Motorola SURFboard SBV6120 Istruzioni per il montaggio

SURFboard®SBV6120

DOCSIS®3.0 Digital Voice Modem

To view the SBV6120 DOCSIS 3.0 Digital Voice Modem Installation Guide, please visit the Motorola website at:

http://broadband.motorola.com/consumers/support/

(select Digital Voice Modems)

Contact your service

provider before

connecting your

Motorola SBV6120

DOCSIS 3.0 Digital

Voice Modem to your

existing telephone

wiring.

Connect each TEL port

to a telephone only,

never to a traditional

phone service.

Install Sheet

SURFboard®SBV6120

DOCSIS®3.0 Digital Voice Modem

Install Sheet

Troubleshooting

The Problem The Solution

Green POWER light is OFF Check that the SBV6120 DOCSIS 3.0 Digital Voice Modem is plugged into the AC adapter and wall outlet.

Cannot receive or send data If you have cable TV, check that your TV is working and the picture is clear.

If you cannot receive your regular TV channels, your data service will not function.

Check the coaxial cable connection to the SBV6120 DOCSIS 3.0 Digital Voice Modem and wall outlet.

Hand-tighten if necessary.

Check that the Ethernet cable is properly connected to the SBV6120 DOCSIS 3.0 Digital Voice Modem and

your computer.

Check the IP address by following the steps in “Verifying the IP Address” in the Installation Guide. On

computers using UNIX®or Linux®, you must have Adobe Acrobat Reader installed before opening the

Installation Guide. Call your cable provider if you need an IP address.

Check the lights on the front panel. Note the ﬁrst light from top to bottom that is off. This light indicates

where the error occurred as described in Front-Panel Lights and Error Conditions in the Installation Guide.

This information is to help you quickly solve a problem. Before calling your service provider, try unplugging

and plugging in the cable modem power cord in the AC wall outlet to restart the cable modem.

MOTOROLA and the Stylized M Logo are registered in the US Patent &Trademark Ofﬁce. SURFboard is a registered trademark of General Instrument Corporation, a wholly-owned subsidiary of Motorola, Inc. Linux®is

a registered tredemark of LinusTorvalds in the U.S. and other countries. UNIX is a registered trademark of the Open Group in the United States and other countries. Adobe, Adobe Acrobat. and Adobe Acrobat Reader

are registered trademarks of Adobe Systems, Inc. All other product or service names are the property of their respective owners. No part of the contents of this document may be reproduced or transmitted in any

form or by any means without the written permission of the publisher.

565495-001-a 11/08
