This guarantee is valid in the UK and Ireland

only. It is in your interest to retain the retailers receipt

as proof of purchase. Please quote the following

information if the product develops a fault. These

numbers can be found on the base unit of the product.

Model No. Serial No.

(Please enter numbers for future reference)

All Morphy Richards products are individually tested

before leaving the factory. In the unlikely event of any

appliance proving to be faulty within 28 days of

purchase it should be returned to the place of purchase

for it to be replaced.

If the fault develops after 28 days and within 24

months of original purchase, you should take the

appliance to your nearest service agent. A list

containing details of your nearest service agent is

included with your appliance but please contact the

helpline quoting Model number and Serial number should

you require further assistance, repair or replacement of

the product is subject to the following exclusions. (see

Exclusions).

If you suspect a fault, follow the simple checks

detailed below before returning the appliance or

calling the helpline.

1 Check the dustbag and filters for blockages.

2 Check the hose and tubes for blockages.

3 Check the plug is firmly in the socket and the

supply is switched on.

4 Make sure the socket is working by trying

another appliance.

To qualify for the 2 year parts and labour guarantee

the appliance must have been used according to the

manufacturers instructions.

EXCLUSIONS

Morphy Richards shall not be liable to replace

or repair the goods under the terms of the

Guaranteewhere:

1 The fault has been caused or is attributable to

accidental use, misuse, negligent use or used

contrary to the manufacturers recommendations.

2 Continuing to use the cleaner when the bag is full.

3 Where the fault has been caused by power

surges or damage caused in transit.

4 The appliance has been used on a voltage

supply other than that marked on the

products.

5 Repairs have been attempted by persons other

than our service staff (or authorised dealer).

6 Where the appliance has been used for hire

purposes or non-domestic use.

7 The guarantee excludes consumables such as

bags, filters and air freshners.

This guarantee does not confer any rights other

than those expressly set out above and does not cover

any claims for consequential loss or damage. This

guarantee is offered as an additional benefit and does

not affect your statutory rights as a consumer.

If for any reason this item is replaced during the 2

year guarantee period, the guarantee on the new item

will be calculated from original purchase date. Therefore

it is vital to retain your original till receipt or invoice to

indicate the date of initial purchase.

Pod compact bagless vacuum cleaner

2 year parts and labour guarantee

Instruction manual

The After Sales Division, Morphy Richards Ltd, Mexborough, South Yorkshire, England, S64 8AJ

Helpline (office hours ): UK (local rate) 08450 777700, Republic of Ireland 1800 409119

Important SafeguardsImportant Safeguards

Important Safeguards

Thisproducthasbeendesignedwith

yoursafety inmind.However,for safe

operation, it is important that you

observethefollowing points:

1Read all the instructions.

2Useonly genuineMorphyRichards

spare parts and accessories.

3If the electrical cable becomes

damagedthe complete cable

assembly must be replaced.

Do not attempt this task yourself,

contact Morphy Richards using the

helplinenumber on the front ofthis

leaflet.

4Do not use to pick up any liquids.

5Neveruse thisappliance to vacuum

hot ashes, hot cigarette ends, hot

coals or other similar items.

6Neveruse inthepresence of

explosiveliquids orvapours such

aspetrol, copier toner,orother

volatilesubstances.

7Never pick up acids, asbestos or

asbestos dust.

8Do not store the appliance near hot

ovensorheatingappliances.

9Theapplianceshouldneverbe left

runningunsupervised.

10Childrendo notunderstand the

dangersassociated withoperating

electricalappliances.Neverallow

children to use this appliance.

11 Do not use or keep this product

outside when it is raining.

12Nevermodify the cleaner inanyway.

13Repairsto electrical appliances are

onlyto be undertaken by authorised

serviceagents.Unprofessional

repairscan be dangerousfor users.

14Thisvacuum cleaneris intendedfor

domestic use only. Misuse or use

forcommercial or anyotherpurpose

will rendertheguaranteeinvalid.

15DISCONNECTFROMTHESUPPLY

BEFOREATTEMPTINGANY

CLEARINGOF BLOCKAGESOR

REPLACEMENTOFTHEFILTERS.

Electrical requirementsElectrical requirements

Electrical requirements

When using this appliance outdoors it

should be additionally protected by a RCCB

(Residual Current Circuit Breaker).

Check that the voltage on the rating plate of

your appliance corresponds with your house

electricity supply which must be A.C. (Alter-

nating current).

For appliances with fitted plug.

If the socket outlets in your home are not

suitable for the plug supplied with this

appliance the plug should be removed and the

appropriate one fitted.

SAVE THESESAVE THESE

SAVE THESE

INST UCTIONSINST UCTIONS

INST UCTIONS

IMP0RTANT:THEPLUGREMOVEDFROM

THEMAINSLEAD,IFSEVERED,MUSTBE

DESTROYEDASA PLUG WITHABARED

FLEXIBLECORDISHAZARDOUSIFENGAGED

INTOALIVESOCKETOUTLET.

Should the fuse in the 13 amp plug require

changing a 13 amp BS1362 fuse must be

fitted.

FeaturesFeatures

Features

Flexible hose

Pod release latch

Carrying handle

Cable rewind button

Power on/off switch

Wheels

Dust pod

Hose inlet

Storage hook

Accessory hook

Floor nozzle

Crevice tool

Brush tool (clips onto )

Extension tubes

Hose handle

AssemblyAssembly

Assembly

Your pod vacuum cleaner has an efficient

suction action to provide high levels of

cleaning on all types of surface around the

home.

Always remove the plug from the

power socket before fitting or removing

accessories.

Insert flexible hose

Insert the flexible hose in the hose inlet

duct on the front of the product, press until

it clicks into position.

To remove flexible hose

Press the release button to release the

flexible hose. Pull the hose firmly from the

hose inlet duct.

Fitting the extension tubes

and accessories

Join the two extension tubes together.

and attach the extension tubes to the handle

end of the hose. Some tasks may be easier

with only one extension tube fitted.

Attach the floor nozzle to the extension

tubes. The floor nozzle can be used for

carpets, rugs, hard floors and tiles.

Other accessories include:

•Crevice tool for awkward places,

corners and behind radiators etc.

•Brush attachment for pelmets, delicate

objects, sofas and armchairs.

ControlsControls

Controls

On/Off power control

Press the on/off switch down to turn

the appliance on. Press again to turn off.

Suction control on handle

The suction power

can be adjusted using

the fingertip control

on the handle.

Closed: full suction

Open: low suction

Standby positionStandby position

Standby position

During short breaks in cleaning, the tubes can

be held in an upright, ‘standby’ position, whilst

you move furniture for instance.

CAUTION : Ensure that the appliance is never

left unattended whilst it is switched on.

After vacuumingAfter vacuuming

After vacuuming

1 Switch off the vacuum cleaner.

2 Unplug from the mains.

3 Use a hand or foot to operate the cable

rewind .

CAUTION : When using

the cable rewind,

always hold the plug

as the cable will

rewind quickly.

StorageStorage

Storage

positionposition

position

The vacuum cleaner can be stored in an

upright position. Slide storage hook into the

slot on the base of the product and the tubes,

hose and floor nozzle are held securely.

Emptying the PodEmptying the Pod

Emptying the Pod

Disconnect the

cleaner from the

mains socket.

Disconnect the

hose from the hose

inlet duct.

Remove the pod by

pushing the pod

release latch.

Remove the filter basket

and empty the pod into a

waste bin.

If the dust is tightly

packed tap the front

cover.

Shake the filter basket into the waste bin, this

will remove most of the dust.

The filter basket can be cleaned further using

the dusting brush (attached to the crevice tool).

If suction is low after cleaning, the filter basket

should be washed in warm water, (no detergent)

and left to dry thoroughly before replacing.

NEVERREPLACE THEFILTERBASKETWHEN

STILL DAMP.

eassembleeassemble

eassemble

Replace the filter

ensuring that the seal is

good.

Replace the pod onto the

main body.

Changing and cleaningChanging and cleaning

Changing and cleaning

the other filtersthe other filters

the other filters

This cleaner is fitted with a motor protection

filter.NEVER USE THE VACUUM CLEANER

WITHOUT THIS FILTER IN PLACE.

To clean the motor protection filter

1 Remove the filter from the filter grille.

2 Rinse the filter in lukewarm water and dry

the filter completely.

3 Put the filter back into the filter grille and

reassemble.

Morphy Richards products are intended for non commercial use only.

Morphy Richards has a policy of continuous improvement in product quality and design.

The Company, therefore, reserves the right to change the specification of its models at any time.

Morphy Richards Ltd, Mexborough,

South Yorkshire, England, S64 8AJ 442/8673/06 Rev 1

Purchasing newPurchasing new

Purchasing new

filtersfilters

filters

Only use original Morphy Richards filters.

Replacement filters can be purchased by

calling our Helpline number on the front of this

booklet.

Care and maintenanceCare and maintenance

Care and maintenance

Your cleaner is manufactured to withstand

normal day-to-day use, but an occasional

wipe over will help maintain its good looks.

Abrasive cleaners should not be used.

Changing the microChanging the micro

Changing the micro

exhaust filterexhaust filter

exhaust filter

This filter should be replaced every 12

months or sooner if required.

Remove the exhaust filter grille by pulling the

locking tabs towards you. Remove the used

filter. Insert the clean micro exhaust filter and

replace the filter grille.

IMPORTANT

•All filters should be checked

regularly for signs of damage,

preferably after each cleaning task.

The filters must be replaced

immediately if they become

damaged.

•Always disconnect the cleaner from

the mains when checking filters.

•Always make sure all filters are fitted

before use. Failure to do so may

result in damage to your product.

locking tabs

Altri manuali Morphy Richards Aspirapolvere

Morphy Richards

Morphy Richards IB70045 Manuale utente

Morphy Richards

Morphy Richards PERFORMAIR CYCLONIC VACUUM CLEANER Manuale utente

Morphy Richards

Morphy Richards Bagged cylinder Vacuum Manuale utente

Morphy Richards

Morphy Richards PERFORMAIR CYCLONIC VACUUM CLEANER 71062 Manuale utente

Morphy Richards

Morphy Richards IB73190 Manuale utente

Morphy Richards

Morphy Richards POD CYCLONE VACUUM CLEANER - REV 1 Manuale utente

Morphy Richards

Morphy Richards GOBLIN 1400W WET AND DRY CLEANER Manuale utente

Morphy Richards

Morphy Richards IB73340 Manuale utente

Morphy Richards

Morphy Richards ORB PETS CYCLONE VACUUM CLEANER - REV 1 Manuale utente

Morphy Richards

Morphy Richards Ultralight bagless vacuum cleaner Manuale utente

Morphy Richards

Morphy Richards PerformAir Upright Vacuum Manuale utente

Morphy Richards

Morphy Richards LOX VACUUM CLEANER Manuale utente

Morphy Richards

Morphy Richards 732000 Supervac Manuale utente

Morphy Richards

Morphy Richards 73294 Manuale utente

Morphy Richards

Morphy Richards Storm 73215 Manuale utente

Morphy Richards

Morphy Richards Boxer wet & dry vacuum cleaner Manuale utente

Morphy Richards

Morphy Richards IB73091 Manuale utente

Morphy Richards

Morphy Richards SuperVac 732102 Manuale utente

Morphy Richards

Morphy Richards ESSENTIALS BAGLESS VACUUM CLEANER - REV 1 Manuale utente

Morphy Richards

Morphy Richards Perfom air VC71067MUK Manuale utente

Morphy Richards

Morphy Richards 73285 BAGLESS UPRIGHT VACUUM CLEANER Manuale utente

Morphy Richards

Morphy Richards Supervac 732009 Manuale utente

Morphy Richards

Morphy Richards BAGLESS CYLINDER VACUUM CLEANER - REV 2 Manuale utente

Morphy Richards

Morphy Richards 73270 Manuale utente

Manuali Aspirapolvere popolari di altre marche

Bissell

Bissell LittleGreen Proheat 1425 Series Manuale utente

Panasonic

Panasonic MC-YL637S147-AE Manuale utente

NEFF

NEFF N17XH10 0 Series Manuale utente

LG A9 Series Manuale utente

Oreck

Oreck Cordless Captura BK51700 Series Manuale utente

Kogan

Kogan KAVACROBVWA Manuale utente

Kränzle

Kränzle VENTOS 50 ID Guida utente

EVVO

EVVO Ai35 Manuale utente

DeWalt

DeWalt DWH200D Manuale utente

Pontec

Pontec Pondomatic Vacuum Cleaner Manuale utente

Cleanmaxx

Cleanmaxx PC-P007E Manuale utente

Exido

Exido 240-114 Manuale utente

RIDGID

RIDGID WD1685AU0 Manuale utente

Ezviz

Ezviz RE4P Manuale utente

STG global

STG global TANVAC HDV3000 Manuale utente

Shark

Shark ROTATOR PRO COMPLETE NV550 Series Manuale utente

Factory

Factory M3340 Manuale utente

Shop-Vac

Shop-Vac VN92 SERIES Manuale utente
