Motorola FX871 Manuale utente

User Manual

FX871

Fixed Wireless Phone

SAFETY INFORMATION

1. EXPOSURE TO RADIO FREQUENCY (RF) ENERGY

Your phone contains a transmitter and a receiver. When it is ON, it receives and

also sends out radio frequency (RF) signals. When you communicate with your phone,

the system handling your call controls the power level at which your phone transmits.

Your phone is designed to comply with local regulatory requirements in your

country concerning exposure of human beings to RF energy.

2. OPERATIONAL PRECAUTIONS

To assure optimal phone performance and make sure human exposure to RF

energy is within the guidelines set forth in the relevant standards; always adhere to

the following procedures.

3. EXTERNAL ANTENNA CARE

Use only the supplied Motorola approved antenna. Unauthorized antennas,

modifications, or attachments could damage the phone.

Do NOT hold the antenna when the phone is IN USE. Holding the antenna

affects call quality and may cause the phone to operate at a higher power level than

needed. In addition, use of unauthorized antennas may result in non-compliance with

the local regulatory requirements in your country.

4. PHONE OPERATION

When placing or receiving a phone call, hold your phone as you would use a

wireless telephone.

To maintain compliance with RF energy exposure guidelines, ensure the phone

antenna is at least 10 inches (25centimeters) from your body when transmitting.

5. APPROVED ACCESSORIES

Use of accessories not approved by Motorola, including but not limited to

batteries and antennas, may cause your phone to exceed RF energy exposure

guidelines.

6. RF ENERGY INTERFERENCE / COMPATIBILITIES

Nearly every electronic device is susceptible to RF energy interference from

external sources if inadequately shielded, designed, or otherwise configured for RF

energy compatibility. In some circumstances your phone may cause interference.

7. MEDICAL DEVICES

1) Pacemakers

Pacemaker manufacturers recommend that a minimum separation of 10 inches

(25centimeters) be maintained between the fixed wireless phone and a pacemaker.

Persons with pacemakers should:

Always keep the phone more than 10 inches (25 centimeters) from your pacemaker

when the phone is turned ON. Turn OFF the phone immediately if you have any

reason to suspect that interference is taking place.

2) Hearing Aids

Some digital wireless phones may interfere with some hearing aids. In the event of

such interference, you may want to consult your hearing aid manufacturer to discuss

alternatives.

3) Other Medical Devices

If you use any other personal medical device, consult the manufacturer of your device

to determine if it is adequately shielded from RF energy. Your physician may be able

to assist you in obtaining this information.

8. BATTERIES

Batteries can cause property damage and / or bodily injury such as burns if a

conductive material such as jewelry, keys, or beaded chains touches exposed

terminals. The conductive material may complete an electrical circuit (short circuit)

and become quite hot. Exercise care in handling any charged battery, particularly

when placing it inside a pocket, purse or other container with metal objects. Use only

original batteries and chargers.

Please don’t use any damaged battery or charger and use the battery only for

its intended purpose.

Don’t apply extreme shock to the battery. It’s dangerous to disassemble a

battery or to apply extreme shock to the battery via nail or heavy metal objects.

Keep the charger or batteries out of reach of small children or babies.

Always try to keep the battery between -10 ~ 55 Celsius.

Use only manufacturer approved rechargeable batteries and charger

designated for this devise.

9. Seizures / Blackouts

Some people may be susceptible to epileptic seizures or blackouts when

exposed to flashing lights, such as when watching television or playing video games.

These seizures or blackouts may occur even if a person never had a previous seizure

or blackout.

If you experienced seizures or blackouts, or if you have a family history of such

occurrences, please consult with your doctor.

PHONE OVERVIEW

(1)

Antenna

(10)

Right soft key

(2)

LCD

(11)

Left soft key

(3)

Volume key Up/Down / OK key

(12)

Loudspeaker

(4)

Phonebook key

(13)

Microphone

(5) FM key (14) Query key

(6)

Send key

(15)

Receiver

(7)

End/Power key

(8) Speakerphone key

(9)

Numeric key

INSTALLATION

[1] Connect the coil cord to both the handset and the transceiver (phone).

[2] Install the antenna to the antenna connector. Hold the plastic portion of the

antenna and turn the metal screw clock-wise.

[3] Connect the adaptor to the AC Wall outlet and put adapter jack into the hole on the

rear side of transceiver

[4] Remove the battery door and Insert SIM card into the SIM slot in the right direction.

After this, please Connect the rechargeable battery pack into the battery plug and

replace the battery door.

[5] After installing the handset correctly, press the power key which is on the right of

the front panel for about 3 seconds, the phone will then automatically test whether the

SIM Card is inserted and valid. Wait for the antenna icon to display indicator bars

before you make a call.

Note:

The battery pack is a backup for emergencies in case of a power failure. Do not

operate the phone without having the AC/DC adaptor connected.

Be sure to carefully match the positive and negative terminals as shown on the

battery. When using the phone for the first time, charge it for over 6 hours to

ensure optimum battery charge.

Caution:

It is prohibited to use the SIM card for this Fixed Wireless Phone in other GSM

phone. Once the SIM pin number is entered, the SIM pin maybe automatically

changed so the initial PIN is no longer valid. Therefore, it is highly

recommended

NOT to take out the SIM card once it is installed in this product.

DO NOT bend or scratch your SIM card, and avoid exposing it to static

electricity, water, or dirt.

KEY FUNCTION

[1] Left / Right Soft Key ( Menu / Call logs key )

Press the left soft key (Menu/OK) to perform the function indicated by the text on

the screen above the key.

Press the right soft key (Call Logs/Back) to directly access the Dial Record list

Note:

The functions of the soft keys depend on the guiding text shown above the keys. For

example, when the text Menu is above the left soft key, press, and the left key enters

the menu functions. Similarly, pressing the right soft key under the text Call logs

accesses the Dial Record list functions

[2] Send key

Press to make a call to a name / number shown on the screen.

Press to answer a call.

Press to access the list of recently outgoing call .

[3] End key

Press to end a call.

Press once to exit a function and return to the idle screen.

[4] Numeric Keys / ‘＊’ keys / ‘#’ Keys

Used for entering numbers and letters.

Press and hold number 1 key to call the voice mailbox.

Press ‘#’ key to toggle between upper case, lower case and numeric modes in

message mode.

Press ‘＊’ key to toggle between letters and symbols in message mode.

[5] Navigation keys/ Volume key

Press up navigation key to Calendar.

Press down navigation key to ‘Alarm.

Press up/down key to up / down the phone’s menu.

Press Volume up/down key to change volume level.

Press Volume up/down key to move the cursor when entering letters or dialing

number.

[6] Speaker key

If you are using the handset to call and you want to transfer the call to the

speakerphone mode, press the Speaker key button and hang up the receiver to

transfer the call to the speakerphone

[7] FM Radio

Press the shortcut key ( FM Radio ) to directly access the sub-menu, and press

OK key to end FM function on FM playing interface.

[8] Phonebook key

Press the shortcut key ( Phonebook ) to directly access the phone number list.

DISPLAY INDICATORS AND ICONS

The display indicators and icons provide information about the operation of the phone.

The start screen is displayed when the phone is turned ON. Several features can be

used only when the phone is at the start screen.

Signal Strength Indicator

Indicate the strength of the network signal

Volume tone Indicator

Indicate the tones of the Volume

Battery Level indicator

Mute: shows when turn off the volume of MIC

Call Divert

Voice message

Received New message

SMS read already

Sent SMS

Unread SMS

Contacts stored in SIM card

Contacts stored in Phone

shows when turn off the volume of ring tone

BASIC OPERATION

[1] Switching the phone ON and OFF

1) To turn on your phone, press and hold “End key” for a few seconds or until the

display turns on.

2) To turn off your phone, press and hold “End key” for a few seconds.

[2] Making a call

1) Dial a Call

Raise your receiver and enter phone number which you want to call. After entering

phone number and press “Call key” to make a call.

Tip: In some menus like Phonebook, Dial Records, etc. which have individual

phone number, Press “Call key” directly to make a call.

2) Dial the Fixed Phone Extension Number

Some fixed phone extension can’t be called directly, it need a phone exchange. If you

input the pause character ‘P’ between the exchange phone number and extension n

umber, the phone will finish the dial procedure, connect to the extension. To get the “P

”, press the “＊” key some time till the “P” displayed on the phone screen.

3) Dial a International Call

Press the “＊”key some time till the character “+” displayed on the phone screen.

Input the country code and the phone number after the prefix.

4) Dial From Phonebook

Press Phonebook key to get into the phone book. Press Up / Down

key to scroll the list to search the caller’s name. Then press call key to make a call.

5) Speed Dial

Press 2 -

9 keys for a while, the phone number stored in speed dial list will be sent out. Make s

ure the speed dial key has been set up.
