolvere

Morphy Richards

Morphy Richards IB73120 Manuale utente

Morphy Richards

Morphy Richards IB73180 Manuale utente

Morphy Richards

Morphy Richards CYCLONIC BAGLESS UPRIGHT VACUUM CLEANER Manuale utente

Morphy Richards

Morphy Richards ESSENTIALS COMPACT BAGLESS VACUUM CLEANER - REV... Manuale utente

Morphy Richards

Morphy Richards Supervac Deluxe Manuale utente

Morphy Richards

Morphy Richards PerformAir Upright Vacuum Manuale utente

Morphy Richards

Morphy Richards Supervac gold Manuale utente

Morphy Richards

Morphy Richards Ultralight bagless vacuum cleaner Manuale utente

Morphy Richards

Morphy Richards Ultralight vacuum cleaner Manuale utente

Morphy Richards

Morphy Richards SuperVac 732102 Manuale utente

Morphy Richards

Morphy Richards ESSENTIAL MINI VACUUM CLEANER - REV 1 Manuale utente

Morphy Richards

Morphy Richards ESSENTIALS CYLINDER VACUUM CLEANER - REV 3 Manuale utente

Morphy Richards

Morphy Richards IB73105 Manuale utente

Morphy Richards

Morphy Richards IB71050 Manuale utente

Morphy Richards

Morphy Richards Scoot cylinder vacuum cleaner Manuale utente

Morphy Richards

Morphy Richards 732000 Supervac Manuale utente

Morphy Richards

Morphy Richards VC73184 Manuale utente

Morphy Richards

Morphy Richards 73270 Manuale utente

Morphy Richards

Morphy Richards BIG POD BAGLESS VACUUM CLEANER - REV 2 Manuale utente

Morphy Richards

Morphy Richards GOBLIN 1400W WET AND DRY CLEANER Manuale utente

Morphy Richards

Morphy Richards Supervac Deluxe Manuale utente

Morphy Richards

Morphy Richards VC73111 MUK Manuale utente

Morphy Richards

Morphy Richards Supervac deluxe Manuale utente

Morphy Richards

Morphy Richards BAGLESS UPRIGHT VACUUM CLEANER - REV 1 Manuale utente

Manuali Aspirapolvere popolari di altre marche

Bissell

Bissell LittleGreen Proheat 1425 Series Manuale utente

Panasonic

Panasonic MC-YL637S147-AE Manuale utente

NEFF

NEFF N17XH10 0 Series Manuale utente

LG A9 Series Manuale utente

Oreck

Oreck Cordless Captura BK51700 Series Manuale utente

Kogan

Kogan KAVACROBVWA Manuale utente

Kränzle

Kränzle VENTOS 50 ID Guida utente

EVVO

EVVO Ai35 Manuale utente

DeWalt

DeWalt DWH200D Manuale utente

Pontec

Pontec Pondomatic Vacuum Cleaner Manuale utente

Cleanmaxx

Cleanmaxx PC-P007E Manuale utente

Exido

Exido 240-114 Manuale utente

RIDGID

RIDGID WD1685AU0 Manuale utente

Ezviz

Ezviz RE4P Manuale utente

STG global

STG global TANVAC HDV3000 Manuale utente

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manuale utente

Factory

Factory M3340 Manuale utente

Shop-Vac

Shop-Vac VN92 SERIES Manuale utente
