Motorola Audex S805 Manuale utente

Motorola S805 Bluetooth® Stereo Module

S805 Bluetooth®Module

Congratulations on the purchase of an Audex product.

Your Audex helmet or padded hat is the first to combine

coveted R.E.D. styling with leading Bluetooth wireless

technology from Motorola. This cutting edge technology

provides wireless communication and music on or off the

mountain.

Your Audex product features a detachable S805 Bluetooth

module. Equipped with stereo speakers, the S805 allows you

to listen to music wirelessly and never miss a call. The fun

doesn’t have to end with the season since the speakers can

be removed from the helmet or padded hat and worn as

headphones

The feature-rich S805 module packs all the power you need

to get through a full day of activities.

Package Contents

Your Audex helmet or padded hat is accompanied by:

•

S805 Bluetooth module (with included audio cable)

•

Wall charger (with adapters)

•

User's Guide (this booklet)

•

Product registration card (see instructions to redeem

free headband)

1. Your Audex product may contain a product registration card. Follow instructions

to receive a free DJ-style headphone intended for use with the S805 module

(while supplies last).

S805 Bluetooth®Module

Motorola, Inc.

Consumer Advocacy Office

1307 East Algonquin Road

Schaumburg, IL 60196

www.hellomoto.com

1-877-MOTOBLU

1-888-390-6456 (TTY/TDD United Stated for hearing impaired)

Certain mobile phone features are dependent on the capabilities and

settings of your service provider’s network. Additionally, certain features

may not be activated by your service provider, and/or the provider's

network settings may limit the feature’s functionality. Always contact your

service provider about feature availability and functionality. All features,

functionality, and other product specifications, as well as the information

contained in this user's guide are based upon the latest available

information and are believed to be accurate at the time of printing.

Motorola reserves the right to change or modify any information or

specifications without notice or obligation.

MOTOROLA and the Stylized M Logo are registered in the US Patent &

Trademark Office. The Bluetooth trademarks are owned by their proprietor

and used by Motorola, Inc. under license. iPod is a registered trademark of

Apple Computer, Inc., registered in the U.S. and other countries. All other

product or service names are the property of their respective owners.

Caution:

Changes or modifications made in the phone or Bluetooth

module, not expressly approved by Motorola, will void the user’s authority

to operate the equipment.

Manual Number: 6809498A40-O

S805 Bluetooth®Module

R.E.D.

Global Product Services

USA 800 881 3183 JAPAN 03 5738 2555

EUROPE 00800 287 866 13/ +43(0)512 230 230

www.redprotection.com

R.E.D is a registered trademark of R.E.D. Corporation, a division of Burton

Snowboards. Audex is a trademark of R.E.D. Corporation, a division of

Burton Snowboards.

Contents

S805 Bluetooth

Module . . . . . . . . . . . . . . . . . . . . . . . . . 1

Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

S805 Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Charging the S805’s Internal Battery. . . . . . . . . . . . . . . . 10

Pairing Your S805 and Compatible

Bluetooth-Enabled Devices . . . . . . . . . . . . . . . . . . . . . . . 11

Attaching the S805 to Your Helmet/Padded Hat/

Headphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Connecting Your S805 to a Wired Music Source . . . . . 26

Using Your S805 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

Turning Your S805 On and Off. . . . . . . . . . . . . . . . . . . . 27

Making Calls With Your S805 . . . . . . . . . . . . . . . . . . . . 27

Listening to Music With Your S805. . . . . . . . . . . . . . . . 30

S805 Indicator Lights . . . . . . . . . . . . . . . . . . . . . . . . . . 31

S805 Audio Tones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

European Union Directives Conformance

Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Caring for the Environment by Recycling. . . . . . . . . . . 35

Recycling Mobile Phones and Accessories. . . . . . . . . . 35

Safety and General Information . . . . . . . . . . . . . . . . . . 36

Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Consumer Warranty Coverage. . . . . . . . . . . . . . . . . . . . 42

S805 Bluetooth Stereo Module by Motorola

Limited Warranty – North America . . . . . . . . . . . . . . . . . 48

Wireless Phone Safety Tips . . . . . . . . . . . . . . . . . . . . . . . 56

Industry Canada Notice to Users . . . . . . . . . . . . . . . . . . 58

FCC Notice to Users . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Export Law Assurances . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Overview

The Motorola S805 Bluetooth Module allows you to listen to

music and place and receive phone calls from your R.E.D.

helmet or padded hat.

There are three typical scenarios for using the S805

Bluetooth Module:

• Listen to music and make/receive calls from a

compatible Bluetooth-enabled cell phone with both

Advanced Audio Distribution Profile (A2DP) and

Handsfree Profile (HFP).

• Make/receive phone calls from a compatible

Bluetooth-enabled cell phone with Handsfree Profile

(HFP), and listen to music from a wired music source

(such as an iPod

Overview

• Make/receive phone calls from a compatible

Bluetooth-enabled cell phone with Handsfree Profile

(HFP), and listen to music from a Bluetooth-enabled

music source with Advanced Audio Distribution Profile

(A2DP).

Note:

The following table provides guidelines regarding S805

features that depend on the Bluetooth profiles supported and

used by the connected phone or music source:

Profile Description

HFP (Handsfree

Profile) Telephony / Call management:

operations related to placing/

receiving phone calls

A2DP (Advanced

Audio Distribution

Profile)

Stereo music streaming

AVRCP (Audio Video

Remote Control

Profile)

Remote music control (for example,

ability to remotely Play / Pause or

Stop music)

S805 Controls

1—Track Control Wheel

Allows you to skip forward to

the next music track, or skip back to the previous

music track.

2—Play/Pause/Stop Button

Allows you to play,

pause, or stop music when listening to music over a

Bluetooth connection using A2DP and AVRCP profiles.

For audio played back through a wired (non-Bluetooth)

connection, this button allows mute/unmute of

incoming audio. In a call via Bluetooth (Handsfree

profile), this button allows mute/unmute of the

microphone.

3—Microphone

Used when placing or receiving calls.

Music Controls (Right Side)
