MSI MPC 865 PRO Manuale utente

Version 1.0

multi-lingual

G52-B6269X1

QuickInstallationGuide

Trademarks

All trademarksusedinthismanualarethepropertyoftheirrespective owners.

AboutthisManual

Thismanualisdesignedtoprovidetheuseraquick reference forbarebone

setup.AsMPC865 isshippedoutinabarebone,weassumeyou needtheinfor-

mation regardinghowtoassemblythesystem,suchasCPU, RAM,FDD, HDD...,

etc.Basedon thisassumption,wemake thismanualofquick installation guide.

Pleasefollowthedescription stepbysteptoassemblythecomponents.If you

have anyquestion inassemblingthesystem,you cancontactyourdealerorour

technicalsupport.

TechnicalSupport

If aproblemariseswithyoursystemand no solution canbeobtainedfromthe

user’smanual, pleasecontactyourplace ofpurchaseorlocaldistributor.

Revision History

Revision Revision HistoryDate

V1.0FirstReleaseDecember2003

NOTE:Thismanualiswrittenjustforsystemassembly.Forcomplete

information aboutthesystem,pleaserefertotheuser’smanualinCD.

CONTENTS

English.......................................................................................................4

French(FRANÇAIS)..........................................................................................................16

German(DEUTSCH)..........................................................................................................28

Spanish(ESPAÑOL)...........................................................................................................40

Italian(ITALIANO)................................................................................................................52

Russian()...........................................................................64

Polish(POLSKI)...................................................................................................................76

Chinese(繁體中文)..............................................................................................................88

SimplifiedChinese(？蔨いゅ)..................................................................100

Japanese(､鬣ｻｻy)....................................................................................112

???????

SafetyInstructions

1.Alwaysreadthesafetyinstructionsfirst.

2.KeepthisUser’sManualforfuturereference.

3.Keepthisequipmentaway fromhumidity.

4.Lay thisequipmenton areliableflatsurface beforesettingit up.

5.Theopeningson theenclosureareforairconvection hence protectsthe

equipmentfromoverheating.DONOTCOVERTHEOPENINGS.

6.Make surethevoltage ofthepowersource and adjustproperly110/230V

beforeconnectingtheequipmenttothepowerinlet.

7.Place thepowercordsuchaway thatpeoplecannotstepon it. Donot

place anythingoverthepowercord.

8.AlwaysUnplugthePowerCordbeforeinsertinganyadd-on cardormodule.

9.All cautionsand warningson theequipmentshouldbenoted.

10. Neverpouranyliquidintotheopeningthatcoulddamage orcauseelectri-

calshock.

11. If anyofthefollowingsituationsarises,gettheequipmentcheckedbya

service personnel:

lThepowercordorplugisdamaged.

lLiquidhaspenetratedintotheequipment.

lTheequipmenthasbeenexposedtomoisture.

lTheequipmenthasnotworkwell oryou cannotgetit workaccording

toUser’sManual.

lTheequipmenthasdroppedand damaged.

lTheequipmenthasobvioussignofbreakage.

12.DONOTLEAVETHISEQUIPMENTIN ANENVIRONMENT

UNCONDITIONED, STORAGETEMPERATUREABOVE600C(1400F), IT

MAYDAMAGETHEEQUIPMENT.

CAUTION: Dangerofexplosion if batteryisincorrectlyreplaced.

Replace onlywiththesameorequivalenttyperecommendedbythe

manufacturer.

overview

Thisproductisshippedoutasabarebone.Somecomponentsareequipped

whilesomeareoptional. See thefollowingforthestandardand optionalitems:

Thismanualprovidesyou withtheinformation ofsystemsetup.Before

assemblingyoursystem,pleasebepreparedfortheinstallation toolsand appro-

priateitems.If you arenotclearabouttheitems,contactyourdealerforthe

information.

Installation Tools

Screws

You will find twotypesofscrewsinthepackage.

ScrewDriverGloves

Type1Type2

Fastening HDD

Fastening CD-ROM

StandardMainboard,PowerSupply,Case,Cables,Cooler,

RemoteController,CardReader,CD, Manual

OptionalTV-TunerCardMS-8606

Checking theItems

Beforestartingtheassembling,check theitemsyou need.

HDD ModuleCPU

CPUCooler

CD-ROMModule

DDR DIMM

Attention!!!

Thechassisand devicesshownon theinstallation photos

areforyourreference only.Theactualproductsmay vary

inchassiscolor,frontbezeland othercomponent.

S-ATACable

Installation Flowchart

StartRemove Cover

Install HDD

Install CPU&

CoolerInstall Optical

Drives

Install RAM

Replace Cover

RemovingCover

Useyourhand orascrewdrivertounscrew

thethree thumbscrewson theback panel.

Remove thechassiscover.

Firstpull thecoverbackwardand thenlift it

up toremove.

Installinghdd

Locatethebracket. Remove thescrewsto

take outthebracket.

InserttheHDD moduleintothebracket.

UseType2screwstosecuretheHDD tothe

bracket. Remembertofastenthescrewson

bothsides.

Note:ThesystemsupportsbothIDEand S-

ATAHDD.

frontpanel

Replace theHDD intothechassis.

Make surethattheHDD bracketfitsprop-

erlywiththechassis.

ScrewtheHDD tothechassis.
